Engine Oil Pressure Gauge
*
[LG07601(ALL)06/93]
This gauge indicates the engine's oil pressure, not the oil level.
However, if your engine's oil level is low, it could affect the oil
pressure. With the engine running, the pointer should move into
the NORMAL band. If the pointer drops below the NORMAL
band while the engine is running, you have lost oil pressure
and continued operation will cause severe engine damage.
*
[LG07701(ALL)03/95]
If you lose engine oil pressure:
*
[LG07801(ALL)03/95]1.
Pull off the road as soon as safely possible.
*
[LG07901(ALL)03/95]2.
Turn off the engine. If you do not stop the engine as soon as
safely possible, severe engine damage could result.
*
[LG08001(ALL)02/95]3.
Check the engine's oil level, following the instructions on
checking and adding engine oil. Refer toEngine oilin the
Index. If you do not follow these instructions, you or others
could be injured. To assure an accurate reading, your vehicle
should be on level ground.
*
[LG08051(ALL)03/93]4.
If the level is low, add only as much oil as necessary before
you start the engine again. Do not overfill. Do not operate
the engine if the pointer is below the NORMAL band,
regardless of the oil level. Contact your nearest dealer for
further service actions.
[LG08150(ALL)10/94]
7-1/2 pica art:0020540-E
Engine oil pressure gauge Ð mechanical cluster with tachometer
File:05unlgx.ex
Update:Thu Feb 29 09:04:08 1996

Warning Lights and Gauges
91
%*
[LG08900(ALL)01/95]
High Beam Light
*
[LG09001(ALL)03/95]
This light comes on when the headlamps are turned on high
beam or when you flash the lights.
[LG09025(ALL)10/94]
6 pica art:0021266-A
High beam indicator light symbol
%*
[LG09300(ALL)03/95]
ªHeadlamps Onº Alert Chime
[LG09400(ALL)09/95]
This chime sounds if you open the driver's door while the
headlamps or parking lamps are on, and the key is removed
from the ignition.
%*
[LG09500(ALL)01/95]
Fuel Gauge
*
[LG09700(ALL)06/93]
The fuel gauge displays approximately how much fuel is in the
fuel tank only when the ignition switch is ON.
*
[LG09850(ALL)01/95]
For a proper fuel gauge indication after adding fuel, the ignition
switch should be in the OFF position while the vehicle is being
refueled.
*
[LG09860(ALL)06/93]
The fuel gauge indicator may vary slightly when the vehicle is
in motion.
*
[LG09875(ALL)08/93]
With ignition switch OFF, the fuel gauge indicator may drift
from the ignition switch ON position.
File:05unlgx.ex
Update:Thu Feb 29 09:04:08 1996

92
[LG10300(ALL)10/94]
6 pica art:0020752-E
Fuel gauge Ð mechanical cluster with tachometer
%*
[LG11100(ALL)01/95]
Engine Coolant Temperature Gauge
*
[LG11201(ALL)03/95]
This gauge tells you the temperature of the engine coolant, not
the coolant level. If the coolant is not at its proper level or
mixture, the gauge indicator will not be accurate.
*
[LG11301(ALL)08/95]
The pointer moves from the C (cold) mark into the Normal
band as the engine coolant warms up. It is acceptable for the
pointer to fluctuate within the Normal band under normal
driving conditions. Under certain driving conditions, such as
heavy stop and go traffic or driving up hills in hot weather, the
pointer may move to the top of the Normal band.
*
[LG11401(ALL)05/95]
If, under any circumstances, the pointer moves above the
NORMAL band, the engine coolant is overheating and
continued operation may cause engine damage.
*
[LG11501(ALL)01/95]
If your engine coolant overheats:
*
[LG11601(ALL)03/95]1.
Pull off the road as soon as it is safely possible.
*
[LG11701(ALL)03/95]2.
Turn off the engine. If you do not stop the engine as soon as
safely possible, severe engine damage could result.
*
[LG11801(ALL)05/95]3.
Let the engine cool.DO NOT REMOVE COOLANT
SYSTEM FILL CAP UNTIL THE ENGINE IS COOL.
*
[LG11901(ALL)04/95]4.
Check the coolant level following the instructions on
checking and adding coolant to your engine. Refer toEngine
coolantin the Index. If you do not follow these instructions,
you or others could be injured.
File:05unlgx.ex
Update:Thu Feb 29 09:04:08 1996

