FORD EXPLORER 1996 2.G Owners Manual

Accessories
331
[AC02600( X)05/95]
thirty-two pica
chart:0090200-AFile:14unacx.ex
Update:Thu Feb 29 09:16:06 1996

332
[AC02700( X)05/95]
thirty-two pica
chart:0090201-AFile:14unacx.ex
Update:Thu Feb 29 09:16:06 1996

333
Servicing Your Explorer
%*
[SV00300(ALL)03/95]
Service Made Easy
*
[SV00400(ALL)01/95]
Ford has two goals for servicing your vehicle.
*
[SV00500(ALL)01/95]1.
When we can, we design parts that do not need to be
serviced.
*
[SV00600(ALL)01/95]2.
We want to make servicing your vehicle as easy as possible.
To help you:
*
[SV00700(ALL)01/95]
n
We highlight do-it-yourself items in yellow in the engine
compartment so that you can find them easily.
*
[SV00800(ALL)01/95]
n
When possible, we design parts Ð such as the headlamp
bulbs Ð that can be replaced without tools.
*
[SV00900(ALL)05/94]
n
We give you a Maintenance Schedule that makes tracking
routine service for your vehicle easy. The maintenance
schedule is located in theMaintenance Schedule and Record
booklet.
*
[SV01000(ALL)01/95]
This chapter tells you about the basic parts that you need to
check and service regularly.
*
[SV01050(ALL)02/95]
If your vehicle needs professional servicing, your dealership can
provide the parts and service required. Check yourWarranty
Information Bookletto find out which parts and services are
covered. Also see theCustomer Assistancechapter of this Owner
Guide.
*
[SV01300(ALL)03/95]
Ford Motor Company recommends that the Owner Maintenance
Checks listed in theMaintenance Schedule and Recordbooklet be
performed for the proper operation of your vehicle. In addition
to the conditions listed in theOwner Maintenance Checklist,be
alert for any unusual noise, vibration, or other indication that
your vehicle may need service. If you do notice something
unusual, see that your vehicle is serviced promptly.
File:15unsvx.ex
Update:Thu Feb 29 09:20:34 1996

334
%*
[SV01400(ALL)09/95]
NOTE: Always dispose of used automotive fluids in a
responsible manner. Follow your community's
standards for disposing of these types of fluids. Call
your local recycling center to find out about recycling
automotive fluids.
%*
[SV01600(ALL)06/95]
Precautions When Servicing Your Vehicle
*
[SV01700(ALL)06/95]
Be especially careful when inspecting or servicing your vehicle.
Here are some general precautions for your safety:
*
[SV01900(ALL)06/95]
n
If you must work with the engine running, avoid wearing
loose clothing or jewelry that could get caught in moving
parts. Take appropriate precautions with long hair.
*
[SV02000(ALL)06/95]
n
Do not work on a vehicle in an enclosed space with the
engine running, unless you are sure you have enough
ventilation.
*
[SV02100(ALL)08/95]
n
Never get under a vehicle while it is supported only by a
jack. If you must work under a vehicle, use safety stands.
*
[SV02200(ALL)06/95]
n
Keep all lit cigarettes and other smoking materials away
from the battery and all fuel-related parts.
*
[SV02500(ALL)03/95]
If you disconnect the battery, the engine must ªrelearnº its idle
conditions before your vehicle will drive properly. To find out
how the engine does this, seeBatteryin this chapter.
*
[SV02600(ALL)03/95]
Working with the engine off:
*
[SV02660(ALL)03/95]1.
Set the parking brake fully and make sure that the gearshift
is securely latched in P (Park).
*
[SV02700(ALL)06/95]2.
Remove the key from the ignition after you turn the engine
off.
*
[SV02725(ALL)06/95]3.
Block the wheels. This will prevent your vehicle from
moving unexpectedly.
File:15unsvx.ex
Update:Thu Feb 29 09:20:34 1996

Servicing Your Explorer
335
*
[SV02750(ALL)03/95]
Working with the engine on:
[SV02775(ALL)03/95]1.
Set the parking brake fully, and make sure the gearshift is
securely latched in P (Park) (automatic transmission) or
Neutral (manual transmission) and block the wheels.
*
[SV02825(ALL)03/95]2.
Block the wheels. This will prevent your vehicle from
moving unexpectedly.
*
[SV02900(ALL)02/95]
RWARNING
Do not start your engine with the air cleaner removed
and do not remove it while the engine is running.
%*
[SV02950(ALL)03/95]
Opening the Hood
[SV03035(ALL)12/91]1.
Pull the hood release handle, located below the steering
column.
[SV03040(ALL)01/95]
7-1/2 pica art:0020332-B
Hood release handle
*
[SV03050( X)12/91]2.
While applying downward pressure on the hood, push the
hood latch handle located behind the grille near the center
front of the vehicle to the left.
File:15unsvx.ex
Update:Thu Feb 29 09:20:34 1996

