PROVISIONS FOR THE PROCESSING OF A VEHICLE
AT THE END OF ITS LIFE-CYCLE
For years now Fiat has been developing its global commitment towards the safeguarding and protection of the Environment through
the continuous improvement of its production processes and the making of increasingly more “eco friendly” products. With a view to
guaranteeing the best possible service to clients in full observance of environmental standards and in response to the obligations im-
posed by European Directive 2000/53/EC on end-of-life vehicles, Fiat offers its clients the possibility to hand in their vehicle* at the end
of its life span without additional costs.
The European Directive, in fact, provides for the take-back of the vehicle without the last holder or owner of the same incurring
expenses due to the fact that the market value of the vehicle is zero or negative. In particular, in almost all of the countries of the
European Union, up until 1st January 2007, take-back of the vehicle free of charge only applies to vehicles registered from 1 July 2002
on, while, from 2007 on, take-back will be carried out free of charge, independently of the year of registration, provided that the vehi-
cle still contains all its essential component parts (especially engine and body) and is free from additional waste materials.
Our contracted network of authorised treatment facilities has been carefully selected in order to provide a quality service to our cus-
tomers by de-polluting and recycling “End of Life Vehicles” to approved environmental standards. To find out the location of your
nearest authorised treatment facility, offering free of charge take-back, simply contact one of our dealers or refer to the Fiat web site
or call the toll free number 00800 3428 0000.
*
Passenger transportation vehicles to seat a max. of nine persons, having a total admissible weight of 3.5 t
237-244 BRAVO GB 10-05-2007 9:23 Pagina 240
Page 242 of 246
237-244 BRAVO GB 10-05-2007 9:23 Pagina 241
Page 243 of 246
237-244 BRAVO GB 10-05-2007 9:23 Pagina 242
Page 244 of 246
N N
O O
T T
E E
S S
237-244 BRAVO GB 10-05-2007 9:23 Pagina 243
Page 245 of 246
ENGINE OIL CHANGE
1.4 16V- 1.4 T-JET 150 HP
- 1.9 Multijet 8V - 1.9 Multijet 16V
Tank capacity 57
Reserve8-10
Refuel petrol engines with unleaded petrol with octane rating (RON) no lower than 95 only (EN 228 Specifications)
Refuel diesel engines with diesel fuel for motor vehicles only (EN 590 Specifications)
FUEL CAPACITIES (litres)
Fiat Group Automobiles S.p.A. - Quality - Assistenza Tecnica - Ingegneria Assistenziale - Largo Senatore G. Agnelli, 5 - 10040 Volvera - Torino (Italia) - Print N. 603.81.209 - 05/2007 - 1stEdition
1.4 16V- 1.4 T-JET 150 HP 1.9 Multijet8V- 1.9 Multijet 16Vlitres kg litres kg
Fuel tank 2.75 2.4 4.4 3.8
Engine sump and filter 2.9 2.55 4.7 4.0
Add +0.3 bar to the prescribed inflation pressure when the tyres are warm. Recheck pressure value with cold tyres.
With snow tyres, add +0.2 bar to the inflation pressure value prescribed for standard tyres.
When running at speed higher than 160 km/h, inflate tyres at full load inflation values.
T.P.M.S. system not available for tyre 195/65 R15 91H.
COLD TYRE INFLATION PRESSURE (bar)
195/65 R15 91H 2.3 2.3 2.6 2.6
1.4 16V205/55 R16 91H 2.3 2.3 2.6 2.6
225/45 R17 91V 2.3 2.3 2.6 2.6
195/65 R15 91H 2.3 2.3 2.6 2.6
1.9 Multijet 8V205/55 R16 91H 2.3 2.3 2.6 2.6
225/45 R17 91V 2.3 2.3 2.6 2.6
225/40 R18 92V 2.6 2.6 2.9 2.9
1.4 T-JET 150 HP195/65 R15 91V 2.3 2.3 2.6 2.61.9 Multijet 16V
205/55 R16 91V 2.3 2.3 2.6 2.6
225/45 R17 91V 2.3 2.3 2.6 2.6
225/40 R18 92V 2.6 2.6 2.9 2.9STANDARD TYRES
Size Medium load Full load
Front Rear Front Rear
