FORD E SERIES 1996 4.G Owners Manual

293
*
[SV10215( ALL)03/95]
Gasoline and gasoline-methanol blends may
contain small amounts of carcinogens, such as
benzene. Long-term exposure to unleaded
gasoline vapors has caused cancer in laboratory
animals. Further, excessive inhalation of fuel
vapors can cause headache, dizziness, nausea,
loss of coordination, and other symptoms which
could interfere with your ability to safely
operate your vehicle. To the extent possible,
avoid breathing vapors while refueling. If fuel
vapors are inhaled in excessive quantities, move
the victim to fresh air and seek medical
attention.
*
[SV10220( ALL)03/95]
Fuels can also be harmful if absorbed through
the skin. When refueling, be careful not to
splash fuel on yourself or your clothing. If fuel
is splashed on the skin, promptly remove
contaminated clothing and wash the skin
thoroughly with soap and water.
*
[SV10225( ALL)05/95]
Fuels can cause severe eye irritation and possibly
eye damage. If fuel is splashed in the eyes,
remove contact lenses (if worn), flush with large
amounts of water for 15 minutes, and seek
medical attention.
*
[SV10230( ALL)06/95]
You should be particularly careful if you are
taking the medication ªAntabuseº or other forms
of disulfiram for the treatment of alcoholism.
There is a possibility that breathing the vapors
of a gasoline-methanol blend, or skin contact
with such a blend, may cause the same kind of
adverse reaction as drinking an alcoholic
beverage. In sensitive individuals, serious
personal injury or sickness could result. Consult
a physician promptly if you experience an
adverse reaction.
File:14ltsve.ex
Update:Wed Apr 17 08:40:13 1996

294
*
[SV10300( ALL)02/95]
Filling the fuel tank
*
[SV10400( ALL)04/94]
RWARNING
Do not overfill the fuel tank. The pressure
in an overfilled tank may cause leakage
and lead to fuel spray and fire.
*
[SV10500( ALL)01/95]
To fill the fuel tank properly:
*
[SV10550( ALL)01/95]
NOTE: Extinguish all lit cigarettes, other
smoking materials, and any open
flames before fueling your vehicle.
*
[SV10600( ALL)01/95]
1. Remove the fuel cap by following the
instructions above underRemoving the Fuel
Capin this chapter. Proceed to add fuel to
the tank only if your vehicle is on level
ground.
*
[SV10700( ALL)05/95]
2. Make sure that you pump unleaded fuel and
put the nozzle all the way inside the fuel
filler pipe.
*
[SV10800( ALL)06/95]
NOTE: If you spill any fuel on the body of
your vehicle, clean it off immediately.
The fuel may dull or soften the paint
if you do not wash it off.
%*
[SV10900( ALL)06/95]
3. Replace the fuel cap completely when you
are finished. Turn it clockwise 1/4 turn until
it is tight. It will click when it is fully
tightened.
File:14ltsve.ex
Update:Wed Apr 17 08:40:13 1996

295 %
*
[SV11300( ALL)05/95]
Running Out of Fuel
*
[SV11400( ALL)05/95]
If your vehicle runs out of fuel, try to stop on
level ground away from traffic. Add at least two
gallons (8 liters) of fuel to start your vehicle
again. If your vehicle is not on level ground,
you may need as much as five gallons (20 liters)
of fuel to start it.
*
[SV11500( ALL)05/95]
You may need to crank the engine several times
before the fuel system starts to pump fuel from
the tank to the engine.
%*
[SV11600( ALL)05/95]
Fuel Economy
*
[SV11700( ALL)06/95]
Fuel economy is an estimate of the efficiency of
your vehicle and can be calculated as Miles Per
Gallon (MPG) or Liters Per 100 Kilometers
(L/100K).
*
[SV11750( ALL)05/95]
Do not calculate fuel economy during your
vehicle's break-in period. This would not be an
accurate estimate of how much fuel your vehicle
will normally use.
*
[SV11800( ALL)05/95]
To calculate fuel economy:
*
[SV11900( ALL)06/95]
1. Fill the tank completely and record the
initial odometer reading.
*
[SV12000( ALL)06/95]
2. Every time you buy fuel record the
amount (in gallons or liters) purchased.
*
[SV12200( ALL)05/95]
3. After at least three to five tankfuls, fill the
fuel tank and record the final odometer
reading.
*
[SV12225( ALL)05/95]
4. Use these equations to calculate your fuel
economy.
*
[SV12250( ALL)05/95]
q
English: MPG = (total miles)/(gallons used).
*
[SV12275( ALL)05/95]
q
Metric: L/100K = (liters used) x 100/(total
kilometers)
File:14ltsve.ex
Update:Wed Apr 17 08:40:13 1996

