BODYWORK PAINT IDENTIFICATION PLATE
The plate is applied inside the tailgate and it bears the following data:
A - Paint manufacturer
B - Colour name
C - Fiat colour code
D - Respray and touch up code.
CHASSIS MARKING
It is printed on the passenger compartment floor. It can be reached by
lifting the special flap (A) and includes the following data:
❒car model: ZFA 186 000
❒chassis number.
ENGINE MARKING
Engine marking is stamped on the cylinder block and includes the model
and the chassis number.
