FORD CROWN VICTORIA 1996 1.G Owners Manual

175 % [DR01050( GV)03/95]
half page art:0010213-F
The positions of the gearshift
*
[DR01500( ALL)11/94]
Once the gearshift is secure in the desired
position, release the brake pedal and use the
accelerator as necessary.
%*
[DR01700( ALL)01/95]
R (Reverse)
*
[DR01800( ALL)02/95]
With the gearshift in the R (Reverse) position,
the vehicle will move backward. You should
always come to a complete stop before shifting
into or out of R (Reverse).
*
[DR01830( ALL)01/95]
N (Neutral)
[DR01860( ALL)05/94]
In N (Neutral), the wheels of the transmission
are not locked. Your vehicle will roll freely, even
on the slightest incline, unless the parking brake
or brakes are on.
File:rcdrv.ex
Update:Wed Jan 31 10:36:47 1996

176 %
*
[DR01900( ALL)01/95]
Driving
*
[DR01930( GV)01/95]
Your vehicle's gearshift is on the steering
column. The Transmission Control Switch (TCS)
is located on the end of the gearshift lever. The
Transmission Control Indicator Light (O/D OFF)
is located on the instrument panel. You can put
the gearshift lever in any of the several
positions.
*
[DR01950( GV)01/95]
The O/D OFF light is off (not illuminated)
during normal vehicle operation. This allows the
transmission to upshift and downshift from 1st
through 4th gears. When the TCS is pressed, the
Transmission Control Indicator Light will
illuminate (O/D OFF) on the instrument panel.
When this O/D OFF is illuminated the
transmission will upshift and downshift from 1st
through 3rd gears.
[DR01957( ALL)11/94]
If the O/D OFF light does not come ªonº when
the TCS is depressed or if the light ªFLASHESº
when you are driving, have your vehicle
serviced at the first opportunity. If this condition
persists, damage could occur to the transmission.
*
[DR01961( BCGV)01/95]
To return the transmission to normal operation
(1st through 4th gear) depress the TCS again.
This switch may be used to cancel overdrive any
time the vehicle is being driven. Each time your
vehicle is started, the overdrive system will
automatically be in the normal overdrive mode
and the light will not be illuminated.
File:rcdrv.ex
Update:Wed Jan 31 10:36:47 1996

177 %
*
[DR02000( GV)04/95]
When to usej(Overdrive)
*
[DR02100( ALL)01/95]
Overdrive is the usual driving position for an
automatic overdrive transmission. It works the
same way Drive works, automatically upshifting
or downshifting as the vehicle speeds or slows.
*
[DR02200( ALL)01/95]
However, Overdrive also shifts into a fourth
gear Ð an overdrive gear Ð when your vehicle
cruises at an appropriate consistent speed for
any length of time. This fourth gear will increase
your fuel economy when you travel at cruising
speeds.
[DR02520( GV)05/95]
When to usej(Overdrive) Ð with
Transmission Control Switch activated
(TCS)
[DR02603( GV)01/94]
Overdrive may not be appropriate for certain
terrain. If the transmission shifts back and forth
between Third and Fourth gears while you are
driving on hilly roads or if your vehicle does
not have adequate power for climbing hills,
press the TCS located on the shift lever.
*
[DR02605( BCGV)01/95]
You can depress the TCS at any speed.
*
[DR02610( ALL)01/95]
When to use 2 (Second)
*
[DR02620( ALL)01/95]
Use 2 (Second) for start-up on slippery roads or
to give you more engine braking to slow your
vehicle on downgrades.
*
[DR02700( ALL)01/95]
When to use 1 (Low)
*
[DR02800( ALL)03/95]
Use 1 (Low) when driving down steep grades. It
gives more engine braking to slow your vehicle
than 2 (Second) on the downgrades. You can
upshift from 1 (Low) to 2 (Second) or from
1 (Low) to Overdrive at any speed.
File:rcdrv.ex
Update:Wed Jan 31 10:36:47 1996

178
*
[DR03000( ALL)01/95]
P (Park)
*
[DR03100( ALL)01/95]
Always come to a complete stop before you shift
into P (Park). Make sure that the gearshift is
securely latched in P (Park). This locks the
transmission and prevents the rear wheels from
rotating.
*
[DR03200( ALL)05/95]
RWARNING
Always set the parking brake fully and
make sure that the gearshift is securely
latched in P (Park).
*
[DR03225( ALL)05/95]
RWARNING
Never leave your vehicle unattended
while it is running.
*
[DR03300( GV)01/95]
You can tell a column-mounted gearshift is
securely latched in P (Park) if the lever is
adjacent to the P (Park) and you cannot move it
without pulling it toward you and rotating it
downward.
% [DR09720( ALL)03/95]Traction-Lok Axle (If equipped)
[DR09730( ALL)12/91]
This axle provides added traction on slippery
surfaces, particularly when one wheel is on a
poor traction surface. Under normal conditions
the Traction-Lok axle functions as a standard
rear axle.
*
[DR09740( ALL)03/93]
Extended use of other than matching size tires
on a Traction-Lok rear axle could result in a
permanent reduction in effectiveness. This loss of
effectiveness does not affect normal driving and
should not be noticeable to the driver.
File:rcdrv.ex
Update:Wed Jan 31 10:36:47 1996

