FORD AEROSTAR 1996 1.G User Guide
Manufacturer: FORD, Model Year: 1996, Model line: AEROSTAR, Model: FORD AEROSTAR 1996 1.GPages: 353, PDF Size: 2.87 MB
Page 11 of 353
8
%*
[IN06900(ALL)04/95]
Cleaning the Outside of Your
Vehicle
%*
[IN06950(ALL)04/95]
Washing and Polishing Your Vehicle
*
[IN07300(ALL)04/95]
Wash the outside of your vehicle, including the
underside, with a mild detergent.
*
[IN07400(ALL)06/95]
DO NOT:
*
[IN07500(ALL)04/95]
q
Wash your vehicle with hot water
*
[IN07600(ALL)04/95]
q
Wash your vehicle while it sits in direct
sunlight
*
[IN07700(ALL)04/95]
q
Wash your vehicle while the body is hot
*
[IN07800(ALL)07/95]
Pollen, bird droppings and tree sap can damage
the paint, especially in hot weather. Wash your
vehicle as often as necessary to keep it clean.
*
[IN07900(ALL)07/95]
Take similar precautions if your vehicle is
exposed to chemical industrial fallout.
*
[IN07950(ALL)07/95]
Paint damage resulting from fallout is not
related to a defect in paint materials or
workmanship and therefore is not covered by
warranty. Ford, however, believes that continual
improvement in customer satisfaction is a high
priority. For this reason, Ford has authorized its
dealers to repair, at no charge to the owner, the
surfaces of new vehicles damaged by
environmental fallout within 12 months or 12,000
miles (20,000 km) of purchase, whichever comes
first. Customers may be required to bring their
vehicle in for inspection by a Ford
representative.
*
[IN08100(ALL)04/95]
Polish your vehicle to remove harmful deposits
and protect the finish.
File:02cpina.ex
Update:Tue Aug 29 17:33:02 1995
Page 12 of 353
9 %
*
[IN08200(ALL)04/95]
Cleaning Chrome and Aluminum Parts
*
[IN08300(ALL)04/95]
Wash chrome and aluminum parts with a mild
detergent. Do not use steel wool, abrasive
cleaners, fuel or strong detergents.
%*
[IN08400(ALL)04/95]
Cleaning Plastic Parts
*
[IN08500(ALL)04/95]
Some of your vehicle's exterior trim parts are
plastic. Clean with a tar and road oil remover if
necessary. Use a vinyl cleaner for routine
cleaning.
*
[IN08600(ALL)04/95]
Do not clean plastic parts with thinners, solvents
or petroleum-based cleaners.
%*
[IN08700(ALL)04/95]
If you have your vehicle rustproofed, remove
oversprayed rustproofing with a tar and road oil
remover. If rustproofing is not removed from
plastic and rubber parts, it can cause
deterioration.
File:02cpina.ex
Update:Tue Aug 29 17:33:02 1995
Page 13 of 353
11
Safety Restraints
%*
[SR00501(ALL)04/95]
Important Safety Belt Information
*
[SR00600(ALL)03/95]
The use of safety belts helps to restrain you and
your passengers in case of a collision. In most
states and in Canada the law requires their use.
*
[SR00700(ALL)01/95]
Safety belts provide best restraint when:
*
[SR00800(ALL)01/95]
q
the seatback is upright
*
[SR00900(ALL)01/95]
q
the occupant is sitting upright (not slouched)
*
[SR01000(ALL)01/95]
q
the lap belt is snug and low on the hips
*
[SR01100(ALL)01/95]
q
the shoulder belt is snug against the chest
*
[SR01200(ALL)01/95]
q
the knees are straight forward
*
[SR01700(ALL)07/95]
To help you remember to fasten your safety belt,
a warning light may come on and a chime may
sound. SeeSafety Belt Warning Light and Chimein
theWarning Lights and Gaugeschapter.
*
[SR02100(ALL)07/95]
See the following sections in this chapter for
directions on how to properly use these safety
belts. Also seeSafety Restraints for Childrenin this
chapter for special instructions about using
safety belts for children.
%*
[SR02200(ALL)05/95]
RWARNING
Make sure that you and your passengers
wear safety belts. Always drive and ride
with your seatback upright and the lap
belt snug and low across the hips.
File:03cpsra.ex
Update:Tue Aug 29 17:35:04 1995
Page 14 of 353
12
*
[SR02501(ALL)06/95]
RWARNING
Never wear the shoulder belt under the
arm. Never swing it around the neck over
the inside shoulder. Never use a single
belt for more than one person or across
more than one seating position. Each
seating position in your vehicle has a
specific safety belt assembly which is
made up of one buckle and one tongue
that are designed to be used as a pair.
Failure to follow these precautions could
increase the risk and/or severity of injury
in a collision.
*
[SR02550(ALL)08/95]
RWARNING
To reduce the risk of serious injury in a
collision, children should always ride with
the seatback upright.
*
[SR02601(ALL)06/95]
RWARNING
Never drive or ride with a twisted or
jammed safety belt. If you cannot untwist
or unjam the safety belt, see the nearest
qualified technician immediately.
*
[SR02700(ALL)08/95]
RWARNING
Never let a passenger hold a child on his
or her lap while the vehicle is moving.
The passenger cannot protect the child
from injury in a collision.
*
[SR02900(ALL)08/95]
RWARNING
Lock the doors of your vehicle before
driving to lessen the risk of the door
coming open in a collision.
File:03cpsra.ex
Update:Tue Aug 29 17:35:04 1995
Page 15 of 353
13
%*
[SR03000(ALL)05/95]
Combination Lap and Shoulder
Belts
*
[SR03200(ALL)06/95]
While your vehicle is in motion, the combination
lap and shoulder belt adjusts to your movement.
