2009 FORD EDGE QUICK REFERENCE GUIDE
ADDITIONAL FEATURES
PANORAmIc VISTA ROOF™
wITh DUAL POwER
SUNShADES (if equipped)
The panoramic Vista Roof™
and power sunshades are
equipped with an automatic
one-touch, express opening
feature. To open, press and
release
. The front and
rear sunshades will open
simultaneously. Press

again and the panoramic Vista
Roof will open to the ‘comfort’
position. Press
once more
for the roof to fully open.
To stop the one touch open
feature at any time, press
the control again. To close,
pull
down until the glass
panel closes. Firmly pull the
control again to fully close
the Vista Roof™. Pull and
hold the control down again
to close the front and rear
sunshades. To vent from a
closed position, press TILT.
To close, pull and hold TILT.
INTEgRATED KEyhEAD
TRANSmITTER (IKT) AND
REmOTE ENTR y SySTEm
FEATURES
Your vehicle comes
equipped with two specially
programmed Integrated
Keyhead Transmitters (IKTs).
IKTs are both a programmed
ignition key and a remote
keyless entry transmitter.
Press
once to unlock the
driver’s door. The interior
lamps will illuminate.
Press
twice to unlock all
the doors.
Press
within three seconds
to unlatch and open the
power liftgate (if equipped).
Press
to lock all doors.
Press again to confirm that
all doors are closed. The horn
will chirp and the turn lamps
will flash.
Press
to activate the panic alarm. The horn will sound
and the turn lamps will flash.
Press
again or turn the
ignition on to deactivate the
panic alarm.
cAR FINDER: Press
twice
within three seconds. The
horn will chirp and the
turn lamps will flash. It
is recommended that this
method be used to locate your
vehicle, rather than using the
panic alarm.
Ensure that you keep the
IKT adhesive security label
in a safe place for future
reference. Replacement
Integrated Keyhead
Transmitters are only
available through your
authorized dealer.
POwER LIFTgATE (if equipped)
To open the power liftgate
(if equipped), press
on
the instrument panel, or
press
twice within three
seconds on your remote entry
transmitter, or press and
release the control button
located on the liftgate. To
close, press
located on
the left rear quarter panel in
the rear cargo area or press
twice on your remote entry
transmitter. Keep clear of
the liftgate when operating
the rear switch. Your power
liftgate is equipped with an
obstacle detection feature
which will either stop or revert
to a full open position when it
encounters a solid object. For
complete information, please
refer to your Owner’s Guide.
SyNc
® (if equipped)
Your vehicle may
be equipped with SYNC
® – a
hands-free communications
and entertainment system
with special phone and
media features. For more
information, please refer
to the SYNC
® Supplement or to the SYNC
® section in
the Navigation Supplement.
Please also feel free to visit
www.SyncMyRide.com.
USB PORT (if equipped)
If you have SYNC,® your
vehicle will be equipped with
a USB port inside the center
console. This feature allows
you to plug in media playing
devices, memory sticks, and
also to charge devices if they
support this feature. For
more information, please
refer to Accessing and Using
your USB port in the SYNC
®
supplement or the Navigation
system supplement.
AmBIENT LIghTINg

