Instrumentation
Page 57
Turn signal/high beam
Page 8
Instrument clusterPage 56
Hazard flasher
control
Page 58
Windshield
wiper/washer
control
Page 166
Hood release
Page 22, 23
Headlamp control/
Foglamp control*Page 55
Tilt steering
wheel leverPage 54
Ignition switch
Page 59
Speed control*
Page 56
Horn Page 24
Traction control*
Page 25
Power Mirrors*
Page 24
Rear window
defroster control*
TRACTION
CONTROLCHECK
ENGINEO/D
OFF
Res
Set
Acc
CoastOff
On
EF

000123
000010 20 3040506070
80
90
10 0
110
120
13 0MPH
20 406055
80120 10 0
14 0
160
18 0
20012
03
x 1000
4
5
6
7
8
MIRRORS
BRAKE
CH
6
12CInen 17.6.99 10:41 Uhr Seite 6

Instrumentation
8Turn signal
Flashes when the left or right turn
signal or hazard lights are
activated. There are two different instrument
cluster designs. The individual
warning and indicator lights are
described on the following pages.
000123
000010 20 3040506070
80
90
110
120
13 0
MPH
20 4060
55
80120 10 0
14 0
160
18 0
20010 0
EF
BRAKE
CHECK
ENGINEO/D
OFFTRACTION
CONTROL
CH
000123
000010 20 3040506070
80
90
110
120
13 0
MPH
20 4060
55
80120 10 0
14 0
160
18 0
20010 0
EF12
03
x 1000
4
5
6
7
8
O/D
OFFCHECK
ENGINE
BRAKE
TRACTION
CONTROL
CH
INSTRUMENT CLUSTER
LIGHTS AND CHIMES
Alternative design
12CInen 17.6.99 10:41 Uhr Seite 8

Instrumentation
10Traction control system light
(if equipped)
This light comes on when the
traction control system has been
disengaged. It may flash on and off
while driving to indicate the system
is operating.
000123
000010 20 3040506070
80
90
110
120
13 0
MPH
20 4060
55
80120 10 0
14 0
160
18 0
20010 0
EF
000123
000010 20 3040506070
80
90
110
120
13 0
MPH
20 4060
55
80120 10 0
14 0
160
18 0
20010 0
EF12
03
x 1000
4
5
6
7
8
O/D
OFFCHECK
ENGINE
BRAKE
TRACTION
CONTROL
CH
O/D
OFFTRACTION
CONTROL
12CInen 17.6.99 10:41 Uhr Seite 10

Instrumentation
11 O/D Off indicator
(Automatic transaxle only)
Illuminates and remains
illuminated when the transaxle
control switch (TCS) on the side of
the gearshift lever is pressed and
overdrive is turned off. For details,
refer to the Driving chapter.
Indicates the status of the
transaxle and will flash steadily if a
malfunction is detected. If the
flashing persists, have your
transaxle serviced by your dealer
or a qualified service technician as
soon as possible.
If the condition persists, your
transaxle may be damaged.
O/D
OFFTRACTION
CONTROL
O/D
OFFTRACTION
CONTROL
If the light stays on for more than
three (3) seconds after the
ignition is turned to the ON
position or stays on continuously
while you are driving, have the
traction control system checked
by a qualified technician as soon
as possible.
For more information, refer to
Traction Controlin the Driving
chapter.
Low coolant (if equipped)
Briefly illuminates when the
ignition is turned on and the engine
is off. Illuminates when the engine
coolant level is low. Refer to the
Maintenance and care chapter to
check the engine coolant level.
12CInen 17.6.99 10:41 Uhr Seite 11

Instrumentation
12Check engine
Your vehicle is equipped with a
computer that monitors the
engine’s emission control system.
This system is commonly known
as the On Board Diagnostics (OBD
II) system. This OBD II system
protects the environment by
ensuring that your vehicle
continues to meet government
emission standards. The OBD II
system also assists the service
technician in properly servicing
your vehicle.
CHECK
ENGINE
000123
000010 20 3040506070
80
90
110
120
13 0
MPH
20 4060
55
80120 10 0
14 0
160
18 0
20010 0
EF
BRAKE
O/D
OFFCHECK
ENGINETRACTION
CONTROL
CH
000123
000010 20 3040506070
80
90
110
120
13 0
MPH
20 4060
55
80120 10 0
14 0
160
18 0
20010 0
EF12
03
x 1000
4
5
6
7
8
TRACTION
CONTROLO/D
OFFCHECK
ENGINE
BRAKE
TRACTION
CONTROL
CH
12CInen 17.6.99 10:41 Uhr Seite 12

