DODGE VIPER 2004 ZB / 2.G Owners Manual

The controls are as follows:
Fan Control
Use this control to regulate the
amount of air forced through the sys-
tem in any mode you select. Turn the
control clockwise to increase fan
speed. Turn the control to theOÐOff
position to shut off the fan and to
prevent any outside air from entering
the vehicle. This also turns off the A/C compressor.
Temperature Control
Use this control to regulate the tem-
perature of the air inside the passen-
ger compartment. The blue area of the
control indicates cooler temperatures
while the red area indicates warmer
temperatures.
Mode Control
Use this control to select the direction
of air flow.
NOTE:The dot between the mode control icons is a mix
position between the two modes.
The mode control positions are as follows:
Recirculate
Air is recirculated inside the vehicle. You may
choose between Bi-Level and Panel air outlets
while in this mode. Use this mode to tempo-
rarily block out any outside odors, smoke, or
dust and to cool the interior rapidly upon initial start up
in very hot or humid weather.
UNDERSTANDING YOUR INSTRUMENT PANEL 91
4

Panel
Air is directed through the outlets in the instrument
panel. These outlets can be adjusted to direct air
flow.
Bi-Level
Air is directed through the instrument panel and
floor outlets. A small amount of air is also directed
through the defrost outlets.
NOTE:There is a varying temperature differential be-
tween the upper and lower outlets for added comfort.
The warmer air goes to the floor outlets. This feature
provides improved comfort during sunny but cool con-
ditions.
Floor
Air is directed through the floor outlets with a
lesser amount through the defrost outlets.Floor/Defrost
Air is directed through the windshield defrost and
the floor outlets. This setting works best in cold or
snowy conditions that require extra heat at the
windshield. This setting is good for maintaining comfort
while reducing moisture on the windshield.
Windshield Defrost
Air is directed through the windshield defrost
outlet. Use this mode with maximum fan and
temperature settings for best windshield defrosting.
NOTE:The air conditioning compressor operates in this
mode. This dehumidifies the air to help dry the wind-
shield. To improve fuel economy, leave in the Defrost
mode only when necessary.
A/C Pushbutton
With the fan control in the ON position, pushing
the A/C button turns on the air conditioning
compressor. An indicator light above the button
92 UNDERSTANDING YOUR INSTRUMENT PANEL

shows that the Air Conditioning compressor is on. Con-
ditioned air is now directed through the outlets selected.
Pushing the button a second time turns the compressor
OFF.
Slight changes in engine speed or power may be noticed
when the compressor is on. This is a normal occurrence
since the compressor will cycle on and off to maintain
comfort and increase fuel economy.
NOTE:If your air conditioning performance seems
lower than expected, check the front of the A/C con-
denser for an accumulation of dirt or insects.
Rear Window Defroster
Press the button once to turn on the Rear Window
Defroster and a second time to turn it off. A light
above the button shows that the Rear Defroster is On.NOTE:The defroster turns off automatically after 15
minutes of operation. Each later activation will allow 71¤2
minutes of operation.
CAUTION!
To avoid damaging the electrical conductors, do not
use scrapers, sharp instruments, or abrasive window
cleaners on the interior surface of the rear window.
Labels can be peeled off by soaking with warm
water.
UNDERSTANDING YOUR INSTRUMENT PANEL 93
4

Operating Tips
When operating the system during the winter months,
make sure the air intake, at the right side of the hood, is
free of ice, slush, snow or other obstructions such as
leaves. Leaves collected in the air-intake plenum may
reduce air flow and plug the plenum water drains.
The blower air will heat faster in cold weather if you use
only the low blower speeds for the first ten minutes of
vehicle operation.
During engine warm-up in cold weather, use the Defrost
mode to direct any cold air away from the occupants.
94 UNDERSTANDING YOUR INSTRUMENT PANEL

STARTING AND OPERATING
CONTENTS
mStarting Procedures......................97
NIf Engine Fails To Start..................98
NAfter Starting........................100
mTransmission Shifting....................100
NRecommended Shift Speeds..............101
NSkip Shift Light.......................101
mParking Brake.........................102
mBrake System..........................104
NBrake Pad Break-In....................107mPower Steering........................107
mTire Safety Information...................108
NTire Markings........................108
NTire Identification Number (TIN)..........111
NTire Loading And Tire Pressure...........112
mTiresÐGeneral Information................116
NTire Pressure.........................116
NTire Inflation Pressures.................117
NRadial-Ply Tires......................120
5

