MODEL PLATE fig. 1
This is applied to the right-hand side of the
spare wheel shelf and shows the following
data:
VIN (Vehicle Identification Number)
- Car Model and Version code
- Chassis number
IDENTIFICATION DATA
Take note of the identification codes. The
following identification codes are printed
and shown on the plates:
Model plate.
Chassis marking.
fig. 1F0R0247m
FIAT INDIA AUTOMOBILES LTD.
VIN
*
fig. 2F0R0146m
CHASSIS MARKING fig. 2
This is printed on the passegner com-
partment floor bed under the front left
seat.
car model (MCA 110 716);
chassis number.
ENGINE MARKING
Engine marking is stamped on the cylinder
block and includes the model and the
serial number.
160
CORRECT USE
OF THE CAR
AND CONTROLS
DEVICES WARNING
LIGHTS AND
MESSAGES IN AN
EMERGENCY
CAR
MAINTENANCE
INDEX
TECHNICAL
SPECIFICATIONS
DASHBOARD
SAFETY
VERSION110 716Kg
Kg
Kg
Kg 1
2
- Vehicle Mass Data
LINEA Owner HAND BOOK RHD.pdf 160LINEA Owner HAND BOOK RHD.pdf 1608/21/09 2:16:36 PM8/21/09 2:16:36 PM

ENGINE CODES - VERSIONS
Versions Engine type code
1.4 16v 323B6600
1.3 Multijet 199A3000
161
TECHNICAL
SPECIFICATIONS
CAR
MAINTENANCE
CORRECT USE
OF THE CAR
INDEX
DASHBOARD
SAFETY
WARNING
LIGHTS AND
MESSAGES IN AN
EMERGENCY
AND CONTROLS
DEVICES
LINEA Owner HAND BOOK RHD.pdf 161LINEA Owner HAND BOOK RHD.pdf 1618/21/09 2:16:36 PM8/21/09 2:16:36 PM

1.4 16v
323B6600
Otto
4 in line
72 x 84
1368
10.8 ± 0.2
6000
115
4500
4, NGK
ZKR7A-10 C 128
Unleaded petrol 91 RON min
1.3 Multijet
199A3000
Diesel
4 in line
69.6 x 82
1248
17.6 ± 0.2
4000
203
2500
–
Normal Diesel (avoid premium /
additives) 51 Cetane no. min.
ENGINE
GENERAL
Engine code
Cycle
Number and layout of cylinders
Piston bore and stroke mm
Total displacement cm3
Compression ratio
Maximum power
corresponding rpm
Maximum torque Nm
corresponding rpm
Spark plugs
Fuel
162
CORRECT USE
OF THE CAR
AND CONTROLS
DEVICES WARNING
LIGHTS AND
MESSAGES IN AN
EMERGENCY
CAR
MAINTENANCE
INDEX
TECHNICAL
SPECIFICATIONS
DASHBOARD
SAFETY
Kw 66 65
LINEA Owner HAND BOOK RHD.pdf 162LINEA Owner HAND BOOK RHD.pdf 1628/21/09 2:16:36 PM8/21/09 2:16:36 PM

Modifications or repairs to the fuel feed system that are not carried out properly or do not take the system’s
technical specifications into account can cause malfunctions leading to the risk of fire.
WARNING
TRANSMISSION
1.4 16v -1.3 Multijet
Gearbox Five forward gears plus reverse with synchronisers for forward gears
Clutch Self-adjusting with pedal without idle stroke
Drive Front
Fuel feedMultipoint electronic injection Multijet direct injection
“Common Rail”
FUEL FEED/IGNITION
1.4 16v1.3 Multijet
163
TECHNICAL
SPECIFICATIONS
CAR
MAINTENANCE
CORRECT USE
OF THE CAR
INDEX
DASHBOARD
SAFETY
WARNING
LIGHTS AND
MESSAGES IN AN
EMERGENCY
AND CONTROLS
DEVICES
LINEA Owner HAND BOOK RHD.pdf 163LINEA Owner HAND BOOK RHD.pdf 1638/21/09 2:16:37 PM8/21/09 2:16:37 PM

SUSPENSIONS
1.4 16v - 1.3 Multijet
Front
Rear
BRAKES
1.4 16v - 1.3 Multijet
Service brakes:
– front
– rear
Parking brake
IMPORTANT Water, ice and salt sprinkled on the roads may deposit on the brake disks reducing braking efficiency
when the brakes are applied first time.
Telescopic
Hydraulic, Telescopic controlled by hand lever, operating on rear brakes
Steering wheel with jointed, energy absorbing column, Hydraulic power steering with rackdrum brakes with self centring shoes with one control cylinder per wheelventilated disk
STEERING
1.4 16v - 1.3 Multijet
Type
Steering diameter (m)
Steering box ratio (mm/turn) No. of steering wheel turn (lock to lock)
Rack track (mm)11.1
2.65
51
135
164
CORRECT USE
OF THE CAR
AND CONTROLS
DEVICES WARNING
LIGHTS AND
MESSAGES IN AN
EMERGENCY
CAR
MAINTENANCE
INDEX
TECHNICAL
SPECIFICATIONS
DASHBOARD
SAFETY
LINEA Owner HAND BOOK RHD.pdf 164LINEA Owner HAND BOOK RHD.pdf 1648/21/09 2:16:37 PM8/21/09 2:16:37 PM

