WARNINGImproper use of power windows can be dangerous. Before and during its operation
ensure that any passengers are not at risk from the moving window either by
personal objects getting caught on the mechanism or by being injured by it directly.
When leaving the car, the ignition key should be removed to prevent the power
window from being operated inadvertently and harming anyone remaining in the
car.
F0E0081m
ELECTRIC WINDOWS
FRONT SEATS
The electric windows are controlled by two buttons in the inside of the
handle on the driver’s door:
A - to open/close left window;
B - to open/close right window.
If button (A) on driver’s side is pressed for over one second, the
automatic opening/closing function is activated: the window will stop
moving when it reaches the end of its stroke (or when the button is
pressed again).
On the passenger side there is a switch in the door handle to control the
relevant window.

77
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
REAR SEATS
Both internal handles are fitted with the switches (D) for controlling the
relevant windows.
To prevent the buttons on the rear doors being used to open/close the
rear windows, press the lock button (E) (led on), on the instrument
panel.
On versions with optional ESP, the rear window lock button is located
on the panel under the heater controls (F).
F0E0610m
F0E0611m
F0E0609m

TECHNICAL
SPECIFICATIONS
258
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
CAR
MAINTENANCE
INDEXDASHBOARD
AND CONTROLS
IN AN
EMERGENCY
– adjusting the headlight slant.... 88
– beam adjustment abroad ......... 89
Head restraints ................................ 44
Heated rear window
– control ........................................ 65
Heating and climate
control system ............................. 48-50
– adjustable outlets ...................... 49
– climate control with automatic
temperature control ................ 54
– controls.................................. 50-52-54
– cooling ......................................... 52-57
– demisting................................ 51-53-55
– heating ......................................... 50-55
– heating and ventilation ............. 50
– manual climate control
system .......................................... 52
– recirculation .......................... 51-53-57
– ventilation ................................... 51
If an exterior light burns out ....... 186
If an interior light burns out ......... 192
If the battery is flat .......................... 202
Ignition switch .................................. 15
– key positions .............................. 15
– steering lock ............................... 16
Individual settings ............................ 41– key without remote control... 9
– replacing the batteries ............. 10
Lubricants (specifications)............ 250
Main beam headlights
– bulb replacement ...................... 187
– control ......................................... 59
– flashing the headlights ............. 60
Manual climate control system .... 52
Number plate lights ....................... 191
Paintwork
– identification plate ................... 235
– maintenance .............................. 230
Parking ............................................... 140
– handbrake ................................... 141
Parking sensors
– acoustic signal ............................ 97
– activation ..................................... 97
– failure warnings.......................... 98
– general warnings........................ 98
Performance ..................................... 246
Pollen filter........................................ 220
Power steering ................................. 239
– fluid level ..................................... 218 Instrument panel.............................. 17
Instruments
– clock ............................................. 21
– control buttons ......................... 19
– fuel gauge .................................... 18
– rev counter................................. 18
– speedometer .............................. 21
– tachometer ................................. 18
Interior equipment
– ashtray ......................................... 69
– cigar lighter ................................. 69
– current sockets ......................... 70
– driver's oddment tray .............. 67
– food box...................................... 71
– oddment tray under seat ........ 68
– oddment tray under sun visors 68
– passenger's oddment tray ....... 67
– sun visors .................................... 70
Interiors ............................................. 231
Jacking the car ................................. 203
Keys................................................... 8
– code card .................................... 8
– duplicate ...................................... 10
– key with remote control ......... 9
