245 [SV12650( ALL)05/95]
The following decrease fuel economy:
[SV12700( ALL)05/95]
q
Lack of regular, scheduled maintenance
[SV12800( ALL)05/95]
q
Rapid acceleration and excessive speed
[SV12850( ALL)05/95]
q
Driving with your foot on the brake
[SV12900( ALL)05/95]
q
Sudden stops
[SV12950( ALL)05/95]
q
Extended engine idling
[SV13000( ALL)05/95]
q
Using speed control in hilly terrain
[SV13100( ALL)05/95]
q
Extended use of the A/C, defroster, rear
window defroster and other accessories
[SV13200( ALL)05/95]
q
Underinflated tires
[SV13300( ALL)05/95]
q
Heavy loads
[SV13400( ALL)05/95]
q
Aftermarket add-ons such as bike, ski or
luggage racks, bug deflectors, etc.
*
[SV13510( ALL)02/95]
Self-Service Pointers
*
[SV13520( ALL)01/95]
If you choose to do your own fueling, you
should also perform a few simple maintenance
routines. This extra effort will save you
additional money and contribute to the driving
efficiency of your vehicle.
*
[SV13530( ALL)01/95]
The following procedures require only a tire
gauge, a rag, an oil can spout and windshield
washer fluid.
*
[SV13540( ALL)01/95]
q
Check the engine oil at every refueling stop
*
[SV13550( ALL)01/95]
q
Clean the windshield, outside mirrors and
headlights
*
[SV13560( ALL)01/95]
q
Check windshield washer fluid
*
[SV13570( ALL)02/95]
q
Check tires for excessive wear or worn edges
*
[SV13580( ALL)01/95]
q
Check the tire pressure at least monthly
File:rcsvv.ex
Update:Wed Jun 28 16:02:20 1995
Page 262 of 342
![FORD CROWN VICTORIA 1996 1.G Owners Manual 246
%*
[SV13600( ALL)03/95]
Engine Oil Recommendations
*
[SV13610( ALL)04/95]
We recommend using Motorcraft oil or an
equivalent oil meeting Ford Specification
ESE-M2C153-E and displaying the American FORD CROWN VICTORIA 1996 1.G Owners Manual 246
%*
[SV13600( ALL)03/95]
Engine Oil Recommendations
*
[SV13610( ALL)04/95]
We recommend using Motorcraft oil or an
equivalent oil meeting Ford Specification
ESE-M2C153-E and displaying the American](/img/11/4772/w960_4772-261.png)
246
%*
[SV13600( ALL)03/95]
Engine Oil Recommendations
*
[SV13610( ALL)04/95]
We recommend using Motorcraft oil or an
equivalent oil meeting Ford Specification
ESE-M2C153-E and displaying the American
Petroleum Institute CERTIFICATION MARK on
the front of the container.
*
[SV13650( ALL)03/95]
one third page art:0060021-E
The API Certification Mark
*
[SV13670( ALL)01/95]
Neveruse:
*
[SV13680( ALL)01/95]
q
ªNon-Detergentº oils
*
[SV13690( ALL)04/95]
q
Oils labeled API SA, SB, SC, SD, SE, SF or SG
%*
[SV13700( ALL)01/95]
q
Additional engine oil additives, oil treatments
or engine treatments
%*
[SV13702( ALL)03/95]
Engine oils with anSAE 5W-30viscosity are
PREFERREDfor your vehicle. They provide the
best engine performance, fuel economy and
engine protection for all climates down to-15ÊF
(-25ÊC).
%*
[SV13703( ALL)03/95]
Synthetic engine oils which are CERTIFIED and
of the preferred viscosity may be used in your
engine. The engine oil and oil filter must still be
changed according to the maintenance schedule.
