10GETTING TO KNOW YOUR VEHICLE
IMPORTANTThe remote control
system frequency can be disturbed by
significant radio transmissions outside
the car (e.g: mobile phones, HAM ra-
dio systems, etc.) that could cause re-
mote control malfunctioning.
MINISTERIAL
HOMOLOGATION
In the respect of the legislation in
force in each country in the matter of
radio-frequency devices, please note
that:
– the market-specific homologation
numbers are listed in paragraph “Ra-
dio-frequency remote control” in sec-
tion “Technical Specifications”.
– the homologation number is print-
ed on the component for markets
where this is required.
fig. 6
F0D0130m
To insert the metal insert in the key
grip, keep the button Epressed and
turn the insert in the direction shown
by the arrow until hearing the click as
it locks into place. Then release the
button E.
For instructions on ordering addi-
tional remote controls or replacing
the batteries, refer to the relevant
paragraphs in the following pages. Re-
fer to “Radio-frequency remote con-
trol” in section “Technical Specifica-
tions” for the relevant ministerial ho-
mologation.
When pressing the button
E, take care to prevent the
metal insert from causing harm or
damage when it comes out. The
button E should only be pressed
when the key is away from the
body, in particular from the eyes,
and from objects that can be spoilt
(e.g.: clothes). Make sure the key
can never be touched by others, es-
pecially children, who may inad-
vertently press the button E.
WARNING

107GETTING THE BEST OUT OF YOUR VEHICLE
If you still cannot start the engine,
get in touch with a Fiat Dealership.
IMPORTANT When the outside
temperature is low, it is important to
note that the use of a more fluid oil
will facilitate starting the cold engine.
Therefore, in winter, follow the advice
in chapter “Technical specifications”,
paragraph “Fluids and lubricants”.
IMPORTANTNever leave the igni-
tion key at MARwhen the engine is off.
Minibus and School Bus versions:
press the ignition enable button lo-
cated to the left of the steering col-
umn as shown in the specific supple-
ment to this handbook.HOW TO WARM UP
THE ENGINE AFTER IT
HAS JUST STARTED
(petrol and diesel versions)
– Begin to move forward slowly let-
ting the engine turn at medium revs.
Do not accelerate abruptly.
– Do not push the engine to its lim-
it for the first few kilometres. You are
recommended to wait until the
coolant temperature indicator starts
to move.
EMERGENCY START-UP
If the Fiat CODE system fails to
recognise that code transmitted by the
ignition key (warning light Yon the
instrument panel lit) the emergency
start-up can be performed by using the
CODE card code.
See the “In an emergency” section.Catalysed vehicles must
not be bump started
(pushed, towed or coast-
ed downhill) as this could cause
fuel to flow into the catalytic ex-
haust system and damage it be-
yond repair.
Remember that until the
engine has started the
brake booster and power steering
systems will not work and a greater
effort will therefore be required to
depress the brake pedal or turn the
steering wheel.
WARNING

132GETTING THE BEST OUT OF YOUR VEHICLE
SNOW TYRES
Use snow tyres specified in the
“Snow tyres” table in section “Tech-
nical Specifications”.
Fiat Dealershipwill be happy to
provide advice concerning the most
suitable type of tyre for the customer’s
requirements.
For the type of tyre to be used, in-
flation pressures and the specifications
of snow tyres, follow the instructions
given at paragraph “Wheels” in section
“Technical Specifications”.The winter features of these tyres
are reduced considerably when the
tread depth is below 4 mm. In this
case, they should be replaced.
Due to the snow tyre features, un-
der normal conditions of use or on
long motorway journeys, the perfor-
mance of these tyres is lower than that
of normal tyres.
It is therefore necessary to limit their
use to the purposes for which they are
certified.
IMPORTANT When snow tyres
are used with a max. speed index be-
low the one that can be reached by
the vehicle (increased by 5%), place a
notice in the passenger compartment,
plainly in the driver’s view which states
the max. permissible speed of the
snow tyres (as per EC Directive).All four tyres should be the same
(brand and track) to ensure greater
safety when driving and braking and
better driveability.
Remember that it is inappropriate to
change the direction of rotation of
tyres.
The max. speed for snow
tyres with “Q” marking is
160 km/h. The Road Traffic Code
speed limits must however be al-
ways strictly observed.
WARNING

133GETTING THE BEST OUT OF YOUR VEHICLE
SNOW CHAINS
The use of snow chains is regulated
by the legislation in force in the coun-
try the vehicle is driven in.
The chains may only be applied to
the drive wheel tyres (front wheels).We recommend using Lineaccessori
Fiat snow chains.
Check the tautness of the chains af-
ter driving some twenty to thirty me-
tres.With chains
mounted keep
your speed down.
Do not exceed 50 kph. Avoid
holes in the road; do not mount
steps or kerbs. Do not drive long
stretches of snow-free road with
the chains mounted, as this can
damage the vehicle and the road
surface too.
Versions
11
15
MAXI
Tyres on which
chains can be fitted
195/70 R15C
205/70 R15C
215/70 R15 Camping
205/70 R15C
215/70 R15 Camping
215/75 R16C
205/75 R16C
215/75 R16 CampingTypes of snow chains
to be used
Snow chains with
reduced size with max.
protrusion beyond the
tyre profile of 15 mm
For rim size refer to “Wheels” in section “Technical Specifications”.
Refer to the following table
for information on the
wheels where snow chains can be
fitted. Follow the prescriptions.
WARNING

