FORD CROWN VICTORIA 1996 1.G Owners Manual
Manufacturer: FORD, Model Year: 1996, Model line: CROWN VICTORIA, Model: FORD CROWN VICTORIA 1996 1.GPages: 342, PDF Size: 2.56 MB
Page 281 of 342
![FORD CROWN VICTORIA 1996 1.G Owners Manual 265 %
*
[SV28700( ALL)04/95]
Snow Tires and Chains
*
[SV28800( BCGV)01/95]
The tires on your vehicle have all-weather treads
that provide traction in rain or snow. However,
during the winter months in FORD CROWN VICTORIA 1996 1.G Owners Manual 265 %
*
[SV28700( ALL)04/95]
Snow Tires and Chains
*
[SV28800( BCGV)01/95]
The tires on your vehicle have all-weather treads
that provide traction in rain or snow. However,
during the winter months in](/img/11/4772/w960_4772-280.png)
265 %
*
[SV28700( ALL)04/95]
Snow Tires and Chains
*
[SV28800( BCGV)01/95]
The tires on your vehicle have all-weather treads
that provide traction in rain or snow. However,
during the winter months in some climates, you
may need to use snow tires and occasionally
chains for your tires.
*
[SV28900( ALL)05/95]
RWARNING
Snow tires must be the same size and
grade as the tires you currently have on
your vehicle.
*
[SV29000( ALL)02/95]
Use chains on the tires only in an emergency or
if the law requires them where you live. If you
choose to use chains on your vehicle's tires, be
aware of the following:
*
[SV29100( ALL)01/95]
q
Make sure the chains are the right size for
your tires. Use only SAE Class ªSº chains.
Other types may damage your vehicle.
*
[SV29200( ALL)01/95]
q
Put the chains on tightly with the ends held
down securely. Verify that no chain touches
any wiring, brake lines, or fuel lines. Follow
the chain manufacturer's instructions.
*
[SV29300( ALL)01/95]
q
Drive slowly. If you can hear the chains rub
or bang against your vehicle, stop the vehicle
and tighten the chains. If you continue to
hear the chains rub or bang against your
vehicle, remove the chains to prevent damage
to your vehicle.
*
[SV29400( ALL)10/94]
q
Avoid fully loading your vehicle if possible.
*
[SV29500( ALL)05/94]
q
Remove tire chains at the first opportunity
after using them on snow and ice. Do not use
the chains on dry roads.
File:rcsvv.ex
Update:Wed Jun 28 16:02:20 1995
Page 282 of 342
![FORD CROWN VICTORIA 1996 1.G Owners Manual 266 %
*
[SV29600( ALL)04/95]
Cleaning the Wheels
*
[SV29700( ALL)05/95]
Wash the wheels with the same detergent you
use to wash your vehicles body. Do not use
acid-based wheel cleaners, steel wool, a FORD CROWN VICTORIA 1996 1.G Owners Manual 266 %
*
[SV29600( ALL)04/95]
Cleaning the Wheels
*
[SV29700( ALL)05/95]
Wash the wheels with the same detergent you
use to wash your vehicles body. Do not use
acid-based wheel cleaners, steel wool, a](/img/11/4772/w960_4772-281.png)
266 %
*
[SV29600( ALL)04/95]
Cleaning the Wheels
*
[SV29700( ALL)05/95]
Wash the wheels with the same detergent you
use to wash your vehicle's body. Do not use
acid-based wheel cleaners, steel wool, abrasives,
fuel, or strong detergents. These substances will
damage protective coatings. Use tar and road oil
remover to remove grease and tar.
*
[SV29800( ALL)04/95]
NOTE: Before going to a car wash, find out if
the brushes are abrasive.
%
*
[SV30450( ALL)01/95]
Automatic Transmission Fluid
*
[SV30475( ALL)01/95]
Under normal circumstances, you do not need to
check the fluid level of the transmission, since
your vehicle does not use up transmission fluid.
Refer to theMaintenance Schedule and Record
booklet for replacement intervals. However, if
the transmission is not working properly Ð for
instance, the transmission may slip or shift
slowly, or you may notice some sign of fluid
leakage Ð the fluid level should be checked.
