FORD CONTOUR 1997 2.G Manual Online

80
[CF28100(ALL)05/96]
When you use the remote entry UNLOCK, TRUNK or PANIC
controls, the illuminated entry system turns on the interior
lights for 12 seconds. You can turn these lights off by turning
the ignition to the ON position. The interior lights will not turn
off if you have turned them on manually or if a door is open.
[CF28200(ALL)12/95]
NOTE: The illuminated entry system will only work when
the dome light switch is in the ª12º position.
*
[CF28300(ALL)04/96]
Locking the doors
*
[CF28400(ALL)04/96]
To lock all the doors, press the LOCK control.
*
[CF28500(ALL)04/96]
If you would like a signal that the doors are being locked, press
the LOCK control again within five seconds. The doors will lock
again and the horn will beep.
%*
[CF28600(ALL)03/96]
Activating the remote personal alarm
[CF28700(ALL)05/96]
If you wish to activate the remote personal alarm, press the
PANIC control. This will honk the horn and flash the low beam
headlamps and tail lamps for approximately two minutes
forty-five seconds. You can turn it off by pressing the PANIC
control again on the same transmitter or by turning the ignition
key to the ON position.
%*
[CF28800(ALL)03/96]
Replacing the Batteries
*
[CF28900(ALL)01/96]
The remote entry transmitter is powered by two coin type
three-volt lithium 2016 batteries (included) that should last for
several years of normal use. If you notice a significant decrease
in operating range, the batteries should be replaced.
Replacement batteries can be purchased at most pharmacies,
watch stores or at your Ford or Lincoln-Mercury dealer.
File:05cdcfo.ex
Update:Fri Sep 13 08:48:17 1996

Controls and Features
81
*
[CF29000(ALL)01/96]
NOTE: The operating range of the remote entry system can
also be affected by weather conditions (such as very
cold temperatures) or structures around the vehicle
(buildings, other vehicles, radio towers, etc.). Typical
operating range will allow you to be up to 33 feet (10
meters) away from your vehicle.
[CF29100(ALL)12/95]
7-1/2 pica art:0001315-A
Replacing the batteries
*
[CF29200(ALL)01/96]
The transmitter can be snapped apart to replace the batteries by
twisting a thin coin between the two halves of the transmitter.
DO NOT TAKE THE FRONT PART OF THE TRANSMITTER
APART. When installing the new batteries, be sure to place the
positive (+) side down as marked. Snap the two halves back
together.
%*
[CF29300(ALL)02/96]
Replacement/additional transmitters
*
[CF29400(ALL)01/96]
In the event a transmitter is lost, return the remaining
transmitters to your dealer for reprogramming of your remote
entry system. This is necessary to prevent further unauthorized
use of the lost transmitter.
*
[CF29500(ALL)01/96]
Additional transmitters may be purchased from your dealer
(remote entry system will work with up to four transmitters).
Return your existing transmitters to your dealer so the remote
entry system can be reprogrammed with your new and existing
transmitters.
File:05cdcfo.ex
Update:Fri Sep 13 08:48:17 1996

82
*
[CF29600(ALL)01/96]
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC
RULES. OPERATION IS SUBJECT TO THE FOLLOWING
TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE
HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST
ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING
INTERFERENCE THAT MAY CAUSE UNDESIRED
OPERATION.
File:05cdcfo.ex
Update:Fri Sep 13 08:48:17 1996

83
Seating and Safety Restraints
%*
[SS00200(ALL)01/96]
Seats
%*
[SS00300(ALL)02/96]
Head Restraints
*
[SS00400(ALL)01/96]
If you use them properly, head restraints will help protect your
head and neck in a collision.
*
[SS00500(ALL)01/96]
A head restraint helps protect you best if you position it behind
your head and not behind your neck.
[SS00600(ALL)12/95]
If your vehicle has the four-way head restraint, you can adjust it
in four directions. You can raise it two (2) inches (50 mm) from
its normal position, or you can move it forward up to 60Ê until
you reach the desired position.
[SS00700(ALL)12/95]
10-1/2 pica
art:0001216-A
The four-way head restraint
File:06cdsso.ex
Update:Thu Sep 12 11:03:20 1996

84
%*
[SS00800(ALL)12/95]
Manual Seats
[SS00900(ALL)12/95]
10-1/2 pica
art:0001217-C
Manual seat adjustment
*
[SS01000(ALL)01/96]
RWARNING
Never adjust the driver's seat or seatback when the
vehicle is moving.
*
[SS01100(ALL)02/96]
RWARNING
Always drive and ride with your seatback upright and
the lap belt snug and low across the hips.
File:06cdsso.ex
Update:Thu Sep 12 11:03:20 1996

Seating and Safety Restraints
85
%*
[SS01600(ALL)12/95]
Power Seats (If equipped)
[SS01700(ALL)12/95]
If your vehicle has power seats, you can raise or lower the
whole front seat, move the seat forward or backward and tilt
the front or back of the seat up or down.
[SS01800(ALL)12/95]
13-1/2 pica
art:0001297-B
The seat base controls on the driver's seat
File:06cdsso.ex
Update:Thu Sep 12 11:03:20 1996

