FIAT GRANDE PUNTO 2008 199 / 1.G Dualogic Transmission Manual

10
WARNING LIGHTS
AND MESSAGESREDUCE GEARS
Warning light comes on (together with
the message on the reconfigurable multi-
function display) to warn the driver of the
incorrect use of the gearbox.
In this event, the system could automati-
cally activate system protection proce-
dure.MANUAL MODE NOT
AVAILABLE
The message on the reconfigurable mul-
tifunction display comes on when, with en-
gine on, the MANUALmode cannot be
selected. “DUALOGIC”
TRANSMISSION
FAILURE (red)
Turning the ignition key to MAR
the warning light shall come on, but it
should go off a few seconds after.
The warning light comes on flashing on the
cluster (together with the message on the
reconfigurable multifunction display and
the buzzer) to indicate a gearbox failure.
t
In the case of a gearbox
fault, contact Fiat Dealer-
ship as soon as possible to
have the system checked.
If the warning light continues
to stay on (together with the
message on the reconfig-
urable multifunction display),
contact Fiat Dealership.If the message on the recon-
figurable multifunction dis-
play continues to stay on,
contact Fiat Dealership.

11
AUTOMATIC MODE NOT
AVAILABLE
The message on the reconfigurable mul-
tifunction display comes on when, with en-
gine on, the AUTOmode cannot be se-
lected.CLUTCH OVERTEMPERATURE
The message on the reconfigurable mul-
tifunction display comes on together with
the buzzer to indicate clutch overheating.
In this event, reduce gears and stop the
car (turning the engine off) until regular
operating conditions are restored.PUSH BRAKE PEDAL - DELAYED
STARTUP
Messages are displayed in turns and in se-
quence on the reconfigurable multifunc-
tion display, together with the buzzer to
indicate brake pedal failure when trying to
start the engine.
IMPORTANT Messages are displayed on-
ly if at startup a gear other than neutral
(N) is engaged.
If the message on the recon-
figurable multifunction dis-
play continues to stay on,
contact Fiat Dealership.
If the message on the recon-
figurable multifunction dis-
play continues to stay on,
contact Fiat Dealership.
To safeguard clutch efficien-
cy do not use the accelerator
to keep the car still (e.g.:
when the car is parked facing
uphill) since clutch overheating could
damage it. Use the brake pedal and
press the accelerator pedal only when
deciding to move off.
If messages on the reconfig-
urable multifunction display
continue to stay on, contact
Fiat Dealership.

12
GEAR NOT AVAILABLE
The message on the reconfigurable mul-
tifunction display comes on together with
the buzzer in the following cases:
❒system failure inhibiting gear shifting;
or
❒system failure allowing to engage only
first gear (1), second gear (2), third gear
(3) or reverse (R).OPERATION NOT ALLOWED
The message on the reconfigurable mul-
tifunction display comes on together with
the buzzer when the system refuses the
request to change gear since certain in-
dispensable conditions are lacking.
PUSH BRAKE PEDAL - REPEAT
OPERATION
The message on the reconfigurable mul-
tifunction display comes on, in certain cas-
es with the buzzer when under certain
conditions, due to safety reasons, you try
to change gears without pressing the
brake pedal.SET TO NEUTRAL N
The message on the reconfigurable mul-
tifunction display comes on together with
the buzzer to warn the driver that neutral
shall be engaged.
Engaging neutral (N), displayed message
shall turn off.
If the message on the recon-
figurable multifunction dis-
play continues to stay on,
contact Fiat Dealership.If the message on the recon-
figurable multifunction dis-
play continues to stay on,
contact Fiat Dealership.
If the message on the recon-
figurable multifunction dis-
play continues to stay on,
contact Fiat Dealership.

