wipe a sponge with a slightly soapy
solution over the bodywork, frequently
rinsing the sponge;
rinse well with water and dry with a
jet of air or a chamois leather.
WARNING
70)In order to preserve the aesthetic
appearance of the paint abrasive products
and/or polishes should not be used for
cleaning the vehicle.
71)Avoid washing with rollers and/or
brushes in washing stations. Wash the car
only by hand using neutral pH detergents;
dry it with a wet chamois leather. Abrasive
products and/or polishes should not be
used for cleaning the car. Bird droppings
must be washed off immediately and
thoroughly as the acid they contain
is particularly aggressive. Avoid (if at all
possible) parking the vehicle under trees;
remove vegetable resins immediately
as, when dried, it may only be possible to
remove them with abrasive products
and/or polishes, which is highly inadvisable
as they could alter the typical opaqueness
of the paint. Do not use pure windscreen
washer fluid for cleaning the front
windscreen and rear window; dilute it min.
50% with water. Only use pure screen
washer fluid when strictly necessary due to
outside temperature conditions.
WARNING
6)Detergents pollute the water. Only wash
your car in areas equipped to collect and
treat wastewater from this type of activity.
169

TECHNICAL DATA
Everything you may find useful for
understanding how your vehicle
is made and works is contained in this
chapter and illustrated with data, tables
and graphics. For the enthusiasts and
the technician, but also just for those
who want to know every detail of their
car.IDENTIFICATION DATA....................171
ENGINE ..........................................172
WHEELS .........................................175
DIMENSIONS ..................................180
PERFORMANCE .............................183
WEIGHTS........................................186
REFUELLING ..................................193
FLUIDS AND LUBRICANTS ............195
FUEL CONSUMPTION AND CO2
EMISSIONS ....................................198
PRESCRIPTIONS FOR HANDLING
THE CAR AT THE END OF ITS
LIFE ................................................199
170
TECHNICAL DATA

IDENTIFICATION
DATA
VEHICLE IDENTIFICATION
NUMBER (VIN) PLATE
This is applied on the left side of the
luggage compartment fig. 170 (lift the
mat for access) and bears the following
data:
AName of manufacturer.
BType-approval number.
CVehicle type identification code.
DChassis serial number.
EMaximum permitted weight of vehicle
fully laden.
FMaximum permitted weight of vehicle
fully laden plus trailer.
GMaximum permitted weight on first
axle (front).
HMaximum permitted weight on
second axle (rear).
IEngine type.
LBodywork version code.
MSpare part number.
NCorrect value of smoke coefficient
(for diesel engines).
BODYWORK PAINT
IDENTIFICATION PLATE
This is applied on the inside of the
tailgate and contains the following data
fig. 171:
APaint manufacturer.
BColour name.
CFiat colour code.
DRespray and touch-up colour code.
CHASSIS MARKING
This is printed on the crossmember
under the passenger side seat and
bears the following data:
type of vehicle;
chassis serial number.ENGINE MARKING
It is stamped on the cylinder block and
includes the type and the engine serial
number.
170F0Y0501C
171F0Y0003C
171

ENGINE
Versions 1.4 16V 95 HP
Engine code 843A1000
CycleOtto
Number and position of cylinders 4 in line
Piston bore and stroke (mm) 72.0 × 84.0
Total displacement (cm³) 1368
Compression ratio 11 ± 0.2
Maximum power (EC) (kW) 70
Maximum power (EEC) (HP) 95
corresponding engine speed (rpm) 6000
Maximum torque (EEC) (Nm) 127
Maximum torque (EEC) (kgm) 12.9
corresponding engine speed (rpm) 4500
Spark plugs NGK DCPR7E-N-10
Fuel Unleaded petrol 95 R.O.N. (EN228 specifications)
Emission level Euro 6
172
TECHNICAL DATA

Versions 1.3 16V 95 HP Multijet
Engine code 330A1000
CycleDiesel
Number and position of cylinders 4 in line
Piston bore and stroke (mm) 69.6 × 82.0
Total displacement (cm³) 1248
Compression ratio 16.8 ± 0.4
Maximum power (EC) (kW) 70
Maximum power (EEC) (HP) 95
corresponding engine speed (rpm) 3750
Maximum torque (EEC) (Nm) 215
Maximum torque (EEC) (kgm) 21.9
corresponding engine speed (rpm) 1500
Fuel Diesel for motor vehicles (EN590 Specification)
Emission level Euro 6
173

Versions 1.6 16V 120 HP MultiJet
Engine code940C1000
CycleDiesel
Number and position of cylinders 4 in line
Piston bore and stroke (mm) 79.5 × 80.5
Total displacement (cm³) 1598
Compression ratio 16.5 ± 0.4
Maximum power (EC) (kW) 88
Maximum power (EEC) (HP) 120
corresponding engine speed (rpm) 3750
Maximum torque (EEC) (Nm) 320
Maximum torque (EEC) (kgm) 32.6
corresponding engine speed (rpm) 1750
Fuel Diesel for motor vehicles (EN590 Specification)
Emission levelEuro 6
174
TECHNICAL DATA

