FIAT TIPO 4DOORS 2020 Owner handbook (in English)

Weights (kg) 1.3 MultiJet 95 HP1.6 Multijet 120 HP / 1.6 Multijet 115 HP(*****)
Unladen weight (with all fluids, fuel tank filled
to 90% and without optional equipment)1260 / 1205(*****)1310 / 1270(*****)
Payload including the driver(**)500 500
Maximum permitted loads
(***)
– front axle 1050 1050
– rear axle 900 900
– total
1760 / 1705
(*****)1810 / 1770(*****)
Towable loads
– braked trailer 1200 1200
– trailer without brakes 500 500
Maximum load on tow hitch (trailer with
brakes)60 60
Maximum load on roof
(****)45 45
(*****) Version for specific markets (**) If special equipment is fitted, the unladen vehicle weight increases, thus reducing the specified payload.
(***) Loads not to be exceeded. The user should carry goods in the luggage compartment and/on load carrying platform within the maximum permitted loads.
(****) The value shown includes the weight on the roof bars.
199

REFUELLING
1.4 16V 95 HP 1.6 E.TorQ(°)Prescribed fuels and original lubricants
Fuel tank (litres) 45 45
Unleaded petrol with RON no lower than 95
(EN228 specifications)
(*)including a reserve of (litres) 7 7
Engine cooling system (litres) 4.6 5.4
Mixture of distilled water and PARAFLU
UPliquid at 50%(**)
Engine sump (litres) 2.8 4.4
SELENIA K P.E. (1.4 16V 95 HP versions) / SELENIA
DIGITEK P.E. (1.6 E.TorQ versions)
Engine sump and filter (litres) 2.95 4.7
Gearbox casing/differential (litres) 1.76 6.2TUTELA TRANSMISSION GEARFORCE (1.4 16V 95 HP
versions) / TUTELA TRANSMISSION GI/VI (1.6 E.TorQ
versions)
Hydraulic brake circuit (kg) 0.74 0.74 TUTELA TOP 4/S
Windscreen washer fluid reservoir
(litres)3 3 Mixture of water and liquid PETRONAS DURANCE SC 35
(°) For versions/markets where provided
(*) It is advised to use petrol with low sulphur content only (max. sulphur content: 50 ppm)
(**) When the vehicle is used in particularly harsh weather conditions, we recommend using a 60-40 mixture of PARAFLU
UPand demineralised water.
200
TECHNICAL DATA

1.4 T-jet 120 HP LPG(°)Prescribed fuels and original lubricants
Fuel tank (litres)
50/42(**)Unleaded petrol not less than 95 RON (EN
228 specification)(*)/ LPG
(EN589 specification)(***)including a reserve of (litres)
7/8(**)
Engine cooling system (litres) 5.2Mixture of distilled water and PARAFLUUP
liquid at 50%(****)
Engine sump (litres) 2.8
SELENIA MULTIPOWER GAS 5W-40
Engine sump and filter (litres) 3.4
Gearbox casing/differential (litres) 1.8 TUTELA TRANSMISSION GEARFORCE
Hydraulic brake circuit (kg) 0.74 TUTELA TOP 4/S
Windscreen washer fluid reservoir (litres) 3Mixture of water and liquid PETRONAS
DURANCE SC 35
(°) For versions/markets where provided
(**) LPG Tank (*) It is advised to use petrol with low sulphur content only (max. sulphur content: 50 ppm)
(***)The maximum engine power and the car’s performance can only be guaranteed with lead-free petrol with an R.O.N. of 95 or higher.
(****)When the vehicle is used in particularly harsh weather conditions, we recommend using a 60-40 mixture of PARAFLU
UPand demineralised water.
201

1.3 Multijet
95HP E5(*)
1.3 Multijet
95 HP E6 /
E6 ECO1.6 Multijet
120 HP /
1.6 Multijet
115 HP
(***)
Prescribed fuels and original lubricants
Fuel tank (litres) 45 45 45
Diesel for motor vehicles (EN590 Specification)
including a reserve of (litres) 7 7 7
Engine cooling system (litres) 6.1 6.1 6.1Mixture of distilled water and PARAFLU
UP
50%(**)
Engine sump (litres) 3.0 3.7 4.4SELENIA WR FORWARD 0W-30 (for Euro 4, Euro
5 and Euro 6 engines without UREA)
SELENIA WR FORWARD 0W-20 (for 1.6 Multijet
engine with UREA)
SELENIA ECO2 (for 1.3 Multijet engine with UREA) Engine sump and filter (litres) 3.2 3.9 4.8
Gearbox casing/differential (litres) 2.0 2.0 1.8 TUTELA TRANSMISSION GEARFORCE
Hydraulic brake circuit (kg) 0.74 0.74 0.74 TUTELA TOP 4/S
Windscreen washer fluid reservoir
(litres)333Mixture of water and liquid PETRONAS DURANCE
SC 35
UREA tank (for versions/markets,
where provided) approximate
capacity (litres)– 12.5 12.5
AdBlue®(water-UREA solution) standard DIN
70 070 and ISO 22241-1
78) 79)
(*) For versions/markets where provided
(***) Version for specific markets (**) When the vehicle is used in particularly harsh weather conditions, we recommend using a 60-40 mixture of PARAFLUUPand demineralised water.
202
TECHNICAL DATA

IMPORTANT
78)The distribution companies are responsible for the compliance of their product. Observe the precautions of storage and maintenance, in
order to preserve the initial qualities. The manufacturer will not recognise any guarantee in case of malfunctions and damage caused to the
car due to the use of UREA (
AdBlue®
) not in accordance with regulations.
79)Use
AdBlue®
only according to DIN 70 070 and ISO 22241-1. Other fluids may cause damage to the system: also exhaust emissions
would no longer comply with the law.
203

