jump start FORD CONTOUR 1998 2.G Owners Manual

Roadside emergencies
124JUMPSTARTING YOUR
VEHICLE
The gases around the
battery can explode if
exposed to flames, sparks, or lit
cigarettes. An explosion could
result in injury or vehicle damage.
Do not push start your
vehicle. You could damage
the catalytic converter. For
further information, see
Jumper
cablesin the index.
Batteries contain sulfuric
acid which burns skin, eyes,
and clothing.
CDW IVC1-6Roads en C 5/15/97 8:54 PM Page 124

Roadside emergencies
125 Connecting jumper cables
1. Position the vehicles so that they
do not touch one another.
2. Switch off the engine. Switch off
any unnecessary electrical
equipment.
3. Connect the positive (+)
terminal of the discharged battery
to the positive (+) terminal of the
booster battery (1).
4. Connect one end of the second
lead to the negative (–) terminal of
the booster battery and the other
end to a metal part of the engine to
be started (2).
5. Make sure that the jumper
cables are clear of moving parts of
the engine.
12
Do not connect the end of
the second cable to the
negative (-) terminal of the
battery to be jumped. A spark may
cause an explosion of the gases
that surround the battery.
CDW IVC1-6Roads en C 5/15/97 8:54 PM Page 125

Roadside emergencies
126Jump starting
1. Start the booster vehicle and run
the engine at moderately increased
speed.
2. Start the engine of the vehicle
with the discharged battery.
3. Once the engine has been
started, run both vehicles for an
additional three minutes before
disconnecting the cable leads.
Removing jumper cables
1. Remove the jumper cables in
reverse order. Take the cable off
the metallic surface first (1), then
the cable on the negative (-)
booster battery terminal (2).
2. Remove the cable from the
positive (+) terminal of the booster
battery (3) and then the
discharged battery (4).
3. After the disabled vehicle has
been started, allow it to idle for a
while so the engine can “relearn”
its idle conditions.
2
1
3
4
CDW IVC1-6Roads en C 5/15/97 8:54 PM Page 126

CPage
Child safety restraints
built-in child seat . . . . . . . . . . .68
child safety seats . . . . . . . . . . . .74
children and safety belts . . .64, 66
Child safety seats
and air bags . . . . . . . . . . . . . . . .59
attaching with tether straps . . .77
automatic locking mode . . . . . .52
Childproof safety locks . . . . . . . .38
Chimes . . . . . . . . . . . . . . . . . . . . .13
Circuit breakers . . . . . . . . . . . . .112
Cleaning your vehicle
engine compartment . . . . . . . .182
exterior lamps . . . . . . . . . . . . .183
fabric . . . . . . . . . . . . . . . . . . . .184
instrument panel . . . . . . . . . . .184
plastic exterior parts . . . . . . . .183
safety belts . . . . . . . . . . . . . . .185
wheels . . . . . . . . . . . . . . . . . . .181
wiper blades . . . . . . . . . . . . . .183
Climate control system
air conditioning . . . . . . . . . . . . .24
controlling airflow . . . . . . . . . . .23
defrosting . . . . . . . . . . . . . . . . . .26
temperature . . . . . . . . . . . . . . . .23
vents . . . . . . . . . . . . . . . . . . . . . .22
Clock . . . . . . . . . . . . . . . . . . . . . .21
Clutch
operation . . . . . . . . . . . . . . . . . .96
recommended shift speeds . . . .97
Cold engine starting . . . . . . . . . .85
Controls
instrument panel . . . . . . . . . . . .17
mirrors . . . . . . . . . . . . . . . . . . . .20
power seats . . . . . . . . . . . . . . . .48
steering column . . . . . . . . . . . . .27DPage
Daytime running lights . . . . . . . .18
Defects, reporting . . . . . . . . . . .192
Defrost
rear window . . . . . . . . . . . . . . . .19
windshield . . . . . . . . . . . . . . . . .26
Dipstick, engine oil . . . . . . . . . .133
Door mounted controls . . . . . . . .37
Driving under special conditions
heavy load . . . . . . . . . . . . . . . .102
towing a trailer . . . . . . . . . . . .103
E
Electrical system
fuses . . . . . . . . . . . . . . . . . . . . .112
Emergencies, roadside
fuel pump shut-off switch . . . .110
jump starting . . . . . . . . . . . . . .124
towing . . . . . . . . . . . . . . . . . . .127
Emergency brake (see Parking
brake)
Emission control system . . . . . .166
Engine
check engine warning light . . . . .9
fuel pump shut-off switch . . . .110
lubricant specifications . . . . . .188
preparing to start . . . . . . . . . . .82
refill capacities . . . . . . . . . . . .187
starting . . . . . . . . . . . . . . . . . . . .85
Engine block heater . . . . . . . . . .86
Engine coolant
checking and adding . . . . . . . .139
disposal . . . . . . . . . . . . . . . . . .141
low coolant warning light . . . . . .8
refilll capacities . . . . . . . . . . . .187
specifications . . . . . . . . . . . . . .188
Engine fan . . . . . . . . . . . . . . . . .129
Index
194
CDW_Index_en_C 5/15/97 8:59 PM Page 194

