GETTING TO KNOW YOUR CAR
90
To engage the reverse gear (R) from
the neutral position:
– lift the sliding ring A-fig. 111-112
under the knob and move the lever on
the left and then forward.Press the clutch pedal
fully when changing gear.
The floor under the ped-
al must therefore be clear and
any floor mats must lie flat and
not get in the way of the pedals.ELECTRONIC
AUTOMATIC
TRANSMISSION
It has four gears and a reverse which
adapt to the driver’s driving style ac-
cording to the road conditions and the
vehicle load.
IMPORTANTTo use the auto-
matic electronic gear (and the relative
Shift-lock safety device) in the correct
way, read carefully the following in-
structions.
fig. 111
F0B0075b
fig. 112
F0B0302b

GETTING TO KNOW YOUR CAR
133
INSTALLATION OF
ELECTRIC/ ELECTRONIC
DEVICES
Electric/electronic devices installed
after buying the vehicle or in after-
market shall bear the and marking:
Fiat Auto S.p.A. authorizes the in-
stallation of transceivers provided that
installation is carried out at a special-
ized shop, workmanlike performed
and in compliance with manufacturer's
specifications.IMPORTANT Installation of devices
resulting in modifications of vehicle
characteristics may cause driving li-
cense seizing by traffic agents and al-
so the lapse of the warranty as con-
cerns defects due to the abovemen-
tioned modification or traceable back
to it directly or indirectly.
Fiat Auto S.p.A. declines all respon-
sibility for damages caused by the in-
stallation of non-genuine accessories
or not recommended by Fiat Auto
S.p.A. and installed not in compliance
with the specified requirements.RADIO TRANSMITTERS AND
CELLULAR TELEPHONES
Radio transceiver equipment (e.g.: e-
tacs mobile phones, HAM radio sys-
tems and the like) shall not be used in-
side the vehicle unless a separate aer-
ial is mounted on the roof.
IMPORTANT The use of similar de-
vices inside the passenger compart-
ment (without separated aerial) pro-
duces radio-frequency electromag-
netic fields which, amplified by the res-
onance effects inside the passenger
compartment, may cause electrical
systems equipping the vehicle to mal-
function. This could compromise safe-
ty in addition to constituting a poten-
tial hazard for the passengers.
In addition, transmission and recep-
tion of these devices may be affected
by the shielding effect of the vehicle
body.
As concerns EC-approved mobile
phones (GSM, GPRS, UMTS), strictly
comply with the instructions for use
provided by the mobile phone’s man-
ufacturer.

CAR MAINTENANCE
188
Should prevailing use of the vehicle
be under one of the following special-
ly heavy conditions:
– trailer or caravan towing;
– dusty roads;
– short distances (less than 7-8 km)
repeated and with external tempera-
tures below zero;– frequently idling engines or long
distance low speed driving (e.g. door-
to-door deliveries) or in case of a long
term inactivity;
– driving in the city;
carry out the following checks more
frequently than required in the Service
Schedule:
– check front disk brake pad condi-
tions and wear;– check cleanness of locks, bonnet
and boot and lever cleanness and lu-
brication;
– sight inspect the conditions of: en-
gine, gearbox, transmission, pipes and
hoses (exhaust - fuel - brakes), rubber
parts (boots, sleeves, bushes, etc.);
– check battery charge and fluid lev-
el (electrolyte);
– visual check on various drive belt
conditions;
– check and replace pollen filter, if re-
quired;
– check and replace air cleaner, if re-
quired.
HEAVY-DUTY

TECHNICAL SPECIFICATIONS
220
FUEL SUPPLY
MULTIJET Common Rail direct in-
jection with overboost and intercool-
er.TRANSMISSION
CLUTCH
Hydraulically controlled.
MANUAL GEARBOX
Five forward gears and reverse with
synchromesh for front gear engage-
ment.
ELECTRONIC AUTOMATIC
GEARBOX
Two driving methods:
– sequence;
– automatic. Modifications or repairs
to the fuel feed system
that are not carried out
properly or do not take the sys-
tem’s technical specifications in-
to account can cause malfunc-
tions leading to the risk of fire.

INDEX
240
ABS system ................................. 116
- electronic braking force
distributor EBD ...................... 118
Accessories purchased
by the owner .............................. 132
Aerosol cans (warning) .............. 213
Air cleaner ........................... 190-198
Anchoring the load ..................... 110
Armrests ........................................ 33
Ashtray ........................................... 101
ASR system .................................... 121
Audio – video socket .................. 97
Autoclose (function) .................. 17
Automatic climate control
system ......................................... 68
- additional rear controls ........ 77
- failure indication ...................... 78
- front controls........................... 71
- general
instructions .............. 68-69-70-71
- sensors ...................................... 71
- settings....................................... 74
- switching on ............................. 74Automatic electronic transmission
display .......................................... 91
Automatic headlight sensor
(daylight sensor)
- control ...................................... 80
Battery
- advice ........................................ 203
- fluid level (electrolyte) .......... 201
- if the battery is flat.................. 178
- jump starting ............................ 153
- maintenance ............................ 201
- recharging ................................ 178
- replacing the battery ............. 201
Bodywork
- maintenance ............................ 210
- version code ........................... 218
Boot
- anchoring the load .................. 110
- luggage compartment light .... 104
- luggage cover ........................... 111
- luggage retaining net............... 100
- luggage transportation .......... 110
- opening/locking the tailgate
from the outside .................... 109- passenger/luggage separating
net............................................... 112
- tailgate emergency opening . 110
Bonnet ........................................... 112
Bottle/glass/can holder ................ 98
Brake and hydraulic clutch
fluid level ..................................... 198
Brake lights .................................... 166
- third brake light ....................... 168
Brakes
- fluid level .................................. 198
- technical specification ........... 221
Bulbs (replacement) ................... 159
- bulb list ..................................... 160
- front light cluster ................... 162
- general instructions ............... 159
- if an exterior bulb
burns out ................................. 162
- rear light cluster ..................... 166
- types of bulbs .......................... 160
Capacities .................................... 229
Car maintenance ......................... 184
- heavy-duty ............................... 188
- routine maintenance .............. 187
I I
N N
D D
E E
X X

