FIAT 500L 2018 Owner handbook (in English)

Versions 1.6 16V 120 HP MultiJet
Type code940C1000
CycleDiesel
Number and position of cylinders 4 in line
Piston bore and stroke (mm) 79.5 × 80.5
Total displacement (cm³) 1598
Compression ratio 16.5 ± 0.4
Maximum power (EEC) (kW) 88
Maximum power (EEC) (HP) 120
corresponding engine speed (rpm) 3750
Maximum torque (EEC) (Nm) 320
Maximum torque (EEC) (kgm) 32.6
corresponding engine speed (rpm) 1750
Fuel Diesel for motor vehicles (EN590 Specification)
Emission levelEuro 6
179

WHEELS
167) 168)
RIMS AND TYRES
PROVIDED
Pressed steel or alloy rims. Tubeless
radial carcass tyres. All approved tyres
are listed in the registration document.
IMPORTANT If there are any
discrepancies between the Owner
Handbook and the registration
certificate, take the information from the
latter. For safe driving, the car must be
fitted with tyres of the same make
and type on all wheels.
IMPORTANT Do not use air chambers
with tubeless tyres.
SNOW CHAINS
Important notes
83)
NOTE Reduced-width snow chains
with a maximum projection of 9 mm
beyond the tyre profile can be fitted on
195/65 R15 91H and 205/55 R16
91H tyres. 225/45 R17 91V tyres
cannot be fitted with snow chains.The use of snow chains should be in
compliance with local regulations of
each country. In certain countries, tyres
marked with code M+S (Mud and
Snow) are considered as winter
equipment; therefore their use is
equivalent to that of the snow chains.
Snow chains can be fitted to the tyres
of the front wheels (drive wheels) only.
Check the tension of the snow chains
after the first few metres have been
driven.
Using snow chains with tyres with
non-original dimensions may damage
the vehicle.
Using different size or type (M+S, snow,
etc.) tyres between front and rear axle
may adversely affect car handling,
with the risk of losing control of the car
and resulting accidents.
Snow chains cannot be fitted to the
space-saver wheel (for versions/
markets, where provided). If a front tyre
is punctured, replace a rear wheel
with the space-saver wheel and move
the rear wheel to the front axle. In
this way, with two normal drive wheels
at the front, snow chains can be fitted.
180
TECHNICAL DATA

500L versions
Versions Wheels Tyres Snow tyresSpace saver spare
wheel(*)Rim / Tyre
0.9 TwinAir Turbo
Natural Power6Jx15 H2 ET 39 195/65 R15 91H 195/65 R15 91Q (M+S)
4JX16 H ET 15
T135/70 R16 100M 6Jx16 H2 ET 36.5
205/55 R16 91H 205/55 R16 91Q (M+S)
6½Jx16 H2 ET 39
7J x 17 H2 ET 41 225/45 R17 91V 225/45 R17 91Q (M+S)
0.9 TwinAir Turbo
105HP6Jx15 H2 ET 39 195/65 R15 91H 195/65 R15 91Q (M+S)
4JX16 H ET 15
T135/70 R16 100M 6Jx16 H2 ET 36.5
205/55 R16 91H 205/55 R16 91Q (M+S)
6½Jx16 H2 ET 39
7Jx17 H2 ET 41 225/45 R17 91V 225/45 R17 91Q (M+S)
1.4 16V 95 HP6Jx15 H2 ET 39 195/65 R15 91H 195/65 R15 91Q (M+S)
4JX16 H ET 15
T135/70 R16 100M 6Jx16 H2 ET 36.5
205/55 R16 91H 205/55 R16 91Q (M+S)
6½Jx16 H2 ET 39
7Jx17 H2 ET 41 225/45 R17 91V 225/45 R17 91Q (M+S)
1.4 16V 120HP6Jx16 H2 ET 36.5
205/55 R16 91H 205/55 R16 91Q (M+S)
4JX16 H ET 15
T135/70 R16 100M 6½Jx16 H2 ET 39
7Jx17 H2 ET 41 225/45 R17 91V 225/45 R17 91Q (M+S)
1.3 16V MultiJet6Jx15 H2 ET 39 195/65 R15 91H 195/65 R15 91Q (M+S)
4JX16 H ET 15
T135/70 R16 100M 6Jx16 H2 ET 36.5
205/55 R16 91H 205/55 R16 91Q (M+S)
6½Jx16 H2 ET 39
7Jx17 H2 ET 41 225/45 R17 91V 225/45 R17 91Q (M+S)
(*) For versions/markets, where provided
181