86
[SS01900(ALL)12/95]
To move the seat forward or back, slide the seat base control
button forward or back. To raise or lower the height of the seat
base, slide the button up or down. To raise or lower the front of
the seat base, slide the front of the button up or down. To raise
or lower the rear of the seat base, slide the back of the button
up or down.
[SS02000(O )12/95]
Power seatback (if equipped)
[SS02200(ALL)12/95]
13-1/2 pica art:0000462-E
The seatback controls on the driver's seat
[SS02300(ALL)12/95]
To tilt the seatback forward or back, slide the top part of the
top button forward or back. To inflate or deflate the lumbar
support pads, slide the bottom of the button forward or back.
[SS02400(ALL)12/95]
Folding Rear Seats (If equipped)
% [SS02500(ALL)12/95]
The release knobs for the split rear folding seatbacks are in the
trunk. Pull the knob to fold down the seat.
[SS02600(ALL)12/95]
To raise the rear seatback, push the seatback upward until it
locks in place. Make sure it is firmly latched by pushing
forward and back on it.
File:06cdsso.ex
Update:Thu Sep 12 11:03:20 1996

Seating and Safety Restraints
87
*
[SS02700(ALL)02/96]
RWARNING
Check to see that the seat and seatback are latched
securely in position. Keep floor area free of objects that
would prevent proper seat engagement. Never attempt to
adjust the seat while the vehicle is in motion.
[SS02800(ALL)12/95]
10-1/2 pica
art:0001248-B
Folding rear seatback release knob
[SS02810(ALL)01/96]
n
a small storage pocket on the outside of the front seat base
%*
[SS02900(ALL)02/96]
Important Safety Belt Information
*
[SS03000(ALL)02/96]
The use of safety belts helps to restrain you and your
passengers in case of a collision. In most states and in Canada
the law requires their use.
*
[SS03100(ALL)02/96]
Safety belts provide best restraint when:
*
[SS03200(ALL)02/96]
n
the seatback is upright
*
[SS03300(ALL)02/96]
n
the occupant is sitting upright (not slouched)
*
[SS03400(ALL)02/96]
n
the lap belt is snug and low on the hips
*
[SS03500(ALL)02/96]
n
the shoulder belt is snug against the chest
*
[SS03600(ALL)02/96]
n
the knees are straight forward
File:06cdsso.ex
Update:Thu Sep 12 11:03:20 1996

88
*
[SS03700(ALL)02/96]
To help you remember to fasten your safety belt, a warning
light may come on and a chime may sound. SeeSafety Belt
Warning Light and Chimein theInstrumentationchapter.
*
[SS03800(ALL)02/96]
See the following sections in this chapter for directions on how
to properly use these safety belts. Also seeSafety Restraints for
Childrenin this chapter for special instructions about using
safety belts for children.
*
[SS03900(ALL)02/96]
RWARNING
Always drive and ride with your seatback upright and
the lap belt snug and low across the hips.
*
[SS04000(ALL)02/96]
RWARNING
Each seating position in your vehicle has a specific safety
belt assembly which is made up of one buckle and one
tongue that are designed to be used as a pair. 1) Use the
shoulder belt on the outside shoulder only. Never wear
the shoulder belt under the arm. 2) Never swing it
around your neck over the inside shoulder. 3) Never use
a single belt for more than one person.
*
[SS04100(ALL)02/96]
RWARNING
Ford recommends that all safety belt assemblies and
attaching hardware should be inspected by a qualified
technician after any collision. Safety belt assemblies not
in use during a collision should also be inspected and
replaced if either damage or improper operation is noted.
*
[SS04200(ALL)02/96]
RWARNING
Children should always ride with the seatback in the
fully upright position.
File:06cdsso.ex
Update:Thu Sep 12 11:03:20 1996

Seating and Safety Restraints
89
*
[SS04300(ALL)02/96]
RWARNING
Never let a passenger hold a child on his or her lap
while the vehicle is moving. The passenger cannot
protect the child from injury in a collision.
*
[SS04400(ALL)02/96]
RWARNING
Lock the doors of your vehicle before driving to lessen
the risk of the door coming open in a collision.
%*
[SS04500(ALL)02/96]
Combination Lap and Shoulder Belts
*
[SS04600(ALL)02/96]
While your vehicle is in motion, the combination lap and
shoulder belt adjusts to your movement. However, if you brake
hard, turn hard, or if your vehicle receives an impact of 5 mph
(8 km/h) or more, the lap/shoulder belt locks and helps reduce
your forward movement.
*
[SS04700(ALL)01/96]
After you get into your vehicle, close the door and lock it. Then
adjust the seat to the position that suits you best.
*
[SS04800(ALL)02/96]
Pull the combination lap/shoulder belt from the retractor so
that the shoulder portion of the belt crosses your shoulder and
chest. Be sure the belt is not twisted. If it is, remove the twist.
Insert the belt tongue into the proper buckle until you hear a
snap and feel it latch. Make sure the tongue is securely fastened
to the buckle by pulling on tongue.
File:06cdsso.ex
Update:Thu Sep 12 11:03:20 1996