Warning Lights and Gauges
93
*
[LG12240(ALL)01/95]
If the coolant continues to overheat, have the coolant system
serviced as soon as possible.
[LG12325(ALL)10/94]
7-1/2 pica art:0021154-C
Engine coolant temperature gauge Ð mechanical cluster with tachometer
%*
[LG12601(ALL)01/95]
Speedometer
*
[LG12700(ALL)01/95]
The speedometer tells you how many miles (kilometers) per
hour your vehicle is moving.
*
[LG12753(ALL)08/95]
Some vehicles are equipped with a vehicle speed (mph/km/h)
limiting device that is contained within the Powertrain Control
Module (PCM). The purpose of this device is to maintain peak
vehicle speed below a specified limit. (Vehicle speed limits may
vary based on engine displacement.)
*
[LG12756(ALL)05/95]
If you are experiencing an ªengine cut-outº condition at high
speeds, it may be the result of this limiting device. It is a
normal condition and can be avoided by reducing
vehicle/engine speed.
File:05unlgx.ex
Update:Thu Feb 29 09:04:08 1996

94
[LG12790(ALL)08/94]
10-1/2 pica art:0020873-F
Speedometer
%*
[LG12801(ALL)01/95]
Odometer
*
[LG12900(ALL)01/95]
The odometer tells you the total number of miles (kilometers)
your vehicle has been driven.
%*
[LG13000(ALL)11/94]
Trip Odometer
*
[LG13100(ALL)03/93]
If you want to track your mileage up to 999.9 miles
(kilometers), use the trip odometer. Simply set the trip odometer
to zero by pressing the reset button firmly when beginning the
distance you wish to measure.
%*
[LG13250( X)02/95]
Tachometer
*
[LG13300(ALL)05/95]
The tachometer will show you the engine's speed measured in
revolutions per minute (RPM).
*
[LG13400(ALL)05/95]
The tachometer may move slightly when the key is placed in
the ACC or ON position, with the engine off. This is normal
and does not affect the performance of the tachometer when the
engine is running.
File:05unlgx.ex
Update:Thu Feb 29 09:04:08 1996

Warning Lights and Gauges
95
*
[LG13525(ALL)09/95]
Some vehicles are equipped with an engine speed (RPM)
limiting device contained within the Powertrain Control Module
(PCM). The purpose of this device is to maintain peak engine
speed (RPM) below a specified limit. This feature is only
evident on automatic transmission vehicles when shifting
manually (1, 2, D) and on all manual transmission units. (Engine
speed limits may vary based on engine displacement.)
*
[LG13550(ALL)05/95]
If you are experiencing an ªengine cut-outº condition at high
speeds, it may be the result of this limiting device. It is a
normal condition and can be avoided by reducing
vehicle/engine speed.
[LG13650(ALL)05/94]
10-1/2 pica art:0020528-E
Tachometer
[LG13675(ALL)03/93]
NOTE: If the 4.0L engine exceeds 5200 RPM, the PCM will
restrict fuel flow to maintain engine speed at or below
5200 RPM. This function is designed to protect the
engine and should be considered normal operation.
File:05unlgx.ex
Update:Thu Feb 29 09:04:08 1996

96
%*
[LG35000( X)04/95]
The Electronic Message Center
(If equipped)
[LG35050( X)03/95]
The Electronic Message Center (M/C) display, located in the
center of the floor console, works only when your ignition is in
the ON position. Each time the M/C is powered, the display
goes through a self-test by displaying a blank message for two
seconds. This self-test is used to stabilize the systems before
reporting the status of the systems to you.
*
[LG35100( X)01/95]
The M/C tells you about the condition of your vehicle by two
methods:
*
[LG35150( X)01/95]
n
Operator selectable features
*
[LG35200( X)01/95]
n
Continuous warning reporting of monitored systems
*
[LG35250( X)01/95]
You can select different features for the M/C to display by
using the keyboard directly below the M/C display. You will
hear a tone when you press one of these switches. However, if
the M/C detects a warning from any of the monitored systems
then the M/C will display the appropriate warning message.
%*
[LG35300( X)01/95]
Operator Selectable Features
*
[LG35350( X)01/95]
These features are controlled by the switches in the keyboard
below the M/C display. The following pages describe the
operation of the individual switches.
File:05unlgx.ex
Update:Thu Feb 29 09:04:08 1996