179
*
[DR09750( ALL)05/95]
RWARNING
To avoid injury, never run the engine
with one wheel off the ground, such as
when changing a tire.
%
*
[DR09760( BCGV)03/95]
Traction Assist
TM
(If equipped)
*
[DR09770( BCGV)01/95]
Your vehicle may be equipped with the optional
Traction Assist
TM
system. This system helps
prevent wheel spin in order to improve tire
traction and is an especially useful feature when
you drive in hilly areas or on slippery, icy or
snowy roads.
*
[DR09780( BCGV)03/95]
Traction Assist
TM
works automatically by rapidly
applying and releasing the brakes to prevent one
or both of the rear drive wheels from spinning
during acceleration.
[DR09785( BCGV)03/95]
During the Traction Assist
TM
function, which
most often occurs during low speed acceleration
on slippery surfaces, a noise may be heard
coming from the engine compartment. This noise
is created by the ABS pump and is normal and
may last for a few seconds during the
acceleration of the vehicle.
*
[DR09790( BCGV)03/95]
In general, this system improves your vehicle's
stability and acceleration performance when road
conditions warrant. Traction Assist is fully
effective up to approximately 25 mph
(40 km/h). At 25 mph (40 km/h) the function
begins to taper off until it no longer operates
above 34 mph (55 km/h).
[DR09793( BCGV)01/95]
If the Traction Assist
TM
system is cycled
excessively, the system will shut down to
prevent the rear brakes from overheating.
During this shutdown period, the word OFF in
the traction assist switch will be illuminated
showing that the traction assist system is
File:rcdrv.ex
Update:Wed Jan 31 10:36:47 1996

180inoperative. A cooling down period is required
to prevent damage to the rear brakes. This time
period varies and depends on brake usage
during the cooling down period. Anti-Lock
braking is not affected and will function
normally during the cool down period.
[DR09795( BCGV)05/95]
NOTE: Traction-Lok axles are not an available
option on vehicles equipped with
traction assist.
*
[DR09800( ALL)01/95]
Steering Your Vehicle
%*
[DR09900( ALL)01/95]
Your vehicle comes with power steering. Power
steering uses energy from the engine to help
steer your vehicle.
%*
[DR09950( ALL)04/95]
If the amount of effort needed to steer your
vehicle changes at a constant vehicle speed, have
the power steering system checked. If the power
steering system breaks down (or if the engine is
turned off), you can steer the vehicle manually
but it takes more effort.
*
[DR10000( ALL)01/95]
Never hold the steering wheel to the extreme
right or left for more than five seconds if the
engine is running. This can damage the power
steering pump.
[DR10200( BCGV)12/94]
Speed Sensitive Power Steering
(If equipped)
*
[DR10400( GV)01/95]
The steering system in your vehicle is speed
sensitive. This means that the steering effort is
light for parking and heavier for highway
driving. However, if you have to swerve around
an object or another vehicle, your steering will
have full power assist.
File:rcdrv.ex
Update:Wed Jan 31 10:36:47 1996

181
%*
[DR10500( ALL)03/95]
Brakes
%*
[DR10600( ALL)01/95]
Applying the Brakes
[DR10650( ALL)05/94]
Braking non ABS models
[DR11060( GV)12/91]
Your vehicle has front and rear disc brakes with
anti-lock (optional). They adjust automatically as
the brake pads wear down.
*
[DR11100( ALL)04/95]
Apply the brake pedal gradually. Use the
ªsqueezeº technique Ð push on the brake pedal
with a steadily increasing force. This allows the
wheels to continue to roll while you are slowing
down, which lets you steer properly.
[DR11300( ALL)03/95]
On vehicles without anti-lock brakes, extreme
braking can make the wheels lock and slide,
possibly decreasing your control of the steering.
If you lock the wheels, release the brake pedal
and repeat the ªsqueezeº technique.
[DR11310( ALL)05/95]
Braking with ABS brakes
[DR11400( ALL)03/95]
On vehicles with anti-lock brakes, the wheels
will not lock and slide when you press down
hard on the brake pedal. The anti-lock brakes
automatically start releasing and reapplying the
front brakes independently and the rear brakes
together whenever your wheels start to lock. Do
not ªpumpº the brake pedal on vehicles
equipped with anti-lock brakes. When this
happens, you will feel the brake pedal pulse.
This ªpulseº may be an unfamiliar feeling but it
is normal and indicates the ABS is working as
designed.
*
[DR11650( ALL)05/95]
Do not drive with your foot resting on the brake
pedal; you will wear out the linings and increase
your vehicle's stopping distance. Brake rotor
damage may also eventually occur.
File:rcdrv.ex
Update:Wed Jan 31 10:36:47 1996

