ENGINE OIL CONSUMPTION
Max engine oil consumption is usually 400 grams every
1000 km.
When the car is new, the engine needs to run in,
therefore the engine oil consumption can only be
considered stabilised after the first 5000 ÷ 6000 km.
When the engine is hot, take care when working inside the engine compartment to
avoid burns. Remember that when the engine is hot, the fan may cut in: danger of
injury. Scarves, ties and other loose clothing might be pulled by moving parts.WARNING
IMPORTANT The oil consumption depends on driving
style and the conditions under which the car is used.

215
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
IN AN
EMERGENCY
CAR
MAINTENANCEUsed engine oil and filter contain harmful substances for the environment. Contact Fiat Dealership
to have the oil and filter changed, as they are equipped to dispose of the waste oil and filters
respecting the nature and the law. IMPORTANT After adding or changing the oil, let the
engine turn over for a few seconds and wait a few
minutes after turning it off before you check the level.
Do not add oil with specifications other than that already in the engine.
IMPORTANT If a routine check reveals that the oil
level is above the MAX mark, contact Fiat Dealership
to have the correct level restored.

216
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
CAR
MAINTENANCE
ENGINE COOLANT
The coolant level shall be checked with cold engine and shall be between
the MIN and MAX marks on the reservoir.
If the level is low, pour slowly a mixture of 50% water and 50% FL
Selenia PARAFLU UP through the filler neck until reaching the MAX
mark.
A 50-50 mixture of PARAFLU UP and water gives freeze protection to
–35°C.
F0E0682m
The engine cooling system uses PARAFLU UP fluid, top up only with fluid of the same type.
PARAFLU UP cannot be mixed with other types of fluid; if mixed, do nor start the engine and
contact Fiat Dealership immediately.
WARNINGThe cooling system is pressurised. If necessary, replace the cap only with
another genuine one, otherwise system efficiency could be compromised.
Do not remove the reservoir cap when the engine is hot: you risk scalding
yourself.

217
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
IN AN
EMERGENCY
CAR
MAINTENANCE
WINDSCREEN/REAR WINDOW/HEADLIGHT WASHER
FLUID
To top up, remove the cap (you shall hear a click) and then pour a
mixture of water and TUTELA PROFESSIONAL SC 35, in the following
concentrations:
❒30% TUTELA PROFESSIONAL SC 35 and 70% water in summer.
❒50% TUTELA PROFESSIONAL SC 35 and 50% water in winter.
In case of temperatures below –20°C, use undiluted TUTELA
PROFESSIONAL SC 35 fluid.
F0E0683m
WARNINGDo not travel with the windscreen washer reservoir empty. The windscreen washer
is fundamental for improving visibility.
WARNINGCertain commercial additives for windscreen washers are inflammable. The engine
compartment contains hot components which may set it on fire.

218
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
CAR
MAINTENANCE
POWER STEERING FLUID
Check that the fluid level is between the MIN and MAX marks on the
reservoir with the car parked on level ground and engine cold.
When the oil is hot the level may exceed the MAX mark.
If necessary add oil making sure that it has the same specifications as the
oil already in the system.
F0E0684m
The oil consumption is very low; if, after topping up it becomes necessary to top up again quite
soon after, have the system checked by Fiat Dealership for any leaks.
WARNINGDo not allow the power steering fluid to come into contact with the hot parts of
the engine: it is inflammable.

219
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
IN AN
EMERGENCY
CAR
MAINTENANCE
BRAKE FLUID
Unscrew cap (A) and check that the fluid level in the reservoir is at
maximum.
Fluid level in the reservoir shall not exceed the MAX mark.
Check that the fluid level in the reservoir is at maximum.
Top up with the brake fluid specified in the table “Fluids and lubricants”
(see section “Technical Specifications ")
When opening the cap take the utmost care to prevent impurities
entering the tank.
When topping up, always use a funnel with built-in filter with mesh equal
to or lower than 0.12 mm.
F0E00685m
Make sure that the highly corrosive brake fluid does not drip onto the paintwork; if it does, wash it
off immediately with water.
Symbol πon the container indicates synthetic brake fluid, distinguishing it from
the mineral kind. Using mineral fluids irreversibly damages the special braking
system rubber seals.WARNING
Brake fluid is poisonous and highly corrosive. In the event of accidental contact,
wash the parts involved immediately with neutral soap and water, then rinse
thoroughly. Call the doctor immediately if the fluid is swallowed.WARNING

