WINDSCREEN/REAR WINDOW/HEADLIGHT WASHER
FLUID
To top up, remove the cap (you shall hear a click) and then pour a
mixture of water and TUTELA PROFESSIONAL SC 35, in the following
concentrations:
❒30% TUTELA PROFESSIONAL SC 35 and 70% water in summer.
❒50% TUTELA PROFESSIONAL SC 35 and 50% water in winter.
In case of temperatures below –20°C, use undiluted TUTELA
PROFESSIONAL SC 35 fluid.
F0E0683m
WARNINGDo not travel with the windscreen washer reservoir empty. The windscreen washer
is fundamental for improving visibility.
WARNINGCertain commercial additives for windscreen washers are inflammable. The engine
compartment contains hot components which may set it on fire.

226
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
CAR
MAINTENANCE
RUBBER TUBING
As far as the brake system and fuel rubber hoses are
concerned, carefully follow the Service Schedule in this
section. Indeed ozone, high temperatures and
prolonged lack of fluid in the system may cause
hardening and cracking of the hoses, with possible
leaks. Careful control is therefore necessary.
WINDSCREEN/
REAR WINDOW WIPERS
BLADES
Periodically clean the rubber part using special
products; TUTELA PROFESSIONAL SC 35 is
recommended.
If the rubber blades are bent or worn they should be
replaced. In any case they should be changed once a
year.
A few simple notions can reduce the possibility of
damage to the blades:
❒if the temperature fall below zero, make sure that
ice has not frozen the rubber against glass. If
necessary, thaw using an antifreeze product;
❒remove any snow from the glass: in addition to
protecting the blades, this prevents effort on the
motor and overheating;
❒do not operate the windscreen and rear window
wipers on dry glass.
WARNINGDriving with worn wiper blades is a serious hazard, because visibility is reduced in
bad weather.

227
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
IN AN
EMERGENCY
CAR
MAINTENANCE
Changing the windscreen wiper blades
On certain versions, to remove the blade proceed as follows:
❒Raise the windscreen wiper arm and position the blade so that it
forms an angle of 90° with the arm;
❒press tabs (A) (set aside the blade) and remove the blade from the
arm;
❒Fit the new blade by inserting it into the special slot in the arm. Make
sure it is properly locked into place.
Changing the rear window blade
❒Lift the cover (C).
❒Loosen screw (D).
❒Remove the blade to be replaced and fit the new blade, making sure
that during operation it reaches the lower edge of the window.
F0E00688m
F0E0723m

228
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
CAR
MAINTENANCE
SPRAY NOZZLES
If there is no jet of fluid, first make sure there is fluid in the reservoir: see
“Checking fluids” in this section.
Then check that the nozzle holes are not clogged, if necessary use a
needle.
The windscreen jets are directed by adjusting the angle of the nozzles.
Fluid jets shall be directed at about 250 mm from the window upper
edge.
Rear window wiper nozzle holder is set at the base of the rear window
wiper. Nozzles are fixed and cannot be adjusted.
F0E0689m
F0E0690m

231
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
IN AN
EMERGENCY
CAR
MAINTENANCE
Windows
Use specific window cleaner products to clean cloths
to avoid scratching the glass or damaging the
transparency.
IMPORTANT The inside of the rear window should
be wiped gently with a cloth in the direction of the
filaments to avoid damaging the heating device.
Engine compartment
At the end of the winter the engine compartment
should be carefully washed, without directing the jet
against electronic control units. Contact a specialised
workshop to have this done.
IMPORTANT Wash with the engine cold and the
ignition key at STOP. After washing make sure that the
various protections (e.g. rubber caps and various
covers) have not been damaged or removed.
Front headlights
IMPORTANT Never use aromatic substances (e.g.:
petrol) or ketones (e.g.: acetone) for cleaning front
headlight plastic lens.
IMPORTANT Wash with the engine cold and the
ignition key at STOP. After washing make sure that the
various protections (e.g. rubber caps and various
covers) have not been damaged or removed.INTERIORS
Periodically check that water is not trapped under the
mats (due to water dripping off shoes, umbrellas, etc.)
which could cause oxidisation of the sheet metal.
CLEANING SEATS AND FABRIC/JERSEY
UPHOLSTERY
❒Use a soft brush or vacuum cleaner to remove dust.
❒Rub the seats with a sponge moistened with a
solution of water and neutral detergent.
PLASTIC PARTS INSIDE THE CAR
Clean the plastic parts inside the car with a cloth
moistened with a solution of water and non-abrasive
neutral detergent. To remove grease or hard stains,
use special solvent-free products designed not to alter
the appearance and colour of components.
IMPORTANT Do not use alcohol or petrol to clean
the instrument panel.
Detergents cause water pollution.
Therefore the engine compartment should
be washed in areas equipped for
collecting and purifying the liquid used in
the washing process.