File:rcsvv.ex
Update:Wed Jun 28 16:02:20 1995
Page 263 of 342
![FORD CROWN VICTORIA 1996 1.G Owners Manual 247 %
*
[SV13775( ALL)01/95]
Checking and Adding Engine Oil
*
[SV13800( ALL)03/95]
Since the proper amount of engine oil is
important for safe engine operation, check the oil
using the dipstick each t FORD CROWN VICTORIA 1996 1.G Owners Manual 247 %
*
[SV13775( ALL)01/95]
Checking and Adding Engine Oil
*
[SV13800( ALL)03/95]
Since the proper amount of engine oil is
important for safe engine operation, check the oil
using the dipstick each t](/img/11/4772/w960_4772-262.png)
247 %
*
[SV13775( ALL)01/95]
Checking and Adding Engine Oil
*
[SV13800( ALL)03/95]
Since the proper amount of engine oil is
important for safe engine operation, check the oil
using the dipstick each time you put fuel in
your vehicle. Remember the engine must be off,
the oil must be warm and the vehicle must be
parked on level ground.
%*
[SV13900( ALL)04/95]
Checking the engine oil level:
*
[SV14000( ALL)02/95]
1. Turn the engine off after it has warmed up
and allow a few minutes for the engine oil
to drain back into the oil pan.
*
[SV14025( BCGV)03/95]
2. Set the parking brake, making sure the
gearshift is securely latched in P (Park).
*
[SV14100( ALL)02/95]
3. Open the hood. Protect yourself from engine
heat.
*
[SV14200( ALL)03/95]
4. Locate the engine oil dipstick (highlighted in
yellow) and carefully pull it out of the
engine.
*
[SV14300( ALL)01/95]
5. Wipe the dipstick clean and put it back into
position, making sure it is fully seated.
[SV14400( GV)08/93]
one inch art:0000970-A
Engine oil dipstick
*
[SV14500( ALL)03/95]
6. Carefully, pull the dipstick out again. If the
oil level is below the ªADD 1 QTº line, add
engine oil as necessary. If the oil level is
beyond the letter ªFº in Full, engine damage
or high oil consumption may occur and
some oil must be removed from the engine.
File:rcsvv.ex
Update:Wed Jun 28 16:02:20 1995
Page 264 of 342
![FORD CROWN VICTORIA 1996 1.G Owners Manual 248
*
[SV14600( ALL)01/95]
7. Put the dipstick back in and make sure it is
fully seated.
*
[SV14800( ALL)01/95]
It may be necessary to add some oil between oil
changes. Make sure you use a CERTIFIED
e FORD CROWN VICTORIA 1996 1.G Owners Manual 248
*
[SV14600( ALL)01/95]
7. Put the dipstick back in and make sure it is
fully seated.
*
[SV14800( ALL)01/95]
It may be necessary to add some oil between oil
changes. Make sure you use a CERTIFIED
e](/img/11/4772/w960_4772-263.png)
248
*
[SV14600( ALL)01/95]
7. Put the dipstick back in and make sure it is
fully seated.
*
[SV14800( ALL)01/95]
It may be necessary to add some oil between oil
changes. Make sure you use a CERTIFIED
engine oil of the preferred viscosity. Your
vehicle's warranty coverage may not apply if
engine damage is caused by the use of improper
engine oil.
*
[SV15000( ALL)03/95]
Add engine oil through the oil filler cap
highlighted in yellow. To add oil, remove the
filler cap and use a funnel to pour oil into the
opening. Be careful not to overfill the engine.
Recheck the oil level after you finish adding oil.
%*
[SV16300( ALL)01/95]
Changing the Engine Oil and the Oil Filter
*
[SV16400( ALL)04/95]
Change the engine oil and oil filterper the
following, whichever occurs first.
*
[SV16500( ALL)04/95]
one third page art:0060618-C
*
[SV16800( ALL)04/95]
Refer to theMaintenance Schedule and Record
booklet for additional information.
%*
[SV16900( ALL)04/95]
NOTE: Always dispose of used automotive
fluids in a responsible manner. Follow
your community's standards for
disposing of these types of fluids. Call
your local recycling center to find out
about recycling automotive fluids.
File:rcsvv.ex
Update:Wed Jun 28 16:02:20 1995
Page 265 of 342
![FORD CROWN VICTORIA 1996 1.G Owners Manual 249
*
[SV17275( ALL)05/95]
RWARNING
Continuous contact with USED motor oil
has caused cancer in laboratory mice.
