spark plugs replace FIAT DOBLO COMBI 2013 Owner handbook (in English)

193
KNOW
YOUR
VEHICLE
SAFETY
STARTING
AND
DRIVING
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
SERVIC
ING
AND
MAINTENANCE
TECHNICAL
SPECIFICA TIONS
INDEX
●●
●●●●●●
●
●
●●●●●●
●●●●●●
●●●●●●
●●●●●●
●●●●●● ●●●
●●●●●●
Thousands of kilometres 30 60 90 120 150 180
Months 24 48 72 96 120 144
Inspect the conditions of toothed timing drive belt
Replace spark plugs (▲)
Replace accessory drive belt(s)
Replace toothed timing belt (*)
Replace air filter cartridge
Check and, if necessary, top up fluid levels (brakes/hydraulic
clutch, windscreen washer, battery, engine coolant, etc.)
Check engine management system operation
(through diagnostic socket)
Check cleanliness of sliding side door lower guides
(or every 6 months)
Change engine oil and replace oil filter (**)
Change brake fluid (or every 24 months)
Replace pollen filter (or every 24 months)
(*) Regardless of distance covered, the timing belt must be replaced every f\
our years in the case of particularly demanding use (cold cli-
mate, city traffic, long idling) or at least every five years in all ot\
her cases.
(**) If the vehicle annual mileage is less than 10,000 km, the engine oil and\
filter must be replaced every 12 months.
(
▲) For 1.4 Turbo Petrol versions, in order to guarantee correct operatio\
n and prevent serious damage to the engine, it is essential to
observe the following: - only use spark plugs specifically certified for these engines; all spa\
rk plugs should be of the same type and brand (see the “Engine”
paragraph in the "Technical Specifications" chapter);
- strictly comply with the replacement interval recommended for the plug\
s in the Scheduled Servicing Plan;
- it is advisable to contact a Fiat Dealership for plug replacement.

276
KNOWYOUR
VEHICLE
SAFETY
STARTING AND
DRIVING
WARNING
LIGHTS AND MESSAGES
IN AN
EMERGENCY
SERVICING AND
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEXSetting the clock ....................... 22
Side air bags (side bag - window bag) ......... 130-131-132
– general warnings ............. 131
Side/taillights – front bulb replacement ... 172
– rear bulb replacement ..............175-176
– switching on......................... 59
Sliding side doors ..................... 78
Smart washing (windscreen wipers) ............. 61
Snow cha ins ........................... 141
Sockets ................................ 72-73
Spare wheel ........................... 228 – technical specifications .... 228
Spark plugs (type) .................. 223
Speed block system .............. 102
Speedometer .....................14-19
Start&Stop system ................. 104Starting and driving
............... 133
Steering lock and ignition switch ........................................ 9
Steering wheel adjustment .... 39
Steering wheel levers ....... 59-61
Steering wheel lock.................... 9
Steering wheel – adjustment lever ................ 39
– turning circle ..................... 225
Steering – steering wheel adjustment lever ..................................... 39
– technical data ................... 225
Sun visors ................................. 75
Suspensions ............................ 225
Switching courtesy lights on/off ....................................... 69
Symbols ....................................... 4 T
ailgate
– emergency opening from the inside ........................ 85-86
– opening with remote control ............................... 6-7
Technical specifications. ....... 219
Third brake light .................... 176
Top speeds ............................. 229
Topping up the engine oil ... 202 – specifications .................... 247
Tow hook
– installation ................189-190
Towing the vehicle ............... 189
Towing trailers ...................... 139
Trailer (towing) .............189-190
– installing the tow hook .......................... 189-190
Transmission
– technical data ................... 224
