buttons FIAT CROMA 2009 2.G Instant Navigation Manual

16
INSTANT NAV
SWITCHING THE SYSTEM
ON/OFF
The system is switched on by turning the
ignition key to the MAR position and
switches off when the ignition key is
turned to the STOP position.
The system can always be turned on/off
by pressing the (ON/OFF) button 1- fig. 1.
If the system is turned on with the en-
gine switched off, it will automatically
switch off after about 20 minutes.
Dark mode (display dark)
With the system on, if the (ON/OFF)
button 1 - fig. 1 is pressed briefly, the
DARK mode is activated: the display will
go out, but the system remains on and
working.MAIN FUNCTIONS
The Instant Nav features four applica-
tions (Audio, Telephone, Trip Computer
and Navigation) and a general menu. The
four applications are activated by pressing
the MUSIC, TEL, TRIP, NAV buttons.
Press the MENU button to activate the
Menu.
NOTE The Telephone application is only
present with the Blue&Me
TMsystem.
All the applications have a specific Menu
that can be activated by pressing the OK
button/knob.The system also signals the following by
means of messages in the display:
– the presence of any problems/faults;
– information on the application activat-
ed/information on the status of the car.
To interact with the messages displayed,
use the OK button/knob or press button
Nto remove the message from the dis-
play.
603_97_471 CROMA_INSTANT NAV_GB_1ed 23-10-2009 15:29 Pagina 16

19
INSTANT NAV
– by activating the PTY function;
– by selecting a radio station or music
track from a list;
– by selecting the SCM, RDM or RPT
function (the latter is only available in CD
MP3 mode);
– by selecting the PRG function (in CD
mode only). This Menu makes it possible to adjust the
audio settings for the radio, the CD, the
Media Player (if connected) and the au-
dio adjustments for the speakers.
Pressing the MUSIC button activates the
display of information for the audio source
being listened to. Pressing the OK but-
ton/knob gives access to the specific au-
dio source menu being listened to. Press-
ing the
&button briefly activates the
“Mute” function.
VOLUME ADJUSTMENT
To adjust the volume, turn the knob
1-fig.1. The volume can be adjusted to a
maximum level of 40. When the system is
turned off and then turned back on, the
volume will be set at a level of 20.
With the MUTE function, when the knob
1- fig. 1 is turned, the MUTE function is
deactivated.MUTE/PAUSE FUNCTION
To activate the Mute/Pause function,
press the
&button or the &/ESCbut-
ton on the steering wheel briefly.
The Mute/Pause function is deactivated
in the following cases:
– by pressing the MEDIA button;
– by pressing the RADIO button;
– by pressing the PRESET button (in ra-
dio mode only);
– by pressing the
Obutton;
– by pressing the
N/O/
/buttons;
– by pressing the SRC or
N/Obutton
on the steering wheel;
– by opening the Audio adjustments
Menu in the main menu;
– by searching manually for a radio sta-
tion frequency;
A A
U U
D D
I I
O O
603_97_471 CROMA_INSTANT NAV_GB_1ed 23-10-2009 15:29 Pagina 19

22
INSTANT NAV
RADIO FUNCTIONS
With the radio source activated, press-
ing the RADIO button repeatedly selects
one of the following frequency bands:
FM1, FM2, FM
AST, AM.
After having selected the desired fre-
quency, the display will show the follow-
ing information fig. 6:
– radio symbol
– radio station name
– frequency of the station tuned into
– number corresponding to the stored
position;
– frequency band activated (e.g.: FM1);
– programme name and typeRADIO STATION TUNING
Press the
N/O/
/buttons or theN/Obuttons on the steering wheel to
search for a radio station. It is also possi-
ble to select a radio station from a list or
by entering the frequency from the spe-
cific menu.
Manual tuning
This allows the manual search for sta-
tions on the desired band. Press the
N/Obutton briefly and repeatedly to
start the search in the desired direction.
If the
N/Obutton is pressed longer, the
fast search will start and then stop when
the button is released.
Automatic tuning
Press the

or button briefly to au-
tomatically tune into the next station in
the selected direction. If the