220
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
CAR
MAINTENANCE
AIR CLEANER
REPLACEMENT
Undo the four screws, remove cover (A) and take out the filtering
element (B) to be replaced.
POLLEN FILTER
If the car is used frequently in dusty or heavily polluted environments it is
advisable to replace the filtering element more frequently than specified
in the Service Schedule in this section; in particular it should be replaced
if a reduction of the amount of air admitted to the passenger
compartment is noted.
To replace it, take out cover (A) (restrained) using a screwdriver,
remove the second cover by removing the four fastening screws and take
out the filtering element (B) to be replaced.
F0E0172m
F0E0173m
F0E0686m
Petrol version
Diesel version

221
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
IN AN
EMERGENCY
CAR
MAINTENANCE
DIESEL FUEL FILTER
DRAINING THE CONDENSE (diesel versions)
IMPORTANT The presence of water in the fuel circuit
can severely damage the injection system and make
the engine misfire. If the warning light
cturns on,
contact a Fiat Dealership as soon as possible to have
the bleeding operation carried out.
If the warning light comes on immediately after
refuelling, water is probably present in the tank: turn
the engine off immediately and contact Fiat Dealership.
BATTERY
Fiat Multipla battery is of the “Limited maintenance”
type: under normal conditions of use it does not
require topping up with distilled water.
CHECKING THE BATTERY FLUID LEVEL
(electrolyte)
Check the electrolyte level (and top up if required) at
the intervals shown in the Service Schedule in this
section. Have this operation carried out at Fiat
Dealership.
Batteries contain substances that are very harmful for the environment. You are advised to have
the battery changed at a Fiat Dealership, which is properly equipped for disposing of used batteries
respecting nature and law.
The liquid in the battery is poisonous and corrosive. Avoid contact with eyes and
skin. Do not bring naked flames or possible sources of sparks near to the battery:
risk of fire and explosion.WARNING

222
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
CAR
MAINTENANCE
Incorrect fitting of electrical and electronic accessories can seriously damage the car. If after buying
the car, you want to install electric accessories which require permanent electric supply (alarm,
sound system, free-hand phone kit, etc.) contact Fiat Dealership whose qualified personnel, in
addition to suggesting the most suitable devices, will evaluate the overall electric absorption,
checking whether the car’s electric system is capable of withstanding the load required, or whether
it should be integrated with a more powerful battery.
WARNINGWhen working on the battery or near it, always wear the proper goggles.
WARNINGRunning the battery with low fluid level can damage the battery beyond repair and
could also cause its explosion. CHANGING THE BATTERY
If required, replace the battery with a genuine spare
part having the same specifications. If a battery with
different specifications is fitted, the service intervals
given in the “Service Schedule” in this section will nolonger be valid. Refer to the instructions provided by
the battery’s Manufacturer.
WARNINGIf the car is left inactive for long periods at cold, remove the battery and store it in
a warm place to prevent freezing.

223
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
IN AN
EMERGENCY
CAR
MAINTENANCE
USEFUL ADVICE FOR LENGTHENING
THE LIFE OF YOUR BATTERY
To avoid draining your battery and lengthen its life,
observe the following indications:
❒when you park the car, ensure the doors, tailgate
and bonnet are closed properly. Passenger’s
compartment lights must be off;
❒ceiling lights must be off. The car is however
provided with an automatic system for switching off
internal lights;
❒do not keep accessories (e.g.: sound system, hazard
lights, etc.) switched on for a long time when the
engine is not running;
❒before performing any operation on the electrical
system, disconnect the battery negative cable;
❒battery terminals shall always be perfectly tightened.
IMPORTANT A battery which is kept at a charge of
less than 50% (optical indicator with dark colour
without green area in the middle) for any length of
time will be damaged by sulphation leading to a
reduction in cranking power.Moreover, this might lead to a higher risk of the
battery electrolyte freezing (this may even occur at -
10°C). If the car is inactive for a long period of time,
refer to “Storing the car”, in section “Driving your
car”.
If after buying the car, you want to install electric
accessories which require permanent electric supply
(alarm, etc.) contact Fiat Dealership whose qualified
personnel, in addition to suggesting the most suitable
devices, will evaluate the overall electric absorption,
checking whether the car’s electric system is capable
of withstanding the load required, or whether it
should be integrated with a more powerful battery.
In fact, since these devices continue absorbing energy
even when the ignition key is off, they gradually run
down the battery.
The total intake of these systems (factory and after-
market) must be less than 0.6 mA x Ah (of the
battery) as shown in the following table:
Battery Maximum admitted stand-by intake
40 Ah 24 mA
50 Ah 30 mA
