FORD CROWN VICTORIA 1996 1.G Owners Manual

185
will appear in the message center when the
ignition switch is in the ON position, and either
the shutoff switch is in the OFF position, or a
system fault has been detected.
*
[DR14440( GV)01/95]
Normal vehicle operation does not require any
action by the driver.
*
[DR14450( GV)05/95]
RWARNING
On vehicles equipped with Air
Suspension, turn OFF the Air Suspension
switch prior to jacking, hoisting or towing
your vehicle.
[DR14460( GV)03/92]
half page art:0010164-A
The air suspension switch Ð located on the right-hand
vertical trim panel
File:rcdrv.ex
Update:Wed Jan 31 10:36:47 1996

186
*
[DR14500( ALL)01/95]
Driving Under Special Conditions
%*
[DR14600( ALL)01/95]
Tips for Safe Driving
*
[DR14700( ALL)03/95]
As with any new vehicle, yours may drive and
handle differently from your previous vehicle.
Use care until you become accustomed to its
various features and driving characteristics.
*
[DR14800( ALL)03/95]
Operate your vehicle within reasonable limits.
Sudden acceleration, deceleration, turning, or
combinations of these maneuvers can cause a
vehicle to behave differently than anticipated.
%*
[DR15200( ALL)01/95]
Driving in Bad Weather
%*
[DR15300( ALL)01/95]
Slippery roads
*
[DR15400( ALL)03/95]
Drive cautiously on wet or snowy roads:
*
[DR15500( ALL)03/95]
q
Do not quickly move the steering wheel
unless necessary.
*
[DR15600( ALL)01/95]
q
Drive slower than you normally would.
[DR15700( ALL)03/95]
q
Do not use speed control.
*
[DR15800( ALL)01/95]
q
Give your vehicle more distance to stop.
*
[DR15900( ALL)03/92]
q
Pump the brake pedal steadily and evenly to
avoid locking your wheels. (Does not apply
to vehicles with anti-lock brakes.)
*
[DR16000( ALL)02/93]
q
Consider using one of the lower gears.
*
[DR16200( BCGV)01/93]
RWARNING
To avoid skidding and losing control on
slippery roads, do not downshift into First
(1) when you are moving faster than
20 mph (32 km/h).
File:rcdrv.ex
Update:Wed Jan 31 10:36:47 1996

187
*
[DR16225( ALL)03/95]
RWARNING
If your vehicle has speed control, do not
use it on slippery roads. You could lose
control of your vehicle and could injure
someone.
[DR16250( GV)05/94]
If your vehicle gets stuck (for example, in mud
or snow), you may try to ªrockº it out of the
spot. Shift, in a steady rhythm, between forward
(2 [Second] gear is the recommended forward
gear) and reverse gears. At the same time, press
lightly on the accelerator.
*
[DR16400( ALL)05/95]
RWARNING
Do not spin the wheels at over 35 mph
(55 km/h). The tires may fail and injure a
passenger or bystander.
[DR16500( ALL)12/94]
By moving the vehicle backward and forward,
you may gain enough momentum to move out
of the spot. Do not rock the vehicle for more
than a few minutes. This may overheat the
engine, damage the transmission, or damage the
tires. If you are still stuck after a minute or two
of rocking, call for a tow truck.
%*
[DR16700( ALL)01/95]
High water
*
[DR16800( ALL)01/95]
Do not drive through flooded areas unless you
are sure that the water is below the bottom of
the wheel rims.
*
[DR16900( ALL)04/94]
If you must drive through high water, drive
slowly. You may have limited traction or wet
brakes, so allow extra stopping distance because
your vehicle will not stop as quickly as usual.
*
[DR17000( ALL)01/95]
After you drive through the standing water,
apply your brakes gently several times as your
vehicle moves slowly. This helps to dry the
brakes.
File:rcdrv.ex
Update:Wed Jan 31 10:36:47 1996

188
%*
[DR17100( ALL)03/95]
Driving With a Heavy Load
*
[DR17200( ALL)01/95]
There are limits to the amount of weight your
vehicle can carry or tow. The total weight of
your vehicle, plus the weight of the passengers
and cargo, should never be more than the Gross
Vehicle Weight Rating (GVWR). Also, the weight
that your vehicle carries over the front axle and
rear axle should never be more than the Gross
Axle Weight Rating (GAWR) for the respective
axle.
% [DR17300( ALL)05/94]
You can find your vehicle's GVWR and GAWR
on the Safety Compliance Certification Label on
the left front door lock facing or the door latch
post pillar.
*
[DR17400( ALL)01/95]
The weight limits of your vehicle's tires affect
the GVWR or GAWR limitations. Usage of
replacement tires with higher weight limit than
originals does not increase GVWR or GAWR.
Usage of lower capacity replacement tires may
lower GVWR and GAWR limitations.
*
[DR17500( ALL)02/95]
RWARNING
If the GVWR or the GAWR specified on
the Safety Compliance Certification Label
is exceeded, your vehicle may be damaged
or you may lose control and injure
someone.
File:rcdrv.ex
Update:Wed Jan 31 10:36:47 1996

