FORD E SERIES 1996 4.G Owners Manual

120 %
*
[FV18101(BEF )02/95]
Replacing lost transmitters
*
[FV18200(BEF )06/95]
In the event a transmitter is lost, you should
take all your vehicle's transmitters to your
dealer to have the remote entry system
deprogrammed for the lost transmitter. This is
necessary to prevent further unauthorized use of
the lost transmitter.
*
[FV18301(BEF )02/95]
You can also purchase additional transmitters
(up to 4 transmitters can be used) from your
dealer. You will need to take all your
transmitters to the dealer so they can program
them to the remote entry system all at the same
time.
*
[FV18400( E )03/94]
Memory lock (sliding door)
[FV18500( E )05/91]
Your Econoline has a ªMemory Lockº feature
that does not require the sliding door or the
60/40 cargo doors to be closed before using the
power locks. If you lock your doors with the
power lock switch or the Remote Transmitter
while the door is open, the door will
automatically lock after it is closed.
*
[FV18601(BEF )04/95]
Illuminated Entry System (If equipped)
[FV18701(BEF )04/95]
This system will provide illumination of the
vehicle's interior courtesy lamps when either
outside front door handle is pulled or when the
Remote Entry System is used to unlock the door
or sound the Personal Alarm. The system will
automatically turn off after approximately 25
seconds or when the ignition is turned to the
START or ACCESSORY position.
*
[FV18801(BEF )04/94]
NOTE: The inside lights will not turn off if
you have turned them on with the
dimmer knob or if any door is open.
File:08ltfve.ex
Update:Wed Apr 17 08:47:13 1996

121
% [FV19103( E )04/95]
Anti-theft system (If equipped)
*
[FV19106( E )05/95]
When armed, this system helps protect your
vehicle against break-ins or theft.
%*
[FV19109( E )05/95]
When an unauthorized entry occurs, the system
triggers and will:
*
[FV19112( E )05/95]
q
flash the headlamps, parking lamps, and
alarm indicator lamp
*
[FV19115( E )06/95]
q
honk the horn
*
[FV19118( E )05/95]
q
disable the starting circuit to prevent the
vehicle from being started
%*
[FV19121( E )05/95]
Arming the system
*
[FV19124( E )05/95]
1. Remove the key from the ignition.
*
[FV19130( E )05/95]
2. Open any door. The alarm indicator light
will start flashing to remind you to arm the
system.
*
[FV19133( E )05/95]
3. Lock the doors by using the power door
lock switch. The alarm indicator light will
now glow steadily.
*
[FV19134( E )04/95]
NOTE: The system can also be armed by
pressing the LOCK button on the
remote transmitter after the doors have
been closed.
*
[FV19136( E )04/95]
4. Close all doors. The alarm indicator light
will then remain on steadily for
approximately 30 more seconds and then go
out. When the light goes out the system is
armed.
File:08ltfve.ex
Update:Wed Apr 17 08:47:13 1996

122
*
[FV19139( E )06/95]
NOTE: Be sure to close all doors completely. If
not, the alarm indicator light will
remain on. Remember, your anti-theft
system is armed only after the alarm
indicator light remains on steadily for
approximately 30 seconds after the last
door is closed, and then goes out.
*
[FV19154( E )04/95]
The anti-theft system is designed to work with
the factory installed remote entry system. It may
not work with other remote entry systems.
%*
[FV19157( E )05/95]
Disarming an untriggered anti-theft system
[FV19160( E )03/93]
You can disarm the system by unlocking either
front door or the rear door with your door key.
Turn the key all the way to the end of travel or
the system will not disarm.
*
[FV19163( E )04/95]
You can also disarm the system by unlocking
the driver's door by using the UNLOCK button
of the remote entry transmitter.
*
[FV19166( E )04/95]
If the system is armed and you remain in your
vehicle, simply insert the key into the ignition
and turn it to ON. This disarms the system and
allows you to open the door and exit without
triggering the system.
%*
[FV19187( E )05/95]
Disarming a triggered system
*
[FV19190( E )05/95]
The alarm can be disarmed by:
*
[FV19196( E )04/95]
q
unlocking any door with the key, or
*
[FV19199( E )05/95]
q
using the UNLOCK button of the remote
entry transmitter
*
[FV19202( E )05/95]
NOTE: The flashing lights and honking horn
will shut off automatically within 2
minutes 45 seconds after the system is
triggered. It will trigger again if
another intrusion occurs. However, the
starter circuit remains disabled until
the system is disarmed.
File:08ltfve.ex
Update:Wed Apr 17 08:47:13 1996

123
*
[FV19250(BEF )02/95]
Windows
[FV19800( E )02/91]
Side, cargo door and rear door window
controls (If equipped)
[FV19900( E )04/89]
To open, press down on the window latches.
Then depress the levers on each side of the latch
and pull the latch upward. Move the latch out
and depress into the open position. To close,
depress the levers on each side of the latch. Lift
the latch and pull inward, then press down on
the latch to lock the levers.
[FV20000( E )04/89]
quarter page art:0020216-A
Window latch
[FV20100( E )05/95]
RWARNING
Rear doors, rear door flipper windows,
and van conversion windows, should be
closed while driving. This will prevent
exhaust fumes from being drawn into
your vehicle.
[FV20200( E )03/95]
If you can't avoid leaving one or all of the
above windows open, you should pay careful
attention to the following precautions:
[FV20300( E )03/95]
q
Adjust your climate control system to force
outside air into your vehicle.
[FV20400( E )03/95]
q
Completely open the outside air vents, if your
vehicle is so equipped.
File:08ltfve.ex
Update:Wed Apr 17 08:47:13 1996

