100Fuel Economy cannot be reset. That is, these three features are
unaffected by pushing the RESET switch.
%*
[LG36750( X)01/95]
System Check
*
[LG36800( X)01/95]
A press of the SYSTEM CHECK switch causes the M/C to cycle
through a status of each of the systems being monitored. For
each of the monitored systems, the M/C will indicate either an
OK message or a warning message for two seconds. The
sequence of the system check report is as follows:
*
[LG36850( X)01/95]
n
Engine Oil Life Left
*
[LG36900( X)01/95]
n
Engine Oil Level
*
[LG37000( X)01/95]
n
Voltage Level
*
[LG37050( X)01/95]
n
Engine Coolant Temperature
*
[LG37100( X)01/95]
n
Washer Fluid Level
[LG37150( X)04/94]
n
Head Lamps
[LG37200( X)04/94]
n
Tail Lamps
[LG37250( X)04/94]
n
Brake Lamps
[LG37300( X)06/94]
n
Air Ride System (if equipped)
*
[LG37350( X)01/95]
n
Fuel Level
*
[LG37400( X)01/95]
At normal conclusion of the system check sequence, the M/C
will display the last displayed feature before pressing the
SYSTEM CHECK switch or the warnings that are active.
*
[LG37450( X)01/95]
For two of the systems reported in the system check (Engine Oil
Life Left and Fuel Level), there are two messages to describe the
status of the system. For Engine Oil Life Left, the first message
will indicate the oil change status (OK, SOON, REQUIRED) and
the second message will indicate the oil life remaining as a
percentage. If the second message is ªOIL TEMP SIGNAL
ERRORº, this means that there is a problem with the oil
temperature sender system and you should contact your dealer
File:05unlgx.ex
Update:Thu Feb 29 09:04:08 1996

Warning Lights and Gauges
101 for service as soon as possible. For Fuel Level, the first message
will indicate the fuel level status (OK or LOW) and the second
message will indicate the range (distance to empty).
*
[LG37500( X)01/95]
Message center operation during system check
*
[LG37550( X)01/95]
The M/C switches will operate as follows during the System
Check sequence:
*
[LG37600( X)01/95]1.
A press of the SYSTEM CHECK switch will advance the
cycle to the next system message without waiting the two
seconds.
*
[LG37650( X)01/95]2.
A press of the RESET switch anytime during this sequence
will cause the SYSTEM CHECK cycle to conclude
immediately and the last displayed feature before pressing
SYSTEM CHECK will be displayed.
[LG37700( X)04/94]3.
A press of the RANGE, FUEL STATUS, OR FUEL
ECONOMY, switch will conclude the SYSTEM CHECK cycle
and the requested feature will be displayed.
*
[LG37750( X)01/95]4.
A press of the ENGLISH/METRIC switch will halt the
SYSTEM CHECK cycle and display, in the new mode, the
last displayed feature before pressing the SYSTEM CHECK
switch.
*
[LG37800( X)01/95]5.
A press of the OIL CHANGE RESET switch during the
sequence will cause the SYSTEM CHECK cycle to conclude
and the Oil Change Reset Procedure will begin.
*
[LG37850( X)01/95]
System Warnings
[LG37900( X)01/95]
System warnings alert you to possible problems or malfunctions
in your vehicle's operating systems. There are twelve warning
messages which can be displayed by the Message Center (M/C)
to show the status of the monitored systems. When a warning
occurs, the warning message is displayed and a tone sounds.
The warning message will appear at a brighter level if the
instrument panel is dimmed.
File:05unlgx.ex
Update:Thu Feb 29 09:04:08 1996

102
*
[LG37950( X)01/95]
In the event of a multiple warning situation, the M/C will cycle
the display to show all warnings by displaying each warning
message for 4 seconds.
*
[LG38000( X)01/95]
Using the message center while a warning is active
[LG38050( X)04/94]
If you want to display the operator selectable features of the
M/C while a warning is displayed, the warning message may
be removed from the M/C display by pressing the RESET
switch. The M/C will display the last selected feature if there
are no more warning messages. This allows you to use the full
functionality of the M/C after you acknowledge the warning by
pressing the RESET switch and clearing the warning message.
*
[LG38100( X)01/95]
Warning messages which have been reset are divided into two
categories. They will reappear on the display in 10 minutes
from the reset or they will not reappear until an ignition key
OFF-ON cycle. This reappearing of warning messages is a
reminder that these warning conditions still exist within the
vehicle. Warnings may be repeatedly reset. All warning
messages will reappear after an entire SYSTEM CHECK
sequence has been completed.
File:05unlgx.ex
Update:Thu Feb 29 09:04:08 1996

