dashboard warning lights FIAT LINEA RHD 2010 1.G Owners Manual

105
INCOMPLETE DOOR
LOCKING (red)
On certain versions the warn-
ing ligh t turns on when one or more
doors or the tailgate are not properly
shut.
On certain versions the dedicated message
is displayed.
A buzzer will sound when doors/tailgate
are open and the car is moving.EBD FAILURE
(red) (amber)
Warning lights and lit at the same
time with the engine running indicates an
EBD system failure or that the system is
not available.
Early locking of the rear
wheels may occur in the event of violent
braking causing the car to swerve.
Drive
very carefully to a Fiat Dealership to
have the system inspected.
On certain versions
the dedicated message
is displayed.
SEAT BELTS NOT
FA S T E N E D
(red)
The warning light on the display
will light up when the car is moving and the
driver’s seat belt is not correctly fastened.
The warning light will blink and a buzzer will
sound if the front seat belts are not cor-
rectly fastened. The buzzer of the S.B.R.
(Seat Belt Reminder) system may
only be
switched off by a Fiat Dealership. On
some versions the system may be reac-
tivated from the setup menu.
CORRECT USE
OF THE CAR
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES WARNING
LIGHTS AND
MESSAGES
IN AN
LINEA Owner HAND BOOK RHD.pdf 105LINEA Owner HAND BOOK RHD.pdf 1058/21/09 2:16:15 PM8/21/09 2:16:15 PM

106
Go to a Fiat Dealership
as soon as possible if warning
light either does not light
up when the key is turned to
MAR to if while travelling the warning
lights comes on either steady or blink-
ing (along with a message on the dis-
play).
If the light flashes, release the accelerator
pedal to lower the speed of the engine un-
til the warning light stops flashing; contin-
ue the journey at moderate speed, trying
to avoid driving conditions that may cause
further flashing and contact Fiat
Dealership as soon as possible. EOBD ENGINE CONTROL
SYSTEM FAILURE
Under normal conditions, turning the ig-
nition key to MAR, the warning light turns
on
but it should go off after engine starting.
This indicates that the warning light is
working correctly. If the warning light
ei-
ther stays on or comes on while travelling:
steady light: a fault in the supply/ignition
system which could cause high emis-
sions at the exhaust, possible lack of
performance, poor handling and high
consumption levels.
On certain versions the dedicated mes-
sage is displayed.
In these conditions, you may continue
travelling at moderate speed without de-
manding excessive effort from the engine.
Prolonged use of the car with the warn-
ing light on may cause damage.
Go to a
Fiat Dealership as soon as possible.
if warning light will go out after the
fault goes away but it will be stored in the
system.
blinking: indicates the possibility of
damage to the catalyser (see “EOBD
system” in section “Dashboard
and
controls”). INJECTION SYSTEM
FA I L U R E
(Multijet versions -
amber)
EOBD SYSTEM
FAILURE (petrol
versions - amber)
Injection system failure
Under normal conditions, turning the
ig-
nition key to MAR, the warning light turns
on but it should go off after engine start-
ing.
If the warning light stays on or turns
on
when travelling, means a fault in the sup-
ply/ignition system which could cause high
emissions at the exhaust, possible lack of
performance, poor handling and high
con-
sumption levels.
On certain versions the dedicated message
is displayed.
In these conditions, you may continue
travelling at moderate speed without
de-
manding excessive effort from the engine.
Go to a Fiat Dealersh ip as so on as
possible.
CORRECT USE
OF THE CAR
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
WARNING
LIGHTS AND
MESSAGES
LINEA Owner HAND BOOK RHD.pdf 106LINEA Owner HAND BOOK RHD.pdf 1068/21/09 2:16:15 PM8/21/09 2:16:15 PM