or but-
ton is pressed for longer, the rapid search
is launched. When the button is released,
the tuning will stop at the next station that
can be received.Radio stations list selection
Two different lists of radio stations can
be selected: one for the FM band and one
for the AM band. The system continuously
updates the list; it is possible to request
a list update by pressing button
h for a
while.
If reception is not ideal, the automatic
update is less frequent, therefore the list
may appear different after a manual up-
date.
To access the list of radio stations, press
button
h briefly.
The list of stations displays the name of
the station (if available) or the frequency.
The TMC indication is also displayed if the
FM station provides this service.
fig. 6F0L5040g
603_97_471 CROMA_INSTANT NAV_GB_1ed 23-10-2009 15:29 Pagina 22

24
INSTANT NAV
IMPORTANT NOTES
– The AutoSTore function cannot be ac-
tivated with the PTY fuction activated.
– The AF, TA and REG functions are not
available with the AutoSTore function ac-
tivation.
– To interrupt the AutoSTore function,
select another source (CD or Media Play-
er).
– It is possible that sometimes the Au-
toSTore function does not manage to find
6 stations with a strong signal; in this case
only the stations found will be pro-
grammed.
– When the AutoSTore function is ac-
tivated, the stations that were previously
stored on the FM
ASTband are deleted.TA FUNCTION
(traffic information)
Some stations on the FM band can trans-
mit information about traffic conditions.
To activate/deactivate the function, see
the “Specific radio menu” paragraph.
With the TA function activated the vol-
ume can be changed by turning the OK
button/knob. When the volume is changed
during a traffic bulletin, the new value will
only be maintained whilst the bulletin is in
progress.
IMPORTANTIn some countries there
are radio stations that do not broadcast
traffic information even with the TA func-
tion activated.PTY FUNCTION
(programme type selection)
This function makes it possible to give
priority to listening to radio stations that
broadcast programmes classified accord-
ing to the type of PTY. The PTY pro-
grammes may involve emergency mes-
sages or various subjects (e.g. music,
news). To activate/deactivate the function,
see the Specific radio menu paragraph.
IMPORTANTTo activate the PTY
function you must be on the FM band.
If you do not wish to set any programme,
select “None”.
The PTY function cannot be activated if
a PTY search has already been launched
or if the AutoSTore function is activated.
The PTY search is interrupted in the fol-
lowing cases:

– recalling a radio station programmed
or programming a radio station;
– by pressing the RADIO, MEDIA,
NorObuttons.
603_97_471 CROMA_INSTANT NAV_GB_1ed 23-10-2009 15:29 Pagina 24

26
INSTANT NAV
CD/CD MP3
FUNCTIONS
CD/CD MP3 PLAY
To activate playing, insert an Audio CD
in the slot 8 - fig. 1 or, if there is already
a CD inserted, press the MEDIA button.
Playing will start immediately and the dis-
play will show the following screen (fig. 9).
NOTE MPEG LAYER-3 audio decoding
technology licensed from Fraunhofer IIS
and Thomson multimedia.
IMPORTANTDo not use Audio CD
or CD MP3 8cm format supports or a
specific adapator; the use of this format
will damage the system.CD/CD MP3 PLAY STOP/PAUSE
Press button
&to activate the function.
CD/CD MP3 EJECTION
Press the button
˚.
SELECTING A TRACK
FROM THE LIST
First of all press the
h button to dis-
play the list of tracks (Audio CD) or the
list of folders (CD MP3) and then press
the OK button/knob to make the desired
selection.SELECTION NEXT/
PREVIOUS TRACK
Whilst playing a CD it is possible to se-
lect the previous/next track by pressing
the

/buttons briefly.
TRACK FAST FORWARD/
REWIND
Whilst playing an Audio CD or CD MP3
it is possible to fast forward/rewind the
track by pressing the

/buttons for a
while. When the button is pressed af-
ter selecting the track being listened to,
the next track will be selected. If the track
was the last one on the CD, the first track
will be selected when the
button is
pressed.
fig. 9F0L5041g
603_97_471 CROMA_INSTANT NAV_GB_1ed 23-10-2009 15:29 Pagina 26

