FORD F250 1997 Owners Manual

131
*
[SS31300(F )01/96]
8. Double check that the retractor is in the
automatic locking mode. Try to pull more
belt out of the retractor. If you cannot, the
belt is in the automatic locking mode. See
Figure 8.
*
[SS31400(F )04/96]
half page art:0011245-C
Checking the retractor
*
[SS31500(F )01/96]
9. Check to make sure that the child seat is
properly secured prior to each use. If the
retractor is not locked, repeat steps 4
through 7.
*
[SS31600(F )01/96]
To remove the retractor from automatic lock
mode, allow webbing to retract fully to its
stowed position and the retractor will
automatically switch back to the vehicle sensitive
locking mode for normal adult usage.
File:06ltssf.ex
Update:Tue May 28 08:44:33 1996
ProCarManuals.com

132
*
[SS31700(F )05/96]
Installing a Child Safety Seat at the Center
Seating Position with Locking Adjustable
Lap Belt
*
[SS31800(F )01/96]
1. Lengthen the lap belt. To lengthen the belt,
hold the tongue so that its bottom is
perpendicular to the direction of webbing
while sliding the tongue up the webbing.
*
[SS31900(F )01/96]
2. Place the child safety seat in the center
seating position.
*
[SS32000(F )01/96]
3. Route the tongue and webbing through the
child seat according to the child seat
manufacturer's instructions.
*
[SS32100(F )01/96]
4. Insert the belt tongue into the proper buckle
for the center seating position until you hear
a snap and feel it latch. Make sure the
tongue is securely fastened to the buckle by
pulling on tongue.
*
[SS32200(F )01/96]
5. Push down on the child seat while pulling
on the loose end of the lap belt webbing to
tighten the belt.
*
[SS32300(F )01/96]
6. Before placing the child into child seat,
forcibly tilt the child seat from side-to-side
and in forward directions to ensure that the
seat is held securely in place. If the child
seat moves excessively, repeat steps 5
through 6, or properly install the child seat
in a different seating position.
File:06ltssf.ex
Update:Tue May 28 08:44:33 1996
ProCarManuals.com

133 %
*
[SS34500(F )04/96]
Attaching Safety Seats With Tether Straps
*
[SS34600(F )01/96]
General Instructions
[SS34700(F )01/96]
Some manufacturers make safety seats that
include an upper tether strap that goes over the
seatback and attaches to an anchoring point.
Other manufacturers offer the tether strap as an
accessory. Contact the manufacturer of your
child safety seat for information about ordering
a tether strap.
[SS34800(F )05/96]
You can install a tether strap anchor bracket to
the cab inner back panel by using a tether
anchor bracket kit (613D20) available at no
charge from any Ford dealer.
*
[SS35100(F )01/96]
Read and carefully follow the instructions
provided with the kit for installation of the child
tether strap anchor.
*
[SS35200(F )01/96]
Follow the child seat manufacturer's instructions
to attach the tether strap to the tether bracket.
[SS35600(F )01/96]
Ford recommends placement of tethered safety
seats in a rear seating position (Crew Cab and
Super Cab with forward facing rear seat only)
with the tether strap installed to the tether
anchoring point as shown in the instructions
provided with the child tether strap anchor kit.
*
[SS35900(F )01/96]
RWARNING
Only use the tether attachment hole
locations shown in the illustrations. The
tether anchor may not perform properly if
the wrong mounting location is used.
File:06ltssf.ex
Update:Tue May 28 08:44:33 1996
ProCarManuals.com

134 [SS36000(F )04/96]If a tethered seat is installed in the front seat,
Ford recommends placement of the tethered
safety seat in the center front seating position,
with the tether strap secured to the center rear
lap belt tongue or to the webbing of the buckled
center rear lap belt behind the child safety seat.
[SS36100(F )04/96]
The rear lap/shoulder safety belts should not be
used to secure the tether strap of a safety seat
located in the front seat.
*
[SS36200(F )01/96]
RWARNING
Follow these precautions to decrease the
chance of injury in an accident.
*
[SS36400(F )03/96]
In SuperCabs equipped with Center Facing Jump
Seats, the tether strap anchor bracket should be
installed only at the center of the cab's back
panel with the child seat in the front center
seating position. Installing an anchor bracket at
the right rear of the cab may increase risk of
injury to an occupant of the right rear center
facing jump seat in the event of a collision or
sudden stop. If a tethered child seat is installed
in the right front seating position, secure the
tether strap to the webbing of the buckled right
rear lap belt.
*
[SS36500(F )01/96]
RWARNING
Do not install a child seat in a center
facing jump seat.
File:06ltssf.ex
Update:Tue May 28 08:44:33 1996
ProCarManuals.com