Versions Wheels Tyres Snow tyresSpace saver spare
wheel(*)Rim / Tyre
1.6 16V MultiJet6Jx15 H2 ET 39
195/65 R15 91H
(***)195/65 R15 91Q (M+S)
4JX16 H ET 15
T135/70 R16 100M 6Jx16 H2 ET 36.5
205/55 R16 91H 205/55 R16 91Q (M+S)
6½Jx16 H2 ET 39
7Jx17 H2 ET 41 225/45 R17 91V 225/45 R17 91Q (M+S)
(*) For versions/markets, where provided
(***) 1.6 16V 105 HP Multijet versions
500L CROSS versions
Versions Wheels Tyres Snow tyresSpace saver spare
wheel(*)Rim / Tyre
All versions6Jx16 H2 ET 36.5
205/55 R16 91H 205/55 R16 91Q (M+S)
4JX16 H ET 15
T135/70 R16 100M 6½Jx16 H2 ET 39
7Jx17 H2 ET 41 225/45 R17 91V 225/45 R17 91Q (M+S)
7½Jx17 H2 ET 41 225/45 R17 94V 225/45 R17 94V (M+S)
(*) For versions/markets, where provided.
182
TECHNICAL DATA

500L WAGON versions
Versions Wheels Tyres Snow tyresSpace saver spare
wheel(*)Rim / Tyre
0.9 TwinAir Turbo
Natural Power6Jx15 H2 ET 39 195/65 R15 91H 195/65 R15 91Q (M+S)
4JX16 H ET 15
T135/70 R16 100M 6Jx16 H2 ET 36.5
205/55 R16 91H 205/55 R16 91Q (M+S)
6½Jx16 H2 ET 39
7J x 17 H2 ET 41 225/45 R17 91V 225/45 R17 91Q (M+S)
0.9 TwinAir Turbo
105HP6Jx15 H2 ET 39
(**)195/65 R15 91H(**)195/65 R15 91Q (M+S)
4JX16 H ET 15
T135/70 R16 100M 6Jx16 H2 ET 36.5
205/55 R16 91H 205/55 R16 91Q (M+S)
6½Jx16 H2 ET 39
7Jx17 H2 ET 41 225/45 R17 91V 225/45 R17 91Q (M+S)
1.4 16V 95 HP6Jx15 H2 ET 39 195/65 R15 91H 195/65 R15 91Q (M+S)
4JX16 H ET 15
T135/70 R16 100M 6Jx16 H2 ET 36.5
205/55 R16 91H 205/55 R16 91Q (M+S)
6½Jx16 H2 ET 39
7J x 17 H2 ET 41 225/45 R17 91V 225/45 R17 91Q (M+S)
1.4 16V 120HP6Jx16 H2 ET 36.5
205/55 R16 91H 205/55 R16 91Q (M+S)
4JX16 H ET 15
T135/70 R16 100M 6½Jx16 H2 ET 39
7Jx17 H2 ET 41 225/45 R17 91V 225/45 R17 91Q (M+S)
1.3 16V MultiJet6Jx15 H2 ET 39 195/65 R15 91H 195/65 R15 91Q (M+S)
4JX16 H ET 15
T135/70 R16 100M 6Jx16 H2 ET 36.5
205/55 R16 91H 205/55 R16 91Q (M+S)
6½Jx16 H2 ET 39
7Jx17 H2 ET 41 225/45 R17 91V 225/45 R17 91Q (M+S)
(*) For versions/markets, where provided
(**) 5-seater versions
183

