Page 77 of 388
![FORD E SERIES 1996 4.G User Guide 74
*
[LG05900( ALL)01/95]
Charging System Light
*
[LG06000( ALL)03/95]
This light, shown as a battery symbol on your
cluster, indicates that your battery is not being
charged and that you need to have FORD E SERIES 1996 4.G User Guide 74
*
[LG05900( ALL)01/95]
Charging System Light
*
[LG06000( ALL)03/95]
This light, shown as a battery symbol on your
cluster, indicates that your battery is not being
charged and that you need to have](/img/11/4788/w960_4788-76.png)
74
*
[LG05900( ALL)01/95]
Charging System Light
*
[LG06000( ALL)03/95]
This light, shown as a battery symbol on your
cluster, indicates that your battery is not being
charged and that you need to have the electrical
system checked.
*
[LG06050( ALL)05/95]
one inch art:0020777-A
Charging system light
*
[LG06100( ALL)05/95]
This light comes on every time you turn the
ignition to the ON or START position (engine
off). The light should go off when the engine
starts and the alternator begins to charge.
%*
[LG06305(BEF )06/93]
Supplemental Air Bag Readiness Light and
Tone Generator
*
[LG06310(BEF )06/93]
This light illuminates for six seconds when the
ignition is turned to the ON position. If the light
fails to illuminate, continues to flash, remains on,
or if a series of five beeps is heard, have the
system serviced as soon as possible.
*
[LG06315( E )05/95]
one inch art:0020778-B
Supplemental air bag readiness light
File:05ltlge.ex
Update:Wed Apr 17 08:49:15 1996
Page 78 of 388
![FORD E SERIES 1996 4.G User Guide 75
*
[LG06325( E )04/95]
Anti-Theft Alarm Light (If equipped)
*
[LG06335( E )04/95]
This light flashes on and off when the ignition
switch is OFF and any door is opened. As soon
as you lock the doors, FORD E SERIES 1996 4.G User Guide 75
*
[LG06325( E )04/95]
Anti-Theft Alarm Light (If equipped)
*
[LG06335( E )04/95]
This light flashes on and off when the ignition
switch is OFF and any door is opened. As soon
as you lock the doors,](/img/11/4788/w960_4788-77.png)
75
*
[LG06325( E )04/95]
Anti-Theft Alarm Light (If equipped)
*
[LG06335( E )04/95]
This light flashes on and off when the ignition
switch is OFF and any door is opened. As soon
as you lock the doors, the light glows steadily.
Within 30 seconds of closing all the doors, the
light goes out. This indicates that the alarm
system is armed.
*
[LG06345( E )04/95]
one inch art:0020921-A
Anti-Theft Alarm Light
*
[LG06400( ALL)05/94]
Battery Voltage Gauge (Voltmeter)
*
[LG06601( ALL)05/94]
This gauge shows you the battery voltage when
the ignition key is in the ON position.
*
[LG06700( ALL)11/89]
If you are running electrical accessories (when
the engine is off, or idling at a low speed), the
pointer may move toward the lower end of the
normal band. If it stays outside the normal band
area, have your vehicle's electrical system
checked as soon as it is safely possible.
*
[LG06701( ALL)05/95]
If the battery is operating under cold weather
conditions, the pointer may indicate in the upper
range of the NORMAL band while the battery is
charging. If you are running electrical accessories
with the engine off or idling at a low speed, or
the battery is not fully charged, the pointer may
move toward the lower end of the NORMAL
band.
*
[LG06750( ALL)05/94]
If it stays outside the NORMAL band, have your
vehicle's electrical system checked as soon as it
is safely possible.