107
FUEL RESERVE (amber)
Turning the ignitio n key
to
MARthe warning light turns on, but it
should go off after few seconds.
The warning light turns
on when about 7
litres fuel are left in the tank.
IMPORTANT The warning light will
blink
to indicate a system failure. Go to a Fiat
Dealership to have the system che-
cked. ABS SYSTEM FAILURE
(amber)
Turning the ignition key to
MARthe warning light turns on, but it
should go off after few seconds.
The warning light will light up when the
system is either not working or not avail-
able. In the case, the braking system will
work as normal without the extra poten-
tials offered by the ABS system. Drive
carefully and go to a Fiat Dealership
as soon as possible.
On certain
versions the dedicated message
is displayed.
FRONT PASSENGER
AIRBAG
DEACTIVATED
(amber)
Warning light comes on when front
passenger’s airbag is deactivated.
With front passenger’s airbag on, turning
the ignition key to MAR, warning light
comes on steadily for about 4 sec-
onds, it flashes for other 4 seconds and
then it shall go off.
Warning light indicates
failure of warning light .
This condition is indicated by inter-
mittent blinking of warning light
for longer than 4 seconds. In this case,
warning light may not indicate
fault to the system. Contact Fiat
Dealership immediately to have
the system checked before driving off.
WARNING
CORRECT USE
OF THE CAR
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES WARNING
LIGHTS AND
MESSAGES
IN AN
LINEA Owner HAND BOOK RHD.pdf 107LINEA Owner HAND BOOK RHD.pdf 1078/21/09 2:16:15 PM8/21/09 2:16:15 PM

108
GLOW PLUG
WA R M I N G
(Multijet versions - amber)
GLOW PLUG
WARMING FAILURE
(Multijet versions - amber)
Glow plug warming
The warning light will go on when the key
is turned to MAR. It will go out as soon
as the glow plugs have
reached a prede-
termined temperature. Start the engine as
soon as the warning light goes out.
IMPORTANT With hot ambient temper-
ature, warning light stays on for very short
time.
Glow plug warming failure
The warning light will blink in the event
of a failure to the glow plug heating sys-
tem. Go to a Fiat Dealership as soon
as possible.
On certain
versions the dedicated message
is displayed.
WATER IN DIESEL
FUEL FILTER
(Multijet versions - amber)
Turning the ignition key to MARthe
warning light turns on, but it should go off
after few seconds.
The warning light turns on when there is
water in the diesel fuel filter.
On certain
versions the dedicated message
is displayed.
The presence of water in the
feeding circuit may cause se-
vere damage to the injection
system and irregular engine
operation. If warning light lights up
(on some versions with the message on
the display), go to a Fiat Dealership
as soon as possi bl e to hav e the
system bled. Water may have been intro-
duced in the tank if this appears imme-
diate ly afte r refu ellin g: in this case ,
stop the engine immediately and cont-
act a Fiat Dealership.
CAR PROTECTION
SYSTEM FAILURE -
FIAT CODE (amber)
Turning the key to MARthe warning light
shall flash only once and then go off.
If with the ignition key at MAR, the warn-
ing light stays on, this indicates a possible
failure (see “Fiat Code system” in section
“Dashboard and controls”).
IMPORTANT Warning lights and
will come on at the same time to indicate
a Fiat CODE system failure.
If with the engine running the warning light
flashes, this means that the car is not
protected by the engine inhibitor device
(see “Fiat Code system” in section “Dash-
board and controls”).
Contact Fiat Dealership to have all the
key stored.
CORRECT USE
OF THE CAR
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
WARNING
LIGHTS AND
MESSAGES
LINEA Owner HAND BOOK RHD.pdf 108LINEA Owner HAND BOOK RHD.pdf 1088/21/09 2:16:15 PM8/21/09 2:16:15 PM

