Brake system warning
Momentarily illuminates when the
ignition is turned ON and the
engine is off. Also illuminates when
the parking brake is engaged.
Illumination after releasing the
parking brake indicates low brake
fluid level.
Anti-lock brake system (ABS)
(If equipped)
Momentarily illuminates when the
ignition is turned on and the
engine is off. If the light remains
on or continues to flash, the ABS
needs to be serviced.
Turn signal
Illuminates when the left or right
turn signal or the hazard lights are
turned on. If one or both of the
indicators stay on continuously or
flash faster, check for a burned-out
turn signal bulb. Refer toExterior
bulbsin theMaintenance and
carechapter.
High beams
Illuminates when the high beam
headlamps are turned on.
Anti-theft system (if equipped)
Refer toAnti-theft systemin the
Controls and featureschapter.
P!
BRAKE
ABS
THEFT
Instrumentation
10

POSITIONS OF THE IGNITION
1. LOCK, locks the steering wheel,
gearshift lever (automatic
transaxle only) and allows key
removal. On vehicles with a
manual transaxle push the key in
while turning to lock.
2. ACCESSORY, allows the
electrical accessories such as the
radio to operate while the engine
is not running.
3. ON, all electrical circuits
operational. Warning lights
illuminated. Key position when
driving.
4. START, cranks the engine.
Release the key as soon as the
engine starts.
HEADLAMP CONTROL
Rotate the headlamp control
clockwise to the first position to
turn on the parking lamps only.
Rotate to the second position to
also turn on the headlamps.
Daytime running lamps (DRL)
(if equipped)
Turns the highbeam headlamps on
with a reduced output. To activate:
²the engine must be running
²the gearshift must not be in P
(Park)
²the headlamp control is in the
OFF or Parking lamps position.
LOCKACCONSTART0IIIIII4
3
2
1
OFF
Controls and features
26

The Daytime Running
Light (DRL) system will
not illuminate the tail lamps and
parking lamps. Turn on your
headlamps at dusk. Failure to do
so may result in a collision.
High beams
Push forward to activate.
Flash to pass
Pull toward you to activate and
release to deactivate.
TURN SIGNAL CONTROL
²Push down to activate the left
turn signal.
²Push up to activate the right
turn signal.
OFF
OFF
OFF
Controls and features
27

Using the right bulbs
Function Trade Number
Front park/turn lamps 3457 NAK
Foglamps (if equipped) 881
Headlamps-aero high and low beam 9007
Rear license plate lamps 168
High-mount brake lamp 921
Backup lamps 3156K
Brake lamps 3157K
Interior overhead lamp 12V/10W
Warning lights 37
Instrument panel gauge 194
Map lamps
For bulb replacement, see a
qualified service technician or your
dealer.
AIMING THE HEADLAMPS
Your vehicle is equipped with a
Vehicle Headlamp Aim Device
(VHAD) on each headlamp. Each
headlamp may be properly aimed
in the vertical (up/down) and the
horizontal (left/right) directions
using your VHAD system. The
headlamps on your vehicle are
properly aimed at the assembly
plant, and vertical and horizontal
indicators of the VHAD system are
calibrated.
A bubble (vertical indicator) that
is not centered between the two
red lines does not necessarily
indicate out-of-aim headlamps. If
your vehicle is not positioned on a
level surface, the slope will be
L
R
UP
DN
Maintenance and care
172

Air bag supplemental restraint
system ..........................................58
and child safety seats ..............60
description ................................59
disposal ......................................63
indicator light ...........................62
passenger air bag .....................61
Air cleaner filter .......................148
Air conditioning
manual heating and air
conditioning system ............21,24
Anti-lock brake system (ABS)
description ................................88
Anti-theft system ........................44
arming the system ....................44
disarming a triggered system ..46
disarming an untriggered
system .......................................45
Battery .......................................145
Brake fluid
checking and adding ..............136
Brakes ..........................................87
anti-lock .....................................87
anti-lock brake system (ABS)
warning light .............................88
fluid, checking and adding ....136
Break-in period .............................2
Bulbs, replacing ........................163
specifications ..........................172
Cargo cover .................................39
Changing a tire .........................113
Child safety seats ........................66
Chime
headlamps on ............................12
Cleaning your vehicle ...............175
built-in child seat ...................179
engine compartment ..............176
fabric ........................................178
instrument panel ....................178
plastic parts ............................177
safety belts ..............................179
tail lamps .................................178washing ....................................175
waxing .....................................175
wheels ......................................176
Clutch
fluid ..........................................137
Defrost
rear window ..............................25
Emission control system ..........160
Engine
service points ...................130,131
Engine block heater ...................84
Engine coolant
checking and adding .......138,139
disposal ....................................141
refill capacities ........................141
Engine oil ...........................132,134
changing oil and oil filter .......135
checking and adding .......132,134
Exhaust fumes ............................85
Floor mats ...................................38
Foglamps .....................................28
Fuel
calculating fuel economy .......159
improving fuel economy ........103
octane rating ...........................157
quality ......................................158
running out of fuel .................158
safety information relating to
automotive fuels .....................155
Fuel gauge ...................................14
Fuel pump shut-off switch ..39,104
Fuses ..............106,107,108,110,112
Gauges, Mechanical ....................13
engine coolant temperature
gauge .........................................14
Hazard flashers .........................104
Headlamps ...................................26
daytime running lights .............26
flashing ......................................27
high beam .................................27
Heating ........................................18
Index
188

High beams
indicator light ...........................10
Hood
release lever ............................128
Ignition
positions of the ignition ...........26
Instrument panel
lighting up panel and
interior .......................................17
Jump-starting your
vehicle .................................118,120
attaching cables ......................119
disconnecting cables ..............120
Keys
key in ignition chime ...............12
Lamps
dome lamps ........................36,171
fog lamps .................................167
headlamps ...............................165
high-mount brakelamp ...........167
interior lamps ....................36,171
map lamps ..........................36,172
tail lamps .................................169
License plate lamps ..................171
Lights, warning and indicator
air bag ..........................................9
anti-lock brakes (ABS) ............10
anti-theft ...................................10
brake ..........................................10
charging system ........................11
check coolant ............................11
liftgate ajar ................................11
low fuel ........................................7
oil pressure ...............................11
safety belt ...................................9
service engine soon .................7,8
turn signal indicator .................10
Lubricant specifications ...........181
Luggage rack .............................103
Mirrors
side view mirrors (power) .......17
Moon roof ....................................35Odometer .....................................15
Panic alarm feature, remote
entry system ................................42
Parking brake ..............................89
Parts (see Motorcraft parts) ....180
Power steering
fluid, checking and adding ....142
Rear window
wiper ..........................................35
Refill capacities for fluids ........180
Relays .................................106,113
Remote entry system .................39
illuminated entry ......................44
locking/unlocking doors ......40,41
replacement/additional
transmitters ...............................43
replacing the batteries .............42
Reporting safety defects ..........187
Safety restraints
automatic locking mode
(retractor) ............................53,54
extension assembly ..................56
for children ...............................63
for second row bench
seats ............................73,74,78,79
lap and shoulder belts .............52
maintenance ..............................57
proper use .................................51
warning light and chime .....11,57
Safety seats for children
attaching with tether straps ....70
automatic locking mode
(retractor) .................................67
tether anchorage
hardware ..............................70,71
Seats ............................................47
adjusting the seat, manual .......47
folding rear seats ......................50
head restraints ..........................47
Servicing your vehicle ..............123
precautions when servicing ...123