124
*
[FV22901(BEF )03/91]
Using the Power Windows (If equipped)
*
[FV23001(BEF )06/95]
Each door has a power control that opens and
closes the window on that door. The driver's
door has a master control switch that operates
both front door windows. You must place the
ignition switch in the ON or ACC position to
use your power window controls.
*
[FV23501(BEF )05/95]
RWARNING
Do not let children play with the power
windows. They may seriously hurt
themselves. Make sure occupants are clear
of the window(s) before closing.
*
[FV23800(BEF )05/95]
quarter page art:0020203-C
Master control switch
*
[FV24101(BEF )01/95]
Seats
%*
[FV24801(BEF )05/90]
Adjusting the Front Seat Manually
*
[FV24901(BEF )06/95]
To move the front seat forward or rearward:
*
[FV25001(BEF )06/95]
1. Find the adjustment lever at the lower left
corner of the front seat.
*
[FV25101(BEF )06/95]
2. Push the lever to the left to unlatch the seat.
*
[FV25201(BEF )06/95]
3. Move the seat to the desired position.
*
[FV25301(BEF )06/95]
4. Release the lever to latch the seat in its new
position. Make sure the seat locks securely in
place.
File:08ltfve.ex
Update:Wed Apr 17 08:47:13 1996

125
*
[FV26001(BEF )05/95]
RWARNING
Never adjust the driver's seat or seatback
when the vehicle is moving.
*
[FV26100(BEF )05/95]
RWARNING
Do not pile cargo higher than the
seatbacks to avoid injuring people in a
collision or sudden stop.
*
[FV26200(BEF )06/95]
RWARNING
To reduce the risk of serious injury in a
collision, always drive and ride with your
seatback upright and the lap belt snug
and low across the hips.
*
[FV26300(BEF )05/95]
RWARNING
To reduce the risk of serious injury in a
collision, children should always ride with
the seatback upright.
%*
[FV26400(BEF )06/95]
Reclining Bucket Seats
*
[FV27301(BEF )02/92]
You can tilt the seat back of your bucket seats
backward.
[FV27450( E )03/93]
1. On the right hand side of the seat, lift the
recliner handle up and hold it in place.
*
[FV27501(BEF )10/89]
2. Lean against the back of the seat and adjust
it to the position you want.
*
[FV27601(BEF )10/89]
3. Release the handle to lock the seat back in
place.
*
[FV27701(BEF )10/89]
4. To return the seat back upright, lift the
handle and lean forward.
File:08ltfve.ex
Update:Wed Apr 17 08:47:13 1996

126 [FV27901( E )12/91]
one third page art:0020224-CReclining bucket seat
%*
[FV31201( E )12/91]
Quick Release Rear Captain Chairs
[FV31301( E )12/91]
Second row
*
[FV31400( E )12/91]
To remove:
[FV31700( E )12/91]
1. Disengage the lap/shoulder safety belt from
the seat by inserting a key or similar device
into the slot in the detachable anchor and
lifting upward. Stow the tongue end of the
detachable anchor as shown.
[FV31901( E )02/92]
2. Pull the seat latch handle, located on the
right hand side of the seat base, and pull
seat toward the right hand side of vehicle to
disengage four pins from the floor mount.
[FV32001( E )12/91]
one third page art:0020915-A
Removing the quick release rear captains chair
File:08ltfve.ex
Update:Wed Apr 17 08:47:13 1996

127 [FV32101( E )12/91]
3. Remove the seat from the vehicle.
*
[FV32200( E )12/91]
To install the rear bucket seat:
[FV32400( E )12/91]
1. Lift the seat assembly into the vehicle and
position the seat to the floor mount.
[FV32600( E )02/92]
2. Engage the four seat pins into their
respective floor mount holes and push the
seat toward the left hand side of the vehicle
to fully engage.
[FV32700( E )02/92]
one third page art:0020916-B
Installing the quick release rear captains chair
[FV33001( E )12/91]
3. Push the seat latch handle downward to a
full stop. This locks the seat in position.
[FV33101( E )12/91]
4. Before you engage the safety belt, be sure it
is not twisted. Remove any twist, then insert
the tongue end of the detachable anchor into
the detachable anchor until you hear a
ªsnapº and feel the latch engage.
*
[FV33201( E )05/95]
RWARNING
Check to see that the seat is latched
securely in position. Keep floor area free
of objects that would prevent proper seat
engagement. Never attempt to adjust the
seat latch while the vehicle is in motion.
File:08ltfve.ex
Update:Wed Apr 17 08:47:13 1996

128 [FV33400( E )12/91]
three fourths page art:0020783-B
File:08ltfve.ex
Update:Wed Apr 17 08:47:13 1996

129 [FV33501( E )05/95]
two third page art:0020856-C
Rear seat shoulder safety belt Ð stowage (with seat
removed)
% [FV36101( E )02/92]
Quick Release Rear Passenger Seat
Assembly
% [FV36201( E )02/95]
Three Passenger and Four Passenger Bench
and Bed Seats
[FV36300( E )01/89]
To remove the seat assembly:
*
[FV36400( E )06/92]
1. Disengage the lap/shoulder safety belt from
the seat by inserting a key or screwdriver
into the slot in the detachable anchor and
lifting upward. Stow the tongue end of the
detachable anchor as shown in the
illustration.
File:08ltfve.ex
Update:Wed Apr 17 08:47:13 1996