GENERIC FAILURE
INDICATION
(amber)
The warning light turns on in the follow-
ing circumstances.
Engine oil pressure sensor failure
The warning light turns on when failure is
detected in Engine oil pressure sensor Go
to a Fiat Dealership to have the fault
fixed as soon as possible.
External light fault
(where provided)
See description of warning light .
Fuel cut-off switch tripped
The warning light comes on when the fu-
el cut-off switch trips.
The display will show the dedicated mes-
sage.EXTERNAL LIGHT
FAILURE (amber)
The warning light will come on
(some versions only) when a fault
to one of the following lights is detected:
– side/taillights
– brake lights
– rear fog lights
– direction indicators
– number plate lights.
The fault may be caused by: one or more
burnt lamps, a blow protection fuse or in-
terruption of the electrical connection.
On certain versions warning light
comes on instead.
On certain versions the dedicated message
is displayed.
REAR FOG LIGHTS
(amber)
The warning light comes on
when the rear fog lights are turned on.
Speed limit exceeded
(where provided)
The display will show the dedicated mes-
sage when the car exceeds the set speed
limit (see “Multifunctional Display” in sec-
tion “Dashboard and controls”).
Diesel filter failure
(where provided)
The warning light will come on when a
diesel filter system failure is detected. The
display will show the dedicated message
(where provided).
109
CORRECT USE
OF THE CAR
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES WARNING
LIGHTS AND
MESSAGES
IN AN
LINEA Owner HAND BOOK RHD.pdf 109LINEA Owner HAND BOOK RHD.pdf 1098/21/09 2:16:16 PM8/21/09 2:16:16 PM

SIDE/TAIL LIGHTS
AND LOW BEAMS
(green)
FOLLOW ME HOME
(green)
Side/taillights and low beams
The warning light turns on when side/tail-
lights or low beams are turned on.
Follow me home
The warning light will turn when this de-
vice is active (see “Follow me home” in
section “Dashboard and controls”).
The display will show the dedicated mes-
sage.
FRONT FOG LIGHTS
(green) (where provided)
The warning light turns on
when the front fog lights are turned on.
LEFT-HAND
DIRECTION
INDICATOR
(green - intermittent)
The warning light turns on when the di-
The follow ing sym bols may appe ar on
Instrument Panel, but are not applicable
to the Indian version. rection indicator control lever is moved
downwards or, together with the right in-
dicator, when the hazard warning ligh t
button is pressed.
RIGHT-HAND
DIRECTION
INDICATOR
(green - intermittent)
The warning light turns on when the di-
rection indicator control lever is moved
upwards or, together with the left indica-
tor, when the hazard warning light button
is pressed.
MAIN BEAMS (blue)
The warning light turns on
when the main beams are
turned on.
CORRECT USE
OF THE CAR
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
WARNING
LIGHTS AND
MESSAGES
110
Note :
LINEA Owner HAND BOOK RHD.pdf 110LINEA Owner HAND BOOK RHD.pdf 1108/21/09 2:16:16 PM8/21/09 2:16:16 PM

111
STARTING THE ENGINE ................................................... 112
REPLACING A WHEEL ...................................................... 113
WHEN NEEDING TO CHANGE A BULB ..................... 119
IF AN EXTERIOR LIGHT BURNS OUT .......................... 121
IF AN INTERIOR LIGHT BURNS OUT .......................... 126
IF A FUSE BLOWS ................................................................ 128
IF THE BATTERY IS FLAT.................................................. 135
LIFTING THE CAR ............................................................... 135
TOWING THE CAR ........................................................... 135
II I
N N
A A
N N
E E
M M
E E
R R
G G
E E
N N
C C
Y Y
CORRECT USE
OF THE CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES WARNING
LIGHTS AND
MESSAGES IN AN
EMERGENCY
CAR
LINEA Owner HAND BOOK RHD.pdf 111LINEA Owner HAND BOOK RHD.pdf 1118/21/09 2:16:16 PM8/21/09 2:16:16 PM