296 %
*
[SV12300(BEF )05/95]
Comparisons With EPA Fuel Economy
Estimates
*
[SV12400(BEF )05/95]
EPA fuel economy figures are obtained from
laboratory tests under simulated road conditions
and may not reflect the actual conditions you
experience or your style of driving. The EPA
fuel economy estimate is not a guarantee that
you will achieve the fuel economy shown.
%*
[SV12500( ALL)06/95]
Improving Fuel Economy
*
[SV12600( ALL)05/95]
Fuel economy is affected by a number of
variables which can reduce efficiency. You can
improve fuel economy by understanding these
variables and minimizing their effect.
*
[SV12700( ALL)05/95]
The following decrease fuel economy:
*
[SV12800( ALL)05/95]
q
Lack of regular, scheduled maintenance
*
[SV12900( ALL)05/95]
q
Driving with your foot on the brake
*
[SV13000( ALL)05/95]
q
Sudden stops
*
[SV13100( ALL)05/95]
q
Excessive speed
*
[SV13200( ALL)05/95]
q
Extended engine idling
*
[SV13300( ALL)05/95]
q
Heavy loads
*
[SV13400( ALL)05/95]
q
Underinflated tires
*
[SV13500(BEF )05/95]
q
Extended use of the A/C, defroster, rear
window defroster and other accessories
*
[SV13550(BEF )05/95]
q
Aftermarket add-ons such as bike, ski or
luggage racks, bug deflectors, etc.
File:14ltsve.ex
Update:Wed Apr 17 08:40:13 1996

297
*
[SV13600( ALL)02/95]
Engine Oil Recommendations
*
[SV13610( ALL)05/95]
We recommend using Motorcraft oil or an
equivalent oil meeting Ford Specification
WSS-M2C153-F and displaying the American
Petroleum Institute CERTIFICATION MARK on
the front of the container.
*
[SV13655( ALL)03/95]
one third page art:0060020-D
The API Certification Mark
*
[SV13670( ALL)01/95]
Neveruse:
*
[SV13680( ALL)01/95]
q
ªNon-Detergentº oils
*
[SV13690( ALL)04/95]
q
Oils labeled API SA, SB, SC, SD, SE, SF or SG
%*
[SV13700( ALL)01/95]
q
Additional engine oil additives, oil treatments
or engine treatments
[SV13705( EF )04/95]
For vehicles with 5.8L engines
%*
[SV13710( ALL)06/95]
Engine oils with anSAE 5W-30viscosity are
PREFERREDfor your vehicle. They provide the
best engine performance, fuel economy and
engine protection for all climates down to-15ÊF
(-25ÊC).
%*
[SV13725( ALL)03/95]
Synthetic engine oils which are CERTIFIED and
of the preferred viscosity may be used in your
engine. The engine oil and oil filter must still be
changed according to the maintenance schedule.
File:14ltsve.ex
Update:Wed Apr 17 08:40:13 1996

298
*
[SV13730( EF )01/93]
For vehicles with 4.9L, 5.0L or 7.5L engines
[SV13740( ALL)04/95]
Engine oils with anSAE 10W-30viscosity are
PREFERREDfor your vehicle which provide the
best engine protection for all climates down to
-5ÊF (-20ÊC). SAE5W-30 enigne oils may also be
used down to-15ÊF (-25ÊC).
[SV13745( ALL)02/95]
Synthetic engine oils which are CERTIFIED and
of the preferred viscosity may be used in your
engine. The engine oil and oil filter must still be
changed according to the maintenance schedule.
*
[SV13775( ALL)01/95]
Checking and Adding Engine Oil
*
[SV13800( ALL)03/95]
Since the proper amount of engine oil is
important for safe engine operation, check the oil
using the dipstick each time you put fuel in
your vehicle. Remember the engine must be off,
the oil must be warm and the vehicle must be
parked on level ground.
*
[SV13900( ALL)03/95]
Checking the engine oil level:
*
[SV14000( ALL)02/95]
1. Turn the engine off after it has warmed up
and allow a few minutes for the engine oil
to drain back into the oil pan.
*
[SV14075( E M)03/95]
2. Set the parking brake, making sure the
gearshift is securely latched in P (Park).
*
[SV14100( ALL)02/95]
3. Open the hood. Protect yourself from engine
heat.
*
[SV14200( ALL)03/95]
4. Locate the engine oil dipstick (highlighted in
yellow) and carefully pull it out of the
engine.
*
[SV14300( ALL)01/95]
5. Wipe the dipstick clean and put it back into
position, making sure it is fully seated.
File:14ltsve.ex
Update:Wed Apr 17 08:40:13 1996

