FORD E SERIES 1996 4.G Owners Manual

251 [RE15445(E )05/95]
RWARNING
On E-Super Duty vehicles, the parking
brake is on the transmission. Therefore,
the vehicle will not be prevented from
moving when a rear wheel is lifted, even
if the vehicle is in Park and the parking
brake is applied. Be sure to block both
directions of the wheel that is diagonally
opposite to the wheel that is being lifted.
If the vehicle slips off the jack, someone
could be seriously injured.
*
[RE15550(BEF )05/95]
2. Get out the spare tire and jack.
[RE16300( E )01/89]
The jack, jack handle and lug nut wrench are
stowed as shown below.
[RE16400( E )05/91]
one third page art:0020289-D
Jack handle and wrench stowage
*
[RE16800(BEF )12/91]
3. Use the tapered end of the lug nut wrench
to unscrew wheel ornaments attached by
retaining screws. Remove any wheel trim.
Insert the tapered end of the lug nut wrench
behind wheel covers or hubcaps and twist
off.
File:11ltree.ex
Update:Wed Apr 17 08:42:44 1996

252
*
[RE16900(BEF )10/89]
4. Loosen the wheel nuts by pulling up on the
handle of the lug nut wrench about one-half
turn (counterclockwise). Do not remove the
wheel lug nuts until you raise the tire off the
ground.
*
[RE16950(BEF )05/95]
Removing and Replacing the Tire
[RE17000( E )02/95]
1. Unfold the jack handle and lock into the
jack. Use the jack handle to slide the jack
under the vehicle.
*
[RE17175(BEF )05/95]
RWARNING
To avoid injury, never run the engine
with one wheel off the ground, such as
when changing a tire.
*
[RE17200(BEF )05/95]
RWARNING
To lessen the risk of personal injury, do
not put any part of your body under the
vehicle while changing a tire. Do not start
the engine when your vehicle is on the
jack. The jack is only meant for changing
the tire.
[RE17300(BEF )06/95]
2. Positioning the jack
[RE18501( E )01/89]
a. To raise a front or rear wheel, place the
jack as shown in the following
illustrations.
File:11ltree.ex
Update:Wed Apr 17 08:42:44 1996

253 [RE18551(E )11/89]
one third page art:0020296-A
Jacking point (All models except E-Super Duty)
[RE18600(BE )11/89]
one third page art:0021527-A
Jacking point (E-Super Duty)
[RE18900( E )12/91]
one third page art:0020298-B
Instructions for jacking a wheel Ð All models
File:11ltree.ex
Update:Wed Apr 17 08:42:44 1996

254
*
[RE19100( E )08/91]
b. Turn the jack handle clockwise until the
wheel is completely off the ground.
*
[RE21151(BEF )10/92]
one third page art:0020939-B
[RE21400(BEF )06/95]
3. Remove the lug nuts with the lug nut
wrench.
[RE21500(BEF )06/95]
4. Replace the flat tire with the spare tire.
*
[RE21600( EF )06/95]
If your vehicle has dual rear wheels, there are
locating pins on the hubs and wheels with
corresponding holes. When you put the wheel
back on, make sure the pins are lined up with
the proper holes.
[RE21800( EF )06/95]
If your vehicle has single rear wheels, thread the
lug nuts on the wheel studs with the beveled
face toward the wheel. Use the lug nut wrench
to screw the lug nut snugly against the wheel
but do not tighten.
*
[RE21900( EF )01/89]
If your vehicle has dual rear wheels, thread the
two-element swiveling lug nut on the wheel
studs with the flange face toward the wheel. Use
the lug nut wrench to screw the lug nut snugly
against the wheel but do not tighten.
File:11ltree.ex
Update:Wed Apr 17 08:42:44 1996

255
*
[RE22000( EF )05/90]
quarter page art:0020310-A
Single rear wheel nut
*
[RE22100( EFM)05/90]
quarter page art:0020311-A
Dual rear wheel nut
*
[RE22200(BEF )01/95]
5. Lower the vehicle by turning the jack handle
counterclockwise.
[RE22300(BEF )06/95]
6. Remove the jack and fully tighten the lug
nuts in the order shown in the following
illustration.
%*
[RE22425( EF )05/90]
quarter page art:0020317-A
Lug nut tightening sequence
File:11ltree.ex
Update:Wed Apr 17 08:42:44 1996