File:05ltlge.ex
Update:Wed Apr 17 08:49:15 1996
Page 79 of 388
![FORD E SERIES 1996 4.G User Guide 76 [LG07001( E M)03/93]
quarter page art:0020863-BBattery voltage gauge
*
[LG07500( ALL)05/94]
Engine Oil Pressure Gauge
*
[LG07601( ALL)06/93]
This gauge indicates the engines oil pressure,
not the FORD E SERIES 1996 4.G User Guide 76 [LG07001( E M)03/93]
quarter page art:0020863-BBattery voltage gauge
*
[LG07500( ALL)05/94]
Engine Oil Pressure Gauge
*
[LG07601( ALL)06/93]
This gauge indicates the engines oil pressure,
not the](/img/11/4788/w960_4788-78.png)
76 [LG07001( E M)03/93]
quarter page art:0020863-BBattery voltage gauge
*
[LG07500( ALL)05/94]
Engine Oil Pressure Gauge
*
[LG07601( ALL)06/93]
This gauge indicates the engine's oil pressure,
not the oil level. However, if your engine's oil
level is low, it could affect the oil pressure. With
the engine running, the pointer should move
into the NORMAL band. If the pointer drops
below the NORMAL band while the engine is
running, you have lost oil pressure and
continued operation will cause severe engine
damage.
*
[LG07701( ALL)03/95]
If you lose engine oil pressure:
*
[LG07801( ALL)01/95]
1. Pull off the road as soon as safely possible.
*
[LG07901( ALL)04/95]
2. Shut off the engine immediately or severe
engine damage could result.
*
[LG08001( ALL)02/95]
3. Check the engine's oil level, following the
instructions on checking and adding engine
oil. Refer toEngine oilin the Index. If you
do not follow these instructions, you or
others could be injured. To assure an
accurate reading, your vehicle should be on
level ground.
*
[LG08051( ALL)03/93]
4. If the level is low, add only as much oil as
necessary before you start the engine again.
Do not overfill. Do not operate the engine if
the pointer is below the NORMAL band,
regardless of the oil level. Contact your
nearest dealer for further service actions.
File:05ltlge.ex
Update:Wed Apr 17 08:49:15 1996
Page 82 of 388
![FORD E SERIES 1996 4.G User Guide 79
*
[LG11901( ALL)04/95]
4. Check the coolant level following the
instructions on checking and adding coolant
to your engine, seeEngine Coolantin the
Index. If you do not follow these
instructions, y FORD E SERIES 1996 4.G User Guide 79
*
[LG11901( ALL)04/95]
4. Check the coolant level following the
instructions on checking and adding coolant
to your engine, seeEngine Coolantin the
Index. If you do not follow these
instructions, y](/img/11/4788/w960_4788-81.png)
79
*
[LG11901( ALL)04/95]
4. Check the coolant level following the
instructions on checking and adding coolant
to your engine, seeEngine Coolantin the
Index. If you do not follow these
instructions, you or others could be injured.
*
[LG12200( ALL)03/95]
For instructions on checking and adding coolant
to your engine, seeEngine coolantin the Index. If
you do not follow these instructions, you or
others could be injured.
[LG12375( E M)03/93]
quarter page art:0020687-C
Engine coolant temperature gauge
*
[LG12601( ALL)01/95]
Speedometer
*
[LG12700( ALL)01/95]
The speedometer tells you how many miles
(kilometers) per hour your vehicle is moving.
*
[LG12750(BEF )04/95]
Your vehicle contains a speedometer which
receives its input from the Anti-Lock brake
sensor. The speedometer is also used to provide
a speed signal for correct operation of the
vehicle's Powertrain Control Module (PCM),
electronic transmission, and speed control (if so
equipped). Because of this, it is very
IMPORTANT to change the speedometer's
internal conversion constant if the size of the
tires on the vehicle is changed. Changing the
conversion constant to the proper value when
the tires are changed will also ensure that the
speedometer retains the original factory-set
accuracy. NOTE: The conversion constant can
only be changedsix timesonce the vehicle
leaves the factory. Your Ford dealership service
personnel can change the conversion constant.
File:05ltlge.ex
Update:Wed Apr 17 08:49:15 1996
Page 197 of 388
![FORD E SERIES 1996 4.G User Guide 197
*
[DR01250( EF )01/95]
4. Apply the brake pedal and shift to N
(Neutral). (If the vehicle is shifted to P
(Park), you must repeat the previous steps.)