Warning Lights and Gauges
97
[LG35400( X)08/94]
17-1/2 pica
art:0021115-B
Electronic message center
*
[LG35450( X)01/95]
English/Metric
*
[LG35500( X)01/95]
A press of the ENGLISH/METRIC switch allows you to change
the M/C and electronic climate control displays from English to
metric units. When you press this switch, all the displays
change from English to metric or metric to English units. The
displays remain in the units you have chosen until you change
them again, even after you turn off the vehicle and start it
again.
*
[LG35550( X)01/95]
Fuel Range
[LG35600( X)10/94]
A press of the FUEL RANGE switch allows you to display one
of two features (Distance to Empty or Distance Driven). The
first press of the FUEL RANGE switch allows you to display
approximately how many miles or kilometers you can drive
before you run out of fuel.
File:05unlgx.ex
Update:Thu Feb 29 09:04:08 1996

98
*
[LG35650( X)01/95]
To ensure accuracy, turn the ignition OFF when you fill the fuel
tank.
[LG35700( X)06/94]
NOTE: Distance to empty is calculated using a ªRunning
Average Fuel Economyº initialized by the factory. The
value is not the same as the Average Fuel Economy
Display. The Running Average Fuel Economy is based
on more than 500 miles (800 km) of driving history.
Also, the factory default for Running Average Fuel
Economy is reinitialized if the battery is disconnected.
*
[LG35750( X)05/95]
If the ªFUEL LEVEL ERRORº message is displayed, this means
that there is a problem with the fuel indication system and you
should contact your dealer for service as soon as possible.
[LG35800( X)03/95]
A second consecutive press of the FUEL RANGE switch allows
you to display how many miles or kilometers you have driven
since you last reset this feature. A press of the RESET switch
with MILE (KM) DRIVEN displayed resets the distance driven
to 0.0 miles or kilometers.
*
[LG35850( X)05/95]
Fuel Status
*
[LG35900( X)01/95]
A press of the FUEL STATUS switch allows you to display one
of two features (Fuel Remaining or Fuel Used). The first press
of the FUEL STATUS switch allows you to display the
approximate amount of fuel in the tank in whole numbers
(gallons or liters).
*
[LG35950( X)01/95]
If your fuel tank is full or nearly full, the M/C will display the
ªFULL FUEL TANKº message. If your fuel tank is empty or
nearly empty, the M/C will display the ªEMPTY FUEL TANKº
message.
[LG36000( X)04/94]
A second consecutive press of the FUEL STATUS switch allows
you to display the amount of fuel used since you last reset this
feature. A press of the RESET switch with GALLONS (LITERS)
USED displayed resets the amount to 0.0 gallons or liters used.
File:05unlgx.ex
Update:Thu Feb 29 09:04:08 1996

Warning Lights and Gauges
99
*
[LG36050( X)01/95]
Because of factors like rounding of numbers and fuel movement
in the tank, the M/C and the service station fuel pump readings
may disagree slightly.
%*
[LG36100( X)05/95]
Fuel Economy
[LG36150( X)10/94]
A press of the FUEL ECON switch allows you to display one of
two features (Average Fuel Economy or Instantaneous Fuel
Economy). The first press of the FUEL ECON switch will allow
you to display your average fuel economy in miles/gallons or
liters/kilometers. Your M/C computes this figure using the
distance traveled and fuel used information. If you want to reset
this feature, press the RESET switch while the average fuel
economy feature is displayed. Your average fuel economy will
then use data only from after the RESET was pressed to
calculate the new average.
[LG36200( X)10/94]
A second consecutive press of the FUEL ECON switch will
allow you to display the instantaneous fuel economy, which is
the fuel economy that you get at any particular moment. For
example, you can see what your fuel economy is in heavy traffic
or on an open highway. Your fuel economy is affected by such
factors as braking, acceleration, and the type of road you are
driving on.
*
[LG36250( X)01/95]
Your vehicle must be moving for the M/C to calculate the fuel
economy. When your vehicle is not moving, instantaneous fuel
economy will be displayed at 0 miles/gallon or
99 kilometers/100 liters. When you are moving, the M/C will
display between 0 and 99 miles/gallon or between 1 and
99 kilometers/100 liters.
*
[LG36300( X)01/95]
Reset
[LG36350( X)01/95]
A press of the RESET switch will allow you to reset the current
feature being displayed. Warnings, Distance Driven, Average
Fuel Economy, Fuel Used, and your Personalized Oil Reset
Percentage are the only features which respond to the RESET
switch. Distance to Empty, Fuel Remaining, and Instantaneous
File:05unlgx.ex
Update:Thu Feb 29 09:04:08 1996
