If Brakes Do Not Grip Well or Pedal is
ªLowº
%*
[DR23200(BEF )11/89]
If brakes do not grip well, it may indicate the
rear drum brakes need adjustment. To do this,
drive the vehicle in reverse at 5 mph (8 km/h)
on level, dry pavement. Stop the vehicle by
firmly applying the brakes. Repeat this
procedure four or five times.
*
[DR23250( ALL)11/89]
If during normal operation the brake pedal
seems ªlowº, it may indicate the need for a
brake system inspection and/or service. You
should have your brakes checked as soon as
possible.
*
[DR23300( ALL)02/95]
Occasional brake squeal during light to moderate
stops does not affect the function of the brake
system and is normal. However, if the squeal
becomes annoyingly loud or increases
significantly in frequency of occurrence, return
the vehicle to your dealer for inspection.
*
[DR23400(BEF )11/89]
RWARNING
Modifications to the suspension spring
rates and/or vehicle ride height may
adversely affect vehicle stopping ability.
*
[DR23500(BEF )07/92]
If Brakes Pull
*
[DR23600(BEF )05/95]
q
Check tire pressure.
*
[DR23700(BEF )07/92]
q
Perform the self-adjustment procedure
described underIf Brakes Do Not Grip Well or
Pedal is ªLow.º
*
[DR23800(BEF )05/95]
If pull occurs during the first 500 miles
(800 km), make 10 moderately fast stops from
40 mph (65 km/h) and then perform the
self-adjustment procedure above. It may be
necessary to repeat this operation to properly
seat new brake linings and pads.
File:10ltdre.ex
Update:Wed Apr 17 08:44:07 1996

212 %
*
[DR24000( ALL)01/93]
Stopping Distances
*
[DR24100( ALL)11/89]
Stopping distances vary with different loads and
driving conditions. Use caution when
encountering new conditions and acquaint
yourself with vehicle performance. Take full
advantage of engine braking power when
slowing down.
%*
[DR24200( ALL)01/95]
Applying the Brakes
*
[DR24300( ALL)05/95]
Apply the brake pedal gradually. Use the
ªsqueezeº technique Ð push on the brake pedal
with a steadily increasing force. This allows the
wheels to continue to roll while you are slowing
down, which lets you steer properly.
*
[DR24400( ALL)05/95]
RWARNING
Do not drive with your foot resting on the
brake pedal. This will increase your
vehicle's stopping distance and may also
cause brake damage.
*
[DR24500( ALL)05/95]
RWARNING
If you are driving down a long or steep
hill, shift to a lower gear. Do not apply
your brakes continuously, as they may
overheat and become less effective.
*
[DR24600( ALL)03/95]
Using the Parking Brake
*
[DR24650(BEF )01/95]
The parking brake should be used whenever you
park your vehicle.
[DR24830( E M)06/95]
The parking brake pedal is suspended just below
the bottom of the instrument panel to the left of
the service brake. To set the parking brake while
parking your vehicle, press the brake pedal with
your right foot and hold it while you push the
parking brake pedal down firmly with your left
foot.
File:10ltdre.ex
Update:Wed Apr 17 08:44:07 1996

213 [DR24940( E )03/91]
one third page art:0020836-A
Parking Brake
[DR24942( E )03/91]
To release the parking brake, press the service
pedal with your right foot and hold it while you
push the parking brake pedal down firmly with
your left foot.
[DR24945( E )04/94]
one third page art:0020893-A
Parking brake (Commercial stripped chassis only)
[DR24946( E )04/94]
To release the parking brake for Commerical
Stripped Chassis vehicles, press the service brake
pedal with your right foot and pull the parking
brake release lever.
File:10ltdre.ex
Update:Wed Apr 17 08:44:07 1996

214
*
[DR24960( E M)05/95]
RWARNING
Always set the parking brake fully and
make sure the gearshift is latched in P
(Park). Turn off the ignition whenever you
leave your vehicle.
*
[DR25050( ALL)01/93]
RWARNING
If the parking brake is fully released, but
the Brake System light remains on, have
the brakes checked immediately. They
may not be working properly.
*
[DR25100(BEF )06/95]
The parking brake is not designed to stop a
moving vehicle, but you can use the parking
brake to stop your vehicle in an emergency if
the normal brakes fail. However, since the
parking brake applies only the rear brakes, the
stopping distance will increase greatly and the
handling of your vehicle will be adversely
affected.
%
*
[DR25200( ALL)01/95]
Driving Under Special Conditions
*
[DR25250( ALL)01/95]
Tips for Safe Driving
*
[DR25301( ALL)05/95]
As with any new vehicle, yours may drive and
handle differently from your previous vehicle.
Use care until you become accustomed to its
various features and driving characteristics.
*
[DR25350( ALL)03/95]
Operate your vehicle within reasonable limits.
Sudden acceleration, deceleration, turning, or
combinations of these maneuvers can cause a
vehicle to behave differently than anticipated.
File:10ltdre.ex
Update:Wed Apr 17 08:44:07 1996