(if equipped)
Your vehicle may be equipped
with an ambient lighting
feature. The control is located
on the center console and,
when activated, illuminates
footwells, storage bins and
cupholders with a choice
of seven colors. Ambient
lighting is operational when
the ignition is on or in the
accessory position. Press the
control repeatedly to turn
on, cycle through your color
choices, and turn off.
SEcURILOcK™
SecuriLock™ passive
anti-theft system is an
engine immobilization
system. This system is
designed to help prevent the
engine from being started
unless a coded Integrated
Keyhead Transmitter (IKT)
programmed to your vehicle is
used. Using the wrong type of
coded key may lead to a “no
start” condition.
ESSENTIAL INFORmATION
FUEL TyPE AND
TANK cAPAcITy
Front wheel drive vehicles
have a fuel tank capacity of
19.2 gallons (72.7 L) while
All Wheel drive vehicles
have a fuel tank capacity of
20.8 gallons (78.7L). Your
vehicle is designed to use
“Regular” unleaded gasoline
with an octane rating of 87.
Do not use gasoline labeled
as “Regular” in high altitude
areas that are sold with
Octane ratings less than 87.
Do not use E85 fuels that are
blended with a maximum of
85% ethanol.
TIRE PRESSURE
Your tire pressure is
properly set at the
dealership according to the
recommended specifications
found on the Safety
Compliance Certification
Label or Tire Label located on
the on the B-Pillar or the edge
of the driver’s door. Check
your tire pressure at least
once a month and before long
trips (including spare). As an
added safety feature, your
vehicle has a Tire Pressure
Monitoring System (TPMS)
that illuminates a low tire
pressure warning light when
one or more of your tires is
significantly under-inflated.
Improperly inflated tires can
affect vehicle handling and
can fail suddenly, possibly
resulting in loss of vehicle
control. Refer to the Tires,
Wheels and Loading chapter
in your Owner’s Guide for
more information.
FUEL PUmP ShUT -OFF SwITch
The fuel pump shut-off
switch stops the electric fuel
pump from sending fuel to
your engine when your
vehicle has sustained a
substantial jolt. This switch
is located behind a panel on the left side of the cargo
area. For more information,
refer to the Roadside
Emergencies chapter of
your Owner’s Guide.
LOcATION OF SPARE TIRE
If you get a flat tire while
driving, do not apply the
brake heavily. Instead,
gradually decrease your
speed. Hold the steering
wheel firmly and slowly move
to a safe place on the side
of the road. Your vehicle is
equipped with a temporary
spare tire. The spare tire and
tools are located in the rear
cargo area of the vehicle,
under the carpeted floor
panel. For complete details
on how to change your tire,
please refer to the Roadside
Emergencies chapter in your
Owner’s Guide.
REVERSE SENSINg SySTEm
(if equipped)
Your vehicle may be equipped
with a reverse sensing system
which can warn you if there
is a large object behind the
vehicle that may be too low
for you to see. The system
will sound a warning tone that
increases in frequency as the
object gets closer and will
sound continuously when the
object is less than 10 inches
away. Refer to your Owner’s
Guide for safety information
and more details.
S.O.S. POST cRASh
ALERT SySTEm
Your vehicle is equipped with
the S.O.S. Post Crash Alert
system. This system provides
audible and visual alarms in
the event of a crash which
causes the deployment of
airbags or the activation of
the safety belt pretensioners.
The turn signals will flash
and the horn will sound. To
deactivate the system, press
the hazard flasher control,
or you can press on your
remote transmitter.
ROADSIDE ASSISTANcE
Your new Ford Edge comes
with the assurance and
support of 24-hour
emergency roadside
assistance. Roadside
assistance includes
such services as: lockout
assistance, limited fuel
delivery, battery jump
starts, changing a flat tire,
towing, and winch out. To
receive roadside assistance
in the United States, call
1 (800) 241-3673. In
Canada, call 1 (800)
665-2006. For more
information on coverage
period and details of service,
refer to your roadside
assistance information.
ALL whEEL DRIVE
(A wD, if equipped)
Your vehicle may be equipped
with All Wheel Drive (AWD).
The AWD system is always
active and uses all four
wheels to power the vehicle.
This increases traction,
enabling you to drive over
terrain and road conditions
that a conventional two-wheel
drive vehicle cannot. Refer to
your Owner’s Guide for more
information. Note: If your
vehicle is equipped with AWD,
a spare tire of a different size
(other than the tire provided)
should never be used. Using
a different size could cause
the AWD system to stop
functioning and default to
front wheel drive. Your
vehicle is not intended for
off-road use.
1. DRIVER/PASSENgER
TEmPERATURE cONTROLS
Press to increase or decrease
the temperature on the
driver or passenger side of
the vehicle. Pressing the
passenger side control will
activate dual zone where the
driver and passenger are able
to select their own individual
settings. If the passenger side
controls are not activated,
the driver side controls will
determine the temperature
setting for the entire vehicle
(single zone).
2. AUTO
Press to activate automatic
temperature control. The
system will automatically
determine fan speed, airflow
location, A/C (on or off) and
outside or recirculated air
based on your temperature
selection.
3. OFF
Outside air is shut out and
the fan will not operate.
4. DRIVER/P
ASSENgER
hEATED SEATS
Press once for high heat (two lights), twice for low heat
(one light) and a third time
to deactivate (no lights).
5. mANUAL OVERRIDE
cONTROLS
Allows you to manually
determine where airflow
is directed (floor vents,
instrument panel vents,
rear seat floor vents or a
combination). To return to
fully automatic control,
press AUTO.
6. EXT
Press to display the outside
air temperature. Press
again to return to interior
temperature.
7. A/c
Press to activate/deactivate
air conditioning. For a MAX
A/C setting, press A/C,