251
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
CAR
MAINTENANCE
INDEX
DASHBOARD
AND CONTROLS
IN AN
EMERGENCY
TECHNICAL
SPECIFICATIONS
Applications
Mechanical gearbox
and differential
Hydraulic power steering
CV joints
Brake and clutch
hydraulic controls
Cooling circuits.
Proportion:
50% water and 50%
PARAFLU UP
To be used diluted
or undiluted Original fluids
and lubricants
TUTELA CAR
TECHNYX
TUTELA GI/A
TUTELA MRM 2
TUTELA TOP 4
PARAFLU UP (
●)
TUTELA
PROFESSIONAL SC 35 Fluid and lubricant specifications
for correct car operation
Synthetic-based oil, grade SAE 75W- 85,
that passes API GL4 PLUS specifications.
ATF DEXRON II D LEV oil
Molibdenum disulphide, lithium soap based grease,
N.L.G.I. consistency 2
Synthetic fluid FMVSS n° 116DOT 4, ISO 4925,
SAE J 1704, CUNA NC 956-01
Protective with antifreeze action (red colour)
based on inhibited monoethylen glycol,
with O.A.T. formulation,that passes CUNA NC 956-16,
ASTM D 3306 specifications
Mixture of alcohol and surfactants CUNA NC 956 - II
(●) IMPORTANT Do not top up or mix with other fluids having different specifications from the prescribed ones. Lubricants and greases
for transmission Use
Brake fluid
Radiator
antifreeze
Windscreen/
rear window
washer fluid

TECHNICAL
SPECIFICATIONS
256
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
CAR
MAINTENANCE
INDEXDASHBOARD
AND CONTROLS
IN AN
EMERGENCY
I I
N N
D D
E E
X X
– Isofix type child restraint
system .......................................... 126
Ceiling lights
– front ............................................. 63
– front bulb replacement ............ 192
– rear .............................................. 64
– rear bulb replacement ............. 193
Cellular phone set-up ..................... 106
Changing a wheel ............................ 167
Chassis marking .............................. 235
Checking fluid levels
– brake fluid ................................... 219
– engine oil ..................................... 214
– engine oil consumption............ 215
– power steering fluid ................. 218
– windscreen/rear window
washer fluid ................................ 217
Cigar lighter ...................................... 69
Clock .................................................. 21
Clutch ................................................ 238
CO
2emissions ................................ 253
Controls
– front fog lights............................ 65
– fuel cut-off switch ..................... 66 – advice for preserving
the bodywork ............................ 230
– headlights .................................... 231
– identification plate..................... 234
– paint.............................................. 230
– versions ...................................... 236
– warranty ..................................... 229
– windows ...................................... 231
Bonnet ............................................... 85
Boot.................................................... 78
– anchoring the load .................... 80
– extending the boot .................. 81
– opening/closing .......................... 78
Brake fluid level ............................... 219
Brake light (replacement) .............. 190
Brakes ................................................ 239
– fluid level ..................................... 219
– service and emergency brake .. 239
Bulb replacement ............................ 183
Bulb types.......................................... 184
Capacities......................................... 249
Car maintenance ............................. 205
Carrying children safely ................. 120
ABS system...................................... 90
Additional checks ............................ 210
Adjusting the headlight beam ....... 88
Aerial ................................................. 103
Airbags ............................................... 129
– deactivation ................................ 131
– description and operation ..... 129
– front ............................................. 129
– general warnings........................ 134
– side ............................................... 132
Air cleaner ........................................ 220
Air vents
(directional and adjustable) ........ 49
Annual inspection plan ................... 209
Ashtray .............................................. 69
Automatic climate control system 54
Battery
– changing ....................................... 222
– fluid level .................................... 221
– recharging ................................... 202
– useful advice for lengthening
the life of your battery............. 223
Bodywork