256
*
[RE23400(BEF )05/95]
RWARNING
Use of wheels or lug nuts other than
original equipment could cause damage to
the wheel or mounting system and allow
the wheels to come off while the vehicle
is in motion.
[RE23500(BEF )06/95]
7. Replace any wheel covers, ornaments, or hub
caps that your vehicle has. Make sure that
they are screwed or snapped into place.
[RE23615(BEF )06/95]
8. Put the tire, jack, and wrench away. (Make
sure jack is securely fastened so it doesn't
rattle when you drive.) The carrier is
designed to hold the temporary spare which
comes with your vehicle. The stowage of a
full size tire in the spare tire carrier may
damage the tire or the vehicle. The flat full
size tire should be stowed securely in the
vehicle until it can be repaired.
[RE23700(BEF )06/95]
9. Unblock the wheels.
*
[RE24100( EF )06/95]
On vehicles equipped with dual rear wheels
retighten the wheel lug nuts to the specified
torque at 100 miles (160 km), and again at 500
miles (800 km) of new vehicle operation and at
the intervals specified in theMaintenance Schedule
and Recordbooklet.
*
[RE24200( ALL)10/89]
Also retighten to the specified torque at 500
miles (800 km) of operation after any wheel
change or any time the lug nuts are loosened.
*
[RE24301( ALL)05/95]
RWARNING
Failure to retighten wheel lug nuts at
mileages specified could allow wheels to
come off while the vehicle is in motion.
File:11ltree.ex
Update:Wed Apr 17 08:42:44 1996

257 % [RE24375( E )02/89]
ten pica chart:0020318-B
*
[RE24397(BEF )02/95]
If the Engine Cranks But Does
Not Start or Does Not Start After
a Collision
*
[RE24400(BEF )04/95]
The Fuel Pump Shut-off Switch
*
[RE24500(BEF )03/95]
If the engine cranks but does not start or if you
have had a collision, the fuel pump shut-off
switch may have been triggered. The shut-off
switch is a device that stops the fuel pump
when your vehicle has been involved in a
substantial jolt.
*
[RE24600(BEF )01/95]
For information on how to check and reset the
fuel pump shut-off switch, seeFuel pump shut-off
switchin the Index.
File:11ltree.ex
Update:Wed Apr 17 08:42:44 1996

258
*
[RE24700( ALL)05/95]
Towing Your Vehicle
[RE24875( ALL)06/95]
The recommended method to tow your
Econoline is with flatbed or wheel lift
equipment. However, slingbelt towing is
acceptable. On vehicles equipped with an air
dam, the towbar will deform the rubber air dam.
*
[RE27500(BEF )05/95]
RWARNING
Never use a tow bar that attaches to the
bumper when you tow your vehicle. This
could damage the bumper and cause an
accident.
File:11ltree.ex
Update:Wed Apr 17 08:42:44 1996

259
Customer Assistance
*
[HS00205( ALL)06/94]
Roadside Assistance
*
[HS00210( ALL)06/95]
Ford Motor Company has set up a 24-hour,
seven-day-a-week hotline with trained operators
that put you in touch with the help you need if
you experience a problem with your vehicle.
This complimentary service is provided to you
throughout your warranty period of 3 years or
36,000 miles (60,000 km), whichever comes first.
To purchase Roadside Assistance coverages
beyond this period (available through Ford Auto
Club in the United States or Ford and
Lincoln-Mercury dealers in Canada), contact
your Ford or Lincoln-Mercury dealer.
*
[HS00215( ALL)06/94]
Roadside Assistance will cover the following:
*
[HS00220( ALL)06/94]
q
Mount your spare if you have a flat tire.
*
[HS00225( ALL)06/94]
q
Jump-start your battery if it is dead.
*
[HS00230( ALL)06/94]
q
Unlock your vehicle if you are locked out.
*
[HS00235( ALL)06/94]
q
Bring you fuel if you run out.
*
[HS00240( ALL)06/94]
q
Tow your vehicle if you are stranded. Even
non-warranty related tows, like accidents or
getting stuck in mud or snow, are covered
(some exclusions apply, such as impound
towing and repossession).
File:12lthse.ex
Update:Wed Apr 17 08:41:20 1996

260
*
[HS00245( ALL)06/94]
How to use Roadside Assistance
*
[HS00250( ALL)06/94]
Your Roadside Assistance identification card can
be found in the Owner Guide portfolio in your
glove compartment. Complete the card and place
it in your wallet for quick reference.
*
[HS00255( ALL)04/95]
To receive roadside assistance in the United
States call 1-800-241-FORD (in Canada call
1-800-665-2006).
*
[HS00260( ALL)04/95]
Should you need to arrange for roadside
assistance yourself, Ford Motor Company will
reimburse the reasonable cost. To obtain
information about reimbursement call
1-800-241-FORD (in Canada call 1-800-665-2006).
*
[HS00300( ALL)01/95]
If You Have a Service Problem
*
[HS00400( ALL)01/95]
Ford Motor Company has authorized Ford and
Lincoln-Mercury dealerships that can service
your vehicle for you. This chapter tells you how
to get service or maintenance for your vehicle.
%*
[HS00525( ALL)03/95]
Service/Maintenance Concerns
(U.S. or Canada)
*
[HS00600(BEF )04/95]
Ford recommends taking your vehicle to your
selling dealer who wants to ensure your
continued satisfaction. You may, however, take
your vehicle to any authorized Ford or
Lincoln-Mercury dealer. In most cases, your
dealer will be able to resolve your concern.
*
[HS00700( ALL)03/95]
If you are not satisfied with the service you
received from your dealership's service
department, talk to the service manager at the
dealership. If you still are not satisfied, talk to
the owner or general manager of the dealership.
In most cases, you will have your concern
resolved at this level.