and set the temperature to
60°F (16°C) and the highest
blower setting.
8. REcIRcULATION cONTROL
Press
to recirculate cabin
air. Recirculated air may
reduce the amount of time
to cool down the interior of the vehicle and may also help
reduce undesired odors from
reaching the interior of
the vehicle.
9. DEFROST

Distributes outside air through
the windshield defroster and
demister vents to clear fog or
thin ice from the windshield.
10. REAR wINDOw DEFROSTER
Press
to clear the rear
window of thin ice and fog.
Press again to deactivate.
If your vehicle is equipped
with both a rear defroster
and heated mirrors, the same
button will activate both.
11. DUAL (Single/dual
temperature control)
Press to activate dual zone
mode where the driver and
passenger have control of
their individual temperature
settings. Press again to
return to single zone where
the driver’s settings will
determine the temperature
for the entire vehicle.
cLImATE cONTROLS DUAL AUTOmATIc TEmPERATURE cONTROL SySTEm (DATc) wITh hEATED SEATS (if equipped)
Ford Motor Company Customer Relationship Center
P.O. Box 6248 | Dearborn, MI 48121
1-800-392-3673 (FORD)
(TDD for the hearing impaired: 1-800-232-5952) This Quick Reference Guide is not
intended to replace your vehicle
Owner’s Guide which contains more
detailed information concerning the
features of your vehicle, as well as
important safety warnings designed
to help reduce the risk of injury to
you and your occupants. Please
read your entire Owner’s Guide
carefully as you begin learning
about your new vehicle and refer
to the appropriate chapters when
questions arise. All information contained in this
Quick Reference Guide was
accurate at the time of duplication.

We reserve the right to change
features, operation and/or
functionality of any vehicle
specification at any time. Your Ford
dealer is the best source for the
most current information. For
detailed operating and safety
information, please consult your
Owner’s Guide.
9T4J 19G217 AA
August 2008 | First Printing | Quick Reference Guide | Edge | Litho in U.S.A.
FOLD FLAT FRONT PASSENgER SEATBAcK (if equipped)
The front passenger seatback can be folded to a horizontal position to
make room for a long load. To fold the seatback, move the seat as far
back as possible. Push the head restraint release button and move the
head restraint fully down. Pull up on the recliner handle A located on the
outboard side of the seat to fold the front passenger seatback. Without
releasing the handle, push the seatback forward. Move the seat as far
forward as possible.
2ND ROw SEAT REcLINE
To adjust the second row seatback to the desired position, while seated, \
pull the release lever B up and push the seatback rearward.
2ND ROw FOLD FLAT SEATBAcK
To fold down the rear seat, pull up on the lever B on the outboard side of
the seat cushion and let the seatback rotate downward into the load fl\
oor
position. To return to the upright position, rotate the seatback upward
until the seatback latches. The seatback will click when it is locked
into position.
2ND ROw EASyFOLD™ SEATBAcK RELEASE (if equipped)
The control buttons are located on the left-hand rear quarter trim panel\

(accessible from the liftgate area). Press and hold the control to low\
er the
seat. The top portion lowers the RIGHT (40%) seatback, and the bottom \
portion lowers the LEFT (60%) seatback.
SEATINg
A
B