TECHNICAL
SPECIFICATIONS
257
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
CAR
MAINTENANCE
INDEX
DASHBOARD
AND CONTROLS
IN AN
EMERGENCY
– hazard lights................................ 65
– heated rear window ................. 65
– rear fog lights ............................. 65
Consumption
– engine oil ..................................... 215
– fuel ................................................ 252
Current sockets .............................. 70
Dashboard ....................................... 5
Demisting/defrosting................ 51-53-55
– rear window ............................... 51-53
– windscreen and windows ..... 51-53
Diesel fuel filter ............................... 221
Differential ........................................ 238
Dimensions ....................................... 244
Dipped beam headlights
– bulb replacement ...................... 187
– control ......................................... 59
Direction indicators
– control ......................................... 60
– front bulb replacement ............ 188
– rear bulb replacement ............. 190
– side bulb replacement .............. 188
Doors
– child safety device ..................... 75
– opening/closing .......................... 74
Fiat Code (system) ........................ 8
FIX & GO automatic
(quick tyre repair kit) .................. 175
Fluids and lubricants ....................... 250
Front fog lights ................................. 65
– bulb replacement ..................... 187
– control ......................................... 65
Fuel
– consumption ............................. 252
– fuel cut-off switch .................... 66
– gauge ........................................... 18
Fuel filler cap .................................... 108
Fuses replacement .......................... 194
Gearbox
– type............................................... 238
– use ............................................... 142
Glove compartments/oddment trays
– driver's side ................................ 67
– passenger's side ........................ 67
– under seat .................................. 68
– under sun visors ........................ 68
Handbrake ....................................... 141
Hazard lights .................................... 65
Headlights.......................................... 88
– adjusting the headlight beam .. 88
Electric windows ............................ 76
– front ............................................. 76
– rear ............................................... 77
Electrically controlled sunroof ..... 72
– controls ....................................... 73
– roof closure safety system ...... 72
Electronic alarm............................... 11
– deactivation ................................ 13
– operation .................................... 11
– programming .............................. 12
– self-test ........................................ 12
– when alarm is triggered ........... 14
Engine
– identification code..................... 236
– marking ........................................ 235
– technical data ............................. 237
Engine codes ..................................... 236
Engine coolant level ........................ 216
Engine compartment (washing) .... 231
Engine oil
– checking level ............................. 214
– consumption............................... 215
– specifications .............................. 249
EOBD system ................................... 96
ESP (system) ..................................... 92