189 %
*
[DR17503( ALL)01/95]
Limiting Your Vehicle's Load
*
[DR17506( ALL)01/95]
The load that you add to your vehicle must not
exceed the maximum load stated on the Safety
Compliance Certification Decal attached to the
left front door pillar.
*
[DR17509( ALL)01/95]
To figure the weight of your vehicle's load, add
the weights of:
*
[DR17512( ALL)01/95]
q
the driver and passengers
*
[DR17515( ALL)01/95]
q
luggage and any other items that you put in
your vehicle
*
[DR17518( ALL)01/95]
q
the tongue load of the loaded trailer
*
[DR17521( ALL)01/95]
q
the weight of any equipment that has been
added to your vehicle since it was delivered
to your dealer
*
[DR17524( ALL)01/95]
If you do not know the actual weights of these
items, use the following procedure to figure the
weight of a load:
*
[DR17527( ALL)01/95]
1. Weigh your vehicle without the driver,
passengers and luggage. You might take
your vehicle to a shipping company or an
inspection station for trucks.
*
[DR17530( ALL)01/95]
2. Then weigh your vehicle with the driver,
passengers and luggage.
*
[DR17533( ALL)01/95]
3. Subtract the first reading from the second to
figure the total weight of the load.
*
[DR17536( ALL)01/95]
After determining this load, you must also make
sure that the total weight of your vehicle, plus
the load it carries, is less than its GVWR. Also,
make sure that the weight your vehicle carries
over each axle is less than the GAWR for the
respective axle.
File:rcdrv.ex
Update:Wed Jan 31 10:36:47 1996

190
*
[DR17539( ALL)01/95]
If your vehicle exceeds the GVWR, remove cargo
from your vehicle accordingly. If your vehicle
exceeds the GAWR for either axle, shift the load
or remove cargo accordingly.
*
[DR17542( ALL)05/95]
RWARNING
Improper distribution of your vehicle's
load or carrying weight in excess of the
amount shown on the tire decal can cause
rapid tire wear or loss of vehicle control.
%
*
[DR17600( GV)01/95]
Trailer Towing (may require
trailer tow option package)
*
[DR17650( ALL)01/95]
Your vehicle does not come from the factory
fully equipped to tow. No towing packages are
available through Ford or Lincoln/Mercury
dealers.
*
[DR17700( ALL)01/95]
Because towing a trailer puts extra strain on
your vehicle, you must follow certain
precautions for your safety and the good of your
vehicle:
*
[DR17800( ALL)01/95]
q
Stay within the load limits for towing your
vehicle. (SeeTrailer towing specificationsin this
chapter.)
*
[DR17900( ALL)01/95]
q
Carefully and thoroughly prepare your
vehicle for towing, making sure to use the
right equipment and to attach it properly.
(SeePreparing to Towin this chapter.)
*
[DR18000( ALL)01/95]
q
Use extra caution when driving your vehicle
while you tow. (SeeDriving while you towin
this chapter.)
*
[DR18100( ALL)01/95]
q
Service your vehicle more frequently if you
tow a trailer. (SeeServicing your vehicle if you
towin this chapter.)
File:rcdrv.ex
Update:Wed Jan 31 10:36:47 1996

191
*
[DR18175( ALL)01/95]
Ten to 15% of the loaded trailer's weight should
be on the tongue. However, the tongue load
should never exceed 10% of the maximum
weight that your vehicle can safely tow.
*
[DR18250( ALL)05/95]
RWARNING
Do not tow a trailer when the temporary
spare tire is being used.
[DR18300( ALL)12/94]
Your vehicle is classified as a light duty towing
vehicle. The amount of weight that you can
safely tow depends on the optional equipment
on your vehicle. See the following chart.
% [DR18400( ALL)03/90]
Trailer towing specifications
[DR19000( V)05/95]
ten pica chart:0011371-AFile:rcdrv.ex
Update:Wed Jan 31 10:36:47 1996