However, if you brake hard, turn hard, or if
your vehicle receives an impact of 5 mph
(8 km/h) or more, thelap/shoulder belt locks
and helps reduce your forward movement.
*
[SR03400(ALL)05/95]
After you get into your vehicle, close the door
and lock it. Then adjust the seat to the position
that suits you best.
*
[SR03500(ALL)05/95]
Pull the combination lap/shoulder belt from the
retractor so that the shoulder portion of the belt
crosses your shoulder and chest. Be sure the belt
is not twisted. If it is, remove the twist. Insert
the belt tongue into the proper buckle until you
hear a snap and feel it latch. Make sure the
tongue is securely fastened to the buckle by
pulling on tongue.
*
[SR03600(ALL)06/95]
quarter page art:0010018-B
Fastening the front seat combination lap and shoulder belt
[SR03650(ALL)05/95]
NOTE: Be sure to read and understand
Important Safety Belt Informationat the beginning
of this chapter.
File:03cpsra.ex
Update:Tue Aug 29 17:35:04 1995
Page 16 of 353
14 [SR03800(ALL)06/95]
one third page art:0095046-AUnfastening the combination lap and shoulder belts Ð
front and rear outboard seating positions
*
[SR03900(ALL)07/95]
While the belt retracts, guide the tongue to its
original position to prevent it from striking you
or the vehicle.
*
[SR04000(ALL)05/95]
Safety Belts for Front Outboard Passenger
and Rear Outboard Seating Positions
*
[SR04210(ALL)05/95]
Your vehicle is equipped with a dual locking
mode retractor on theshoulderbelt portion of
the combination lap/shoulder safety belt for the
front seat outboard passenger and rear outboard
passengers.
*
[SR04220(ALL)05/95]
Dual locking mode retractors operate in two
ways:
*
[SR04230(ALL)06/95]
Vehicle sensitive (emergency) locking mode
*
[SR04240(ALL)05/95]
In this operating mode, the shoulder belt
retractor will allow the occupant freedom of
movement, locking tight only on hard braking,
hard cornering or impacts of approximately
5 mph (8 km/h) or more. The retractor can also
be made to lock by pulling on the belt.
File:03cpsra.ex
Update:Tue Aug 29 17:35:04 1995
Page 17 of 353
15 %
*
[SR04250(ALL)08/95]
Automatic locking mode
*
[SR04260(ALL)07/95]
In this operating mode, the shoulder belt
retractor will be automatically locked and will
remain locked when the combination
lap/shoulder safety belt is buckled, and does not
allow the occupant freedom of movement. This
mode provides the following:
*
[SR04270(ALL)07/95]
q
A tight lap/shoulder belt on the occupant.
*
[SR04280(ALL)07/95]
q
Child safety seat installation.
*
[SR04300(ALL)07/95]
This modemust be usedwhen installing a child
safety seat on the front passenger seat and rear
outboard seats where dual locking retractors are
provided.
*
[SR04310(ALL)07/95]
To switch the retractor from the emergency
locking mode to the automatic locking mode,
perform the following steps:
*
[SR04320(ALL)08/95]
1. Buckle the lap/shoulder combination belt.
*
[SR04330(ALL)08/95]
2. Grasp the shoulder portion of the belt and
pull downward until all of the belt is
extracted and, when allowed to retract, a
clicking sound is heard. At this time, the belt
retractor is in the automatic locking mode
(child restraint mode).
*
[SR04340(ALL)08/95]
3. A clicking sound will continue to be heard
as the belt is allowed to retract. This
indicates that the retractor is in the
automatic locking mode.
*
[SR04350(ALL)07/95]
NOTE: When the combination lap/shoulder
belt is unbuckled and allowed to
retract completely, the retractor will
switch to the vehicle sensitive
(emergency) locking mode. See the
detailed instructions underSafety Seats
for Childrenin this chapter.
File:03cpsra.ex
Update:Tue Aug 29 17:35:04 1995
Page 18 of 353
16 [SR04375(ALL)08/95]All Two Passenger Bench or Bedseat
*
[SR04400(ALL)12/91]
In addition to anchorages in the floor and roof
structures, some rear safety belts have a
detachable anchor mounted to the outboard side
of the rear seats. This should remain attached,
except when removing the rear seats.
*
[SR04500(ALL)11/93]
The second row passenger side outboard seating
position uses a hook above the sliding/cargo
door to stow the shoulder safety belt when
entering or exiting the vehicle or when it is not
being used.
*
[SR04525(ALL)11/93]
NOTE: When the belt is stowed using the
hook, DO NOT use the hanging belt as
an assist when entering the vehicle.
File:03cpsra.ex
Update:Tue Aug 29 17:35:04 1995
Page 19 of 353
17 [SR04550(ALL)08/95]
three fourths page art:0020880-C
Proper stowage of shoulder safety belt
[SR04800(ALL)06/95]
Disengaging rear seat safety belts for seat
removal
[SR04850(ALL)05/95]
In order to remove the rear seat, the safety belt
must be disengaged from the seat. To disengage
the safety belt from the seat, insert a key or
small screwdriver into the slot provided on the
detachable anchor. Then lift upward.
File:03cpsra.ex
Update:Tue Aug 29 17:35:04 1995
Page 20 of 353
18 [SR05000(ALL)06/95]
three fourths page art:0095047-ADisengaging safety belt for rear seat removal
File:03cpsra.ex
Update:Tue Aug 29 17:35:04 1995