FLUIDS AND LUBRICANTS
80)
Your vehicle is equipped with an engine oil that has been thoroughly developed and tested in order to meet the requirements of
the Scheduled Servicing Plan. Constant use of the prescribed lubricants guarantees the fuel consumption and emission
specifications. Lubricant quality is crucial for engine operation and duration.
If lubricants conforming to the specific request are not available, products that meet the indicated specifications can be used to
top up; in this case optimal performance of the engine is not guaranteed.
PRODUCT SPECIFICATIONS
Use Features SpecificationOriginal fluids and
lubricantsReplacement interval
Lubricant for petrol
engines (1.6 E.TorQ
versions
(°))
SAE 0W-30
ACEA C2 / API SN9.55535-GS1SELENIA DIGITEK P.E.
Contractual Technical
Reference N° F020.B12According to Scheduled
Servicing Plan
Lubricant for petrol
engines (1.4 16V 95 HP
versions)SAE 5W-40
ACEA C3 / API SN9.55535-S2SELENIA K P.E.
Contractual Technical
Reference N° F603.C07According to Scheduled
Servicing Plan
Lubricants for
petrol/LPG engines
(*)SAE 5W-40
ACEA C3 / API SN9.55535-T2SELENIA
MULTIPOWER GAS
5W-40
Contractual Technical
Reference N° F922.E09According to Scheduled
Servicing Plan
Lubricant for Euro 4,
Euro 5 and Euro
6 engines without UREASAE 0W-30
ACEA C29.55535-DS1 or
MS.90047SELENIA WR
FORWARD
Contractual Technical
Reference N° F842.F13According to Scheduled
Servicing Plan
Lubricant for 1.6 Multijet
diesel engines with
UREASAE 0W-20
ACEA C29.55535-DSXSELENIA WR
FORWARD
Contractual Technical
Reference N° F013.K15According to Scheduled
Servicing Plan
(°) Where fitted
(*) For versions/markets where provided
204
TECHNICAL DATA

Use Features SpecificationOriginal fluids and
lubricantsReplacement interval
Lubricant for 1.3 Multijet
engines with UREASAE 0W-20
ACEA C59.55535-DM1SELENIA ECO2
Contractual Technical
Reference N° F049.C18According to Scheduled
Servicing Plan
205

Use Features SpecificationOriginal fluids and
lubricantsApplications
Lubricants and
greases for drive
transmissionSAE 75W grade synthetic
lubricant9.55550-MZ6TUTELA
TRANSMISSION
GEARFORCE
Contractual Technical
Reference N° F002.F10Manual mechanical
transmission
ATF AW-1 automatic
transmission lubricant9.55550-AV2TUTELA
TRANSMISSION GI/VI
Contractual Technical
Reference N° F336.G05Lubricant for versions with
AT6 automatic gearbox
Grease for constant
velocity joints with low
friction coefficient.
N.L.G.I. consistency 0-19.55580 – GRASS IITUTELA STAR 700
Contractual Technical
Reference N° F701.C07Differential side constant
velocity joints
Molybdenum disulphide
grease, for use at high
temperatures. N.L.G.I.
consistency 1-29.55580-GRAS IITUTELA ALL STAR
Contractual Technical
Reference N° F702.G07Wheel side constant
velocity joints
206
TECHNICAL DATA

Use Features SpecificationOriginal fluids and
lubricantsApplications
Brake fluidSynthetic fluid for brake
and clutch systems.
Exceeds specifications:
FMVSS no. 116 DOT 4,
ISO 4925 SAE J1704.9.55597 or MS.90039TUTELA TOP 4/S
Contractual Technical
Reference N° F005.F15Hydraulic brakes and
hydraulic clutch controls
Protective agent for
radiatorsProtective agent with
antifreeze action with
organic formulation.
CUNA NC 956-16, ASTM
D 3306 Specifications.9.55523 or MS.90032PARAFLU
UP(*)
Contractual Technical
Reference N° F101.M01Cooling circuits
proportions of use: 50%
water 50% PARAFLUUP(**)
Diesel fuel additiveAntifreeze additive for
diesel fuel for diesel
engine protection—PETRONAS DURANCE
DIESEL ART
Contractual Technical
Reference N° F601.C06To mix with diesel (25 cc
per 10 litres)
Windscreen washer
fluidMixture of spirits and
surfactants. Exceeds
CUNA NC
956-11 specifications9.55522 or MS.90043PETRONAS DURANCE
SC 35
Contractual Technical
Reference N° F001.D16To be used diluted or
undiluted in screen
washer/wiper systems
Additive for diesel
emissions (UREA)Water-UREA solutionDIN 70 070 and ISO
22241-1
AdBlue®
To be used for filling the
tank UREA on vehicles
equipped with system of
Selective Catalytic
Reduction (SCR)
(*) Do not top up or mix with other fluids which have different specifications from the ones described.
(**) When the vehicle is used in particularly harsh weather conditions, we recommend using a mixture of 60% PARAFLUUPand 40% demineralised water.
IMPORTANT
80)The use of products with different specifications than those indicated above could cause damage to the engine that is not covered by the
warranty.
207

PERFORMANCE
Top speeds after the initial period of usage of the car.
Versions km/h
1.4 16V 95 HP(*)182
1.4 T-jet 120 HP LPG E6
(**)200
1.6 E.TorQ
(*) (**)192
1.3 Multijet 95HP E5
(**)183
1.3 Multijet 95 HP E6 / E6 ECO180
1.6 Multijet 120 HP E6199
1.6 Multijet 115 HP E6
(***)196
(*) Figures obtained using 95 RON unleaded petrol or higher.
(**) For versions/markets where provided
(***) Version for specific markets
208