*
[SV17285( ALL)05/95]
Protect your skin by washing with soap and
water.
%
*
[SV17300( FORD CROWN VICTORIA 1996 1.G Owners Manual 249
*
[SV17275( ALL)05/95]
RWARNING
Continuous contact with USED motor oil
has caused cancer in laboratory mice.
*
[SV17285( ALL)05/95]
Protect your skin by washing with soap and
water.
%
*
[SV17300(](/img/11/4772/w960_4772-264.png)
249
*
[SV17275( ALL)05/95]
RWARNING
Continuous contact with USED motor oil
has caused cancer in laboratory mice.
*
[SV17285( ALL)05/95]
Protect your skin by washing with soap and
water.
%
*
[SV17300( ALL)03/95]
Engine Coolant
%*
[SV17400( ALL)03/95]
Checking the Engine Coolant
*
[SV17500( ALL)01/95]
NOTE: Be sure to read and understand
Precautions When Servicing Your
Vehicleat the beginning of this chapter.
*
[SV17600( BCGV)05/95]
RWARNING
The cooling fan is automatic and may
come on at any time. Always disconnect
the negative terminal of the battery before
working near the fan.
%*
[SV17800( ALL)05/94]
Your vehicle's coolant protects your engine from
overheating in the summer and from freezing in
the winter. Check the level of the coolant at least
once a month. Simply look at the engine coolant
reservoir located in the engine compartment. To
locate the reservoir, see the diagram of your
vehicle's engine underEngine Type, in this
chapter.
*
[SV17850( ALL)05/95]
The coolant additives also protect the entire
cooling system from internal passageway
corrosion and these additives lubricate the water
pump. The coolant should be serviced as noted
in theMaintenance Schedule and Recordbooklet.
File:rcsvv.ex
Update:Wed Jun 28 16:02:20 1995
Page 266 of 342
![FORD CROWN VICTORIA 1996 1.G Owners Manual 250 [SV18000( BCGV)05/94]
half page art:0010761-CThe engine coolant recovery reservoir
%*
[SV18600( ALL)11/94]
Checking hoses
*
[SV18700( ALL)11/94]
Inspect all engine and heater system hoses and
hose FORD CROWN VICTORIA 1996 1.G Owners Manual 250 [SV18000( BCGV)05/94]
half page art:0010761-CThe engine coolant recovery reservoir
%*
[SV18600( ALL)11/94]
Checking hoses
*
[SV18700( ALL)11/94]
Inspect all engine and heater system hoses and
hose](/img/11/4772/w960_4772-265.png)
250 [SV18000( BCGV)05/94]
half page art:0010761-CThe engine coolant recovery reservoir
%*
[SV18600( ALL)11/94]
Checking hoses
*
[SV18700( ALL)11/94]
Inspect all engine and heater system hoses and
hose connections for deterioration, leaks, and
loose hose clamps as specified in theMaintenance
Schedule and Recordbooklet. Repair or replace
with Motorcraft hoses or equivalent as necessary.
*
[SV18800( ALL)01/95]
Adding engine coolant
*
[SV18900( ALL)05/95]
RWARNING
Do not put engine coolant in the container
for the windshield washer fluid.
*
[SV18950( ALL)05/95]
If sprayed to clean the glass, engine coolant or
antifreeze could make it difficult to see through
the windshield.
File:rcsvv.ex
Update:Wed Jun 28 16:02:20 1995
Page 267 of 342
![FORD CROWN VICTORIA 1996 1.G Owners Manual 251 [SV19010( GV)05/95]
RWARNING
Never remove the pressure cap while the
engine is running or hot.
[SV19030( ALL)05/95]
Follow these steps to avoid personal injury that
can be caused by escaping steam FORD CROWN VICTORIA 1996 1.G Owners Manual 251 [SV19010( GV)05/95]
RWARNING
Never remove the pressure cap while the
engine is running or hot.
[SV19030( ALL)05/95]
Follow these steps to avoid personal injury that
can be caused by escaping steam](/img/11/4772/w960_4772-266.png)
251 [SV19010( GV)05/95]
RWARNING
Never remove the pressure cap while the
engine is running or hot.
