Safety, Comfort, and Convenience
[AC01300( E )04/95]
twenty-eight pica chart:0020762-H*
[AC01900( ALL)01/95]
NOTE: When adding accessories, equipment,
passengers, and luggage to your
vehicle, do not exceed the total weight
capacity of the vehicle or of the front
or rear axle (GVWR, GAWR as shown
on the Safety Compliance Certification
Label). Consult your dealer for specific
weight information.
File:13ltace.ex
Update:Wed Apr 17 08:41:05 1996

273
*
[AC02000( ALL)05/95]
NOTE: The Federal Communications
Commission (FCC) or the Canadian
Radio Telecommunications Commission
(CRTC) regulates the use of mobile
communications systems Ð such as
two-way radios, telephones, and theft
alarms Ð that are equipped with radio
transmitters. Any such equipment
installed in your vehicle should comply
with FCC or CRTC regulations and
should be installed only by a qualified
technician.
*
[AC02100( ALL)01/95]
NOTE: Mobile communications systems may
harm the operation of your vehicle,
particularly if they are not properly
designed for automotive use or are not
properly installed. For example, when
operated, such systems may cause the
engine to stumble or stall. In addition,
such systems may themselves be
damaged or their operation affected by
operating your vehicle. (Citizens band
[CB] transceivers, garage door openers,
and other transmitters whose power
output is 5 watts or less will not
ordinarily affect your vehicle's
operation.)
*
[AC02200( ALL)05/95]
NOTE: Because we have no control over the
installation, design, or manufacture of
such systems, Ford cannot assume
responsibility for any adverse effects or
damage that may result if you use this
equipment.
File:13ltace.ex
Update:Wed Apr 17 08:41:05 1996

274
*
[AC02400( ALL)02/89]
ten pica chart:0020464-A
File:13ltace.ex
Update:Wed Apr 17 08:41:05 1996

276 % [AC03500( E )02/95]
thirty-four pica chart:0021239-B
File:13ltace.ex
Update:Wed Apr 17 08:41:05 1996

277 [AC03600( E )02/95]
thirty-six pica chart:0021240-B
File:13ltace.ex
Update:Wed Apr 17 08:41:05 1996

278 [AC03700( E )02/95]
thirty-six pica chart:0021241-B
File:13ltace.ex
Update:Wed Apr 17 08:41:05 1996

279
Servicing Your Econoline
%*
[SV00300( ALL)03/95]
Service Made Easy
*
[SV00400(BEF )01/95]
Ford has two goals for servicing your vehicle.
*
[SV00500(BEF )01/95]
1. When we can, we design parts that do not
need to be serviced.
*
[SV00600(BEF )01/95]
2. We want to make servicing your vehicle as
easy as possible. To help you:
*
[SV00700(BEF )01/95]
q
We highlight do-it-yourself items in yellow in
the engine compartment so that you can find
them easily.
*
[SV00800(BEF )01/95]
q
When possible, we design parts Ð such as
the headlamp bulbs Ð that can be replaced
without tools.
*
[SV00900(BEF )05/94]
q
We give you a Maintenance Schedule that
makes tracking routine service for your
vehicle easy. The maintenance schedule is
located in theMaintenance Schedule and Record
booklet.
*
[SV01000( ALL)01/95]
This chapter tells you about the basic parts that
you need to check and service regularly.
*
[SV01100( ALL)02/95]
If your vehicle needs professional servicing, your
dealership can provide the parts and service
required. Check yourWarranty Information Booklet
to find out which parts and services are covered.
Also see theCustomer Assistancechapter of this
Owner Guide.
*
[SV01300( ALL)03/95]
Ford Motor Company recommends that the
Owner Maintenance Checks listed in the
Maintenance Schedule and Recordbooklet be
performed for the proper operation of your
File:14ltsve.ex
Update:Wed Apr 17 08:40:13 1996

280vehicle. In addition to the conditions listed in
theOwner Maintenance Checklist, be alert for any
unusual noise, vibration, or other indication that
your vehicle may need service. If you do notice
something unusual, see that your vehicle is
serviced promptly.
*
[SV01600( ALL)06/95]
Precautions When Servicing Your
Vehicle
*
[SV01700( ALL)06/95]
Be especially careful when inspecting or
servicing your vehicle. Here are some general
precautions for your safety:
*
[SV01900( ALL)06/95]
q
If you must work with the engine running,
avoid wearing loose clothing or jewelry that
could get caught in moving parts. Take
appropriate precautions with long hair.
*
[SV02000( ALL)06/95]
q
Do not work on a vehicle in an enclosed
space with the engine running, unless you are
sure you have enough ventilation.
*
[SV02100( ALL)06/95]
q
Never get under a vehicle while it is
supported by a jack only. If you must work
under a vehicle, use safety stands.
*
[SV02200( ALL)06/95]
q
Keep all lit cigarettes and other smoking
materials away from the battery and all
fuel-related parts.
*
[SV02500( ALL)03/95]
If you disconnect the battery, the engine must
ªrelearnº its idle conditions before your vehicle
will drive properly. To find out how the engine
does this, seeBatteryin this chapter.
File:14ltsve.ex
Update:Wed Apr 17 08:40:13 1996

281
*
[SV02600( ALL)03/95]
Working with the engine off:
*
[SV02650( E M)03/95]
1. Set the parking brake fully and make sure
that the gearshift is securely latched in P
(Park).
[SV02700( ALL)06/95]
2. Remove the key from the ignition after you
turn the engine off.
[SV02725( ALL)06/95]
3. Block the wheels. This will prevent your
vehicle from moving unexpectedly.
*
[SV02750( ALL)03/95]
Working with the engine on:
*
[SV02785( E M)03/95]
1. Set the parking brake fully and make sure
that the gearshift is securely latched in P
(Park).
*
[SV02795( E M)03/95]
2. Block the wheels. This will prevent your
vehicle from moving unexpectedly.
*
[SV02900( ALL)02/95]
RWARNING
Do not start your engine with the air
cleaner removed and do not remove it
while the engine is running.
*
[SV02950(BEF )03/95]
Opening the Hood
[SV03025( E )05/89]
1. Pull the hood release handle, located on the
left kick panel near the parking brake release
handle.
*
[SV03050(BEF )12/91]
2. While applying downward pressure on the
hood, push the hood latch handle located
behind the grille near the center front of the
vehicle to the left.
*
[SV03100( E )08/94]
3. Disconnect the hood support from the
retaining clip on the radiator support and
place it into the slot marked PROP in the
underside of the hood.
File:14ltsve.ex
Update:Wed Apr 17 08:40:13 1996

282
*
[SV03300(BEF )03/91]
one third page art:0020333-A
Hood release handle
[SV03500( E )02/92]
quarter page art:0020336-D
Hood and support
*
[SV03800( E )08/94]
To close the hood, raise it so that the support
rod comes away from the slotted hole in the
hood. Place the support rod in its retaining clip
and close the hood with enough force to make it
latch. Be sure to oil the hood latch every six
months to maintain smooth operation.
*
[SV03900(BEF )05/90]
Always attempt to lift the hood after closing to
be sure it is securely latched.
File:14ltsve.ex
Update:Wed Apr 17 08:40:13 1996
