FORD CROWN VICTORIA 1996 1.G Owners Manual

235
*
[SV02100( ALL)01/95]
q
Never get under a vehicle while it is
supported by a jack only. If you must work
under a vehicle, use safety stands.
*
[SV02200( ALL)01/95]
q
Keep all lit cigarettes and other smoking
materials away from the battery and all
fuel-related parts.
*
[SV02800( ALL)03/95]
Working with the engine off:
*
[SV03000( BCGV)03/95]
1. Set the parking brake fully and make sure
that the gearshift is securely latched in
P (Park).
*
[SV03100( ALL)03/95]
2. Remove the key from the ignition after you
turn the engine off.
*
[SV03150( ALL)03/95]
3. Block the wheels. This will prevent your
vehicle from moving unexpectedly.
*
[SV03200( ALL)03/95]
Working with the engine on:
*
[SV03400( BCGV)03/95]
1. Set the parking brake fully and make sure
that the gearshift is securely latched in
P (Park).
*
[SV03501( ALL)03/95]
2. Block the wheels. This will prevent your
vehicle from moving unexpectedly.
*
[SV03600( ALL)02/95]
RWARNING
Do not start your engine with the air
cleaner removed and do not remove it
while the engine is running.
File:rcsvv.ex
Update:Wed Jun 28 16:02:20 1995

236 %
*
[SV03650( ALL)03/95]
Opening the Hood
[SV03800( ALL)03/95]
1. Inside the vehicle, pull the hood release
located under the lower left corner of the
instrument panel.
[SV03850( GV)03/94]
one third page art:0010175-C
The hood release under the instrument panel
[SV04000( ALL)03/95]
2. Go around to the front of the vehicle, and
release the auxiliary catch that is located
under the front edge of the hood at the
center of the vehicle.
[SV04050( GV)05/94]
one third page art:0010176-C
The auxiliary catch under the front edge of the hood
*
[SV04200( BCGV)01/95]
3. Lift the hood until the counterbalanced
hinges hold it open.
File:rcsvv.ex
Update:Wed Jun 28 16:02:20 1995

237
*
[SV04400( BCGV)01/95]
Whenever you close the hood, latch it securely.
*
[SV04450( ALL)01/95]
NOTE: Apply lubricant to the hood latch at
six-month intervals to maintain smooth
and trouble-free operation.
%
*
[SV04600( ALL)05/95]
Engine Compartment
*
[SV04800( GV)01/95]
Your vehicle has a 4.6 liter engine. The following
page shows a diagram of where to find items
that you should regularly service.
File:rcsvv.ex
Update:Wed Jun 28 16:02:20 1995

238 [SV05800( GV)05/95]
full page art:0010329-DA 4.6 liter SFI engine
File:rcsvv.ex
Update:Wed Jun 28 16:02:20 1995

239 %
*
[SV05850( ALL)04/95]
Cleaning the Engine
*
[SV06000( ALL)04/95]
A clean engine is more efficient because a
buildup of grease and dirt acts as an insulator,
keeping the engine warmer than usual.
*
[SV06020( ALL)05/95]
q
Extreme care must be used if a power washer
is used to clean the engine. The high pressure
fluid could penetrate sealed parts and
assemblies causing damage or malfunctions.
*
[SV06040( ALL)04/95]
q
In order to avoid possible cracking of the
engine block or fuel injection pump, do not
spray a hot engine or injection pump with
cold water.
*
[SV06060( ALL)04/95]
q
The alternator, distributor and air intake must
be covered. Covering these components will
help prevent water damage.
*
[SV06080( ALL)04/95]
q
Never wash or rinse the engine while it is
running. Water getting into the engine may
cause internal damage.
%
*
[SV06100( ALL)03/95]
Filling the Fuel Tank
*
[SV06220( GV)01/95]
The fuel filler door is outside the vehicle on the
driver's side near the back. To fill the fuel tank:
[SV06550( ALL)05/95]
1. After opening the fuel filler door, remove
the cap carefully and slowly by turning it
counterclockwise 1/2 to 3/4 turn.
[SV06650( ALL)05/95]
RWARNING
The fuel system may be under pressure. If
the fuel cap is venting vapor or if you
hear a hissing sound while disengaging
the fuel cap, wait until it stops before
completely removing the cap. Otherwise,
fuel may spray out and injure you or
others.
File:rcsvv.ex
Update:Wed Jun 28 16:02:20 1995

240 [SV06700( ALL)05/95]2. Put the nozzle all the way inside the fuel
filler pipe before pumping the fuel.
[SV06800( ALL)05/95]
NOTE: If you spill any fuel on the body of
your vehicle, clean it off immediately.
The fuel may dull or soften the paint
if you do not wash it off.
[SV06850( ALL)05/95]
3. Replace the fuel cap completely when you
are finished. Turn it clockwise 1/4 turn until
it is tight. It will click when it is fully
tightened.
[SV06875( ALL)05/95]
4. Push the fuel door closed.
[SV06900( ALL)05/95]
RWARNING
If you lose the fuel cap, replace it with a
Motorcraft or equivalent fuel cap. If you
do not use the proper fuel cap, the
pressure in the fuel tank can damage the
fuel system or cause it to work improperly
in a collision, endangering you and your
passengers.
[SV06950( ALL)05/95]
NOTE: If you replace your fuel cap with an
aftermarket fuel filler cap, the customer
warranty may be void for any damage
to the fuel tank and/or fuel system.
[SV07500( ALL)05/95]
Choosing the Right Fuel
[SV07600( ALL)05/95]
Use only UNLEADED FUEL in your vehicle.
Using leaded fuel is prohibited by federal law.
Your warranty may not apply if your vehicle is
damaged because you used the wrong fuel.
[SV07701( ALL)05/95]
Using a high-quality fuel makes your vehicle
more responsive and maintain its good fuel
economy and emissions. It should not be
necessary to add any aftermarket products to
your fuel tank if you continue to use a
high-quality fuel.
File:rcsvv.ex
Update:Wed Jun 28 16:02:20 1995