215
*
[DR25501( ALL)02/95]
Wheel Spin
*
[DR25550( ALL)11/92]
q
Extreme acceleration can cause the rear
wheels to spin, perhaps resulting in reduced
steering control.
*
[DR25601( ALL)05/90]
If the wheels spin during vehicle start-up, shift
to a different gear:
*
[DR25800( ALL)03/93]
q
Electronic 4-Speed Automatic Transmission
E4OD: use 2 (Second)
*
[DR26050( EF )05/90]
q
3-Speed Automatic (C6): use 2 (Second)
*
[DR26301( ALL)01/89]
Move forward slowly and evenly. If this does
not work, try rocking the vehicle.
%*
[DR26550( ALL)05/90]
High Speed Driving
*
[DR26575( ALL)06/95]
Ford Motor Company recommends obeying
posted speed limits.
*
[DR26601( ALL)05/95]
RWARNING
Driving too fast for conditions creates the
possibility of loss of vehicle control.
Driving at very high speeds for extended
periods of time may result in damage to
vehicle components.
*
[DR26625(BEF )12/91]
Speed limiter
*
[DR26652(BEF )05/95]
All models are equipped with an Electronic
Engine Control (EEC) system which limits the
maximum engine speed and thus road speed in
top gear. Vehicle operation is normal since the
controlled maximum speed is above posted
highway speeds in North America.
File:10ltdre.ex
Update:Wed Apr 17 08:44:07 1996

216 %
*
[DR26701( ALL)01/95]
Driving in Bad Weather
%*
[DR26750( ALL)01/95]
Slippery roads
*
[DR26801( ALL)03/95]
Drive cautiously on wet or snowy roads:
*
[DR26850( ALL)03/95]
q
Do not quickly move the steering wheel
unless necessary.
*
[DR26901( ALL)01/95]
q
Drive slower than you normally would.
*
[DR26951( ALL)01/95]
q
Give your vehicle more distance to stop.
*
[DR27025(BEF )06/95]
q
To stop on ice, shift to N (Neutral) below
10 mph (16 km/h) and gently pump brakes.
(Except with 4WAL)
*
[DR27050( ALL)02/93]
q
Consider using one of the lower gears.
*
[DR27201( E M)06/95]
RWARNING
To avoid skidding and losing control on
slippery roads, do not downshift into 1
(First) when you are moving faster than
20 mph (32 km/h).
*
[DR27401( E )01/93]
RWARNING
The Anti-Lock Brake System may not
prevent brake lock-up on extremely
slippery surfaces.
*
[DR27450(BEF )03/95]
Traction-Lok Rear Axle (If equipped)
*
[DR27501(BEF )03/95]
This axle provides added drive away traction on
slippery surfaces, particularly when one or more
wheels are on a surface with poor traction.
*
[DR27550(BEF )03/93]
Extended use of other than matching size tires
on a Traction-Lok rear axle could result in a
permanent reduction in effectiveness. This loss of
effectiveness does not affect normal driving and
should not be noticeable to the driver.
File:10ltdre.ex
Update:Wed Apr 17 08:44:07 1996

217
*
[DR27601(BEF )05/95]
RWARNING
To avoid injury, never run the engine
with one wheel off the ground, such as
when changing a tire.
%*
[DR27651( ALL)01/95]
High water
*
[DR27675( ALL)06/92]
Never attempt to cross water that is fast flowing
or of unknown depth.
*
[DR27701( ALL)05/90]
Do not drive through flooded areas unless you
are sure that the water is below the bottom of
the wheel hubs.
*
[DR27750( ALL)04/94]
If you must drive through high water, drive
slowly. You may have limited traction or wet
brakes, so allow extra stopping distance because
your vehicle will not stop as quickly as usual.
*
[DR27801( ALL)01/95]
After you drive through the standing water,
apply your brakes gently several times as your
vehicle moves slowly. This helps to dry the
brakes.
*
[DR27820(BEF )06/95]
NOTE: If the transmission and transfer case is
submerged in water, their fluids should
be checked and changed, if necessary.
*
[DR27825( ALL)03/93]
NOTE: All rear axle lube quantities must be
replaced every 100,000 miles
(160,000 km) or if the axle has been
submerged in water. Otherwise, the
lube should not be checked or changed
unless a leak is suspected or repair
required.
File:10ltdre.ex
Update:Wed Apr 17 08:44:07 1996

