FIAT 500L 2019 Owner handbook (in English)

500L WAGON versions
TyresUnladen/medium load Full load
Space saver
spare wheel(*)Front Rear Front Rear
195/65 R15 91H 2.4 2.4 2.8 2.7
4.2 205/55 R16 91H 2.4 2.2
2.5 / 2.7
(**)2.5 / 2.7(**)
225/45 R17 91V 2.4 2.2
2.5 / 2.7(**)2.5 / 2.7(**)
(*) For versions/markets, where provided
(**) 7-seater versions
WARNING
163)The maximum speed for snow tyres marked “Q” is 160 km/h, while it is 190 km/h for “T” tyres and 210 km/h for "H" tyres. The highway
code speed limits must however always be complied with.
164)DO NOT fit wheel hub caps when using integral hub caps fixed (with springs) to the steel rim and after sale tyres provided with Rim
Protector. Use of unsuitable tyres and wheel caps may cause sudden decrease of tyre pressure.
WARNING
72)Keep the vehicle's speed down when snow chains are fitted; never exceed 50 km/h. Avoid potholes, do not drive over steps or
pavements and do not drive long distances over roads without snow, to avoid damaging both your vehicle and the road surface.
179

DIMENSIONS
500L VERSIONS
Dimensions are expressed in mm and refer to the car equipped with its original tyres. Height is measured with car unladen.
A B C D E F (*) G H (*) I
4242 850 2612 7801658/1667
(**)1522 2018 1519 1784
(*) Minor variations in size are possible depending on the dimensions of the rims.
(**) 500L PRO versions
172F0Y0636C
180
TECHNICAL DATA

500L CROSS VERSIONS
Dimensions are expressed in mm and refer to the car equipped with its original tyres. Height is measured with car unladen.
A B C D E F (*) G H (*) I
4276 871 2612 793 1679 1513/1522 2018 1511/1519 1800
(*) Minor variations in size are possible depending on the dimensions of the rims.
173F0Y0637C
181

500L WAGON VERSIONS
Dimensions are expressed in mm and refer to the car equipped with its original tyres. Height is measured with car unladen.
A B C D E F (*) G H (*) I
4375 850 2612 913 1667 1513/1522 2018 1511/1519 1784
(*) Minor variations in size are possible depending on the dimensions of the rims.
174F0Y0638C
182
TECHNICAL DATA

PERFORMANCE
Top speeds after the initial period of usage of the car.
500L VERSIONS
Versionskm/h
1.4 16V 95 HP176
1.4 16V 95 HP PRO176
1.3 16V 95 HP Multijet171
1.3 16V 95 HP Multijet PRO171
1.3 16V 95CV MultiJet Dualogic169
1.6 16V 120 HP MultiJet189
1.6 16V 120 HP Multijet PRO189
183

500L CROSS VERSIONS
Versionskm/h
1.4 16V 95 HP162
1.3 16V 95 HP Multijet166
1.3 16V 95CV MultiJet Dualogic163
1.6 16V 120 HP MultiJet183
184
TECHNICAL DATA

500L WAGON VERSIONS
Versionskm/h
1.4 16V 95 HP176
1.3 16V 95 HP Multijet171
1.3 16V 95CV MultiJet Dualogic169
1.6 16V 120 HP MultiJet189
185

WEIGHTS
NOTE Towing trailers is not permitted on versions for Cyprus.
500L / 500L CROSS / 500L PRO VERSIONS
Weights (kg)1.4 16V 95 HP
500L versions Cross versions PRO versions
Unladen weight (with all fluids,
fuel tank 90% full and without
optional equipment):1300 1320 1300
Payload including the driver
(A)505 480 505
Maximum permitted loads
(B)
- front axle:1050
– rear axle:1000
- total: 1805 1800 1805
Towable loads
– braked trailer: 1000
– non-braked trailer: 400
Maximum load on roof: 60
Maximum load on ball joint
(braked trailer):60
(A) If special equipment is fitted (sunroof, tow hitch, etc.) the unladen car weight increases, thus reducing the specified payload in relation to themaximum
permissible loads.
(B) Loads not to be exceeded. The user is responsible for arranging goods in the luggage compartment and/or load platform within the maximum permittedloads.
186
TECHNICAL DATA

Weights (kg)1.3 16V 95 HP Multijet
500L versions Cross versions PRO versions
Unladen weight (with all fluids, fuel tank 90% full and
without optional equipment):1400 1420 1400
Payload including the driver
(A)510 505 510
Maximum permitted loads
(B)
- front axle:1050
– rear axle:1000
- total: 1910 1925 1910
Towable loads
– braked trailer:1000
– non-braked trailer:400
Maximum load on roof:60
Maximum load on ball joint (braked trailer): 60
(A) If special equipment is fitted (sunroof, tow hitch, etc.) the unladen car weight increases, thus reducing the specified payload in relation to themaximum
permissible loads.
(B) Loads not to be exceeded. The user is responsible for arranging goods in the luggage compartment and/or load platform within the maximum permittedloads.
187

Weights (kg) 1.3 16V 95CV MultiJet Dualogic
500L versions Cross versions PRO versions
Unladen weight (with all fluids, fuel tank 90% full and
without optional equipment):1410 1430 1410
Payload including the driver
(A)505 500 505
Maximum permitted loads
(B)
- front axle:1050
– rear axle:1000
- total: 1915 1930 1915
Towable loads
– braked trailer:1000
– non-braked trailer:400
Maximum load on roof:60
Maximum load on ball joint (braked trailer): 60
(A) If special equipment is fitted (sunroof, tow hitch, etc.) the unladen car weight increases, thus reducing the specified payload in relation to themaximum
permissible loads.
(B) Loads not to be exceeded. The user is responsible for arranging goods in the luggage compartment and/or load platform within the maximum permittedloads.
188
