FAILURE WARNINGS
In the event of failure, the ESP system is automatically disconnected and
the instrument panel warning light (A) comes on together with the
message on the display (see section “Warning lights and messages”).
In this case, go to a Fiat Dealership as soon as possible.
WARNINGDuring the use of the space-saver spare wheel, the ESP system carries on working.
However, you must remind that the space-saver spare wheel presents dimensions
smaller than the standard tyre and therefore its grip is reduced as to the other car
tyres.
For correct operation of the ESP system, the tyres must absolutely be of the same
brand and type on all wheels, in perfect conditions and, above all, of type, brand
and size specified.WARNING

95
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
When travelling the ASR can be switched off and on
again pressing switch (A) on the centre console.
When the ASR is off this is shown by the lighting up of
the led on the switch.If the ASR is switched off when travelling, it will turn
on again automatically the next time the engine is
started.
When travelling on snow with snow chains, it may be
helpful to turn the ASR off: in fact, in these conditions,
slipping of the driving wheels when moving off makes it
possible to obtain better drive.
WARNINGThe performance of the system, in terms of active safety should not induce the
driver to take pointless and unnecessary risks. The style of driving must in any case
always be adapted to the conditions of the road surface, visibility an traffic. Road
safety is always the driver’s responsibility.
For correct operation of the ASR system, the tyres must absolutely be of the same
brand and type on all wheels, in perfect conditions and, above all, of type, brand
and size specified. WARNING

147
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT USE
OF THE CAR
F0E0192m
ASSEMBLY DIAGRAM
The tow hook structure must be fastened in the points
shown by the symbol (
Ø) using 6 M8 screws and 6
M10 screws.
Anchorage points 1 are to be fitted with spacers Ø 25
x 6 mm.
The internal plates 5 shall have a minimum thickness of
5 mm, the external plates 2, 3 and 4 shall have a
minimum thickness of 5 mm.
The person installing the tow hook must attach, at the
same height as the ball, a plate (well in sight) of
suitable size and material, on which is written:
MAXIMUM LOAD ON BALL: 70 kg.
After fitting, screw holes shall be sealed to prevent
exhaust gas inlet.
Rear wheel axle
loaded
Standard
ball
coupling

148
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT USE
OF THE CAR
ASSEMBLY DIAGRAM
The tow hook structure must be fastened in the points
shown by the symbol (
Ø) using 6 M8 screws and 6
M10 screws.
Anchorage points 1 are to be fitted with spacers Ø 21
x 4 mm.
The internal plates 5 shall have a minimum thickness of
5 mm, the external plates 2 and 3 shall have a
minimum thickness of 5 mm; outer washer 4 must be
at least 2 mm thick.
The person installing the tow hook must attach, at the
same height as the ball, a plate (well in sight) of
suitable size and material, on which is written:
MAXIMUM LOAD ON BALL: 70 kg.
After fitting, screw holes shall be sealed to prevent
exhaust gas inlet.
F0E0193m
Rear wheel axle
loaded
Standard
ball
coupling

149
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT USE
OF THE CAR
SNOW TYRES
These tyres have been specially designed for driving on
snow or ice, to be fitted in place of the standard tyres.
Use snow tyres of the same size as the standard tyres
provided with the car.
Fiat Dealership will be happy to provide advice
concerning the most suitable type of tyre for the
customer’s requirements.
For the type of tyre to be used, inflation pressures and
the specifications of snow tyres, follow the
instructions given in paragraph “Wheels” in section
“Technical specifications”.
The winter features of these tyres are reduced
considerably when the tread depth is below 4 mm. In
this case, they should be replaced.
Due to the snow tyre features, under normal
conditions of use or on long motorway journeys, the
performance of these tyres is lower than that of
standard tyres.It is therefore necessary to limit their use to the
purposes for which they are certified.
IMPORTANT When snow tyres are used with a max
speed index below the one that can be reached by the
car (increased by 5%), place a notice in the passenger
compartment, plainly in the driver’s view which states
the max permissible speed of the snow tyres (as per
EC Directive).
All four tyres should be the same (brand and track) to
ensure greater safety when driving and braking and
better driveability.
Remember that it is inappropriate to change the
direction of rotation of tyres.
The max speed for snow tyres with “Q” marking is 160 km/h. The Road Traffic
Code speed limits must however be always strictly observed.WARNING

167
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
IN AN
EMERGENCY
BUMP STARTING
Never bump start the engine by pushing, towing or
coasting downhill.
This could cause fuel to flow into the catalytic
converter and damage it beyond repair.
IMPORTANT Remember that the servobrake and
electrical power steering system are not operating
until the engine is started, a greater effort will
therefore be required to press the brake pedal or turn
the steering wheel.IF A TYRE IS PUNCTURED
GENERAL INSTRUCTIONS
For versions/markets where applicable, the car can be
fitted with a quick tyre repair kit called FIX & GO,
replacing the usual tool fitting, the spare wheel lifting
winch and the space-saver spare wheel.
Normal spare small wheel, or (where provided)
normal size spare wheel, can be supplied on request;
for its use, follow what indicated below.
VAN versions are fitted as standard with a spare
wheel with steel rim of the same type and size as the
standard wheels mounted on the car.
Wheel changing and correct use of the jack and space-
saver spare wheel call for some precautions as listed
below.
WARNINGAlert other drivers that the car is stationary in compliance with local regulations:
hazard warning lights, warning triangle, etc. Any passengers on board should leave the
car, especially if it is heavily laden. Passengers should stay away from oncoming traffic
while the wheel is being changed. If parked on a slope or rough surface, chock the
wheels with wedges or other suitable devices to prevent the car from rolling.