%*
[SV30550( ALL)02/95]
Checking the Automatic Transmission
Fluid
*
[SV30560( ALL)02/95]
It is preferable to check the transmission fluid
level at normal operating temperature
150ÊF-170ÊF (66ÊC-77ÊC),after approximately
20 miles (30 km) of driving. However, if
necessary, you can check the fluid level without
having to drive 20 miles (30 km) to obtain a
normal operating temperature if outside
temperatures are above50ÊF (10ÊC).
[SV30575( ALL)03/94]
With the vehicle on a level surface, start the
engine and, while fully applying the brake
pedal, move the transmission shift selector
through all of the gear ranges allowing sufficient
time for each position to engage.Securely latch
the transmission shift selector in the P (Park)
position, fully set the parking brake and leave
the engine running.
File:rcsvv.ex
Update:Wed Jun 28 16:02:20 1995
Page 283 of 342
![FORD CROWN VICTORIA 1996 1.G Owners Manual 267 [SV30601( GV)03/93]
NOTE: Your vehicle should not be driven if
the fluid level is below the bottom
hole on the dipstick.
*
[SV30650( ALL)02/95]
Wipe off the dipstick cap, pull the dipstick out
and FORD CROWN VICTORIA 1996 1.G Owners Manual 267 [SV30601( GV)03/93]
NOTE: Your vehicle should not be driven if
the fluid level is below the bottom
hole on the dipstick.
*
[SV30650( ALL)02/95]
Wipe off the dipstick cap, pull the dipstick out
and](/img/11/4772/w960_4772-282.png)
267 [SV30601( GV)03/93]
NOTE: Your vehicle should not be driven if
the fluid level is below the bottom
hole on the dipstick.
*
[SV30650( ALL)02/95]
Wipe off the dipstick cap, pull the dipstick out
and wipe the indicator end clean. Put the
dipstick back into the filler tube and make sure
it is fully seated. Pull the dipstick out and read
the fluid level.
*
[SV30701( GV)01/95]
When checking fluid at normal operating
temperatures150ÊF-170ÊF (66ÊC-77ÊC), thefluid
level should be within the crosshatched area on
the dipstick. When the vehicle has not been
driven, and outside temperatures are above68ÊF
(20ÊC), the fluid levels should be between the
holes on the dipstick.
*
[SV30715( ALL)01/95]
NOTE: If the vehicle has been operated for an
extended period at high speeds or in
city traffic during hot weather, or
pulling a trailer, the vehicle should be
turned off for about 30 minutes to
allow the fluid to cool before checking.
%*
[SV30725(M CGV)05/95]
Adding Automatic Transmission Fluid
[SV30750( ALL)03/94]
Before adding any fluid, be sure that the correct
type will be used. Use only MERCONHfluid.
*
[SV30775( ALL)03/95]
Add fluid in 1/2 pint (.25L) increments through
the filler tube to bring the level to the correct
area on the dipstick. DO NOT OVERFILL. If the
level is above the top hole on the dipstick,
excess fluid should be removed by a qualified
technician.
%*
[SV30801( ALL)04/95]
NOTE: Always dispose of used automotive
fluids in a responsible manner. Follow
your community's standards for
disposing of these types of fluids. Call
your local recycling center to find out
about recycling automotive fluids.
File:rcsvv.ex
Update:Wed Jun 28 16:02:20 1995
Page 284 of 342
![FORD CROWN VICTORIA 1996 1.G Owners Manual 268 [SV30850( GV)10/94]
one third page art:0010384-EDetail of the automatic transmission dipstick
%*
[SV31900( ALL)03/95]
Brake Fluid
*
[SV32000( ALL)04/95]
Under normal circumstances, your vehicle
sh FORD CROWN VICTORIA 1996 1.G Owners Manual 268 [SV30850( GV)10/94]
one third page art:0010384-EDetail of the automatic transmission dipstick
%*
[SV31900( ALL)03/95]
Brake Fluid
*
[SV32000( ALL)04/95]
Under normal circumstances, your vehicle
sh](/img/11/4772/w960_4772-283.png)
268 [SV30850( GV)10/94]
one third page art:0010384-EDetail of the automatic transmission dipstick
%*
[SV31900( ALL)03/95]
Brake Fluid
*
[SV32000( ALL)04/95]
Under normal circumstances, your vehicle
should not use up brake fluid rapidly. However,
expect the level of the brake fluid to slowly fall
as you put more mileage on your vehicle and
the brake lining wears.
