Setting the retractor to automatic locking mode
*
[SR16395(BEF )06/95]
6. Allow the belt to retract. Pull up on the
shoulder webbing. A clicking sound will be
heard as the belt retracts. This indicates the
retractor is in the automatic locking mode.
Push down on the child seat while you pull
up on the belt to remove any slack in the
belt. Figures 5 and 6.
File:03ltsre.ex
Update:Wed Apr 17 08:51:22 1996

49
*
[SR16400(BEF )06/95]
half page art:0011242-A
*
[SR16405(BEF )06/95]
half page art:0011243-A
File:03ltsre.ex
Update:Wed Apr 17 08:51:22 1996

50
*
[SR16410(BEF )06/95]
7. Before placing the child in the child seat,
forcibly tilt the seat from side to side, and
tug it forward to make sure that the seat is
securely held in place, Figure 7.
*
[SR16412(BEF )06/95]
half page art:0011244-A
Checking that the seat is secure
File:03ltsre.ex
Update:Wed Apr 17 08:51:22 1996

51
*
[SR16415(BEF )06/95]
8. Double check that the retractor is in the
automatic locking mode. Try to pull more
belt out of the retractor. If you cannot, the
belt is in the automatic locking mode,
Figure 8.
*
[SR16420(BEF )06/95]
half page art:0011245-B
Checking the retractor
*
[SR16425(BEF )06/95]
9. Check to make sure that the child seat is
properly secured prior to each use. If the
retractor is not locked, repeat steps 4
through 7.
*
[SR16430(BEF )06/95]
To remove the retractor from automatic lock
mode, allow webbing to retract fully to its
stowed position and the retractor will
automatically switch back to the vehicle sensitive
locking mode for normal adult usage.
File:03ltsre.ex
Update:Wed Apr 17 08:51:22 1996

52 [SR16440(BEF )04/95]Installing a Child Safety Seat at the Rear
Center Seating Position with Locking
Adjustable Lap Belt
[SR16450(BEF )04/95]
1. Lengthen the lap belt. To lengthen the belt,
hold the tongue so that its bottom is
perpendicular to the direction of webbing
while sliding the tongue up the webbing.
[SR16455(BEF )04/95]
2. Place the child safety seat in the center
seating position.
[SR16460(BEF )04/95]
3. Route the tongue and webbing through the
child seat according to the child seat
manufacturer's instructions.
[SR16465(BEF )04/95]
4. Insert the belt tongue into the proper buckle
for the center seating position until you hear
a snap and feel it latch. Make sure the
tongue is securely fastened to the buckle by
pulling on tongue.
[SR16470(BEF )04/95]
5. Push down on the child seat while pulling
on the loose end of the lap belt webbing to
tighten the belt.
[SR16475(BEF )04/95]
6. Before placing the child into child seat,
forcibly tilt the child seat from side-to-side
and in forward directions to ensure that the
seat is held securely in place. If the child
seat moves excessively, repeat steps 5
through 6, or properly install the child seat
in a different seating position.
File:03ltsre.ex
Update:Wed Apr 17 08:51:22 1996

53
*
[SR18400(BEF )06/95]
Attaching Safety Seats With Tether Straps
*
[SR18410(BEF )05/95]
General Instructions
[SR18413(BEF )02/95]
Some manufacturers make safety seats that
include an upper tether strap that goes over the
seatback and attaches to an anchoring point.
Other manufacturers offer the tether strap as an
accessory. Contact the manufacturer of your
child safety seat for information about ordering
a tether strap.
[SR18418( E )04/95]
You can install a tether strap anchor bracket to
the back of the seat by using a tether anchor kit
(613D74), available at no charge from any Ford
dealer.
*
[SR18420(BEF )05/95]
Read and follow the instructions provided with
the kit carefully for installation of the child
tether strap anchor.
*
[SR18501(BEF )05/95]
Follow the child seat manufacturer's instructions
to attach the tether strap to the tether bracket.
[SR18600( E )03/91]
Ford recommends placement of tethered safety
seats in a rear seating position with the tether
strap attached to the tether anchoring point as
shown in the following illustration. The front,
right hand seating position may be used if it is
the only seating position available.
File:03ltsre.ex
Update:Wed Apr 17 08:51:22 1996