112
STARTING THE
ENGINE
EMERGENCY START-UP
Go to a Fiat Dealership immediately
if instrument panel warning light
comes
on steady.
JUMP STARTING fig. 1
If the battery is flat, the engine may be
started using an auxiliary battery with the
same capacity or a little
higher than the
flat one. Proceed as follows to start the engine:
connect positive terminals (+near the
terminal) of the two batteries with a
jump lead;
with a second lead, connect the nega-
tive terminal (–) of the auxiliary battery
to an earthing point on the engine or
the gearbox of the car to be
started;
start the engine;
when the engine has been started, re-
move the leads reversing the order
above.
If after a few attempts the engine does not
start, do not insist but contact the
near-
est Fiat Dealership.
This procedure must be per-
formed by expert personnel
because incorrect actions may cause
electrical
discharge of considerable in-
tensity. Furthermore, battery fluid is
poisonous
and corrosive: avoid contact
with your skin and eyes. Keep naked
flames away from the battery.
No
smoking. Do not cause sparks.
WARNING
fig. 1
CORRECT USE
OF THE CAR
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
WARNING
LIGHTS AND
MESSAGES IN AN
EMERGENCY
F0R0242m
LINEA Owner HAND BOOK RHD.pdf 112LINEA Owner HAND BOOK RHD.pdf 1128/21/09 2:16:16 PM8/21/09 2:16:16 PM

113
IMPORTANT Never connect the negative
terminals of the two batteries directly:
sparks could ignite explosive gas released
from the battery. If the auxiliary battery is
installed on another car, prevent
acciden-
tal contact between metallic parts of the
two cars.JUMP STARTING
Never jump start the engine by pushing,
towing or driving downhill.
This could
cause a flow of fuel into the catalytic con-
verter and damage it beyond repair.
IMPORTANT Remember that the brake
booster and the power steering system
are not operating until
the engine is start-
ed, a greater effort will therefore be re-
quired to press the brake pedal or turn
the steering wheel.
REPLACING A WHEEL
GENERAL INSTRUCTIONS
Wheel changing and correct use of the
jack and spare wheel call for some pre-
cautions as listed below.
Indicate that the car is sta-
tionary according to the laws
in force: hazard lights, triangle, etc.
Passengers should leave the car, par-
ticularly if it is very loaded and
wait
for the wheel to be changed away
from on-coming traffic . Apply the
handbrake.
WARNING
CORRECT USE
OF THE CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES WARNING
LIGHTS AND
MESSAGES IN AN
EMERGENCY
CAR
LINEA Owner HAND BOOK RHD.pdf 113LINEA Owner HAND BOOK RHD.pdf 1138/21/09 2:16:16 PM8/21/09 2:16:16 PM

114
The spare wheel is specific
for your car. Do not use it on
cars of different models. Do not use
spare wheels of different models on
your car. The wheel bolts are specif-
ic for your car. Do not use them on
cares of different models. Do not use
bolts of different models on your car.
WARNING
Repair and refit the standard
wheel as soon as possible.
Do not apply grease to the bolt
threading before assembly: the bolts
could come loose unexpectedly.
WARNING
The jack may only be used to
replace wheels on the car
which it equips or other cars of the
same model.
Never use the jack for
other purposes, such as lifting other
car models. Never use the jack to car-
ry out repairs under the car. Incorrect
positioning of the jack may cause the
car to fall. Do not use the jack
for
loads higher than those shown on the
label.
WARNING
Incorrect wheel cup assem-
bly may cause it to come off
when the car is travelling. Never tam-
per with the inflation valve. Never in-
troduce tools of any kind between rim
and tyre. Check tyre and spare wheel
pressure regularly referring to the
val-
ues shown in the “Technical Specifi-
cations” chapter.
WARNING
Important notes:
the jack weighs 1.76 kg;
the jack requires no adjustment;
the jack cannot be repaired: replace
with an original spare part if damaged;
no tool other than its handle may be fit-
ted on the jack.
CORRECT USE
OF THE CAR
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
WARNING
LIGHTS AND
MESSAGES IN AN
EMERGENCY
LINEA Owner HAND BOOK RHD.pdf 114LINEA Owner HAND BOOK RHD.pdf 1148/21/09 2:16:16 PM8/21/09 2:16:16 PM