135
%*
[SS36600(F )03/96]
Safety Belt Maintenance
[SS36700(F )03/96]
Check your safety belt system periodically to
make sure that it works properly and isn't
damaged. If the webbing shows any wear, nicks
or cuts, have it examined by a qualified
technician to determine if replacement is
necessary. Always have your safety belt system
checked after a collision by a qualified
technician.
*
[SS36800(F )03/96]
All safety belt assemblies, including retractors,
buckles, front seat belt buckle support assemblies
(slide bar) (if so equipped), child safety seat
tether bracket assemblies (if so equipped), and
attaching hardware, should be inspected after
any collision. Ford recommends that all safety
belt assemblies used in vehicles involved in a
collision be replaced. However, if the collision
was minor and a qualified technician finds that
the belts do not show damage and continue to
operate properly, they do not need to be
replaced. Safety belt assemblies not in use
during a collision should also be inspected and
replaced if either damage or improper operation
is noted.
File:06ltssf.ex
Update:Tue May 28 08:44:33 1996
ProCarManuals.com

137
Starting
%*
[TO00200(FM)01/96]
Fuel-Injected Engines
[TO00300(F )04/96]
NOTE: For owners of diesel-powered vehicles,
refer to theDiesel Engine Owners Guide
Supplementfor information on starting
your vehicle.
*
[TO00500(F )01/96]
When starting a fuel-injected engine,the most
important thing to remember is to avoid
pressing down on the accelerator before or
during starting. Only use the accelerator when
you have problems getting your vehicle started.
SeeStarting Your Enginein this chapter for
details about when to use the accelerator while
you start your vehicle.
%*
[TO00700(F )05/96]
Because your vehicle's engine is electronically
controlled by a computer, some control
conditions are maintained by power from the
battery. If you ever disconnect the battery, install
a new battery, or experience a dead battery, you
must allow the computer to ªrelearnº its idle
conditions before your vehicle will idle at its
best. To let the engine do this, apply the parking
brake, put the gearshift in P (Park) (automatic
transmission) or Neutral (manual transmission),
turn off all the accessories, and start the vehicle.
Let the engine idle for at least one minute.
*
[TO00900(F )01/96]
If you do not let the engine relearn its idle, the
idle quality of your vehicle may be adversely
affected until the idle is relearned. Your vehicle
will eventually relearn its idle while you drive
it, but it takes much longer than if you use the
previous procedure.
File:08lttof.ex
Update:Tue May 28 08:44:45 1996
ProCarManuals.com

138
[TO01000(FM)01/96]
Starting your vehicle
%*
[TO01100(FM)01/96]
Preparing to Start Your Vehicle
*
[TO01200(FM)02/96]
RWARNING
Do not start your vehicle in a closed
garage or in other enclosed areas. Exhaust
fumes can be toxic. Always open the
garage door before you start the engine.
*
[TO01300(FM)01/96]
Before you start your vehicle, do the following:
*
[TO01400(F )01/96]
1. Make sure all occupants in the vehicle
buckle their safety belts. SeeSafety Restraints
in the Index for more details.
*
[TO01600(FM)01/96]
2. Make sure the headlamps and other
accessories are turned off when starting.
*
[TO01700(F )01/96]
3.If you have an automatic transmission,
make sure that the gearshift lever is in P
(Park) and the parking brake is set before
you turn the key.
*
[TO01900(F )01/96]
4.If you have a manual transmission,make
sure that the parking brake is fully set, push
the clutch pedal to the floor, and put the
gearshift into Neutral before you turn the
key. (Remember, the starter will operate only
if the clutch pedal is pushed in all the way).
%*
[TO02000(F )01/96]
Testing the Warning Lights
*
[TO02100(F )02/96]
Before you start your vehicle, you should test
the warning lights on the instrument panel to
make sure that they work. Refer to the
Instrumentationchapter.
[TO02200(F )04/96]
If your Brake Warning Light does light up with
the key in the ON position, you may not have
fully released the parking brake or the brake
fluid may be low.
File:08lttof.ex
Update:Tue May 28 08:44:45 1996
ProCarManuals.com