Warning Lights and Gauges
103
*
[LG38150( X)01/95]
The following is a list of warning messages and their associated
reset category:
[LG38200( X)04/94]
fourteen pica
chart:0021147-A*
[LG38250( X)01/95]
Check Engine Temp
*
[LG38300( X)01/95]
This warning message is displayed when the engine coolant is
overheating. Stop the vehicle as soon as safely possible, turn off
engine and let it cool. Check the coolant and level following the
instructions in theServicing Your Vehiclechapter. If you do not
follow these instructions, you or others could be injured.
*
[LG38350( X)01/95]
Check Charging System
*
[LG38400( X)03/95]
This warning message is displayed when the electrical system is
not maintaining a proper voltage. If you are running electrical
accessories when the engine is idling at a low speed, turn off as
many of the electrical loads as soon as safely possible. If this
warning stays on or comes on when the engine is operating at
normal speeds, have the electrical system checked as soon as it
is safely possible.
File:05unlgx.ex
Update:Thu Feb 29 09:04:08 1996

104
*
[LG38450( X)01/95]
Low Fuel Level
*
[LG38500( X)01/95]
This warning message is displayed when you have
approximately 50 miles (80 km) left before you run out of fuel.
*
[LG38550( X)01/95]
Low Oil Level
*
[LG38600( X)01/95]
This warning message is displayed when your engine oil level is
low. If this warning message is displayed, check the level of the
engine oil.
*
[LG38650( X)02/95]
To check your oil:
*
[LG38700( X)05/95]1.
Park your vehicle on level ground, turn off the engine and
wait at least 5 minutes for the oil to drain back into the oil
pan.
*
[LG38750( X)01/95]2.
Use the dipstick to check the oil. If the level is low, add oil,
but do not overfill.
*
[LG38800( X)01/95]
If you are parked on a steep incline, the LOW OIL LEVEL
warning may come on when you start your vehicle, even
though the oil is at the correct level.
*
[LG38850( X)01/95]
For information about adding oil, seeEngine oilin the Index.
%*
[LG38900( X)05/95]
Low Washer Fluid Light
*
[LG38950( X)04/95]
This warning message is displayed when the washer fluid
reservoir is less than one quarter full.
[LG39000( X)01/95]
Check Head Lamps
[LG39050( X)08/94]
This warning message is displayed when you turn on your
headlamps and at least one of them is burned out. A high beam
headlamp burn out is not monitored.
[LG39100( X)04/94]
Check Tail Lamps
[LG39150( X)04/94]
This warning message is displayed when you turn on your rear
parking (tail) lamps and at least one of them is burned out.
File:05unlgx.ex
Update:Thu Feb 29 09:04:08 1996

Warning Lights and Gauges
105
[LG39200( X)04/94]
Check Brake Lamps
[LG39250( X)03/95]
This warning message is displayed when you turn on your
brakelamps by pressing the brake pedal and at least one of the
lamps is burned out.
[LG39300( X)04/94]
If you use additional lights, such as trailer lights, or if you
replace the headlamps or bulbs with equipment that is not equal
to the original equipment from Ford, you may get a false
ªCHECK LAMPSº warning or no warning at all.
[LG39350( X)06/94]
Air Ride Switch Off (If equipped)
[LG39400( X)03/95]
This warning message is displayed when the air suspension
switch, located in the rear jack stowage area on the left side, is
off. For information about the operation of the air suspension
switch, seeAutomatic ride control systemin the Index.
[LG39450( X)06/94]
Check Air Ride System (If equipped)
[LG39500( X)03/95]
This warning message is displayed when an air suspension
system fault has been detected. If this warning message is
displayed while driving, safely pull off the road at your earliest
convenience. If the vehicle is loaded beyond the recommended
maximum payload, the CHECK AIR RIDE SYSTEM message
may be displayed. This is a normal condition if the vehicle is
overloaded. To correct this condition, remove or redistribute the
payload per the recommended maximum requirements. Turn the
ignition switch from ON to OFF and ON again. If the warning
message reappears, turn the air suspension switch (located in
the rear jack stowage area on the left side) OFF and take your
vehicle to a dealership for service as soon as possible.
*
[LG39550( X)01/95]
Change Oil Soon or Oil Change Required
*
[LG39600( X)01/95]
One of these warning messages is displayed when the engine oil
life remaining is 5% or less. When Oil Life Left is between 5%
and 0%, the ªCHANGE OIL SOONº message will be displayed.
When Oil Life Left reaches 0%, the ªOIL CHANGE REQUIREDº
message will be displayed.
File:05unlgx.ex
Update:Thu Feb 29 09:04:08 1996

