technical data FIAT MULTIPLA 2006 1.G Owners Manual

24
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
INITIAL TEST
Turn the ignition key to MAR. The message CHECK IN PROGRESS will appear on the configurable multifunction
display. This means that the electronic systems aboard the car are being checked. The test will last for approximately
four seconds. If no faults are found, the message OK will appear on the display after the engine has been started.
IMPORTANT If a failure message appears on the configurable multifunction display, see “Warning lights and
messages” in this section.
TRIPAB I/100kmi°C°Fu
Standard display Engine
running
Turn the ignition
key to MAR
if there are no
faults
The Service Schedule establishes the interventions to be carried out every 20,000 km. This message will appear automatically when the key is
turned to MAR when a distance of 2,000 km (or miles) before the service deadline is reached. The message is then represented every 200 km
until there are 200 km left to the deadline after which the message is represented every 100 km, 50 km, etc... The data can only be reset by a
Fiat Dealership.

28
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
❒Press the MODE button (for longer than 2 seconds)
when in MODE 2 to store data and to go back to
the standard screen (exit the Menu).
❒Press the MODE button (for less than one second)
when in MODE 1 to store the set time and adjust
the minutes; minutes will start flashing after pressing
the MODE button (MODE 1). Press button
âor
ãto set the minutes.Press the button one to increase by one unit at a time.
Hold the button pressed to increase or decrease the
time fastly.
When the required time approaches, release the
control and complete the setting by pressing the
button once at a time.
a) Press the MODE button (for longer than 2 seconds)
when in MODE 2 to store data and to go back to
the standard screen (exit the Menu).
b) Press the MODE button (for less than one second)
when in MODE 1 to store the set time and minutes.
Press
âto surf the menu.

35
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
SERVICE
The SERVICE function is used to
acquire information concerning
correct maintenance of your car.
Proceed as follows to reference
information:
Menu
Back to menu
Back to
standard display See ACCESSING
THE MAIN MENU
Qâ
ã
â
ã
âã
â
ã
ã
â
âã
â
â
ã
QR
IMPORTANT The Service Schedule establish-
es the interventions to be carried out every
20,000 km. This message will appear automat-
ically when the key is turned to MAR when a
distance of 2,000 km (or miles) before the
service deadline is reached. The message is
then represented every 200 km until there
are 200 km left to the deadline after which
the message is represented every 100 km, 50
km, etc... The data can only be reset by a Fiat
Dealership.

38
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLSWhen the external lights are on, âand ãwill always
go from TRIP to ILLUMINATION (see
“Dimmer” in this section).
With km/l consumption condition on.
WPress the button when TRIP A data is displayed to reset TRIP
A and TRIP B at the same time.
See WARNING LIGHTS
and MESSAGES
in this section
Standard display
QPress the MODE button to return automatically to the stan-
dard display
Failures
detected?NO
YES
V
VVVV
V
QW
QW
See
INITIAL
CHECK
continued
QWQW

39
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
TRIP B
ONNO
YES
Back to
standard display
continued
Q
Q
W
W
QQWW
VVV
W
Press the button when TRIP
B data is displayed to reset TRIP
B only.
QPress the MODE button to auto-
matically return to the standard display
When the external lights are on,
âand ãwill always go from TRIP to
ILLUMINATION see “Dimmer”
in this section

110
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
DIESEL PARTICULATE FILTER (DPF)
The Diesel Particulate Filter is a mechanical filter,
integral with the exhaust system, that physically traps
particulates present in the exhaust gases of Diesel
engines.
The diesel particular filter has been adopted to
eliminate almost totally particulates in compliance with
current / future law regulations.
During normal use of the car, the engine control unit
records a set of data (e.g.: travel time, type of route,
temperatures, etc.) and it will then calculate how much
particulates has been trapped by the filter.
Since this filter physically traps particulates, it shall be
cleaned (reclaimed) at regular intervals by burning
carbon particles.
Reclaiming procedure is controlled automatically by
the engine control unit according to the filter
conditions and the conditions of use of the car.During reclaiming the following phenomena could take
place: idling slight increase, fan activation, slight smoke
increase, high exhaust temperatures. These situations
shall not be considered as faults and they do not affect
car performance and environment.
If the dedicated message is displayed, refer to section
“Warning lights and messages”.

