FIAT DOBLO 2008 1.G Owners Manual

FUEL CAPACITY (litres) ENGINE OIL CHANGE
1.4 1.3 Multijet 1.9 Multijet
litres kg litres kg litres kg
Oil sump2.4 2.1 3.0 2.6 4.0 3.5
Oil sump and filter2.6 2.25 3.2 2.8 4.3 3.7
Dispose of waste oil properly
Versions Size Medium load Full load
Front Rear Front Rear
Passenger Transportation 185/65 R15 88T 2.3 (*) 2.3 (*) 2.3 2.7
Family (7 seater) 185/65 R15 92T 2.3 2.7 2.3 2.7
Cargo standard capacity/Combi N1185/65 R15 92T 2.3 2.7 2.3 2.7
Cargo extra capacity/Long wheelbase 175/75 R14 C99/98T 3.0 3.5 3.0 3.5
Combi N1 exra capacity 175/75 R14 C99/98T 2.8 3.0 3.0 3.5
Passenger Transportation Natural Power 175/70 R14 88T 2.6 3.0 2.6 3.0
Cargo Natural Power 175/70 R14 C95/93S 2.8 3.5 2.8 3.5
With warm tyres the pressure should be +0.3 bar in relation to the prescribed value. Check again the correct pressure when the tyres are cold.
(*) Up to 3 people + 50 kg.
Tank capacity.................................................................................................................... 60
Reserve.......................................................................................................................... 5 - 7
Use only unleaded petrol with a rated octane number (RON) not less than 95.
Refuel diesel vehicles with diesel fuel for motor vehicles (EN590 Specification).
COLD TYRE INFLATION PRESSURE (bar)
Fiat Group Automobiles S.p.A. - Customer Services - Technical Services - Service Engineering
Largo Senatore G. Agnelli, 5 - 10040 Volvera - Torino (Italia)
Print no. 603.81.542 - 12/2008 - 2
ndedition
212-220 Doblo GB 16-12-2008 14:26 Pagina 220