[SV32200( BCGV)03/95]
Check the brake fluid at each scheduled engine
oil change or at least once a year. You can do
this by looking at the fluid level in the plastic
reservoir on the master cylinder. Also, see label
on reservoir cap. (To locate the master cylinder,
seeThe Engine Typesin the Index.) The fluid
level should be between the MIN and MAX
marks.
*
[SV32350( ALL)05/95]
RWARNING
Brake fluid is toxic.
*
[SV32375( ALL)05/95]
If brake fluid contacts eyes, flush eyes with
running water for 15 minutes. Get medical
attention if irritation persists. If taken internally,
drink water and induce vomiting. Get medical
attention immediately.
File:rcsvv.ex
Update:Wed Jun 28 16:02:20 1995
Page 285 of 342
![FORD CROWN VICTORIA 1996 1.G Owners Manual 269
*
[SV32400( ALL)03/95]
If the fluid is low, carefully clean and remove
the cap from the reservoir. Fill the reservoir to
the MAX line with Ford High Performance
DOT 3 Brake Fluid C6AZ-19542-AA,
C6 FORD CROWN VICTORIA 1996 1.G Owners Manual 269
*
[SV32400( ALL)03/95]
If the fluid is low, carefully clean and remove
the cap from the reservoir. Fill the reservoir to
the MAX line with Ford High Performance
DOT 3 Brake Fluid C6AZ-19542-AA,
C6](/img/11/4772/w960_4772-284.png)
269
*
[SV32400( ALL)03/95]
If the fluid is low, carefully clean and remove
the cap from the reservoir. Fill the reservoir to
the MAX line with Ford High Performance
DOT 3 Brake Fluid C6AZ-19542-AA,
C6AZ-19542-BA, or equivalent DOT 3 fluid
meeting Ford specification ESA-M6C25-A.
*
[SV33100( ALL)01/95]
RWARNING
If you use a brake fluid that is not
DOT 3, you will cause permanent damage
to your brakes.
*
[SV33200( ALL)01/95]
Do not fill the reservoir above the MAX line.
[SV33300( GV)10/90]
one third page art:0010385-A
The brake fluid reservoir
*
[SV33700( ALL)01/95]
If you find that the fluid level is excessively low
Ð below the seam or ridge on the outside of the
plastic reservoir Ð have the brake system
inspected.
*
[SV33750( ALL)01/95]
RWARNING
Do not let the reservoir for the master
cylinder run dry. This may cause the
brakes to fail.
File:rcsvv.ex
Update:Wed Jun 28 16:02:20 1995
Page 286 of 342
![FORD CROWN VICTORIA 1996 1.G Owners Manual 270
%*
[SV34800( ALL)03/95]
Power Steering Fluid
*
[SV34900( ALL)01/95]
Check the level of the power steering fluid at
least twice a year (i.e., every Spring and Fall).
%*
[SV35000( ALL)03/95]
Checkin FORD CROWN VICTORIA 1996 1.G Owners Manual 270
%*
[SV34800( ALL)03/95]
Power Steering Fluid
*
[SV34900( ALL)01/95]
Check the level of the power steering fluid at
least twice a year (i.e., every Spring and Fall).
%*
[SV35000( ALL)03/95]
Checkin](/img/11/4772/w960_4772-285.png)
270
%*
[SV34800( ALL)03/95]
Power Steering Fluid
*
[SV34900( ALL)01/95]
Check the level of the power steering fluid at
least twice a year (i.e., every Spring and Fall).
%*
[SV35000( ALL)03/95]
Checking and Adding Power Steering
Fluid
*
[SV35100( ALL)02/95]
1. Start the engine and let it run until the
power steering fluid reaches normal
operating temperature. The power steering
fluid will be at the right temperature when
the engine coolant temperature gauge in the
instrument cluster is near the center of the
NORMAL operating temperature range.
*
[SV35200( ALL)01/95]
2. While the engine idles, turn the steering
wheel back and forth several times. Make
sure that the cap assembly is installed at this
time.
*
[SV35300( ALL)05/95]
3. Turn the engine off.
*
[SV35420( GV)11/94]
4. Check the fluid level in the power steering
fluid reservoir. The fluid level should be
between the MIN and MAX lines on the side
of the reservoir.
*
[SV35550( GV)11/94]
5. If the power steering fluid is below the MIN
mark, add fluid in small amounts until the
level is between the MIN and MAX lines on
the side of the reservoir.