[SV19030( ALL)05/95]
Follow these steps to avoid personal injury that
can be caused by escaping steam or engine
coolant.
*
[SV19060( GV)01/95]
1. Before you remove the cap, turn the engine
off and let it cool. Even when the engine is
cool, be careful when you remove the
pressure cap.
[SV19145( ALL)03/95]
2. When the engine is cool, wrap a thick towel
around the cap and turn it slowly
counterclockwise to unscrew.
*
[SV19150( ALL)03/95]
3. Step back while the pressure releases.
[SV19160( ALL)12/94]
4. When you are sure that all the pressure has
been released, use the cloth to press the cap
down, turn it, and remove it.
*
[SV19175( GV)02/95]
5. Stand away from the reservoir opening. Hot
steam may blow out or hot engine coolant
may even splash out.
*
[SV19190( ALL)03/95]
To find out how much engine coolant mixture
your vehicle's coolant system can hold, seeRefill
capacities for fluidsin the Index.
% [SV19200( ALL)12/94]
Add engine coolant only to the recovery
reservoir.If the coolant level is low, add a 50/50
or appropriate mixture of water and the type of
engine coolant that Ford specifies. You may add
water by itself only in an emergency, but you
should replace it with a 50/50 or appropriate
mixture as soon as possible.
*
[SV19300( ALL)01/95]
Have your dealer check the engine cooling
system for leaks if you have to add more than a
quart (liter) of engine coolant more than once a
month.
File:rcsvv.ex
Update:Wed Jun 28 16:02:20 1995
Page 268 of 342
![FORD CROWN VICTORIA 1996 1.G Owners Manual 252
*
[SV19350( ALL)02/95]
Ford Premium Cooling System Fluid is an
optimized formula that will protect all metals
and rubber elastomers used in Ford engines for
four years or 50,000 miles (80,000 km). FORD CROWN VICTORIA 1996 1.G Owners Manual 252
*
[SV19350( ALL)02/95]
Ford Premium Cooling System Fluid is an
optimized formula that will protect all metals
and rubber elastomers used in Ford engines for
four years or 50,000 miles (80,000 km).](/img/11/4772/w960_4772-267.png)
252
*
[SV19350( ALL)02/95]
Ford Premium Cooling System Fluid is an
optimized formula that will protect all metals
and rubber elastomers used in Ford engines for
four years or 50,000 miles (80,000 km). It is not
necessary and not recommended to use
supplemental coolant additives in your gasoline
powered vehicle. These additives may harm
your engine cooling system. Follow the
recommended service interval for changing your
engine coolant.
*
[SV19450( ALL)04/94]
NOTE: When you change or add engine
coolant, it is important to maintain
your engine coolant concentration
between 40%(-11ÊF [-24ÊC]) and 60%
(-62ÊF [-52ÊC]),depending on your local
climate conditions. Below 40% you will
lose freeze protection and above 60%
your engine may overheat on a warm
day.
[SV19460( ALL)12/94]
NOTE: The use of an improper coolant may
void your warranty for the engine
cooling system. Use only a premium
nationally recognized brand name
engine coolant. Do not use alcohol,
methanol antifreeze or engine coolant
mixed with alcohol or methanol
antifreeze. If you do not use the proper
coolant, the aluminum radiator on your
vehicle will corrode.
*
[SV19470( ALL)05/95]
Ford Motor Company expressly authorizes the
Ford Rotunda engine coolant recycling process
and chemicals. Use only Ford Rotunda recycled
engine coolant or an equivalent recycled engine
coolant that is certified by the supplier to meet
Ford specification ESE-M97B44-A.