192
*
[DR20900( ALL)01/95]
Preparing to Tow
*
[DR21000( ALL)01/95]
For your safety and for the good of your
vehicle, use the right equipment for the type of
trailer you tow. Also, make sure that all towing
equipment is properly attached to your vehicle.
If you are not certain that you are using the
right equipment in the proper manner, see your
Ford or Lincoln-Mercury dealer.
*
[DR21100( ALL)01/95]
Do not use hitches that clamp onto your
vehicle's bumper. The bumper is not designed to
bear the load.
*
[DR21125( ALL)01/95]
Always check the pressure in all your vehicle's
tires when preparing to tow (see inflation
recommendation on the tire label).
%*
[DR21150( ALL)01/95]
Using the hitch
[DR21350( V)05/95]
Your vehicle uses one of two types of hitches
(Class III hitch is an option available in Canada
only), depending on how much your trailer
weighs. The Class I hitch will allow you to tow
a trailer weighing up to 2,000 lbs. (907 kg.).
Because this type of hitch places the tongue load
of a trailer on the rear wheels of your vehicle,
you must distribute the load in your trailer so
that only 10 to 15% of the total weight of the
trailer is on the tongue.
[DR21500( V)05/95]
A Class III hitch and the optional trailer tow III
package (option available in Canada only) will
allow you to tow a trailer weighing up to to
5,000 lbs. (2,270 kg). This type of hitch
distributes the tongue load of a trailer evenly
between the front and rear wheel of your vehicle
and the trailer wheels.
File:rcdrv.ex
Update:Wed Jan 31 10:36:47 1996

193
*
[DR21600( ALL)01/95]
Tie down the load so that it does not shift and
change the weight on the hitch. This will
prevent damage to your vehicle and make your
vehicle easier to handle.
[DR21607( V)05/95]
Hook-Up and Adjustment Procedure Ð
Load Equalizing Hitch (option available in
Canada only)
*
[DR21610( GV)01/95]
Your vehicle is equipped with a rear air
suspension system. When hooking up a trailer
using a load equalizing hitch, always use the
following procedure:
*
[DR21615( GV)01/95]
1. Place the unloaded vehicle on a level
surface. With the ignition on and all doors
closed, allow the vehicle to level
automatically (approximately one to two
minutes).
*
[DR21620( GV)01/95]
2. Turn the air suspension switch on the right
side of the trunk to OFF.
*
[DR21625( GV)01/95]
3. Measure the height of a reference point on
the front and rear bumpers at the center of
the vehicle.
*
[DR21630( GV)01/95]
4. Attach trailer to vehicle and adjust the hitch
equalizer(s) so that the front bumper height
is 0 to 1/2 inch below the unloaded height.
After adjustment, the rear bumper should be
no higher than in step 3.
*
[DR21635( GV)01/95]
5. Turn the air suspension switch ON.
*
[DR21640( GV)01/95]
RWARNING
Adjusting an equalizing hitch so the rear
bumper of the vehicle is lower or higher
than it was unloaded will defeat the
function of the load equalizing hitch and
may cause unpredictable handling.
File:rcdrv.ex
Update:Wed Jan 31 10:36:47 1996

194 %
*
[DR21650( ALL)01/95]
Connecting the safety chains
*
[DR21700( ALL)01/95]
Always attach the trailer's safety chains to your
vehicle. They help protect your trailer if the
hitch breaks.
*
[DR21800( ALL)01/95]
To connect the trailer's safety chains:
*
[DR21900( ALL)01/95]
1. Cross the chains under the trailer tongue
and attach them to your vehicle's frame or
hook retainers. Never attach the safety
chains to your vehicle's bumper. The bumper
is not designed to bear the weight of a
trailer.
*
[DR22000( ALL)01/95]
2. Make sure that you leave enough slack in
the chains to allow you to turn corners.
*
[DR22100( ALL)01/95]
If you use a rental trailer, follow the instructions
that the rental agency gives you.
%*
[DR22150( ALL)01/95]
Connecting the trailer's brakes
*
[DR22200( ALL)01/95]
Electric brakes and manual, automatic, or
surge-type hydraulic brakes are safe if you
install them properly and adjust them according
to the manufacturer's instructions. Be sure that
your trailer's brakes meet local and federal
regulations.
[DR22250( ALL)03/95]
If your vehicle is equipped with the optional
trailer tow package, provisions have been made
under the instrument panel for installation of an
electronic brake controller.
File:rcdrv.ex
Update:Wed Jan 31 10:36:47 1996