28
INSTANT NAV
Programme tracks
(with Audio CD only)
By selecting this item it is possible to
programme (fig. 11) a play list of tracks.
– “Reset”: deletion of all the numbers
entered;
– “Delete”: deletion of the last number
entered;
– “OK”: confirms the number sequence
entered.
After having confirmed the number se-
quence, it will start playing the music
tracks selected. MEDIA PLAYER
FUNCTIONS (only in
the presence of the
Blue&Me
TMsystem)
This mode is only available in the pres-
ence of the Blue&MeTMsystem).
LAUNGHING MEDIA PLAYER
MODE
The Media Player mode is automatically
produced (with the AutoPlay function ac-
tivated) by inserting a USB memory stick
containing music files with the device con-
nected to the USB port of the car or
through selecting the “Media Player”
source by pressing the MEDIA button.
In Media Player mode the main screen
will display the following information (fig.
12).CONTROLS AVAILABLE
By pressing the

/buttons you can
select the next/previous track. By press-
ing the
N/Obuttons you can select the
next or previous folder/artist/music genre
depending on the selection mode activat-
ed.
fig. 11F0L5042gfig. 12F0L5043g
603_97_471 CROMA_INSTANT NAV_GB_1ed 23-10-2009 15:29 Pagina 28

36
INSTANT NAV
STOPS MANAGEMENT
This makes it possible to change the
route during navigation inserting stop-
overs.
The following items can be selected:
– “Add stop”
– “Organize stops”
– “Show destination”
Add stop
This makes it possible to add a stop-over
by selecting one of the following items:
– “Insert address”
– “Personal destinations”
– “Last destinations”
Organize stops
This makes it possible to organize the
stop-overs for the route: the order of
stop-overs entered can be changed and/or
removed.Show destination
This makes it possible to show details of
the destination set in the display. By se-
lecting “Modify” you return to the “En-
ter destination” menu.
By selecting “Map” the display will show
the map surrounding the current desti-
nation, full screen, which can be moved by
pressing the
N/O/
/buttons.INSERT DIVERSION
This allows a detour to be inserted into
the route set (fig. 21). In this case the sys-
tem will select an alternative way. The In-
stant Nav will search for the closest al-
ternative way and will calculate a new
route so that you rejoin the previous
route after X km (X is the value that you
can set on the screen).
A message will be displayed if no alter-
native roads are available.
If, on the other hand, alternative roads
are available, the display will show the new
distance from the destination. Select “Yes”
or “No” to confirm or cancel the new
route.
fig. 21F0L5046g
RIVOLI
TORINO
5km
603_97_471 CROMA_INSTANT NAV_GB_1ed 23-10-2009 15:29 Pagina 36

51
INSTANT NAV
Measures (temperature/distance/
consumption)
Select the item “Measures” by turning
the OK button/knob and then press the
actual knob to confirm.
The display will show the following
screen (fig. 35).
Select the desired unit of measurement.
Turn the OK button/knob, select OK and
then press the actual knob to confirm.
NOTE The selection of the unit of mea-
surement for the temperature is only
available if the outside temperature sen-
sor is present.SOUNDS
This makes it possible to adjust the vol-
ume of the voice messages, the instrument
panel buzzer and the buttons buzzer in the
car (fig. 36).
“Voice message volume”
(Voice message volume
adjustment)
Select the item and adjust the volume by
turning the OK button/knob and then
press the actual knob to confirm.
There are 40 levels for the volume ad-
justment.“Warnings volume”
(Adjustment of instrument panel
buzzer volume)
Adjustment of the volume for signals for
any warnings supplied by the instrument
panel.
This adjustment can only be made with
the ignition key in the MAR position.
There are 7 levels for the volume ad-
justment.
“Buttons volume”
(Adjustment of buttons buzzer
volume)
This adjustment can only be made with
the ignition key in the MAR position.
There are 7 levels for the volume ad-
justment.
fig. 35F0L5005gfig. 36F0L5016g
603_97_471 CROMA_INSTANT NAV_GB_1ed 23-10-2009 15:29 Pagina 51