TECHNICAL
SPECIFICATIONS
258
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
CAR
MAINTENANCE
INDEXDASHBOARD
AND CONTROLS
IN AN
EMERGENCY
– adjusting the headlight slant.... 88
– beam adjustment abroad ......... 89
Head restraints ................................ 44
Heated rear window
– control ........................................ 65
Heating and climate
control system ............................. 48-50
– adjustable outlets ...................... 49
– climate control with automatic
temperature control ................ 54
– controls.................................. 50-52-54
– cooling ......................................... 52-57
– demisting................................ 51-53-55
– heating ......................................... 50-55
– heating and ventilation ............. 50
– manual climate control
system .......................................... 52
– recirculation .......................... 51-53-57
– ventilation ................................... 51
If an exterior light burns out ....... 186
If an interior light burns out ......... 192
If the battery is flat .......................... 202
Ignition switch .................................. 15
– key positions .............................. 15
– steering lock ............................... 16
Individual settings ............................ 41– key without remote control... 9
– replacing the batteries ............. 10
Lubricants (specifications)............ 250
Main beam headlights
– bulb replacement ...................... 187
– control ......................................... 59
– flashing the headlights ............. 60
Manual climate control system .... 52
Number plate lights ....................... 191
Paintwork
– identification plate ................... 235
– maintenance .............................. 230
Parking ............................................... 140
– handbrake ................................... 141
Parking sensors
– acoustic signal ............................ 97
– activation ..................................... 97
– failure warnings.......................... 98
– general warnings........................ 98
Performance ..................................... 246
Pollen filter........................................ 220
Power steering ................................. 239
– fluid level ..................................... 218 Instrument panel.............................. 17
Instruments
– clock ............................................. 21
– control buttons ......................... 19
– fuel gauge .................................... 18
– rev counter................................. 18
– speedometer .............................. 21
– tachometer ................................. 18
Interior equipment
– ashtray ......................................... 69
– cigar lighter ................................. 69
– current sockets ......................... 70
– driver's oddment tray .............. 67
– food box...................................... 71
– oddment tray under seat ........ 68
– oddment tray under sun visors 68
– passenger's oddment tray ....... 67
– sun visors .................................... 70
Interiors ............................................. 231
Jacking the car ................................. 203
Keys................................................... 8
– code card .................................... 8
– duplicate ...................................... 10
– key with remote control ......... 9

TECHNICAL
SPECIFICATIONS
259
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
CAR
MAINTENANCE
INDEX
DASHBOARD
AND CONTROLS
IN AN
EMERGENCY
Pretensioners ................................... 117
Protecting the environment.......... 109
Radio-frequency remote control 9
– description ................................. 9
– ministerial homologation......... 255
Rear fog lights
– bulb replacement ..................... 190
– control ......................................... 65
Rear window shelf removal .......... 83
Rear window washer
– control ......................................... 62
– fluid level ..................................... 217
Rear window wiper
– blades ........................................... 227
– control ......................................... 62
– nozzle ........................................... 228
Rearview mirrors
– door mirrors .............................. 46
– driving mirror ............................ 46
Reconfigurable multifunction
display ............................................. 22
Remote control
(door locking/unlocking) ............. 9
Reversing light (replacement)....... 190
Rims and tyres ................................. 240– accessories.................................. 106
– aerial............................................. 103
– hands-free kit ............................. 104
– radio transmitters and
cellular telephones .................... 15
– speakers ...................................... 102
– standard equipment .................. 102
Spark plugs ........................................ 237
Speedometer .................................... 21
Starting the engine .......................... 137
– bump starting ............................. 167
– emergency starting ................... 165
– how to warm up the engine
after it has just started ............. 139
– ignition switch ............................ 15
– jump starting .............................. 166
– starting procedure
for diesel versions ..................... 138
– starting procedure
for petrol versions .................... 137
– stopping the engine................... 140
Steering .............................................. 239
Steering column lock ...................... 16
Steering column stalks
– left stalk ....................................... 61
– right stalk .................................... 59 Roof rack/ski rack ........................... 87
Rubber tubing................................... 226Seat belts.......................................... 112
– general instructions .................. 118
– how to keep the seat belts
always in efficient conditions ... 120
– load limiters .............................. 118
– pretensioners ............................. 117
– rear seat belts ........................... 114
– transporting children in safety.. 120
– type Isofix child restraint
system .......................................... 126
Seats ................................................... 41
– cleaning ........................................ 231
– front ............................................. 41
– moving ......................................... 81
– rear ............................................... 42
– removing ..................................... 84
Service Schedule .............................. 207
Side/taillights
– control ......................................... 59
– front bulb replacement ............ 189
– rear bulb replacement ............ 190
Snow chains ...................................... 150
Snow tyres ........................................ 149
Sound system ................................... 102