299
*
[SV14400( ALL)06/95]
quarter page art:0010364-D
Engine oil dipstick
*
[SV14500( ALL)02/95]
6. Carefully, pull the dipstick out again. If the
oil level is below the ªADD 1 QT.º line, add
engine oil as necessary. If the oil level is
beyond the letter ªFº in FULL, engine
damage or high oil consumption may occur
and some oil must be removed from the
engine.
*
[SV14600( ALL)01/95]
7. Put the dipstick back in and make sure it is
fully seated.
*
[SV14800( ALL)01/95]
It may be necessary to add some oil between oil
changes. Make sure you use a CERTIFIED
engine oil of the preferred viscosity. Your
vehicle's warranty coverage may not apply if
engine damage is caused by the use of improper
engine oil.
*
[SV15000( ALL)03/95]
Add engine oil through the oil filler cap
highlighted in yellow. To add oil, remove the
filler cap and use a funnel to pour oil into the
opening. Be careful not to overfill the engine.
Recheck the oil level after you finish adding oil.
File:14ltsve.ex
Update:Wed Apr 17 08:40:13 1996

300
*
[SV16300( EFM)06/95]
Changing the Engine Oil and the Oil Filter
*
[SV16500( ALL)04/95]
Change the engine oil and oil filterper the
following, whichever occurs first.
*
[SV16600(BEF )04/95]
one third page art:0060618-C
Oil change intervals
*
[SV16625( ALL)06/95]
NOTE: Idling the engine for extended periods
will accumulate more hours of use on
your vehicles than is actually indicated
by the mileage odometer.
Consequently, the odometer reading
can be often misleading when
determining the right time to change
your engine oil and filter.
*
[SV16650(BEF )06/95]
If you are using your Ford vehicle in a manner
which allows it to remain stationary while the
engine is running for long periods (door to
door delivery, taxi, police, power/utility
company trucks, or similar duty), then Ford
recommends you increase the frequency of oil
and filter changes to an interval equivalent to
200 ENGINE HOURS of use. Since most
vehicles are not equipped with hourmeters, it
may be necessary for you to approximate your
idle time and plan oil/filter changes
accordingly.
File:14ltsve.ex
Update:Wed Apr 17 08:40:13 1996

301
*
[SV16700( EF )06/93]
If your vehicle is over 8500 GVWR and the
above conditions do not apply, change the
engine oil and oil filter every 6 months or 5,000
miles (8,000 km), whichever comes first.
*
[SV16800( ALL)06/95]
Refer to theMaintenance Schedule and Record
booklet for additional information.
*
[SV16900( EF )03/94]
NOTE: Refer to thePower Stroke Diesel Engine
Owner's Guide Supplementfor oil
viscosity, filter application and oil and
filter change intervals.
%*
[SV17250( ALL)04/95]
NOTE: Always dispose of used automotive
fluids in a responsible manner. Follow
your community's standards for
disposing of these types of fluids. Call
your local recycling center to find out
about recycling automotive fluids.
*
[SV17275( ALL)06/95]
RWARNING
Continuous contact with USED motor oil
has caused cancer in laboratory mice.
*
[SV17280( ALL)06/95]
Protect your skin by washing with soap and
water.
*
[SV17300( ALL)03/95]
Engine Coolant
*
[SV17400( ALL)02/95]
Checking the engine coolant
*
[SV17700( ALL)10/89]
Your vehicle's engine coolant protects the engine
from overheating in the summer and from
freezing in the winter. Check the level of the
engine coolant at least once a month, but
preferably each time you stop for fuel. Simply
look at the engine coolant recovery reservoir
located in the engine compartment. To locate
this reservoir, see the diagram of your vehicle's
engine underEngine typesin this chapter.
File:14ltsve.ex
Update:Wed Apr 17 08:40:13 1996

302
*
[SV17750( ALL)03/95]
If the engine coolant has not been checked for a
long period of time the engine coolant reservoir
may eventually empty. If the engine coolant
reservoir empties, check the engine coolant level
in the radiator. Read the following warnings
before removing the radiator cap. If it is
necessary to fill the radiator, refer to theEngine
Coolant Refill Procedurein this chapter for
instructions.
*
[SV17950(BEF )01/95]
Adding engine coolant
[SV18100( E )05/94]
quarter page art:0020355-C
Checking engine coolant radiator level
% [SV18300( E )07/92]
quarter page art:0020357-B
Adding engine coolant
*
[SV18400( ALL)05/95]
RWARNING
Do not put engine coolant in the container
for the windshield washer fluid.
*
[SV18420( ALL)06/95]
If sprayed to clean the glass, engine coolant or
antifreeze could make it difficult to see through
the windshield.
File:14ltsve.ex
Update:Wed Apr 17 08:40:13 1996