*
[DR01260( EF )01/95]
5. Start the vehicle.
FORD E SERIES 1996 4.G User Guide 197
*
[DR01250( EF )01/95]
4. Apply the brake pedal and shift to N
(Neutral). (If the vehicle is shifted to P
(Park), you must repeat the previous steps.)
*
[DR01260( EF )01/95]
5. Start the vehicle.](/img/11/4788/w960_4788-196.png)
197
*
[DR01250( EF )01/95]
4. Apply the brake pedal and shift to N
(Neutral). (If the vehicle is shifted to P
(Park), you must repeat the previous steps.)
*
[DR01260( EF )01/95]
5. Start the vehicle.
*
[DR01265( EF )06/95]
If you need to shift out of P (Park) by using the
alternate procedure described above, it is
possible that a fuse has blown and that your
brakelamps may also not be functional. Please
refer to the chapter titledServicing Your Econoline
in this Owner Guide for instructions on checking
and replacing fuses.
*
[DR01270( EF )05/95]
RWARNING
DO NOT DRIVE YOUR VEHICLE UNTIL
YOU VERIFY THAT THE BRAKELAMPS
ARE WORKING.
%*
[DR01300( EF )01/95]
R (Reverse)
*
[DR01400( EF )02/95]
With the gearshift in the R (Reverse) position,
the vehicle will move backward. You should
always come to a complete stop before shifting
into or out of R (Reverse).
*
[DR01500( EF )01/95]
Driving
*
[DR01600( EF )06/95]
When to use D (Drive)
*
[DR01700( EF )12/91]
This is the normal driving position. As the
vehicle picks up speed, automatic upshifts from
First gear to Second and Second to Third will
occur. The transmission automatically downshifts
as speed decreases.
*
[DR01800( EF )01/95]
When to use 2 (Second)
*
[DR01900( EF )12/91]
Use 2 (Second) to drive up moderately steep
grades, to start-up on slippery roads or to
provide engine braking on downgrades.
*
[DR02000( EF )12/91]
Do not go faster than 55 mph (88 km/h) in this
gear.
File:10ltdre.ex
Update:Wed Apr 17 08:44:07 1996
Page 206 of 388
![FORD E SERIES 1996 4.G User Guide 206
*
[DR15915( ALL)01/95]
Steering Your Vehicle
%*
[DR15945( ALL)01/95]
Your vehicle comes with power steering. Power
steering uses energy from the engine to help
steer your vehicle.
%*
[DR15950( ALL FORD E SERIES 1996 4.G User Guide 206
*
[DR15915( ALL)01/95]
Steering Your Vehicle
%*
[DR15945( ALL)01/95]
Your vehicle comes with power steering. Power
steering uses energy from the engine to help
steer your vehicle.
%*
[DR15950( ALL](/img/11/4788/w960_4788-205.png)
206
*
[DR15915( ALL)01/95]
Steering Your Vehicle
%*
[DR15945( ALL)01/95]
Your vehicle comes with power steering. Power
steering uses energy from the engine to help
steer your vehicle.
%*
[DR15950( ALL)04/95]
If the amount of effort needed to steer your
vehicle changes at a constant vehicle speed, have
the power steering system checked. If the power
steering system breaks down (or if the engine is
turned off), you can steer the vehicle manually
but it takes more effort.
*
[DR15960( ALL)01/95]
Never hold the steering wheel to the extreme
right or left for more than five seconds if the
engine is running. This can damage the power
steering pump.
*
[DR15985( ALL)05/90]
NOTE: After any severe impact such as
striking large potholes, sliding into
curbs on icy roads, or a collision
involving the front end, observe the
steering wheel alignment. If the spokes
of the steering wheel seem to be in a
different position while going straight
down the road, have the front
suspension and steering checked for
possible damage.
*
[DR21400( ALL)03/95]
Brakes
*
[DR21500( ALL)01/93]
Front Disc Brakes
*
[DR21600(BEF )06/95]
The front disc brakes are self-adjusting. They do
not require service other than periodic inspection
for pad wear.