182
*
[DR11700( ALL)03/95]
NOTE: If you are driving down a long or
steep hill, shift to a lower gear and do
not apply your brakes continuously. If
you apply your brakes continuously,
they may overheat and become less
effective.
%*
[DR11800( ALL)03/95]
Occasional brake squeal during light to moderate
stops does not affect the function of the brake
system and is normal. However, if the squeal
becomes louder or more frequent, have your
brakes inspected by your dealer or a qualified
service technician.
[DR11900( ALL)05/94]
Ford Motor Company has not found any
detrimental effects of popular mobile radio
transmitting equipment installed on vehicles
with the anti-lock brake system, if the equipment
is installed according to the manufacturer's
instructions. However, if mobile radio
transmitting equipment is installed in your
vehicle and, if either the anti-lock brake system
cycles or the check anti-lock light comes on at
any time other than right after you turn the key
to ON or during a sudden stop, have your
mobile radio dealer inspect the installation.
%*
[DR12000( ALL)03/95]
Parking Brake
*
[DR12050( ALL)01/95]
The parking brake should be used whenever
you park your vehicle.
[DR12500( BCGV)03/95]
The parking brake pedal is suspended just below
the bottom of the instrument panel to the left of
the brake pedal.
[DR13000( GV)03/95]
To manually set the parking brake after parking
your vehicle, apply the brake pedal with your
right foot and hold it while you push the
parking brake down firmly and fully with your
left foot. The brake system warning light will
glow. The parking brake will not set with the
transmission in any forward gear position.
File:rcdrv.ex
Update:Wed Jan 31 10:36:47 1996

183 [DR13600( GV)03/94]
one third page art:0010319-E
The parking brake
*
[DR13800( BCGV)05/95]
RWARNING
Always set the parking brake fully and
make sure that the gearshift is securely
latched in P (Park).
*
[DR14125( GV)01/95]
Your vehicle has an automatic parking brake
release. As you move the gearshift selector to
any forward gear with the engine running, the
parking brake automatically releases. Your
parking brake will not release automatically
when you shift into R (Reverse). To release the
parking brake manually, pull the brake release
handle [marked (P)] located on the lower left
corner of the instrument panel. The pedal is now
released and will reset the next time you press
the pedal. The Brake System Warning Light will
glow if the parking brake is not fully released
when the engine is running.
*
[DR14175( GV)11/91]
RWARNING
To prevent personal injury, do not release
the parking brake while outside the
vehicle.
File:rcdrv.ex
Update:Wed Jan 31 10:36:47 1996

184
*
[DR14200( ALL)03/95]
Always check the Brake Warning Light each
time you start your engine. Driving with the
parking brake on will cause the brakes to wear
out quickly and will reduce the fuel economy.
*
[DR14300( ALL)01/93]
RWARNING
If the parking brake is fully released, but
the Brake System light remains on, have
the brakes checked immediately. They
may not be working properly.
[DR14400( ALL)07/93]
The parking brake system is designed for static
parking only and is not designed to stop a
moving vehicle, but you can use the parking
brake to stop your vehicle in an emergency if
the normal brakes fail. However, since the
parking brake applies only the rear brakes, the
stopping distance will increase greatly and the
handling of your vehicle will be adversely
affected.
% [DR14415( GV)05/94]Rear Air Suspension System
(If equipped)
[DR14425( GV)10/90]
If your vehicle is equipped with an automatic
load leveling rear air suspension system, it will
maintain the rear vehicle height at a constant
level by automatically adding air or releasing air
from the rear air springs to offset changes in
vehicle loads.
[DR14430( GV)03/94]
A shutoff switch is located in the trunk on the
right hand vertical trim panel. If this switch is in
the OFF position, the automatic leveling system
will not operate. The switch should be OFF
whenever jacking up or towing the vehicle. If
you have the mechanical cluster, ªAIR SUSPº
will appear in the cluster, if you have an
electronic cluster, ªCHECK AIR SUSPENSIONº
File:rcdrv.ex
Update:Wed Jan 31 10:36:47 1996