54 [SR18625( E )02/92]
two third page art:0020794-BTether strap anchorage locations
*
[SR18950(BEF )06/95]
RWARNING
Only use the tether attachment hole
locations shown in the illustrations. The
tether anchor may not perform properly if
the wrong mounting location is used.
*
[SR19500(BEF )05/95]
RWARNING
Failure to follow these precautions could
increase the chance of injury in an
accident.
File:03ltsre.ex
Update:Wed Apr 17 08:51:22 1996

55
Starting Your Econoline
*
[ST01700( ALL)03/95]
Ignition
*
[ST01800( ALL)01/95]
Understanding the Positions of the Ignition
*
[ST02000( ALL)05/90]
quarter page art:0020004-B
The positions of the key in the ignition lock cylinder.
*
[ST02200( ALL)05/95]
ON allows you to test your vehicle's warning
lights (except the brake system warning light) to
make sure they work before you start the
engine. The key returns to the ON position once
the engine is started and remains in this position
while the engine runs.
*
[ST02300( ALL)03/95]
START cranks the engine. Release the key once
the engine starts so that you do not damage the
starter. The key should return to ON when you
release it. The START position also allows you
to test the brake warning light.
*
[ST02400( ALL)03/95]
OFF allows you to shut off the engine and all
accessories without locking the steering wheel or
the automatic transmission gearshift lever.
[ST02550( E M)07/94]
LOCK locks the steering wheel. It also locks the
gearshift.
*
[ST02700( ALL)01/95]
LOCK is the only position that allows you to
remove the key. The LOCK feature helps to
protect your vehicle from theft.
File:04ltste.ex
Update:Wed Apr 17 08:49:38 1996

56 %
*
[ST02800( ALL)05/95]
If the key is stuck in the LOCK position, move
the steering wheel left or right until the key
turns freely.
%*
[ST02900( ALL)03/95]
ACCESSORY allows some of your vehicle's
electrical accessories such as the radio and the
windshield wipers to operate while the engine is
not running.
*
[ST03025(BEF )03/91]
Ignition Key Buzzer or Chime
*
[ST03050(BEF )03/91]
The buzzer or chime will sound if you open the
driver's door while the key is in the ignition.
Never leave your vehicle unattended with the
key in the ignition.
%*
[ST03075( ALL)02/95]
Removing the Key From the Ignition
[ST03125( E M)03/91]
Procedures for removing your key from the
ignition are as follows:
[ST03350( E M)03/91]
Your vehicle's gearshift lever is mounted on
the column:
*
[ST03400( ALL)06/95]
1. Put the gearshift in P (Park).
*
[ST03500( ALL)03/91]
2. Set the parking brake fully before removing
your foot from the service brake. (This will
avoid ªbindingº or ªloadingº the park gear
if you park on a grade.)
*
[ST03600( ALL)03/95]
3. Turn the ignition key to LOCK.
*
[ST03700( ALL)03/95]
4. Remove the key.
*
[ST04625( E M)06/95]
RWARNING
Always set the parking brake fully and
make sure the gearshift is securely latched
in P (Park).
File:04ltste.ex
Update:Wed Apr 17 08:49:38 1996

57
*
[ST04750( ALL)01/93]
RWARNING
Do not leave children, unreliable adults,
or pets alone in your vehicle. They could
accidentally injure themselves or others
through inadvertent operation of the
vehicle. Further, on hot, sunny days,
temperatures in a closed vehicle could
quickly become high enough to cause
severe and possibly fatal injuries to
people as well as animals.
%
*
[ST04800( ALL)03/95]
Fuel-Injected Engines
*
[ST04850( EF )04/94]
NOTE: For owners of diesel-powered vehicles,
refer to theDiesel Engine Owners Guide
Supplementfor information on starting
your vehicle.
*
[ST04900(BEF )03/95]
When starting a fuel-injected engine,the most
important thing to remember is to avoid
pressing down on the accelerator before or
during starting. Only use the accelerator when
you have problems getting your vehicle started.
SeeStarting Your Enginein this chapter for
details about when to use the accelerator while
you start your vehicle.
%*
[ST05050( E )05/95]
Because your vehicle's engine is electronically
controlled by a computer, some control
conditions are maintained by power from the
battery. If you ever disconnect the battery, install
a new battery, or experience a dead battery you
must allow the computer to ªrelearnº its idle
conditions before your vehicle will drive
properly. To let the engine do this, put the
gearshift in P (Park), turn off all the accessories,
and start the vehicle. Let the engine idle for at
least one minute.
File:04ltste.ex