Versions Wheels Tyres Snow tyresSpace saver spare
wheel(*)Rim / Tyre
1.6 16V MultiJet6Jx15 H2 ET 39
(***)195/65 R15 91H(***)195/65 R15 91Q (M+S)
4JX16 H ET 15
T135/70 R16 100M 6Jx16 H2 ET 36.5
205/55 R16 91H 205/55 R16 91Q (M+S)
6½Jx16 H2 ET 39
7Jx17 H2 ET 41 225/45 R17 91V 225/45 R17 91Q (M+S)
(*) For versions/markets, where provided
(***) Only 1.6 16V 105 HP Multijet 5-seater versions
184
TECHNICAL DATA

COLD TYRE INFLATION PRESSURE (bar)
When the tires are warm, the inflation pressure should be + 0.3 bar in relation to the recommended figure. However, recheck
that the value is correct with the tyre cold. With snow tyres, add +0.2 bar to the pressure value prescribed for standard tyres.
500L versions
TyresUnladen/medium load Full load
Space saver
spare wheel(*)Front Rear Front Rear
195/65 R15 91H 2.2 2.0 2.5 2.5
4.2 195/65 R15 91H
(**)2.4 2.4 2.8 2.9
205/55 R16 91H 2.2 2.0 2.5 2.5
205/55 R16 91H
(****)2.4 2.0 2.5 2.5
205/55 R16 91H
(***)2.4 2.2 2.6 2.8
225/45 R17 91V 2.2 2.0 2.5 2.5
225/45 R17 91V
(****)2.4 2.0 2.5 2.5
225/45 R17 91V
(***)2.4 2.2 2.6 2.8
225/45 R17 94V
(***)2.4 2.2 2.6 2.8
(*) For versions/markets, where provided
(**) 1.6 16V 105 HP Multijet version
(****) 1.6 16V 120 HP Multijet version (***) Cross versions
185

0.9 TwinAir Turbo Natural Power versions
TyresUnladen/medium load Full load
Space saver
spare wheel(*)Front Rear Front Rear
195/65 R15 91H 2.4 2.4 2.8 2.8
4.2 205/55 R16 91H 2.2 2.0 2.5 2.8
205/55 R16 91H GoodYear
(**)2.6(***)2.4(***)2.6(***)2.8(***)
205/55 R16 91H GoodYear(**)2.2(****)2.0(****)2.5(****)2.5(****)
225/45 R17 91V 2.2 2.0 2.5 2.8
(*) For versions/markets, where provided
(**) For versions/markets, where provided. Tyres offering equivalent performance can be used as an alternative.
(***) ECO
(****) ECO consumption is not guaranteed with comfort pressures
500L WAGON versions
TyresUnladen/medium load Full load
Space saver
spare wheel(*)Front Rear Front Rear
195/65 R15 91H 2.4 2.4 2.8 2.7
4.2 205/55 R16 91H 2.4 2.2
2.5 / 2.7
(**)2.5 / 2.7(**)
225/45 R17 91V 2.4 2.2
2.5 / 2.7(**)2.5 / 2.7(**)
(*) For versions/markets, where provided
(**) 7-seater versions
186
TECHNICAL DATA

WARNING
167)The maximum speed for snow tyres marked “Q” is 160 km/h, while it is 190 km/h for “T” tyres and 210 km/h for "H" tyres. The highway
code speed limits must however always be complied with.
168)DO NOT fit wheel hub caps when using integral hub caps fixed (with springs) to the steel rim and after sale tyres provided with Rim
Protector. Use of unsuitable tyres and wheel caps may cause sudden decrease of tyre pressure.
WARNING
83)Keep the vehicle's speed down when snow chains are fitted; never exceed 50 km/h. Avoid potholes, do not drive over steps or
pavements and do not drive long distances over roads without snow, to avoid damaging both your vehicle and the road surface.
187

DIMENSIONS
500L URBAN VERSIONS
Dimensions are expressed in mm and refer to the car equipped with its original tyres. Height is measured with car unladen.
A B C D E F (*) G H (*) I
4242 850 2612 7801658/1678(**)
/1667 (***)1522 2018 1519 1784
(*) Minor variations in size are possible depending on the dimensions of the rims.
(**) Natural Power versions / (***) 500L PRO versions
186F0Y0636C