138IN AN EMERGENCY
1. STOP THE VEHICLE
– Stop the vehicle in a position that
is not dangerous for oncoming traffic
where you can change the wheel safe-
ly. The ground should be flat and ad-
equately firm. If you have to change
the wheel at night, choose a lit area if
possible.
– Turn the engine off and pull up the
handbrake.
– Engage first or reverse gear.
– Alert other drivers that the vehicle
is stationary in compliance with local
regulations: hazard warning lights,
warning triangle, etc.
Any passengers should get out and
wait as far away as possible from the
danger of traffic.
If the road is sloping or bumpy, place
wedges or other suitable material to
prevent the vehicle from moving, un-
der the wheels.2. TAKE OUT THE TOOLS,
JACK AND SPARE WHEEL
The tools are in the cab near the
seats.
Please note:
– the jack weights 4.2 kg;
– the jack requires no adjustments;
– the jack cannot be repaired. If it
breaks it must be replaced with a new
jack;
– no other tool, apart from the ex-
tension and the ratchet wrench shown
in this chapter can be fitted to the jack.
The spare wheel is located under the
rear part of the load bed.
Do not lubricate the bolt
threads before fitting
them back: they could come
loose.
WARNING
Check tyre pressure and
spare wheel pressure regu-
larly. Refer to section “Technical
Specifications”.
WARNING

182VEHICLE MAINTENANCE
– the use of zinc-plated sheet steel
which is highly resistant to rust;
– the spraying of the underbody, en-
gine compartment, inside the wheel-
houses and other parts with wax-
based products with a high protective
capacity;
– spraying plastic-coating materials
to protect the most exposed points:
under the door, inside the wings, the
edges, etc.;
– the use of “open” box sections to
prevent condensation and water from
building up and rusting the inside of
the parts.
BODY AND UNDERBODY
WARRANTY
Your Ducato is covered by warranty
against any original structural or body
part being perforated by rust. Refer to
the Warranty Booklet for the general
terms.TIPS FOR KEEPING THE BODY
IN GOOD CONDITIONS
Paintwork
The paintwork is not only to make
your vehicle look attractive but also
to protect the steel.
If the paint is scuffed or scratched
deeply you are therefore advised to
touch up as necessary to prevent rust
from forming.
Only use genuine products when
touching up the paintwork (see sec-
tion “Technical Specifications”).
Ordinary maintenance of the paint-
work means washing it. The frequency
you should do this depends on the
conditions and the environment the
vehicle is driven in.
For example:
– areas with a high level of air-pollu-
tion;
– roads sprinkled with road saltwash;
– parking under trees which drop
resin. In these cases, wash your vehi-
cle more frequently.To wash the vehicle properly:
1)wash the body using a low pres-
sure jet of water;
2) wipe a sponge with a slightly
soapy solution over the bodywork,
frequently rinsing the sponge;
3) rinse well with water and dry
with a jet of air or a chamois leather.
When drying the vehicle, be careful
to get at those parts which are not so
easily seen, e.g. the door frames, bon-
net and around the headlights where
water can most readily collect. You
should leave the vehicle out in the
open so that any water remaining can
evaporate more easily.

185TECHNICAL SPECIFICATIONS
T T
E E
C C
H H
N N
I I
C C
A A
L L
S S
P P
E E
C C
I I
F F
I I
C C
A A
T T
I I
O O
N N
S S
VEHICLE
IDENTIFICATION
DATA
CHASSIS MARKING fig. 1
This is stamped on the wheelhouse
near the passenger seat. It can be
reached by lifting the special plastic
flap in the carpeting over the wheel
arch and it includes:
– vehicle model ZFA 244.000
– chassis serial number.ENGINE MARKING
The marking is stamped on the cylin-
der block and includes the model and
the serial number.
See the following pages for the en-
gine codes together with the body-
work codes.MODEL PLATE
The model plate fig. 2includes the
following identification data:
A - Manufacturer’s name
B - Homologation number
C - Vehicle type code
D- Vehicle ID code (Chassis serial
number)
fig. 1
F0D0126m
fig. 2
F0D0026m

186TECHNICAL SPECIFICATIONS
E- Maximum vehicle weight fully
loaded
F - Maximum vehicle weight fully
loaded with trailer
G - Maximum vehicle weight on
front axle
H - Maximum vehicle weight on rear
axle
I - Engine type
L - Body version code
M - Smoke opacity index (for diesel
engines).
This plate is fastened to the front
crossmember in the engine compart-
ment A-fig. 3.BODYWORK PAINT
IDENTIFICATION PLATE
The plateA-fig. 4 is set on the left-
hand inner side of the bonnet.It bears the following data fig. 5:
A - Paint manufacturer
B - Colour name
C - Fiat colour code
D- Respray and touch up code.
fig. 3
F0D0188m
fig. 4
F0D0189m
fig. 5
F0D0025m