WHEELS
163) 164)
RIMS AND TYRES
PROVIDED
Pressed steel or alloy rims. Tubeless
radial carcass tyres. All approved tyres
are listed in the registration document.
IMPORTANT If there are any
discrepancies between the Owner
Handbook and the registration
certificate, take the information from the
latter. For safe driving, the car must be
fitted with tyres of the same make
and type on all wheels.
IMPORTANT Do not use air chambers
with tubeless tyres.
SNOW CHAINS
Important notes
72)
NOTE Reduced-width snow chains
with a maximum projection of 9 mm
beyond the tyre profile can be fitted on
195/65 R15 91H and 205/55 R16
91H tyres. 225/45 R17 91V tyres
cannot be fitted with snow chains.The use of snow chains should be in
compliance with local regulations of
each country. In certain countries, tyres
marked with code M+S (Mud and
Snow) are considered as winter
equipment; therefore their use is
equivalent to that of the snow chains.
Snow chains can be fitted to the tyres
of the front wheels (drive wheels) only.
Check the tension of the snow chains
after the first few metres have been
driven.
Using snow chains with tyres with
non-original dimensions may damage
the vehicle.
Using different size or type (M+S, snow,
etc.) tyres between front and rear axle
may adversely affect car handling,
with the risk of losing control of the car
and resulting accidents.
Snow chains cannot be fitted to the
space-saver wheel (for versions/
markets, where provided). If a front tyre
is punctured, replace a rear wheel
with the space-saver wheel and move
the rear wheel to the front axle. In
this way, with two normal drive wheels
at the front, snow chains can be fitted.
175

500L versions
Versions Wheels Tyres Snow tyresSpace saver spare
wheel(*)Rim / Tyre
1.4 16V 95 HP6Jx15 H2 ET 39 195/65 R15 91H 195/65 R15 91Q (M+S)
4JX16 H ET 15
T135/70 R16 100M 6Jx16 H2 ET 36.5
205/55 R16 91H 205/55 R16 91Q (M+S)
6½Jx16 H2 ET 39
7Jx17 H2 ET 41 225/45 R17 91V 225/45 R17 91Q (M+S)
1.3 16V MultiJet6Jx15 H2 ET 39 195/65 R15 91H 195/65 R15 91Q (M+S)
4JX16 H ET 15
T135/70 R16 100M 6Jx16 H2 ET 36.5
205/55 R16 91H 205/55 R16 91Q (M+S)
6½Jx16 H2 ET 39
7Jx17 H2 ET 41 225/45 R17 91H 225/45 R17 91Q (M+S)
1.6 16V MultiJet6Jx16 H2 ET 36.5
205/55 R16 91H 205/55 R16 91Q (M+S)
4JX16 H ET 15
T135/70 R16 100M 6½Jx16 H2 ET 39
7Jx17 H2 ET 41 225/45 R17 91H 225/45 R17 91Q (M+S)
(*) For versions/markets, where provided
500L CROSS versions
Versions Wheels Tyres Snow tyresSpace saver spare
wheel(*)Rim / Tyre
All versions6Jx16 H2 ET 36.5
205/55 R16 91H 205/55 R16 91Q (M+S)
4JX16 H ET 15
T135/70 R16 100M 6½Jx16 H2 ET 39
7Jx17 H2 ET 41 225/45 R17 91V 225/45 R17 91Q (M+S)
7½Jx17 H2 ET 41 225/45 R17 94V 225/45 R17 94V (M+S)
(*) For versions/markets, where provided.
176
TECHNICAL DATA

500L WAGON versions
Versions Wheels Tyres Snow tyresSpace saver spare
wheel(*)Rim / Tyre
1.4 16V 95 HP6Jx15 H2 ET 39 195/65 R15 91H 195/65 R15 91Q (M+S)
4JX16 H ET 15
T135/70 R16 100M 6Jx16 H2 ET 36.5
205/55 R16 91H 205/55 R16 91Q (M+S)
6½Jx16 H2 ET 39
7J x 17 H2 ET 41 225/45 R17 91V 225/45 R17 91Q (M+S)
1.3 16V MultiJet6Jx15 H2 ET 39 195/65 R15 91H 195/65 R15 91Q (M+S)
4JX16 H ET 15
T135/70 R16 100M 6Jx16 H2 ET 36.5
205/55 R16 91H 205/55 R16 91Q (M+S)
6½Jx16 H2 ET 39
7Jx17 H2 ET 41 225/45 R17 91V 225/45 R17 91Q (M+S)
1.6 16V MultiJet– – 195/65 R15 91Q (M+S)
4JX16 H ET 15
T135/70 R16 100M 6Jx16 H2 ET 36.5
205/55 R16 91H 205/55 R16 91Q (M+S)
6½Jx16 H2 ET 39
7Jx17 H2 ET 41 225/45 R17 91V 225/45 R17 91Q (M+S)
(*) For versions/markets, where provided
177

COLD TYRE INFLATION PRESSURE (bar)
When the tyres are warm, add +0.3 bar to the pressure value prescribed. However, recheck that the value is correct with the
tyre cold. With snow tyres, add +0.2 bar to the pressure value prescribed for standard tyres.
500L versions
TyresUnladen/medium load Full load
Space saver
spare wheel(*)Front Rear Front Rear
195/65 R15 91H 2.2 2.0 2.5 2.5
4.2 205/55 R16 91H 2.2 2.0 2.5 2.5
205/55 R16 91H
(****)2.4 2.0 2.5 2.5
205/55 R16 91H
(***)2.4 2.2 2.6 2.8
225/45 R17 91V 2.2 2.0 2.5 2.5
225/45 R17 91V
(****)2.4 2.0 2.5 2.5
225/45 R17 91V
(***)2.4 2.2 2.6 2.8
225/45 R17 94V
(***)2.4 2.2 2.6 2.8
(*) For versions/markets, where provided
(****) 1.6 16V 120 HP Multijet version (***) Cross versions