121
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
All restraint devices must bear the certification data,
together with the control brand, on a solidly fixed
label which must absolutely never be removed.Over 1.50 m in height, from the point of view of
restraint systems, children are considered as adults
and wear the seat belts normally.
Lineaccessori Fiat offers seats for each weight group,
which are the recommended choice, as they have been
designed and experimented specifically for Fiat cars.
WARNINGWith passenger’s air bag active, never place child’s seats with the cradle facing
backwards since the air bag activation could cause to the child serious injuries,
even mortal, regardless of the seriousness of the crash that triggered it. You are
advised to carry children always with proper restraint systems on the rear seats, as
this is the most protected position in the case of a crash.
WARNINGSERIOUS DANGER Should it be absolutely necessary to carry a baby on the front
passenger seat with a child's seat with the cradle facing backwards, deactivate the
passenger's air bags (front and side on the seat, where provided) using the key
switch and then check warning light
Fon the cluster to make sure that
deactivation has actually took place (see paragraph “ Manual deactivation of
passenger's front air bag”).
The front passenger's seat shall be adjusted in the most backward position to
prevent any contact between child's seat and dashboard.

163
CORRECT USE
OF THE CAR
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
WARNING
LIGHTS AND
MESSAGES
163
Warning Messagelight on panel on display
OUTSIDE LIGHTS (green)
When the side/taillights are switched on.
MAIN BEAM HEADLIGHTS (blue)
When main beam headlights are switched on.
SERVICE
This message will appear on the reconfigurable display at 2000 km from the service schedule dead-
line (every 20,000 km for 100
16Vversions and every 30,000 km for JTD 120 versions) and when
the key is turned to MAR every 200 km, until there are 200 km left, and then every 100, 50, etc...
The data can only be reset at Fiat Dealership.
WARNING LIGHT FAILURE
This message will appear on the reconfigurable display when a failure concerning the warning
lights shown is found
WATER IN DIESEL FUEL FILTER (amber)
(diesel versions)
When there is water in the diesel fuel filter.
3
1
The presence of water in the fuel circuit may cause serious damage to the entire injection system.
Contact Fiat Dealership as soon as this warning light comes on.
c

233
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
CAR
MAINTENANCE
INDEX
DASHBOARD
AND CONTROLS
IN AN
EMERGENCY
TECHNICAL
SPECIFICATIONS
T T
E E
C C
H H
N N
I I
C C
A A
L L
S S
P P
E E
C C
I I
F F
I I
C C
A A
T T
I I
O O
N N
S S
IDENTIFICATION DATA ................................................. 234
ENGINE CODES - BODYWORK VERSIONS .............. 236
ENGINE ................................................................................. 237
FUEL FEED/IGNITION ....................................................... 238
TRANSMISSION .................................................................. 238
BRAKES .................................................................................. 239
SUSPENSIONS ..................................................................... 239
STEERING ............................................................................. 239
WHEELS ................................................................................. 240
DIMENSIONS ....................................................................... 244
PERFORMANCE ................................................................... 246
WEIGHTS ............................................................................... 247
CAPACITIES ......................................................................... 249
FLUIDS AND LUBRICANTS ........................................... 250
FUEL CONSUMPTION ....................................................... 252
CO
2EMISSIONS .................................................................. 253
RADIOFREQUENCY REMOTE CONTROL
MINISTERIAL HOMOLOGATION ................................. 254

234
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
CAR
MAINTENANCE
INDEX
DASHBOARD
AND CONTROLS
IN AN
EMERGENCY
TECHNICAL
SPECIFICATIONS
IDENTIFICATION DATA
You are advised to note the identification codes. The identification data
stamped and given on the plates and their position are the following:
1 - Model plate.
2 - Chassis marking.
3 - Bodywork paint identification plate.
4 - Engine marking.
MODEL PLATE
The plate is to be found in the engine compartment and bears the
following identification data:
A - Manufacturer’s name
B - Homologation number
C - Vehicle type code
D - Chassis number
E - Maximum vehicle weight fully loaded
F - Maximum vehicle weight fully loaded with trailer
G - Maximum vehicle weight on first axle (front)
H - Maximum vehicle weight on second axle (rear)
I - Engine type
L - Body version code
M - Spare part code
N - Correct grade of smoke (diesel engines).
F0E0186m
F0E0654m