218
*
[DR27850( ALL)11/89]
Rocking the vehicle
*
[DR27950( ALL)05/95]
If your vehicle gets stuck (for example, in mud
or snow), you may rock it out of the spot. Shift
in a steady rhythm between forward and reverse
gears. Allow the transmission to fully engage,
then press lightly on the accelerator. Do not rock
the vehicle for more than a few minutes. This
may overheat the engine and transmission,
causing damage to both. In addition, other
vehicle systems and components may also be
damaged.
*
[DR27975( ALL)05/95]
RWARNING
Do not spin the wheels at over 35 mph
(55 km/h). The tires may fail and injure a
passenger or bystander.
*
[DR28050(BEF )03/95]
Driving With a Heavy Load
*
[DR28101(BEF )01/95]
There are limits to the amount of weight your
vehicle can carry or tow. The total weight of
your vehicle, plus the weight of the passengers
and cargo, should never be more than the Gross
Vehicle Weight Rating (GVWR). Also, the weight
that your vehicle carries over the front axle and
rear axle should never be more than the Gross
Axle Weight Rating (GAWR) for the respective
axle.
*
[DR28150(BEF )01/95]
The weight limits of your vehicle's tires affect
the GVWR or GAWR limitations. Usage of
replacement tires with higher weight limit than
originals does not increase GVWR or GAWR.
Usage of lower capacity replacement tires may
lower GVWR and GAWR limitations.
File:10ltdre.ex
Update:Wed Apr 17 08:44:07 1996

219
*
[DR28201(BEF )02/95]
RWARNING
If the GVWR or the GAWR specified on
the Safety Compliance Certification Label
is exceeded, your vehicle may be damaged
or you may lose control and injure
someone.
*
[DR28750( ALL)01/93]
Vehicle/Trailer Loads
*
[DR28801( ALL)06/92]
All vehicles may tow a Class I trailer provided
the Gross Combined Weight (GCW) is less than
or equal to the GVWR shown on the Safety
Compliance Certification Label. For heavier
trailer applications, refer to the towing
information found later in this chapter.
*
[DR28950(BEF )02/95]
Trailer Towing (may require trailer tow
option package)
*
[DR29001( ALL)03/91]
Towing a trailer puts additional loads on your
vehicle's engine, transmission, axle, brakes, tires
and suspension. For your safety and for the
good of your vehicle, use the right equipment
for the type of trailer you tow.
*
[DR29025( ALL)09/92]
Your trailer towing capability will vary based on
the standard and optional equipment on your
vehicle. Refer to the followingVehicle
Loading/Towing Informationand the Trailer
Towing Tables to determine the specific towing
capability of your vehicle.
*
[DR29050( ALL)02/92]
q
Stay within the load limits when you tow.
*
[DR29101( ALL)01/95]
q
Carefully and thoroughly prepare your
vehicle for towing, making sure to use the
right equipment and to attach it properly.
(SeePreparing to Towin this chapter.)
*
[DR29151( ALL)01/95]
q
Use extra caution when driving your vehicle
while you tow. (SeeDriving while you towin
this chapter.)
File:10ltdre.ex
Update:Wed Apr 17 08:44:07 1996

220
*
[DR29201( ALL)01/95]
q
Service your vehicle more frequently if you
tow a trailer. (SeeServicing your vehicle if you
towin this chapter.)
*
[DR29350( ALL)05/94]
Do not tow a trailer until your vehicle has been
driven at least 500 miles (800 km).
%
*
[DR29401( ALL)06/92]
Vehicle Loading/Towing
Information
*
[DR29450(BEF )03/91]
Your vehicle's load capacity is designated by
weight, not volume, so you cannot necessarily
use all available space with large or heavy loads.
Maximum safe vehicle weights as well as tire,
rim sizes and inflation pressures are specified for
your vehicle at the assembly plant on the Safety
Compliance Certification Label. The Certification
Label is located on the left front door lock facing
or the door latch post pillar.
*
[DR29501( ALL)12/91]
Trucks, unlike passenger cars, are basically
custom vehicles designed to carry a load. Most
owners start with a base vehicle and add
production and dealer installed and/or
aftermarket components to suit their tastes and
purposes. Even trucks that are purchased for
personal transportation only are likely to have
considerable optional equipment, such as step
bumpers and light bars, for example.
*
[DR29525( ALL)06/95]
RWARNING
Passengers should not be allowed to ride
in the cargo area. Persons not riding in a
seat with a fastened seat belt are much
more likely to suffer serious injury in a
collision. Cargo should always be secured
to prevent it from shifting and causing
damage to the vehicle or harm to
passengers.
File:10ltdre.ex
Update:Wed Apr 17 08:44:07 1996