Instrumentation
13 The check engine indicator light
illuminates when the ignition is first
turned to the ON position to check
the bulb. If it comes on after the
engine is started, one of the
engine’s emission control systems
may be malfunctioning. The light
may illuminate without a
driveability concern being noted.
The vehicle will usually be drivable
and will not require towing.
What you should do if the check
engine light illuminates
Light turns on solid:
This means that the OBD II system
has detected a malfunction.
Temporary malfunctions may cause
your check engine light to
illuminate. Examples are:
• The vehicle has run out of fuel.
(The engine may misfire or run
poorly)
• Poor fuel quality or water in the
fuel.
• The fuel cap may not have been
securely tightened.
12CInen 17.6.99 10:41 Uhr Seite 13

Instrumentation
14These temporary malfunctions can
be corrected by filling the fuel tank
with good quality fuel and/or
properly tightening the fuel cap.
After three drive cycles without
these or any other temporary
malfunctions present, the check
engine light should turn off. (A
driving cycle consists of a cold
engine startup followed by mixed
city/highway driving.) No
additional vehicle service is
required.
If the check enginelight remains
on, have your vehicle serviced at
the first available opportunity.
Light is blinking:
Engine misfire is occuring which
could damage your catalytic
converter. You should drive in a
moderate fashion (avoid heavy
acceleration and deceleration) and
have your vehicle serviced at the
first available opportunity.
Under engine misfire
conditions, excessive
exhaust temperatures could
damage the catalytic converter,
the fuel system, interior floor
coverings or other vehicle com-
ponents, possibly causing a fire.
12CInen 17.6.99 10:41 Uhr Seite 14

Instrumentation
15
CHECK
ENGINEAir bag readiness
Briefly illuminates when the
ignition is turned on. If the light
fails to illuminate, continues to
flash, or remains on, have the
system serviced immediately. Low fuel reminder
Illuminates as an early reminder of
a low fuel condition indicated on
the fuel gauge (refer to Fuel
Gauge in this chapter for more
information). When refueling the
vehicle after the light first comes
on, the amount of fuel that can be
added will be less than the
advertised capacity since there is
still fuel in the tank. The ignition
must be in the ON position for this
lamp to illuminate. The lamp will
also illuminate for several seconds
immediately after the ignition is
turned to the ON position
regardless of the fuel level for bulb
verification.
CHECK
ENGINE
CHECK
ENGINEFront foglamps (if equipped)
Illuminates when foglamps are
switched on.
Refer to Foglamp controlin the
Controls and features chapter for
notes on use.
12CInen 17.6.99 10:41 Uhr Seite 15

Instrumentation
16Brake system warning
Extinguishes when the parking
brake is released. Illuminates after
releasing the parking brake to
indicate low brake fluid level.
Illumination while driving may
indicate that one of the braking
circuits has failed. The second
braking circuit will remain intact.
However, you will need to brake
harder and allow for increased
stopping distances.
BRAKE
BRAKE
Alternative design
EF
BRAKE
O/D
OFF
000123
000010 20 3040506070
80
90
110
120
13 0
MPH
20 4060
55
80120 10 0
14 0
160
18 0
20010 0
CHECK
ENGINETRACTION
CONTROL
CH
000123
000010 20 3040506070
80
90
110
120
13 0
MPH
20 4060
55
80120 10 0
14 0
160
18 0
20010 0
EF12
03
x 1000
4
5
6
7
8
O/D
OFFCHECK
ENGINE
BRAKE
TRACTION
CONTROL
CH
12CInen 17.6.99 10:41 Uhr Seite 16

Instrumentation
17 Anti-lock brake system (ABS)
(if equipped)
Momentarily illuminates when the
ignition is turned on and the engine
is off. If the light stays on or
continues to flash, the ABS needs
to be serviced.
BRAKE
BRAKE
Alternative design
Brake system and ABS warning
lights
If both warning lights illuminate at
the same time while driving, stop
the vehicleas soon as it is safe to
do so. Have the braking system
checked by your dealer or qualified
service technician before
continuing your journey.
When stopping the vehicle, slowly
reduce the speed. Use the brakes
with great care. Have the system checked by your
dealer or qualified technician
before continuing your journey.
BRAKE
BRAKE
Alternative design