171
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
IN AN
EMERGENCY
❒to take out the small wheel, or (where provided) the normal size spare
wheel, you have to operate by wrench (A), provided in supply, on
relating bolt; turning it anticlockwise the wheel will lower until it
reaches the ground, to remove it from the supporting hoist, move the
locking bell underneath from position 1 to position 2;
❒only when 15” rims in alloy are present, check bracket (B) is supplied
for spare wheel and its fastening studs (C);
WARNING Check bracket (where provided) must compulsorily be
positioned in rim interior; fastening is through two studs. For positioning
the bell-shaped portion, follow relating pictures (positioning with spare
wheel in alloy, spare wheel made of metal sheet or spare small wheel).
❒Remove check bracket (B) (if present) unscrewing the two fastening
studs (C);
❒Remove the wheel cap (where provided) using a screwdriver as a lever
on the edge of the cap. Loosen the wheel bolts on the wheel to be
changed by approximately one turn;
❒For alloy rims, loosen the anchorage bolts and rock the car to remove
the alloy rim more easily from the wheel hub;
❒Turn the jack hand wheel to open it partially;
F0E0123m
F0E0124m
F0E0727mF0E0726m
Positioning bell-shaped portion with
spare wheel made of metal sheet
Positioning bell-shaped portion with
spare small wheel Positioning bell-shaped portion with
spare wheel in alloy

174
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
IN AN
EMERGENCY
IMPORTANT To fasten bolt (A) use only the wrench supplied; never use
pneumatic screwer since the hooking system could be damaged. To
check the correct fastening of small wheel, or (where provided) normal
size spare wheel, follow attached table providing the number of rough
guide clicks to be heard in order that complete locking is ensured.
F0E0123m
IMPORTANT Do not mount the cup on spare small wheel.
The space-saver spare wheel is narrower than the standard wheels and it
is only to be used to drive the distance necessary to reach a garage
where the flat wheel can be repaired.
IMPORTANT The wheel in alloy with 17” rim cannot be anchored to the
winch.
Number of clicks for the Number of clicks for the
occurrence of hooking occurrence of hooking
with check bracket without check bracket
Spare small wheel18 (*) 18
15” spare wheel
9(❒)
in alloy
15” spare wheel made
(❒)5
of metal sheet
(*) Where a check bracket is present, the bell-shaped portion must be positioned on the
rim, not on the bracket.
(❒) Solutions not allowed.

240
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
CAR
MAINTENANCE
INDEX
DASHBOARD
AND CONTROLS
IN AN
EMERGENCY
TECHNICAL
SPECIFICATIONS
WHEELS
RIMS AND TYRES
Pressed steel or alloy rims (where provided). Tubeless
tyres with radial carcass.
All homologated tyres are listed in the log book.
IMPORTANT In the event of discrepancies between
the information provided on this OWNER
HANDBOOK and the LOG BOOK, consider the
specifications shown in the log book only.
Attaining to the prescribed size, to ensure safety of
the car in movement, it must be fitted with tyres of
the same make and type on all wheels.
IMPORTANT Do not use inner tubes with Tubeless
tyres.
WHEEL GEOMETRY
Front wheel toe-in measured from rim to rim: –3 ±1
mm.
SPACE-SAVER SPARE WHEEL
Pressed steel rim. Tubeless tyre.SNOW TYRES
Use the snow tyres specified in section “Driving your
car” in paragraph “Snow tyres”.
SNOW CHAINS
Only use low profile chains, see section “Driving your
car” in paragraph “Snow chains”.
UNDERSTANDING TYRE MARKING
Example: 185/65 R15 88H
185 = Nominal width (distance between sidewalls
in mm).
65 = Height/width ratio (as a percentage).
R = Radial tyre.
15 = Rim diameter in inches.
88 = Load rating.
H = Maximum speed rating.

242
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
CAR
MAINTENANCE
INDEX
DASHBOARD
AND CONTROLS
IN AN
EMERGENCY
TECHNICAL
SPECIFICATIONS
UNDERSTANDING RIM MARKING
The following are the necessary indications to understand the meaning of
the markings on the rim, as shown in the figure.
Example: 6 J x 15 H2
6 = rim width in inches (1)
J = rim drop center outline (side projection where the tyre bead rests)
(2)
15 = rim nominal diameter in inches (corresponds to diameter of the
tyre to be mounted) (3 =Ø)
H2 = “hump“ shape and number (relief on the circumference holding the
TUBELESS tyre bead on the rim)
F0E0228m
Snow Space-saver spare wheel
Rim Tyre Tyre Rim Tyre
100
16V- JTD 1206 J x15 185/65 R15 88H 185/65 R15 88Q 4B x 15 125/80 R15 95M
6
bJ x15 195/60 R15 88H (*) 195/60 R15 88Q
7 J x17 205/45 R17 88V (*) (❒)–
VAN 100 16V6 J x15185/65 R15 88H 185/65 R15 88Q spare wheel VAN JTD 120195/60 R15 88H (*) 195/60 R15 88Q with standard size
(*) Where provided.
(❒) Tyre that cannot be fitted with snow chains