NCompact Spare Tire Ð If Equipped.........120
NTire Spinning........................121
NTread Wear Indicators..................122
NReplacement Tires.....................122
NAlignment And Balance.................123
mLow Tire Pressure (Ltp) System.............124
NLow Tire Indicator....................124
mTire Chains...........................125
mSnow Tires...........................125
mTire Storage...........................126
mTire Rotation Recommendations............126mGround Clearance......................126
mFuel Requirements......................127
NReformulated Gasoline.................127
NGasoline/Oxygenate Blends..............128
NMMT In Gasoline.....................128
NSulfur In Gasoline.....................129
NMaterials Added To Fuel................129
mAdding Fuel..........................129
mVehicle Loading........................130
mTrailer Towing.........................130
96 STARTING AND OPERATING

STARTING PROCEDURES
CAUTION!
Long periods of engine idling, especially at high
engine speeds, can cause excessive exhaust tempera-
tures which can damage your vehicle. Do not leave
your vehicle unattended with the engine running.
WARNING!
Do not leave animals or children inside parked
vehicles in hot weather; interior heat build up may
cause serious injury or death.
Fully apply the parking brake, press the clutch pedal to
the floor, and place the gear selector in NEUTRAL before
starting the engine.NOTE:The engine will not start unless the clutch pedal
is pressed to the floor.
Normal Startingof either a cold or a warm engine does
not require pumping or depressing the accelerator pedal.
To start the vehicle, turn the key to the ON position and
press the red ENGINE START button located on the
instrument panel and release when the engine starts. If
STARTING AND OPERATING 97
5

the engine has not started within 3 seconds, slightly
depress the accelerator pedal while continuing to crank.
If the engine fails to start within 10 seconds, turn the key
to the ªOFFº position, wait 5 seconds, then repeat the
normal starting procedure.If Engine Fails to Start
NOTE:The Remote Keyless Entry Transmitter MUST be
used to unlock the vehicle and disarm the alarm system.
In the event of a lost or defective Remote Keyless
Transmitter, the security system can be momentarily
disarmed to allow the vehicle to be started.
See the paragraph on the Vehicle Theft Security System in
Section 2 of this manual
98 STARTING AND OPERATING

WARNING!
Do not attempt to push or tow your vehicle to get it
started. Unburned fuel could enter the catalytic
converter and once the engine has started, ignite and
damage the converter and vehicle. If the vehicle has
a discharged battery, booster cables may be used to
obtain a start from a booster battery or the battery in
another vehicle. This type of start can be dangerous
if done improperly, so follow this procedure care-
fully. See section 6 of this manual for jump starting
instructions.
If the engine fails to start after you have followed the
ªNORMAL STARTINGº procedure, it may be flooded.
Push the accelerator pedal all the way to the floor and
hold it there while cranking the engine. This should clear
any excess fuel in case the engine is flooded.NOTE:To prevent damage to the starter, do not crank
the engine for more than 15 seconds at a time. Wait 10 to
15 seconds before trying again.
If the engine has been flooded, it may start to run, but not
have enough power to continue running when the start
button is released. If this occurs, continue cranking with
the accelerator pedal pushed all the way to the floor.
Release the accelerator pedal and the start button once
the engine is running smoothly.
If the engine shows no sign of starting after two 15
second periods of cranking with the accelerator pedal
held to the floor, the ªNORMAL STARTINGº procedure
should be repeated.
STARTING AND OPERATING 99
5

After Starting
The idle speed will automatically decrease as the engine
warms up.
WARNING!
Never pour fuel or other flammable liquid into the
throttle body air inlet opening in an attempt to start
the vehicle. This could result in flash fire causing
serious personal injury.
TRANSMISSION SHIFTING
NOTE:The parking brake should be engaged and the
gear selector placed in REVERSE before leaving the
vehicle, especially on an incline.
Fully depress the clutch pedal before you shift gears. As
you release the clutch pedal, lightly depress the accelera-
tor pedal.Be sure the transmission is in FIRST gear, (not THIRD),
when starting from a standing position. Damage to the
clutch can result from starting in THIRD.
For most city driving you will find it easier to use only
the lower gears. For steady highway driving with light
accelerations, 6th gear is recommended.
Never drive with your foot resting on the clutch pedal, or
try to hold the vehicle on a hill with the clutch pedal
partially engaged. This will cause abnormal wear on the
clutch.
Never shift into REVERSE until the vehicle has come to a
complete stop.
NOTE:During cold weather, until the transmission
lubricant has warmed, you may have difficulty shifting.
This is normal and not harmful to the transmission.
100 STARTING AND OPERATING