241 [SV08750( ALL)05/95]
Octane recommendations
[SV08800( ALL)05/95]
Your engine is designed to use fuel with an
octane rating of 87. In most cases it is not
necessary to use a fuel with an octane rating
higher than 87. At service stations, the octane
rating is displayed in a label on the pumps.
[SV08900( ALL)05/95]
one inch art:0060001-C[SV09100( ALL)05/95]
Using a fuel with a lower octane rating can
cause persistent and heavy knocking, which can
damage the engine.
[SV09200( ALL)05/95]
Do not be concerned if your vehicle sometimes
knocks lightly when you drive up a hill or when
you accelerate. However, see your dealer or a
qualified service technician if persistent heavy
knocking occurs because this can damage the
engine.
[SV09350( ALL)05/95]
If your vehicle has problems with starting, rough
idle or hesitation problems when the engine is
cold, it may be caused by fuel with low
volatility. Try a different brand of fuel. If the
condition persists, see your dealer or a qualified
service technician.
File:rcsvv.ex
Update:Wed Jun 28 16:02:20 1995

242 [SV09800( ALL)05/95]Gasolines for clean air
[SV09900( ALL)05/95]
Fuels in certain areas of the country are required
to contain oxygenates to improve air quality.
Common oxygenates are ethanol or grain alcohol
(blended at no more than 10%), methanol or
wood alcohol (blended at no more than 5% with
cosolvents and additives), and MTBE or methyl
tertiary butyl ether (blended at no more than
15%).
[SV09950( ALL)05/95]
Reformulated gasoline is also required in certain
areas of the U.S. These fuels are designed to
further reduce emissions from your vehicle.
[SV10000( ALL)05/95]
Generally, you should not experience difficulties
operating your vehicle on fuels containing
oxygenates. We encourage you to use these
fuels.
[SV10185( ALL)05/95]
Safety Information Relating to Automotive
Fuels
[SV10195( ALL)05/95]
RWARNING
Automotive fuels can cause serious injury
or death if misused or mishandled. To
minimize the risk that you will be
injured, please read the following
information carefully and observe the
recommended precautions.
[SV10197( ALL)05/95]
q
Turn vehicle off when refueling
[SV10199( ALL)05/95]
q
Do not smoke when refueling. Fuels are
extremely flammable.
[SV10201( ALL)05/95]
q
Do not siphon any fuel by mouth.
File:rcsvv.ex
Update:Wed Jun 28 16:02:20 1995

243 [SV10205( ALL)05/95]
RWARNING
Gasoline or gasoline blended with
methanol can cause blindness and
possible death when swallowed. If any
fuel is swallowed, call a physician or
poison control center immediately.
[SV10209( ALL)05/95]
q
Avoid breathing vapors while refueling.
[SV10211( ALL)05/95]
q
If fuel is splashed on the skin, wash with
soap and water.
[SV10225( ALL)05/95]
q
If fuel is splashed in the eyes, remove contact
lenses (if worn), flush with water for 15
minutes, and seek medical attention.
[SV10227( ALL)05/95]
Gasoline and gasoline blends may contain small
amounts of carcinogens, such as benzene.
Long-term exposure to unleaded gasoline vapors
has caused cancer in laboratory animals.
[SV10230( ALL)05/95]
If you are taking the medication ªAntabuseº or
other forms of disulfiram for the treatment of
alcoholism, vapor or skin contact with a
gasoline-methanol blend may cause the same
kind of adverse reaction as drinking an alcoholic
beverage. In sensitive individuals, serious
personal injury or sickness could result. Consult
a physician promptly if you experience an
adverse reaction.
[SV11300( ALL)05/95]
Running Out of Fuel
[SV11350( ALL)05/95]
NOTE: Avoid running out of fuel because this
situation may have an adverse effect on
modern powertrain components.
[SV11500( ALL)05/95]
You may need to crank the engine several times
before the fuel system starts to pump fuel from
the tank to the engine.
File:rcsvv.ex
Update:Wed Jun 28 16:02:20 1995

244
[SV11600( ALL)05/95]
Calculating Fuel Economy
[SV11700( ALL)05/95]
Fuel economy is an estimate of the efficiency of
your vehicle, and can be calculated as Miles Per
Gallon (MPG) or Liters Per 100 Kilometers
(L/100K).
[SV11750( ALL)05/95]
Do not calculate fuel economy during your
vehicle's break-in period. This would not be an
accurate estimate of how much fuel your vehicle
will normally use.
[SV11800( ALL)05/95]
To calculate fuel economy:
[SV11900( ALL)05/95]
1. Fill the fuel tank completely and record the
initial odometer reading.
[SV12000( ALL)05/95]
2. Every time you buy fuel, record the
amount (in gallons or liters) purchased.
[SV12100( ALL)05/95]
3. After at least 3-5 tankfuls, fill the fuel tank
and record the final odometer reading.
[SV12200( ALL)05/95]
4. Use these equations to calculate your fuel
economy:
[SV12250( ALL)05/95]
q
English: MPG = (total miles driven)V
(gallons used)
[SV12275( ALL)05/95]
q
Metric: L/100k = (liters used)V
(100 kilometers)
[SV12300( ALL)05/95]
Comparisons With EPA Estimates
[SV12400( ALL)05/95]
EPA fuel economy figures are obtained from
laboratory tests under simulated road conditions
and may not reflect the actual conditions you
experience or your style of driving. The EPA
fuel economy estimate is not a guarantee that
you will achieve the fuel economy shown.
