FORD BRONCO 1988 Owners Manual

252manual is available from Ford Motor Company
for all authorized tow truck operators. Have
your tow truck driver refer to this manual for
the proper hook-up and towing procedures for
your vehicle.
*
[RE26300(B F )06/94]
Towing Four-Wheel Drive Vehicles With a
Lever-Operated Transfer Case
*
[RE26400(B F )06/94]
q
Place transmission gearshift (automatic or
manual) in N (Neutral).
*
[RE26425(B F )06/94]
q
Lock steering wheel straight ahead if vehicle
is to be towed with rear wheels off the
ground.
*
[RE26450(B F )12/89]
q
Set manual locking hubs in FREE position or
disengage the automatic locking hubs by
shifting the transfer case to 2H and drive the
vehicle in the opposite direction for a
minimum of 10 feet (3 meters) in a straight
line.
*
[RE26475(B F )06/94]
NOTE: Confirm by observation that the front
driveshaft is not rotating prior to
towing with the rear wheels off the
ground.
*
[RE26500(B F )06/94]
q
Place transfer case in N (Neutral).
*
[RE26615(B F )03/91]
NOTE: The transfer case neutral setting is
located between 4H and 4L. In order to
place the transfer case in neutral, first
place the lever in the 4H position, then
push down (toward the ground) on the
shift knob and at the same time pull
slightly rearward until the lever is
between the 4H and 4L position. With
the ignition in the on position, both
4x4 and LOW RANGE indicator lights
will be off when the transfer case is in
neutral. These lights will also be off
when the transfer case is in the 2H
position.
File:ltreb.ex
Update:Fri Jun 9 15:25:48 1995
ProCarManuals.com

253
*
[RE26650(B F )06/94]
There are no wrecker or recreational vehicle
towing restrictions on method or distance if the
above preparations are made.
*
[RE26700(B F )06/94]
q
Vehicle speed should not exceed 55 mph
(88 km/h). This applies with the front wheels
off the ground, the rear wheels off the
ground, or both front and rear wheels on the
ground.
*
[RE26800(B F )06/94]
Towing Four-Wheel Drive Vehicles With
Touch Drive Electric Shift Transfer Case
*
[RE26900(B F )06/94]
q
Place transmission gearshift (automatic or
manual) in N (Neutral).
*
[RE27000(B F )05/90]
q
Place transfer case in 2H.
*
[RE27050(B F )05/90]
NOTE: Both the4 x 4 and LOW RANGE
indicator lights in the instrument panel
will be off when the transfer case is in
2H.
*
[RE27200(B F )06/94]
q
Lock steering wheel straight ahead if vehicle
is to be towed with rear wheels off the
ground.
*
[RE27301(B F )06/94]
q
When towing your vehicle with the rear
wheels off the ground, the front axle
automatic locking hubs must first be
disengaged by shifting the transfer case to 2H
and moving the vehicle forward for a
minimum of 10 feet (3 meters) in a straight
line. Do not exceed a vehicle speed of
55 mph (88 km/h) while towing.
*
[RE27350(B F )06/94]
NOTE: Confirm by observation that the front
driveshaft is not rotating prior to
towing with the rear wheels off the
ground.
File:ltreb.ex
Update:Fri Jun 9 15:25:48 1995
ProCarManuals.com

254
*
[RE27400(B F )11/92]
q
When towing your vehicle with the rear
wheels on the ground or all four wheels on
the ground and the driveshafts connected, do
not exceed 35 mph (56 km/h) or
transmission damage could result. If a
distance of 50 miles (80 km) is exceeded,
disengage the automatic locking hubs and
disconnect the rear driveshaft from the axle
and secure. (Max speed 55 mph [88 km/h]
with driveshafts disconnected.)
*
[RE27500(BEF )03/91]
RWARNING
Never use a tow bar that attaches to the
bumper when you tow your vehicle. This
could damage the bumper and cause an
accident.
File:ltreb.ex
Update:Fri Jun 9 15:25:48 1995
ProCarManuals.com

255
Customer Assistance
%*
[HS00205( ALL)06/94]
Roadside Assistance
*
[HS00210( ALL)05/95]
Ford Motor Company has set up a 24-hour,
seven-day-a-week hotline with trained operators
that put you in touch with the help you need if
you experience a problem with your vehicle.
This complimentary service is provided to you
throughout your warranty period of 3 years or
36,000 miles (3 years or 60,000 km), whichever
comes first. To purchase Roadside Assistance
coverages beyond this period, through Ford
Auto Club, contact your Ford or
Lincoln-Mercury dealer (not available in
Canada).
*
[HS00215( ALL)06/94]
Roadside Assistance will cover the following:
*
[HS00220( ALL)06/94]
q
Mount your spare if you have a flat tire.
*
[HS00225( ALL)06/94]
q
Jump-start your battery if it is dead.
*
[HS00230( ALL)06/94]
q
Unlock your vehicle if you are locked out.
*
[HS00235( ALL)06/94]
q
Bring you fuel if you run out.
*
[HS00240( ALL)06/94]
q
Tow your vehicle if you are stranded. Even
non-warranty related tows, like accidents or
getting stuck in mud or snow, are covered
(some exclusions apply, such as impound
towing and repossession).
File:lthsb.ex
Update:Fri Jun 9 15:25:09 1995
ProCarManuals.com