187TECHNICAL SPECIFICATIONS
ENGINE CODES - BODYWORK VERSIONS
Version 11
Van short wheelbase
Van short wheelbase
Van medium wheelbase
Van high sided medium wheelbase
Van high sided medium wheelbase
Truck medium wheelbase
Truck short wheelbase
Chassis cab short wheelbase
Chassis cab short wheelbase Camping Car
Chassis cab medium wheelbase
Chassis cab medium wheelbase Camping Car
Transport ambulance short wheelbase
Panorama short wheelbase
Combi 6 seater short wheelbase
Chassis cab with load bed short wheelbase
Chassis cab with load bed short wheelbase Camping Car
Chassis cab with load bed medium wheelbase
Chassis cab with load bed medium wheelbase Camping Car
Van short wheelbase
Van short wheelbase
Van medium wheelbaseEngine
2.0
2.0
2.0
2.0
2.0
2.0
2.0
2.0
2.0
2.0
2.0
2.0
2.0
2.0
2.0
2.0
2.0
2.0
2.0 JTD
2.0 JTD
2.0 JTDEngine
code
RFL
RFL
RFL
RFL
RFL
RFL
RFL
RFL
RFL
RFL
RFL
RFL
RFL
RFL
RFL
RFL
RFL
RFL
RHV
RHV
RHVBodywork
version
244ATMFA AX
244ATMFA BX
244ATMFB AX
244ATMNB AX
244ATMNB BX
244ATMDB AX
244ATMDA AX
244ATMAA AX
244ATMAA AXC
244ATMAB AX
244ATMAB AXC
244ATMTA AX
244ATMPA 00
244ATMRA 01
244ATMCA AX
244ATMCA AXC
244ATMCB AX
244ATMCB AXC
244AAMFA AX
244AAMFA BX
244AAMFB AX

188TECHNICAL SPECIFICATIONS
Version 11
Van high sided medium wheelbase
Van high sided medium wheelbase
Chassis cab short wheelbase
Chassis cab short wheelbase Camping Car
Truck short wheelbase
Chassis cab with load bed short wheelbase
Chassis cab with load bed short wheelbase Camping Car
Chassis cowl short wheelbase
Chassis cowl short wheelbase Camping Car
Chassis cab medium wheelbase
Chassis cab medium wheelbase Camping Car
Truck medium wheelbase
Chassis cab with load bed medium wheelbase
Chassis cab with load bed medium wheelbase Camping Car
Panorama short wheelbase
Combi 6 seater short wheelbase
Combi short wheelbase low roof
Combi medium wheelbase low roof
Chassis cowl short wheelbase “city centre”
Chassis cab with load bed short wheelbase “city centre”
Truck short wheelbase “city centre”
Chassis cab with load bed medium wheelbase “city centre”
Truck medium wheelbase “city centre”
Van short wheelbase low roof “city centre”
Van short wheelbase high roof “city centre”
Van medium wheelbase low roof “city centre”
Van medium wheelbase high sided “city centre”
Van medium wheelbase extra high “city centre”
Van short wheelbase low roof (9 q)Engine
2.0 JTD
2.0 JTD
2.0 JTD
2.0 JTD
2.0 JTD
2.0 JTD
2.0 JTD
2.0 JTD
2.0 JTD
2.0 JTD
2.0 JTD
2.0 JTD
2.0 JTD
2.0 JTD
2.0 JTD
2.0 JTD
2.0 JTD
2.0 JTD
2.0 JTD
2.0 JTD
2.0 JTD
2.0 JTD
2.0 JTD
2.0 JTD
2.0 JTD
2.0 JTD
2.0 JTD
2.0 JTD
2.0 JTDEngine
code
RHV
RHV
RHV
RHV
RHV
RHV
RHV
RHV
RHV
RHV
RHV
RHV
RHV
RHV
RHV
RHV
RHV
RHV
RHV
RHV
RHV
RHV
RHV
RHV
RHV
RHV
RHV
RHV
RHVBodywork
version
244AAMNB AX
244AAMNB BX
244AAMAA AX
244AAMAA AXC
244AAMDA AX
244AAMCA AX
244AAMCA AXC
244AAMBA AX
244AAMBA AXC
244AAMAB AX
244AAMAB AXC
244AAMDB AX
244AAMCB AX
244AAMCB AXC
244AAMPA 02
244AAMRA 03
244AAMFA ZX
244AAMRB 26
244AAMRA 03
244DAMBA AX
244DAMCA AX
244DAMDA AX
244DAMCB AX
244DAMDB AX
244DAMFA AX
244DAMFA BX
244DAMFB AX
244DAMNB AX
244DAMNB BX