106
*
[LG39650( X)01/95]
An oil change is required whenever indicated by the M/C. USE
ONLY RECOMMENDED ENGINE OILS (SeeEngine oilin the
Index).
*
[LG39700( X)01/95]
The M/C will tell you the percent of oil life left during System
Check. This percentage is based on your driving history and the
time since your last oil change. In order to ensure accurate oil
life left indications, you should only perform the following OIL
CHANGE RESET Procedure after you have the oil changed.
*
[LG39801( X)01/95]
Oil Change Reset
[LG39901( X)08/94]
A press of the OIL CHANGE RESET switch will allow you to
reset the oil life feature to 100% (or your Personalized Oil Reset
Percentage). After you have the oil changed, you must execute
the following procedure. Press the OIL CHANGE RESET switch
and hold for five seconds as the M/C counts down for five
seconds. After a successful reset the Message Center will display
ªOIL LIFE RESET TO 100%.º If you have established a
Personalized Oil Reset Percentage, the display will show that
percentage instead of 100%. To ensure accurate oil life
indicators, perform this reset procedure only after an oil change.
[LG40001( X)08/94]
Your Personalized Oil Reset Percentage allows you to establish a
smaller oil change interval than the manufacturer's
recommended interval. To establish your Personalized Oil Reset
Percentage perform the following procedure:
[LG40101( X)08/94]1.
Press and hold the OIL CHANGE RESET switch and press
the RESET switch while the display is still counting down
the 5 seconds to reset. The display will change to ªSTART
OIL LIFE AT XXX%.º
[LG40201( X)08/94]2.
Press the OIL CHANGE RESET switch until the displayed
percentage is the Personalized Oil Reset Percentage that you
desire. Your choices are 100%, 90%, 80%, 70%, 60%, 50%,
40% and 30%.
File:05unlgx.ex
Update:Thu Feb 29 09:04:08 1996

Warning Lights and Gauges
107
[LG40301( X)08/94]3.
Press the RESET switch to complete the procedure. A press
of any switch besides RESET or OIL CHANGE RESET will
abort this procedure and will not establish your new
Personalized Oil Reset Percentage.
[LG40401( X)08/94]
When your Personalized Oil Reset Percentage has been
established, it will be used beginning with the completion of
your next OIL CHANGE RESET procedure.
File:05unlgx.ex
Update:Thu Feb 29 09:04:08 1996

109
Instrument Panel Controls
[IP00250( X)12/95]
33-1/2 pica
art:0090198-B
Instrument Panel & Controls
File:06unipx.ex
Update:Thu Feb 29 09:05:45 1996

110
[IP00400( X)03/95]
The main controls for the climate control system, lights, message
center, lamps, clocks and radio are on the instrument panel.
%*
[IP00475(ALL)09/95]
NOTE: Any cleaner or polish that increases the gloss (shine)
of the upper part of the instrument panel should be
avoided. The dull finish in this area is to help protect
the driver from undesirable windshield reflection.
%*
[IP00500(ALL)06/95]
The Climate Control Systems
*
[IP00601(ALL)12/91]
Your vehicle is equipped with a control assembly designed to
handle either a combination A/C-Heater System or a
Heater-Only System.
%*
[IP00801(ALL)10/93]
Instrument Panel Registers
*
[IP00901(ALL)02/95]
There are four registers in the instrument panel. Each of these
registers contains a louver assembly which can be manually
adjusted to direct airflow up, down, left and right. An
illustration of the register locations follows.
[IP01201(ALL)04/94]
7-1/2 pica art:0020099-D
Instrument panel registers
[IP01400(ALL)12/91]
Air Conditioning (A/C) Controls (Manual Air
Conditioning)
*
[IP01450(ALL)02/95]
The control for your air conditioning and heater system is
located at the center of the instrument panel below the radio
and will operate only when the ignition key is turned to the
ON position. Your air conditioner and heater will heat and/or
cool your vehicle interior depending on the function position
File:06unipx.ex
Update:Thu Feb 29 09:05:45 1996