256
*
[HS00245( ALL)06/94]
How to use Roadside Assistance
*
[HS00250( ALL)06/94]
Your Roadside Assistance identification card can
be found in the Owner Guide portfolio in your
glove compartment. Complete the card and place
it in your wallet for quick reference.
*
[HS00255( ALL)04/95]
To receive roadside assistance in the United
States call 1-800-241-FORD (in Canada call
1-800-665-2006).
*
[HS00260( ALL)04/95]
Should you need to arrange for roadside
assistance yourself, Ford Motor Company will
reimburse the reasonable cost. To obtain
information about reimbursement call
1-800-241-FORD (in Canada call 1-800-665-2006).
*
[HS00300( ALL)01/95]
If You Have a Service Problem
*
[HS00400( ALL)01/95]
Ford Motor Company has authorized Ford and
Lincoln-Mercury dealerships that can service
your vehicle for you. This chapter tells you how
to get service or maintenance for your vehicle.
%*
[HS00525( ALL)03/95]
Service/Maintenance Concerns (U.S. or
Canada)
*
[HS00600(BEF )04/95]
Ford recommends taking your vehicle to your
selling dealer who wants to ensure your
continued satisfaction. You may, however, take
your vehicle to any authorized Ford or
Lincoln-Mercury dealer. In most cases, your
dealer will be able to resolve your concern.
*
[HS00700( ALL)03/95]
If you are not satisfied with the service you
received from your dealership's service
department, talk to the service manager at the
dealership. If you still are not satisfied, talk to
the owner or general manager of the dealership.
In most cases, you will have your concern
resolved at this level.
File:lthsb.ex
Update:Fri Jun 9 15:25:09 1995
ProCarManuals.com

257
*
[HS01000( ALL)03/95]
If you are away from home when your vehicle
needs to be serviced, or if you need more help
than the dealer gave you, contact the Ford
Customer Assistance Center to find an
authorized dealership that may be able to help.
*
[HS01010( ALL)04/95]
In the U.S., contact:
%*
[HS01025( ALL)03/95]
one inch art:0060100-E
*
[HS01050( ALL)03/95]
If you live in Canada and have any questions or
concerns that the dealership cannot answer,
contact the Customer Assistance Centre.
%*
[HS01075( ALL)04/95]
one inch art:0060101-C
*
[HS01200( ALL)04/95]
Please have the following information available
when contacting Ford Customer Assistance:
*
[HS01300( ALL)04/95]
q
your telephone number (both business and
home)
*
[HS01400( ALL)04/95]
q
the name of the dealer and the city where the
dealership is located
*
[HS01500( ALL)03/95]
q
the year and make of your vehicle
*
[HS01550( ALL)03/95]
q
the date purchased
*
[HS01600( ALL)03/95]
q
the current mileage on your vehicle
File:lthsb.ex
Update:Fri Jun 9 15:25:09 1995
ProCarManuals.com

258
*
[HS01700( ALL)03/95]
q
your Vehicle Identification Number (VIN)
(listed on your owner card)
*
[HS02200( ALL)03/95]
If you still have a service or product complaint,
you may wish to contact the Dispute Settlement
Board (U.S. only) or the Canadian Motor Vehicle
Arbitration Plan (CAMVAP) in Canada.
%
*
[HS02300( ALL)02/95]
The Dispute Settlement Board
(U.S. Only)
*
[HS02400( ALL)03/95]
The Dispute Settlement Board is a voluntary,
independent dispute-settlement program
available free to owners or lessees of qualifying
Ford Motor Company vehicles.
*
[HS02500( ALL)01/95]
The Dispute Settlement Board may not be
available in all states. Ford Motor Company
reserves the right to change eligibility
limitations, modify procedures and/or to
discontinue this process at any time without
notice and without incurring obligations.
*
[HS02600( ALL)01/95]
What Kind of Cases Does the Board
Review?
*
[HS02700( ALL)03/95]
The Board reviews all product performance and
service complaints on Ford, Mercury and Lincoln
Cars and Ford and Mercury Light Trucks under
warranty that have not been resolved by a
dealer or Ford Motor Company.
*
[HS02750( ALL)03/95]
The Board does not review issues involving:
*
[HS02800( ALL)01/95]
q
A non-Ford product
*
[HS02900( ALL)01/95]
q
A non-Ford dealership
*
[HS03100( ALL)01/95]
q
A vehicle sales transaction
*
[HS03200( ALL)01/95]
q
A request for reimbursement of consequential
expenses unless incidental to a service or
product complaint being reviewed
*
[HS03300( ALL)01/95]
q
Items not covered by your warranty
File:lthsb.ex
Update:Fri Jun 9 15:25:09 1995
ProCarManuals.com