[SV35650( GV)12/94]
6. When you are finished, put the cap assembly
back on the reservoir.
File:rcsvv.ex
Update:Wed Jun 28 16:02:20 1995
Page 287 of 342
![FORD CROWN VICTORIA 1996 1.G Owners Manual 271 [SV35750( GV)12/94]
half page art:0010657-C
Fluid level for power steering
[SV35875(M GV)03/95]
Use only power steering fluid that meets Ford
Specification MerconHATF XT-2-QDX.
*
[SV35900( ALL)01/ FORD CROWN VICTORIA 1996 1.G Owners Manual 271 [SV35750( GV)12/94]
half page art:0010657-C
Fluid level for power steering
[SV35875(M GV)03/95]
Use only power steering fluid that meets Ford
Specification MerconHATF XT-2-QDX.
*
[SV35900( ALL)01/](/img/11/4772/w960_4772-286.png)
271 [SV35750( GV)12/94]
half page art:0010657-C
Fluid level for power steering
[SV35875(M GV)03/95]
Use only power steering fluid that meets Ford
Specification MerconHATF XT-2-QDX.
*
[SV35900( ALL)01/95]
If the power steering fluid is low, do not drive
your vehicle for a long period of time before
adding fluid. This can damage the power
steering pump.
[SV36150( GV)03/93]
If you must check the power steering fluid when
it is cold, make sure that the fluid reaches the
MIN mark on the reservoir.
% [SV36280( GV)12/94]Fuses, High Current Fuses, Fuse
Links, and Circuit Breakers
*
[SV36400( ALL)03/95]
Fuses (conventional and high current) and circuit
breakers protect your vehicle's wiring system
from overloading. If electrical parts in your
vehicle are not working, the system may have
been overloaded and blown a fuse or tripped a
circuit breaker. Before you replace or repair any
File:rcsvv.ex
Update:Wed Jun 28 16:02:20 1995
Page 288 of 342
![FORD CROWN VICTORIA 1996 1.G Owners Manual 272electrical parts, check the appropriate fuses
(conventional and high current) or circuit
breakers.
*
[SV36600( ALL)03/95]
The following charts tell you which fuses or
circuit breakers protect the w FORD CROWN VICTORIA 1996 1.G Owners Manual 272electrical parts, check the appropriate fuses
(conventional and high current) or circuit
breakers.
*
[SV36600( ALL)03/95]
The following charts tell you which fuses or
circuit breakers protect the w](/img/11/4772/w960_4772-287.png)
272electrical parts, check the appropriate fuses
(conventional and high current) or circuit
breakers.
*
[SV36600( ALL)03/95]
The following charts tell you which fuses or
circuit breakers protect the wiring for each
electrical part of your vehicle. If a fuse blows or
a circuit breaker opens a circuit,allthe parts of
your vehicle that use that circuit will not work.
*
[SV36610( ALL)01/95]
Once you have determined which fuses or circuit
breakers to check, follow the procedures under
Checking and replacing fusesorChecking and
replacing circuit breakersin this chapter.
[SV37400( GV)03/93]
half page art:0011155-B
The instrument panel fuse panel
File:rcsvv.ex
Update:Wed Jun 28 16:02:20 1995
Page 289 of 342
![FORD CROWN VICTORIA 1996 1.G Owners Manual 273 %
*
[SV37500( ALL)02/95]
The Instrument Panel Fuses, Circuit
Breakers and Relays
[SV38400( V)03/95]
thirty-two pica chart:0010395-KFile:rcsvv.ex
Update:Wed Jun 28 16:02:20 1995 FORD CROWN VICTORIA 1996 1.G Owners Manual 273 %
*
[SV37500( ALL)02/95]
The Instrument Panel Fuses, Circuit
Breakers and Relays
[SV38400( V)03/95]
thirty-two pica chart:0010395-KFile:rcsvv.ex
Update:Wed Jun 28 16:02:20 1995](/img/11/4772/w960_4772-288.png)
273 %
*
[SV37500( ALL)02/95]
The Instrument Panel Fuses, Circuit
Breakers and Relays
[SV38400( V)03/95]
thirty-two pica chart:0010395-KFile:rcsvv.ex
Update:Wed Jun 28 16:02:20 1995
Page 290 of 342

274
File:rcsvv.ex