File:10ltdre.ex
Update:Wed Apr 17 08:44:07 1996
Page 210 of 388
![FORD E SERIES 1996 4.G User Guide 210
*
[DR22950(BE )05/95]
4WABS driver warning light
[DR22955(BE )08/94]
The 4WABS computer continuously monitors the
system while driving for any electrical faults or
system malfunctions. In addition FORD E SERIES 1996 4.G User Guide 210
*
[DR22950(BE )05/95]
4WABS driver warning light
[DR22955(BE )08/94]
The 4WABS computer continuously monitors the
system while driving for any electrical faults or
system malfunctions. In addition](/img/11/4788/w960_4788-209.png)
210
*
[DR22950(BE )05/95]
4WABS driver warning light
[DR22955(BE )08/94]
The 4WABS computer continuously monitors the
system while driving for any electrical faults or
system malfunctions. In addition, the 4WABS
computer performs an initial system check called
bulb proveout when the vehicle ignition is
switched on. During bulb proveout, the amber
ªABSº light on the instrument cluster will
momentarily illuminate and then go out.
*
[DR22960(BE )03/93]
NOTE: After starting the vehicle and upon
initial drive-off, the driver may notice
a single pulse of the brake pedal and a
noise from the engine compartment.
This is part of the initial system check
and is normal.
[DR22965(BE )08/94]
Should a malfunction in the 4WABS system
occur, the amber ªABSº light on the instrument
cluster will come on and stay on indicating that
the antilock system has been shut down and the
vehicle needs to be serviced. Normal braking is
not affected unless the red brake warning light
is also illuminated.
*
[DR22970(BE )10/94]
NOTE: It is important to note that when the
ABS Warning Light is illuminated the
ABS system is disabled. The vehicle
must be serviced immediately to
restore the benefits of the Anti-lock
system.
*
[DR22975(BE )10/94]
NOTE: Mobile phones or radio transmitters
not installed by Ford Motor Company
may interfere with the Anti-lock
System. Should the Anti-lock system
activate unexpectedly or the Anti-lock
Warning Light illuminate after
installation of such a unit, have the
installation of the unit checked.
File:10ltdre.ex
Update:Wed Apr 17 08:44:07 1996
Page 217 of 388
![FORD E SERIES 1996 4.G User Guide 217
*
[DR27601(BEF )05/95]
RWARNING
To avoid injury, never run the engine
with one wheel off the ground, such as
when changing a tire.
%*
[DR27651( ALL)01/95]
High water
*
[DR27675( ALL)06/92]
Never a FORD E SERIES 1996 4.G User Guide 217
*
[DR27601(BEF )05/95]
RWARNING
To avoid injury, never run the engine
with one wheel off the ground, such as
when changing a tire.
%*
[DR27651( ALL)01/95]
High water
*
[DR27675( ALL)06/92]
Never a](/img/11/4788/w960_4788-216.png)
217
*
[DR27601(BEF )05/95]
RWARNING
To avoid injury, never run the engine
with one wheel off the ground, such as
when changing a tire.
%*
[DR27651( ALL)01/95]
High water
*
[DR27675( ALL)06/92]
Never attempt to cross water that is fast flowing
or of unknown depth.
*
[DR27701( ALL)05/90]
Do not drive through flooded areas unless you
are sure that the water is below the bottom of
the wheel hubs.
*
[DR27750( ALL)04/94]
If you must drive through high water, drive
slowly. You may have limited traction or wet
brakes, so allow extra stopping distance because
your vehicle will not stop as quickly as usual.
*
[DR27801( ALL)01/95]
After you drive through the standing water,
apply your brakes gently several times as your
vehicle moves slowly. This helps to dry the
brakes.
*
[DR27820(BEF )06/95]
NOTE: If the transmission and transfer case is
submerged in water, their fluids should
be checked and changed, if necessary.