259
*
[HS03400( ALL)01/95]
q
Alleged liability claims
*
[HS03450( ALL)01/95]
q
Property damage where such damage is
significant when compared to the economic
loss alleged under the warranty dispute
*
[HS03500( ALL)01/95]
q
Cases currently in litigation
*
[HS03600( ALL)01/95]
q
Vehicles not used primarily for personal,
family, or household purposes
*
[HS03650( ALL)01/95]
NOTE: Complaints involving vehicles on
which applicable express written new
vehicle warranties have expired at
receipt of your application are not
eligible. Eligibility may differ
according to state law. For example, see
the unique brochure for California
purchasers/lessees.
*
[HS03700( ALL)04/95]
How Does the Board Work?
*
[HS03800( ALL)04/95]
The Board has four members:
*
[HS03900( ALL)04/95]
q
three consumer representatives
*
[HS04000( ALL)04/95]
q
a Ford or Lincoln-Mercury dealer
*
[HS04200( ALL)04/95]
Consumer candidates for Board membership are
recruited and trained by an independent
consulting firm. Dealers are chosen because of
their business leadership qualities.
*
[HS04300( ALL)04/95]
If the involved vehicle is within 36 months and
36,000 miles of the date of delivery (warranty
start date), you have a right to make an oral
presentation before the Board by indicating your
choice on the application. Also, oral
presentations may be requested by the Board. A
decision is made by the Board by simple
majority vote.
*
[HS04350( ALL)04/95]
Board members review all the materials related
to each complaint and, based on the available
information, arrive at a fair and impartial
File:lthsb.ex
Update:Fri Jun 9 15:25:09 1995
ProCarManuals.com

260decision. Decisions are based on the written
statements and any oral presentations made by
each of the involved parties.
*
[HS04400( ALL)04/95]
Because the Board usually meets only once a
month, some cases will take longer than 30 days
to be reviewed. The Board will make every
effort to resolve each case within 40 days after it
receives the customer application form.
*
[HS04500( ALL)04/95]
After your case has been reviewed, the Board
will mail you its decision in writing. It will also
provide you with a form to indicate your
acceptance or rejection of an award decision. The
decisions of the Board are binding on the dealer
and Ford, but customers may have other options
available to them under state or federal law.
*
[HS04600( ALL)04/95]
The decisions of the Board, however, may be
introduced into evidence by any party in
subsequent legal proceedings that may be
initiated.
*
[HS04700( ALL)01/95]
How Do You Contact the Board?
*
[HS04800( ALL)04/95]
Write to the Board at the following address to
request a brochure/application. You will be sent
a brochure and a one-page customer application
form. The form should be completed and mailed
to the same address.
*
[HS04900( ALL)02/93]
one inch art:0060102-B
File:lthsb.ex
Update:Fri Jun 9 15:25:09 1995
ProCarManuals.com

261
*
[HS05100( ALL)04/95]
What is the Review Process?
*
[HS05200( ALL)04/95]
Your application will be reviewed and if it is
determined to be eligible, you will receive an
acknowledgment indicating the file number
assigned to your application and the local Board
address. At the same time, your dealer and Ford
Motor Company representative are asked to
submit statements.
*
[HS05300( ALL)04/95]
To review your case properly, the Board needs
the following information:
*
[HS05400( ALL)04/95]
q
legible copies of all documents and
maintenance or repair orders that relate to
the case
*
[HS05500( ALL)04/95]
q
the year, make, model, and vehicle
identification number
*
[HS05600( ALL)04/95]
q
the date you bought your vehicle
*
[HS05700( ALL)04/95]
q
the date of repair and the mileage at the time
of repair
*
[HS05800( ALL)04/95]
q
the current mileage
*
[HS05900( ALL)04/95]
q
the name of the dealer who sold you the
vehicle or who serviced your vehicle
*
[HS06000( ALL)04/95]
q
a brief description of your unresolved
complaint
*
[HS06100( ALL)05/95]
q
a brief summary of actions that were taken
with the dealer and Ford Motor Company
*
[HS06200( ALL)05/95]
q
the names (if known) of all people you
contacted at the dealership
*
[HS06300( ALL)04/95]
q
a description of the action you want done to
resolve your concern.
*
[HS06305( ALL)04/95]
Should your application NOT qualify for review,
an explanation will be mailed to you.
File:lthsb.ex
Update:Fri Jun 9 15:25:09 1995
ProCarManuals.com