139 %
*
[TO02300(FM)01/96]
Starting Your Engine
*
[TO02400(FM)01/96]
To start your engine:
*
[TO02500(FM)01/96]
1. Follow the steps underPreparing to Start
Your Vehicleat the beginning of this section.
*
[TO02600(FM)01/96]
2. Turn the ignition key to the ON position.
*
[TO02700(FM)01/96]
3. DO NOT depress the accelerator pedal when
starting your engine. DO NOT use the
accelerator while the vehicle is parked.
*
[TO02800(FM)01/96]
4. Turn the key to the START position
(cranking) until the engine starts. Allow the
key to return to the ON position after the
engine has started.
*
[TO02900(FM)01/96]
If you have difficulty in turning the key,
rotate the steering wheel slightly because it
may be binding.
%*
[TO03000(FM)01/96]
For a cold engine:
*
[TO03100(FM)01/96]
q
At temperatures10ÊF (-12ÊC) andbelow:If
the engine does not start infifteen (15)
secondson the first try, turn the key to OFF,
wait approximately ten (10) seconds so you
do not flood the engine, then try again.
*
[TO03200(FM)01/96]
q
At temperaturesabove10ÊF(-12ÊC):If the
engine does not start infive (5) secondson
the first try, turn the key to OFF, wait
approximately ten (10) seconds so you do not
flood the engine, then try again.
*
[TO03300(FM)01/96]
q
Do not hold the key in the START position
for more thanfifteen (15) secondsat a time.
File:08lttof.ex
Update:Tue May 28 08:44:45 1996
ProCarManuals.com

140 %
*
[TO03400(FM)01/96]
For a warm engine:
*
[TO03500(FM)01/96]
q
Do not hold the key in the START position
for more thanfive (5) secondsat a time. If
the engine does not start within five (5)
seconds on the first try, turn the key to the
OFF position. Wait a few seconds after the
starter stops, then try again.
*
[TO03600(FM)01/96]
Whenever you start your vehicle, release the key
as soon as the engine starts. Excessive cranking
could damage the starter.
*
[TO03700(FM)01/96]
After you start the engine, let it idle for a few
seconds. Keep your foot on the brake pedal and
put the gearshift lever in gear. Release the
parking brake. Slowly release the brake pedal
and drive away in the normal manner.
%*
[TO03800(FM)05/96]
NOTE: Your vehicle is equipped with a
brake-shift interlock feature. This
feature prevents you from shifting
from P (Park) unless you have the
brake pedal depressed. (The ignition
must be in the ON position.) If you
cannot shift from P (Park) with the
brake pedal depressed:
*
[TO03900(FM)05/96]
1. Apply the parking brake.
*
[TO04000(FM)05/96]
2. Remove the key.
*
[TO04100(F )05/96]
3. Insert the key and rotate it one position
clockwise (ignition in the OFF position).
*
[TO04200(FM)05/96]
4. Apply the brake pedal and shift to N
(Neutral). (If the vehicle is shifted back to P
[Park], you must repeat the previous steps.)
*
[TO04300(FM)05/96]
5. Start the vehicle.
File:08lttof.ex
Update:Tue May 28 08:44:45 1996
ProCarManuals.com

141
*
[TO04400(FM)05/96]
If you need to shift out of P (Park) by using the
alternate procedure described above, it is
possible that a fuse has blown and that your
brakelamps may also not be functional. Please
refer to the chapter titledRoadside Emergenciesin
this Owner Guide for instructions on checking
and replacing fuses.
*
[TO04500(FM)05/96]
RWARNING
DO NOT DRIVE YOUR VEHICLE UNTIL
YOU VERIFY THAT THE BRAKELAMPS
ARE WORKING.
[TO04600(FM)04/96]
For cold or warm engines:
*
[TO04700(FM)01/96]
If the engine still does not start after two
attempts:
*
[TO04800(FM)01/96]
1. Turn the ignition key to the OFF position.
*
[TO04900(FM)01/96]
2. Press the accelerator all the way to the floor
and hold it.
*
[TO05000(FM)01/96]
3. Turn the ignition key to the START position.
*
[TO05100(FM)01/96]
4. Release the ignition key when the engine
starts.
*
[TO05200(FM)03/96]
5. Release the accelerator gradually as the
engine speeds up.
*
[TO05300(FM)05/96]
If the engine still does not start, the fuel pump
shut-off switch may have been activated. For
directions on how to reset the switch seeFuel
Pump Shut-Off Switchin the index.
*
[TO05500(F )01/96]
A computer system controls the engine's idle
speed. When you start your vehicle, the engine's
idle speed normally runs higher than when it's
warmed up. These faster engine speeds will
make your vehicle move slightly faster than its
File:08lttof.ex
Update:Tue May 28 08:44:45 1996
ProCarManuals.com