336
[SV03750( X)02/95]
17-1/2 pica
art:0020555-G
Hood
*
[SV03775(ALL)09/95]
NOTE: Read and understandPrecautions When Servicing Your
Vehicleat the beginning of this chapter before
opening the hood.
[SV03850( X)08/94]
Close the hood with enough force to make it latch. Be sure to
oil the hood latch every six months to maintain smooth
operation.
*
[SV03900(ALL)05/90]
Always attempt to lift the hood after closing to be sure it is
securely latched.
%*
[SV04500(ALL)04/95]
Engine Compartment
[SV04875( X)03/95]
Your Explorer has either a 4.0 Liter EFI, V-6 engine or a 5.0
Liter EFI, V-8 engine.
[SV05505( X)10/92]
The following page shows a diagram of the engine and where
to find items that you should regularly service.
File:15unsvx.ex
Update:Thu Feb 29 09:20:34 1996

Servicing Your Explorer
337
[SV05625(ALL)03/95]
33-1/2 pica
art:0090153-A
4.0L engine compartment service points
File:15unsvx.ex
Update:Thu Feb 29 09:20:34 1996

338
[SV05650( X)09/95]
full page art:0090135-C
5.0L engine compartment service
File:15unsvx.ex
Update:Thu Feb 29 09:20:34 1996

Servicing Your Explorer
339
%*
[SV05660(ALL)04/95]
Cleaning the Engine
*
[SV05665(ALL)04/95]
A clean engine is more efficient because a buildup of grease and
dirt acts as an insulator, keeping the engine warmer than usual.
*
[SV05670(ALL)07/95]
n
Extreme care must be used if a power washer is used to
clean the engine. The high pressure fluid could penetrate
sealed parts and assemblies causing damage or malfunctions.
*
[SV05675(ALL)08/95]
n
In order to avoid possible cracking of the engine block or
fuel injection pump, do not spray a hot engine or injection
pump with cold water.
[SV05680(ALL)03/95]
n
The alternator, coils and air intake must be covered.
Covering these components will help prevent water damage.
*
[SV05685(ALL)04/95]
n
Never wash or rinse the engine while it is running. Water
getting into the engine may cause internal damage.
%*
[SV06100(ALL)03/95]
Filling the Fuel Tank
[SV06375( X)04/94]
10-1/2 pica
art:0020556-C
Fuel filler door
File:15unsvx.ex
Update:Thu Feb 29 09:20:34 1996

340
%*
[SV06550(ALL)02/91]
Opening the Fuel Filler Door
*
[SV06600(ALL)10/94]
To open the fuel filler door of your vehicle, just insert your
finger in the divot and pull the door open all the way.
*
[SV06610(ALL)02/95]
Filling the fuel tank
*
[SV06620(ALL)04/94]
RWARNING
Do not overfill the fuel tank. The pressure in an
overfilled tank may cause leakage and lead to fuel spray
and fire.
*
[SV06630(ALL)01/95]
To fill the fuel tank properly:
*
[SV06640(ALL)09/95]
NOTE: Extinguish all lit cigarettes, other smoking materials,
and any open flames before fueling your vehicle.
[SV06800(ALL)08/94]1.
Unscrew the fuel cap by exerting pressure on the plastic lock
bar and rotating the fuel cap counterclockwise.
[SV06850(ALL)08/94]2.
Turn the fuel cap 1/2 to 3/4 of a turn until a hissing sound
is heard. Wait until the hissing sound stops and then
continue rotating counterclockwise to remove the fuel cap.
[SV06900(ALL)01/95]
Make sure that you follow the above fuel cap removal
instructions and use caution. Such caution will minimize the
possibility of fuel spraying during removal of the fuel cap.
[SV06910(ALL)01/95]3.
Make sure that you pump unleaded fuel and put the nozzle
all the way inside the fuel filler pipe.
[SV06920(ALL)01/95]
If you spill any fuel on the body of your vehicle, clean it off
immediately. The fuel may dull or soften the paint if you do
not wash it off.
*
[SV06950(ALL)03/91]
To replace and secure the fuel cap; place it in position and
rotate it clockwise until it clicks (ratchets). Doing so will not
damage or break the fuel cap. The ratcheting mechanism allows
the fuel cap to be sealed without overtightening.