*
[DR27825( ALL)03/93]
NOTE: All rear axle lube quantities must be
replaced every 100,000 miles
(160,000 km) or if the axle has been
submerged in water. Otherwise, the
lube should not be checked or changed
unless a leak is suspected or repair
required.
File:10ltdre.ex
Update:Wed Apr 17 08:44:07 1996
Page 245 of 388
![FORD E SERIES 1996 4.G User Guide 245
*
[RE01400( ALL)04/95]
3. Park the booster vehicle close to the hood of
the disabled vehicle.Make sure the vehicles
do not touch each other.Set the parking
brake on both vehicles and stay clear of FORD E SERIES 1996 4.G User Guide 245
*
[RE01400( ALL)04/95]
3. Park the booster vehicle close to the hood of
the disabled vehicle.Make sure the vehicles
do not touch each other.Set the parking
brake on both vehicles and stay clear of](/img/11/4788/w960_4788-244.png)
245
*
[RE01400( ALL)04/95]
3. Park the booster vehicle close to the hood of
the disabled vehicle.Make sure the vehicles
do not touch each other.Set the parking
brake on both vehicles and stay clear of the
engine cooling fan and other moving parts.
*
[RE01500( ALL)03/95]
4. Check all battery terminals and remove any
excessive corrosion before you attach the
jumper cables.
*
[RE01600( ALL)02/95]
5. Turn on the heater fan in both vehicles.
Turning on the fan helps protect the
electrical system from voltage surges. Turn
off all other switches and lights in both
vehicles to prevent possible damage to either
vehicle's electrical systems.
%*
[RE01700( ALL)05/95]
Connecting the jumper cables
*
[RE01800( ALL)03/95]
1. Connect one end of the first jumper cable to
the positive (+) terminal of the discharged
battery. (You can connect either jumper cable
to the positive (+) terminal, as long as you
use the same cable for both positive
terminals.) Most jumper cables have a red
cable and a black cable. The red cable is
generally used for the positive terminals and
the black for the negative ones.
[RE01850( E )05/91]
NOTE: DO NOT jump-start your auxilliary
battery.
*
[RE01900( ALL)04/95]
2. Connect the other end of the first cable to
the positive (+) terminal of the booster
battery.
*
[RE02000( ALL)05/95]
3. Connect one end of the second cable to the
negative (-) terminal of the booster battery
Ð NOT to the discharged battery.
*
[RE02100( ALL)04/95]
4. Connect the other end of the second cable to
a good metallic surface on the engine or
frame of the disabled vehicle.
File:11ltree.ex
Update:Wed Apr 17 08:42:44 1996
Page 257 of 388
![FORD E SERIES 1996 4.G User Guide 257 % [RE24375( E )02/89]
ten pica chart:0020318-B
*
[RE24397(BEF )02/95]
If the Engine Cranks But Does
Not Start or Does Not Start After
a Collision
*
[RE24400(BEF )04/95]
The Fuel Pump Shut-off Swit FORD E SERIES 1996 4.G User Guide 257 % [RE24375( E )02/89]
ten pica chart:0020318-B
*
[RE24397(BEF )02/95]
If the Engine Cranks But Does
Not Start or Does Not Start After
a Collision
*
[RE24400(BEF )04/95]
The Fuel Pump Shut-off Swit](/img/11/4788/w960_4788-256.png)
257 % [RE24375( E )02/89]
ten pica chart:0020318-B
*
[RE24397(BEF )02/95]
If the Engine Cranks But Does
Not Start or Does Not Start After
a Collision
*
[RE24400(BEF )04/95]
The Fuel Pump Shut-off Switch
*
[RE24500(BEF )03/95]
If the engine cranks but does not start or if you
have had a collision, the fuel pump shut-off
switch may have been triggered. The shut-off
switch is a device that stops the fuel pump
when your vehicle has been involved in a
substantial jolt.
*
[RE24600(BEF )01/95]
For information on how to check and reset the
fuel pump shut-off switch, seeFuel pump shut-off
switchin the Index.
File:11ltree.ex
Update:Wed Apr 17 08:42:44 1996