13
TOWING THE CAR
Make sure that the gearbox is in neutral
(N) (checking that the car moves if
pushed) and tow as for a car with tradi-
tional mechanical gearbox (see Owner
Handbook).
Should it be impossible to set to neutral,
do not tow the car and contact Fiat
Dealership.
IF A FUSE BLOWS
For fuse location see pictures in paragraph “If a fuse blows” in section “In an emergency”
in the Owner Handbook.
PETROL VERSIONS
DIESEL VERSIONS
FUSE AMPERE
Reversing light 87 5
Dualogic gearbox fuse box (power supply + battery) 84 10
Dualogic gearbox fuse box (power supply + key) 16 5
FUSE AMPERE
Dualogic gear control power unit and gear lever
selector (fuel supply and key) 84 10
Dualogic gearbox fuse box (power supply + key) 16 5

14
CHECKING OIL LEVEL
DUALOGIC GEARBOX HYDRAULIC SYSTEM OIL
For the transmission control oil level check and for clutch actuation system oil check/replacement (Multijet version) get in touch
only with the Fiat Service Network.
Waste gearbox oil contains dangerous substances for the environment. For chang-
ing the oil we advise contacting Fiat Dealerships who are equipped for disposing
of used oil respecting nature and the law.WARNING
SERVICE SCHEDULE
1.4 1.3 Multijet
Check the transmission Every Every
control oil level 30.000 km 30.000 km
Check level for the clutch Every
actuation hydraulic system_
30.000 km
Replace oil for the clutch Every
actuation hydraulic system _
60.000 km (or every 2 years)
AIR CLEANER
To have the air cleaner replaced contact Fiat Dealership.

15
PERFORMANCE
Top speed after initial car use is 165 km/h with engine 1.4.
Top speed after initial car use is 175 km/h with engine 1.3 Multijet 90 HP.
ENGINE CODES - BODYWORK VERSIONS
Versions Engine Body version
code 3 door 5 door
4 seat 5 seat
1.4350A1000 199AXB11 15B 199AXB11 15 199BXB11 16
1.3 Multijet 90 HP199A3000199AXD11 17B 199AXD11 17 199ABXD11 18
199AXD11 17D (❍) 199AXD11 17C (❍) 199AXD11 18B (❍)
(❍) Version with DPF

16
TRANSMISSION
1.4 1.3 Multijet 90HP
Five forward gears and reverse Six forward gears and reverse
Gearbox with electrohydraulic system electrohydraulic system
with electronic control with electronic control
ClutchSingle-disk, dry with Single-disk, dry with electric-hydraulic control electric-hydraulic control
Drive Front Front

17
1.4
3 door 3 door 5 door
4 seat 5 seat 5 seat
1025 1025 1040
480 560 560
850 850 850
850 850 850
1505 1585 1600
1000 1000 1000
400 400 400
75 75 75
60 60 601.3 Multijet 90HP
3 door 3 door 5 door
4 seat 5 seat 5 seat
1130 1130 1145
480 560 560
950 950 950
850 850 850
1610 1690 1705
1000 1000 1000
400 400 400
75 75 75
60 60 60
WEIGHTS
Weights (kg)
Kerb weight
(including fuel, space-saver spare
wheel, tools and accessories):
Payload (*)
including the driver:
Maximum admitted loads (**)
– front axle:
– rear axle:
– total:
Towable loads:
– trailer with brakes:
– trailer without brakes:
Maximum load on roof:
Maximum load on tow hitch:
(*) If special equipment is fitted (sunroof, tow hitch, etc.) the unladen car weight increases thus reducing the specified payload.
(**) Loads not to be exceeded. It is the driver’s responsibility to place goods in the boot and/or on the loading surface in accor-
dance with the maximum permissible loads.

18
kg
0,59
– 1.41.3 Multijet 90HP
kg
0,43
0,040
CO2 EMISSIONS
CO2emissions according to 199/100/EC Directive (gr x 100 km).
CO
2emission value referred to combined consumption is 134 (gr x 100 km) with engine 1.4.
CO
2emission value referred to combined consumption is 116 (gr x 100 km) with engine 1.3 Multijet 90 HP.
CAPACITIES
Dualogic gearbox
hydraulic system
Clutch hydraulic system
litres
0,7
–litres
0,505
0,038Specified fuels
Recommended products
TUTELA CAR CS SPEED -
Special oil with “ATF
DEXRON III” additive
TUTELA TOP4
Synthetic fluid FMVSS no. 116
DOT 4, ISO 4925 SAE J1704,
CUNA NC 956- 01

19
FUEL CONSUMPTION
Fuel consumption according to 1999/100/EC Directive Urban Extra-urban Combined(litres x 100 km)
1.46.85.0 5.7
1.3 Multijet 90 HP5.6 3.7 4.4
Consumption in AUTO-ECO logic.