READING TYRE
MARKINGS fig. 3
Example: 185/65 R 15 88T
185 = Nominal width (S, distance in mm
between sidewalls).
65 = Heigh t/width ratio (H/S) in per-
centage.
R = Radial tyre.
15 = Rim diameter in inches (Ø).
88 = Load rate (capacity).
T = Maximum speed rating.
WHEELS
RIMS AND TYRES
Pressed steel or alloy rims. Tubeless ra-
dial carcass tyres.
Respect the prescribed size to ensure
safety of the car in movement. Fit tyres
of the same make and type on all wheels.
IMPORTANT Do not use inner tubes
with Tubeless tyres.
fig. 3F0R0147m
SPARE WHEEL
Pressed steel rim Tubeless tyre.
WHEEL GEOMETRY
Toe-in total front: 0.3 ± 1 mm
Toe-in total rear: 3.4 ± 2.0 mm
The values refer to the car in running or-
der.
165
TECHNICAL
SPECIFICATIONS
CAR
MAINTENANCE
CORRECT USE
OF THE CAR
INDEX
DASHBOARD
SAFETY
WARNING
LIGHTS AND
MESSAGES IN AN
EMERGENCY
AND CONTROLS
DEVICES
LINEA Owner HAND BOOK RHD.pdf 165LINEA Owner HAND BOOK RHD.pdf 1658/21/09 2:16:37 PM8/21/09 2:16:37 PM

READING RIM
MARKINGS fig. 3
Example: 6J x 15 ET44
6 = rim width in inches 1.
J = rim drop centre outline (sid e
projection where the tyre bead
rests) 2.
15 = rim nominal diameter in inches
(corresponds to diameter of the
tyre to be mounted) 3= Ø.
ET44 = wheel camber angle (distance be-
tween the disc/rim supportin g
plane and the wheel rim centre
line). Load rating (capacity)
70= 335 kg 81= 462 kg
71= 345 kg 82= 475 kg
72= 355 kg 83= 487 kg
73= 365 kg 84= 500 kg
74= 375 kg 85= 515 kg
75= 387 kg 86= 530 kg
76= 400 kg 87= 545 kg
77= 412 kg 88= 560 kg
78= 425 kg 89= 580 kg
79= 437 kg 90= 600 kg
80= 450 kg 91= 615 kg Maximum speed rating
Q= up to 160 km/h.
R= up to 170 km/h.
S= up to 180 km/h.
T= up to 190 km/h.
U= up to 200 km/h.
H= up to 210 km/h.
V= up to 240 km/h.
Maximum speed rating
for snow tyres
QM + S= up to 160 km/h.
TM + S= up to 190 km/h.
HM + S= up to 210 km/h.
166
CORRECT USE
OF THE CAR
AND CONTROLS
DEVICES WARNING
LIGHTS AND
MESSAGES IN AN
EMERGENCY
CAR
MAINTENANCE
INDEX
TECHNICAL
SPECIFICATIONS
DASHBOARD
SAFETY
LINEA Owner HAND BOOK RHD.pdf 166LINEA Owner HAND BOOK RHD.pdf 1668/21/09 2:16:37 PM8/21/09 2:16:37 PM

195/60 R15 88T 195/60 R15 88T
195/60 R15 88T195/60 R15 88T
195/60 R15 88T 195/60 R15 88T 6J X 15'’ 6J X 15'’
6J X 15'’ 6J X 15'’
6J X 15'’(Alloy wheel) 6J X 15'’(pressed steel)
Version Rims Tyres fitted
(where provided)Spare wheel (where provided)Rim Tyre
1.3 Multijetactive
dynamic
emotion 1.4 16v
167
TECHNICAL
SPECIFICATIONS
CAR
MAINTENANCE
CORRECT USE
OF THE CAR
INDEX
DASHBOARD
SAFETY
WARNING
LIGHTS AND
MESSAGES IN AN
EMERGENCY
AND CONTROLS
DEVICES
LINEA Owner HAND BOOK RHD.pdf 167LINEA Owner HAND BOOK RHD.pdf 1678/21/09 2:16:37 PM8/21/09 2:16:37 PM

COLD TYRE INFLATION PRESSURE (bar)
Ty r e
Medium load Full load
Front Rear Front Rear
195/60 R15 88T 2.3 2.1 2.3 2.3
Add +0.3 bar to the prescribed inflation pressure when the tyres are warm. Recheck pressure value with cold tyres.
168
CORRECT USE
OF THE CAR
AND CONTROLS
DEVICES WARNING
LIGHTS AND
MESSAGES IN AN
EMERGENCY
CAR
MAINTENANCE
INDEX
TECHNICAL
SPECIFICATIONS
DASHBOARD
SAFETY
LINEA Owner HAND BOOK RHD.pdf 168LINEA Owner HAND BOOK RHD.pdf 1688/21/09 2:16:37 PM8/21/09 2:16:37 PM

DIMENSIONS
