run flat FIAT MULTIPLA 2006 1.G Owners Manual

142
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT USE
OF THE CAR
USING THE MANUAL GEARBOX
To engage gears, press down the clutch and shift the gear lever into one
of the positions shown (the diagram is also shown on the gear lever
knob).
To engage reverse (R), wait until the car has stopped and, from neutral
move the gear lever to the right and back.
IMPORTANT The car can only be put into reverse gear when it has
stopped moving completely. With the engine running, before engaging the
reverse, wait at least 2 seconds with the clutch pedal fully down to
prevent damaging and grating the gears.
P0E0243m
Do not drive with your hand resting on the gear lever as the force exerted, even if slight, could lead
over time to premature wear on the gearbox internal components.
To change gears properly you must push the clutch pedal fully down. It is therefore
essential that there is nothing under the pedals: make sure mats are lying flat and
do not get in the way of the pedals.WARNING

178
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
IN AN
EMERGENCY
In the event of a puncture caused by foreign bodies, it is possible to repair tyres showing damages
on the track or shoulder up to max 4 mm diameter.
Repairs are not possible in case of damages on the wheel rim (bad groove
distortion causing air loss). Do not remove foreign bodies (screws or nails) from the
tyre.WARNING
WARNINGHoles and damages on the tyre side walls cannot be repaired. Do not use the quick
tyre repair kit if damaging is due to running with flat tyre.

181
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
IN AN
EMERGENCY
❒if also in this case, after 5 minutes from turning the
compressor on it is still impossible to reach at least
1.8 bar, do not start driving since the tyre is
excessively damaged and the quick tyre repair kit
cannot guarantee suitable sealing, contact Fiat
Dealership;
❒if the proper tyre pressure has been reached (see
paragraph “Inflation pressure” in section “Technical
Specifications”, start driving immediately;❒after driving for about 10 minutes stop and check
again the tyre pressure; pull up the handbrake;
WARNING
WARNING
WARNING
Apply the sticker in a visible position
for the driver to indicate that the tyre
has been treated with the quick tyre
repair kit. Drive carefully especially
when cornering. Do not exceed 80
km/h. Avoid heavy braking and
accelerating.
It is of vital importance to
communicate that the tyre has been
repaired using the quick tyre repair kit.
Hand the instruction brochure to the
personnel charged with treating the
tyre repaired with the kit. If the pressure falls below 1.8 bars, do
not drive any further: the quick tyre
repair kit Fix & Go automatic cannot
guarantee proper hold
because the tyre
is too much damaged.
Contact Fiat
Dealership.
❒if pressure read is at least 1.8 bar, restore proper
pressure (with engine running and handbrake on)
and restart;
❒drive with the utmost care to the nearest Fiat
Dealership.
