203
•Never use alcohol, petrol, chemical products, detergents,
stain removers, wax, solvents and “wash and polish” products.
•Rinse immediate to remove soap to prevent stains. Repeat
the operation if needed.
•Rinse immediately, and repeat this operation if necessary.
If you choose to waterproof the soft top, strictly follow the
instructions on the package of the waterproofing product you
have selected in order to obtain optimal results.
•The rubber seals on the soft top must be cleaned exclusively
with water. If you notice that this trim is dry or is sticking, apply
talcum powder or products specifically for rubber trim (silicone
spray).
7) ROOF RACK/SKI RACK
The use of transversal bars on longitudinal ones prevents the
use of the sunroof, because the latter, while opening, interferes
with the bars. Therefore do not move the sunroof if transversal
bars have been fitted.
8) EOBD SYSTEM
If, when the ignition key is turned to the MAR position, the
Uwarning light either does not come on or, when driving, it
comes on constantly or flashing (along with a message in the
display, for versions/markets, where provided) contact a Fiat
Dealership as soon as possible. The operation of the
Uwarning light may be checked by traffic police using appropriate
equipment. Comply with the laws and regulations of the country
where you are driving.
9) DOORS
Make sure to take the key with you once a door or the tailgate
is locked, to prevent locking the same key inside the vehicle.
If the key has been locked in, it can only be recovered using
the second provided key.10) MULTIMEDIA
• Only clean the front panel and the display lens with a soft,
clean, dry, anti-static cloth.
Cleaning and polishing products may damage the surface. Never
use alcohol, petrols and derivatives.
• Do not use the display as a base for supports with suction pads
or adhesives for external navigators or smartphones or similar
devices
11) REFUELLING YOUR DIESEL ENGINE VEHICLE
Vehicles with a diesel engine must only be filled with diesel fuel for
motor vehicles, in compliance with European Standard EN 590.
The use of other products or mixtures may damage the engine
beyond repair and consequently invalidate the warranty, due to
the damage caused. If you accidentally introduce other types of
fuel into the tank, do not start the engine. Empty the tank. If the
engine has been run for even an extremely limited amount of time,
you must not only drain the fuel tank, but the rest of the supply
circuit as well.
12) SEAT BELTS - PRETENSIONERS
Operations which lead to impacts, vibrations or localised heating
(over 100°C for a maximum of six hours) in the area around the
pretensioner may damage or deploy it. Contact a Fiat Dealership
should intervention be necessary on these components.
13) STARTING AND STOPPING THE ENGINE
• It is advisable not to demand maximum performance from your
car (e.g. excessive accelerations, long distances at top rpm,
excessive intense braking, etc.) as soon as the engine is started.
• When the engine is switched off never leave the key turned to
MAR to prevent useless current absorption from draining the
battery.
VEHICLE SAFETY
(CONTINUES) (CONTINUED)
