stop start FIAT IDEA 2009 1.G Service Manual

173
STARTING
AND DRIVING
IN AN
EMERGENCY
TECHNICAL
SPECIFICATIONS
ALPHABETICAL
INDEX
DASHBOARD
AND
CONTROLS
SAFETY
WARNING
LIGHTS AND
MESSAGES
MAINTENANCE
AND CARE
FUEL FILTER
(green filter)
DRAINING CONDENSATION
(Multijet versions)
The presence of water in the
feeding circuit may cause se-
vere damage to the injection system
and irregular engine operation. If the
warning lights
con the cluster lights
up or a message appears on the re-
configurable multifunctional display
(some versions), contact a Fiat Dea-
lership to have the system bled. Wa-
ter may have been introduced in the
tank if this appears immediately af-
ter refuelling: in this case, stop the en-
gine immediately and contact a Fiat
Dealership.
WARNING
BATTERY
The car fits a low-maintenance battery: in
normal usage conditions the electrolyte
does not need topping up with distilled
water.
CHECKING CHARGE
AND ELECTROLYTE LEVEL
The operations must be carried out as de-
scribed in this Owner’s Handbook only by
specialised personnel. Topping must be
carried out by specialised personnel at a
Fiat Dealership.
The battery fluid is poiso-
nous and corrosive. Avoid
contact with the skin and eyes. Keep
naked flames and sources of sparks
away from the battery: risk of explo-
sion and fire.
WARNING
CHANGING THE BATTERY
If required, replace the battery with a ge-
nuine spare part having the same specifi-
cations.
If a battery with different specifications is
fitted, the service intervals given in the
“Service schedule” in this section will no
longer apply.
Follow the battery manufacturer’s in-
structions for maintenance.
Running the battery with an
excessively low liquid level
will damage the battery beyond re-
pair and even cause an explosion.
WARNING
Incorrect assembly of electric
and electronic devices may
cause severe damage to your
car. Go to a Fiat Dealership if
you want to install accessories (alarms,
mobile phone, etc.): they will suggest
the most suitable devices and advise
you if a higher capacity battery needs
to be installed.

175
STARTING
AND DRIVING
IN AN
EMERGENCY
TECHNICAL
SPECIFICATIONS
ALPHABETICAL
INDEX
DASHBOARD
AND
CONTROLS
SAFETY
WARNING
LIGHTS AND
MESSAGES
MAINTENANCE
AND CARE
WHEELS AND TYRES
Check the pressure of each tyre, including
the spare wheel, approximately once
every two weeks and before setting off on
a long journey: this check must be perfor-
med with the tyre rested and cold.
It is normal for pressure to increase when
the car is used. For the correct tyre in-
flation pressure, see “Wheels” in “Tech-
nical specifications” section.
Incorrect pressure causes abnormal tyre
wearfig. 15:
A: normal pressure: evenly worn tread.
B: low pressure: tread particularly worn
on the edges.
C: excessive pressure: tread particularly
worn in the middle.
The tyres must be replaced when the
tread is less than 1.6 mm thick. In all ca-
ses, follow the laws in force in the coun-
try where you are driving.
IMPORTANT NOTES
❒Avoid braking suddenly, burning starts
and violent knocks against the curb,
potholes or other obstacles if possible.
Long distances on rough roads may da-
mage the tyres;
❒check the tyres regularly for cuts on the
sides, swelling or irregular tread wear.
Go to a Fiat Dealership if required.
❒Do not overload your vehicle: this may
cause serious damage to wheels and ty-
res;
❒if a tyre is punctured, stop the vehicle
immediately and charge it to avoid da-
mage to the tyre, the rim, suspensions
and steering system;
❒a tyre will age even if it is not used mu-
ch. Cracks in the tread and on the si-
dewalls are a sign of ageing. Have the
tyres checked by specialised personnel
if they have been fitted for longer than
6 years. Remember to check the spa-
re wheel very carefully;
❒In case of replacement, always fit new
tyres, avoiding those with an unknown
origin.
fig. 15F0H0216m
Remember that the road
holding qualities of your car
also depends on the correct inflation
pressure of the tyres.
Excessively low pressure will cause
overheating of the tyre and may cau-
se severe tyre damage.
WARNING
Do not exchange the tyres
from the left to the right of
the car and vice versa.
Do not repaint alloy wheel rims at
temperatures higher than 150°C. The
mechanical characteristics of the
wheels might be disrupted.
WARNING
❒If a tyre is replaced, also change the in-
flation valve.
❒to allow even wear between the front
and rear tyres, it is advisable to chan-
ge them over every 10-15 thousand ki-
lometres, keeping them on the same si-
de of the car so as not to reverse the
direction of rotation.