File:rcsvv.ex
Update:Wed Jun 28 16:02:20 1995
Page 269 of 342
![FORD CROWN VICTORIA 1996 1.G Owners Manual 253 %
*
[SV19480( ALL)04/95]
NOTE: Always dispose of used automotive
fluids in a responsible manner. Follow
your communitys standards for
disposing of these types of fluids. Call
your local recycling FORD CROWN VICTORIA 1996 1.G Owners Manual 253 %
*
[SV19480( ALL)04/95]
NOTE: Always dispose of used automotive
fluids in a responsible manner. Follow
your communitys standards for
disposing of these types of fluids. Call
your local recycling](/img/11/4772/w960_4772-268.png)
253 %
*
[SV19480( ALL)04/95]
NOTE: Always dispose of used automotive
fluids in a responsible manner. Follow
your community's standards for
disposing of these types of fluids. Call
your local recycling center to find out
about recycling automotive fluids.
*
[SV19500( ALL)03/95]
Use Ford Premium Cooling System Fluid
E2FZ-19549-AA (in Canada, Motorcraft CXC-8-B)
or an equivalent engine coolant that meets Ford
Specification ESE-M97B44-A.
*
[SV19550( ALL)01/95]
Leave the engine coolant in all year. Make sure
that the coolant will not freeze at the
temperature level in which you drive during
winter months. Keep a mixture of engine coolant
in your engine that has a protection rating of at
least-34ÊF (-37ÊC), orwhatever protection rating
is appropriate for the climate in which you live.
%*
[SV20100( ALL)04/95]
Engine coolant drain and flush
*
[SV20200( ALL)11/94]
Proper procedures for a complete coolant drain
and flush of the cooling system can be found in
theCar Service Manual. Following these
recommended procedures will ensure that the
specified coolant level and a 50/50 or
appropriate mixture of coolant and water is
maintained.
%*
[SV20300( ALL)02/95]
Engine coolant refill procedure
*
[SV20400( ALL)01/95]
When the entire cooling system is drained and
refilled, the following procedure should be used
to ensure a complete fill:
*
[SV20450( ALL)05/95]
NOTE: It is imperative the following
procedure be adhered to. Failure to do
so could result in damage to your
engine.
File:rcsvv.ex
Update:Wed Jun 28 16:02:20 1995
Page 270 of 342
![FORD CROWN VICTORIA 1996 1.G Owners Manual 254
*
[SV22014( ALL)03/95]
q
With the engine OFF and cool, remove the
pressure cap, located on the coolant reservoir.
Remove the heater hose and clamp, located
on the rear of the intake manifold.
*
[S FORD CROWN VICTORIA 1996 1.G Owners Manual 254
*
[SV22014( ALL)03/95]
q
With the engine OFF and cool, remove the
pressure cap, located on the coolant reservoir.
Remove the heater hose and clamp, located
on the rear of the intake manifold.
*
[S](/img/11/4772/w960_4772-269.png)
254
*
[SV22014( ALL)03/95]
q
With the engine OFF and cool, remove the
pressure cap, located on the coolant reservoir.
Remove the heater hose and clamp, located
on the rear of the intake manifold.
*
[SV22021( ALL)03/95]
q
Add a 50/50 mixture of specified coolant and
water to the coolant reservoir. Refer toRefill
Capacitieslater in this chapter for the correct
amount. Add coolant to the reservoir until
the coolant continuously flows out of the tube
in the rear of engine. Reattach hose and
secure clamp.
[SV22026( ALL)03/95]
q
Continue to fill the reservoir until the coolant
is at the FULL COLD level.
*
[SV22031( ALL)05/95]
q
Reinstall the pressure cap to the fully
installed position.
*
[SV22036( ALL)05/95]
q
Start and idle the engine until the radiator
upper hose is warm (this indicates the
thermostat is open and coolant is flowing
through the entire system).
*
[SV22041( ALL)03/95]
q
Immediately shut off the engine and let cool.
Cautiously remove the pressure relief cap and
add a 50/50 mixture of specified coolant and
water until the coolant is at the COLD FILL
level in the coolant reservoir.
*
[SV22046( ALL)03/95]
q
Reinstall the pressure cap securely.
*
[SV22050( ALL)03/95]
q
Check for leaks at the draincock.
*
[SV22055( ALL)03/95]
q
Recheck the engine coolant level, using the
recommended procedure, after one or two
occasions of vehicle use.
File:rcsvv.ex
Update:Wed Jun 28 16:02:20 1995