INDEX
242
- switching the alarm
system off.................................. 16
- when the alarm is triggered.. 16
Electronic automatic
transmission ............................... 90
- display ....................................... 91
- driving in automatic mode .... 94
- driving in sequence mode ..... 94
- failure indication ..................... 95
- lever position ........................... 91
- moving the car ......................... 93
- selection lever.......................... 91
- sound warnings (buzzers) .... 96
- starting the engine ................. 93
- stopping the engine ................ 96
- technical specifications ......... 221
- towing the car ........................ 180
Electronic braking force
distributor EBD ......................... 118
Electronic control units
(warnings) ................................... 204
Engine
- engine marking ....................... 218
- identification code ................. 219
- technical specifications ......... 219
Engine compartment
(washing) ..................................... 212Engine coolant level .................... 194
Engine coolant temperature
gauge ............................................ 53
Engine oil
- checking the level .................. 193
Engine oil consumption ............. 193
Engine oil level .............................. 193
EOBD system .............................. 122
ESP system .................................... 119
- ASR function ........................... 121
- ESP action ................................. 121
- failure indication ...................... 121
- MSR function ........................... 122
- operation ................................. 120
- TC function ............................. 121
Exterior lights (controls) ........... 79
Fiat CODE system ..................... 11
- CODE card ............................. 14
Flashing
(main beam headlights) ............ 81
Follow me home .......................... 79
Front and side airbags ................ 124
- deactivating the passenger’s
front air bag manually............. 127
- general notes .......................... 128
- passenger’s front airbag ........ 125- side airbags
(side bag -window bag) ......... 127
Front ceiling light ........................ 102
- bulb replacement ................... 168
Front doors
- autoclose ................................... 19
- opening/closing ........................ 19
- super lock ................................. 22
Front fog lights
- bulb replacement .................... 165
- control ...................................... 81
Front seats .................................... 24
- adjustment ....................... 24-25
- armrests ................................... 33
- head restraints ........................ 32
- heating ...................................... 25
- interior settings .............. 31-32
- storing the driver’s
seat position ............................ 25
- swivel ......................................... 26
Fuel
- consumption ........................... 232
- fuel cut off switch.................... 87
- fuel filler cap ............................ 134
- fuel level gauge ....................... 53
Fuel consumption ........................ 232
Fuel cut off switch ....................... 87

INDEX
245
Safe driving ................................. 139
- before getting behind the
wheel ........................................ 140
- driving at night ........................ 142
- driving in the fog .................... 143
- driving in the mountains ....... 143
- driving in the rain ................... 142
- driving on snow and ice ....... 144
- driving with ABS ..................... 144
- when travelling ....................... 140
Seat belts
- general instructions ............... 40
- height adjustment.................... 37
- load limiting devices .............. 40
- maintenance ............................. 42
- pretensioners ........................... 39
- use .................................... 36-38-39
Side lights
- control ...................................... 79
- front bulb replacement .......... 165
Sliding doors
- opening/closing ........................ 20
Snow chains .................................. 150
Spectacles holder ......................... 98
Speedometer .............. 51-52-53
Starting the engine ...................... 136
- bump starting ................. 138-154- ignition switch ......................... 16
- jump starting ........................... 153
- stopping the engine ................ 138
- warming up the engine ......... 138
Steering
- technical specifications........... 222
Steering column lock .................. 18
Steering column stalks ............... 79
- left-hand stalk ......................... 79
- right-hand stalk ....................... 82
Steering wheel
-adjustment ................................ 34
Stopping the engine .................... 138
Storing the car ............................. 151
- restarting the car after
storage ....................................... 151
Sunroof (electric) ......................... 107
- opening/closing .............. 107-108
Sun curtains ................................... 100
Sun visors ...................................... 99
Suspensions
- specifications ........................... 221
Symbols ......................................... 6
TC system .................................... 121
Technical specifications ............. 214The signs to help you drive
correctly ...................................... 5
Tilting loading shelf ...................... 99
Toggles .......................................... 100
Tools .............................................. 156
Total and partial kilometre
counter ....................................... 54
Total and partial kilometre
counter display ........................... 54
Towing a trailer ........................... 148
Towing the car ............................ 180
Transmission
- technical specifications........... 221
Transporting children
in safety ....................................... 40
Transporting luggage ................... 110
- luggage cover ........................... 111
Trip computer .............................. 85
Tyre pressure .............................. 205
Tyres
- changing a wheel .................... 156
- general notes............................ 205
- maintenance ............................ 205
- snow chains .............................. 150
- tyre pressure............................ 225
- understanding tyre marking .. 223
- winter tyres ............................. 149