179
STARTING
AND DRIVING
IN AN
EMERGENCY
TECHNICAL
SPECIFICATIONS
ALPHABETICAL
INDEX
DASHBOARD
AND
CONTROLS
SAFETY
WARNING
LIGHTS AND
MESSAGES
MAINTENANCE
AND CARE
Exterior plastic parts must be cleaned in
the same way as the rest of the car.
Where possible, do not park under trees;
the resinous substance many species re-
lease give the paint a dull appearance and
increase the possibility of triggering rust
processes.
IMPORTANT Bird droppings must be wa-
shed off immediately and thoroughly as the
acid they contain is particularly aggressi-
ve.
Windows
Use specific window cleaner products. Al-
so use clean cloths to avoid scratching the
glass or damaging the transparency.
IMPORTANT Wipe the rear window in-
side gently with a cloth in the direction
of the filaments to avoid damaging the hea-
ting device.Front headlights
IMPORTANT Never use aromatic sub-
stances (e.g.: petrol) or ketenes (e.g.: ace-
tone) for cleaning front headlight plastic
lens.
Engine compartment
At the end of every winter, wash the en-
gine compartment thoroughly, taking ca-
re not to aim the jet of water directly at
the electronic control units or at the
windscreen wiper motors. Have this ope-
ration performed at a specialised work-
shop.
IMPORTANT Perform this operation on
a cold engine and with the key at STOP.
After the washing operation, make sure
that the various protections (e.g. rubber
caps and guards) have not removed or da-
maged.Detergents pollute the envi-
ronment. The vehicle should
be washed in areas equipped
for collecting and purifying
the liquid used in the washing process.
Never use flammable pro-
ducts, such as petrol ether or
rectified petrol to clean inside the car.
The electrostatic charges which are
generated by rubbing during the clea-
ning operation may cause a fire.
WARNING

203
STARTING
AND DRIVING
IN AN
EMERGENCY
MAINTENANCE
AND CARE
DASHBOARD
AND
CONTROLS
SAFETY
WARNING
LIGHTS AND
MESSAGES
TECHNICAL
SPECIFICATIONS
ALPHABETICAL
INDEX
Rear view mirrors ....................... 42
Rear window wiper
- blades ........................................ 177
- controls .................................... 62
- nozzles ....................................... 176
Rearscreen washer
- controls .................................... 62
- fluid level .................................. 171
Refulling ......................................... 90
Rev counters ................................ 19
Reversing light
- bulb replacement .................. 150
Rims ................................................ 190
Roof rails ...................................... 81
Rubber hoses ................................ 176
Safety .............................................. 93
Seat belts
- general information ................ 97
- height adjustment ................... 95
- maintenance ............................. 99- warming up the engine once
started ....................................... 113
Starting up and driving ................ 111
Steering lock ................................. 18
Steering wheel adjustment ........ 36
Steering ........................................... 188
Storing the car .............................. 122
Storing the car ............................... 122
Sun roof ......................................... 72
Sun visors ...................................... 71
Suspension ..................................... 188
Symbols ........................................... 9
Technical data ............................. 181
Third brake light
- bulb replacement .................. 151
Towing the car ............................. 159
Towing trailers ............................. 117
Transmission ................................. 187
Two-zone automatic climate
control system ............................ 51 - S.B.R. system............................. 94
- use .............................................. 94
Seatbelt tensioners ...................... 97
Seats ................................................ 36
Side air bags .................................. 108
Side lights
- bulb replacement .................... 149
- controls .................................... 58
Smart washing .............................. 61
Snow chains .................................. 121
Spark plugs .................................... 185
Speedometer ................................. 8
Starting the engine ........................ 112
- bump starting............................ 135
- ignition switch .......................... 18
- jump starting ............................ 134
- procedure for Multijet
versions ..................................... 112
- procedure for petrol
versions ...................................... 112
- stopping the engine ................. 113