HPage
High-mount brakelamp . . . . . . .174
Hood
latch location . . . . . . . . . . . . . .132
release lever . . . . . . . . . . . . . .132
Horn . . . . . . . . . . . . . . . . . . . . . . .29
I
Identification Number, Vehicle
(VIN) . . . . . . . . . . . . . . . . . . . . .191
Idle, relearning . . . . . . . . . . . . .149
Idle, speed . . . . . . . . . . . . .149, 189
Ignition
chime . . . . . . . . . . . . . . . . . . . . .13
positions on the ignition . . . . . .27
Instrument cluster . . . . . . . . . . . . .6
Instrument panel
cleaning . . . . . . . . . . . . . . . . . .184
lighting up the panel . . . . . . . . .19
Integrated child seat (see Built-in
child seat)
Intermittent wipers . . . . . . . . . . .31
Introduction . . . . . . . . . . . . . . . . . .2
J
Jack
positioning . . . . . . . . . . . . . . . .122
storage . . . . . . . . . . . . . . . . . . .121
Jump starting your vehicle
attaching cables . . . . . . . . . . . .125
disconnecting cables . . . . . . . .126
K
Keys
key in ignition warning chime .13
positions of the ignition . . . . . .27
Index
196LPage
Lamps
bulb replacement specification
chart . . . . . . . . . . . . . . . . . . . . .175
daytime running light system . .18
flashing the lamps . . . . . . . . . . .30
foglamps . . . . . . . . . . . . . .18, 172
hazard flashers . . . . . . . . .29, 110
headlamps . . . . . . . . . . . . . . . . .17
high beams . . . . . . . . . . . . . . . . .30
high-mounted brake lamp . . . .174
instrument panel, dimming . . .19
interior lamps . . . . . . . . . . . . . .36
reading lamps . . . . . . . . . . . . . .36
replacing bulbs . . . . . . . . . . . .170
rear lamps . . . . . . . . . . . . . . . .173
Lights, warning and indicator
air bag . . . . . . . . . . . . . . . . . . . .10
anti-lock brakes (ABS) . . . . . . .11
brake . . . . . . . . . . . . . . . . . . . . .11
charging system . . . . . . . . . . . . .7
check engine . . . . . . . . . . . . . . . .9
engine oil pressure . . . . . . . . . .11
high beam . . . . . . . . . . . . . . . . . .7
low coolant . . . . . . . . . . . . . . . . .8
low fuel . . . . . . . . . . . . . . . . . . . .9
overdrive off . . . . . . . . . . . . . . . .9
safety belt . . . . . . . . . . . . . . . . . .7
testing the warning lights . . . . .12
turn signal indicator . . . . . . . . . .6
Load limits . . . . . . . . . . . . . . . . .100
Lubricant specifications . . . . . .188
Luggage compartment . . . . . . . .39
CDW_Index_en_C 5/15/97 8:59 PM Page 196
