FORD F250 1997 Owners Manual

[PI00500(F )09/95]
thirty-six pica chart:File:01ltpif.ex
Update:Tue May 28 08:39:31 1996
ProCarManuals.com

*
[PI00800(FM)01/96]
thirty-six pica chart:
File:01ltpif.ex
Update:Tue May 28 08:39:31 1996
ProCarManuals.com

*
[PI02300( ALL)04/01]
Table of ContentsIntroduction ...................................................... 1
Instrumentation .............................................. 11
Audio ................................................................ 27
Controls and Features .................................. 57
Seating and Safety Restraints .................... 95
Starting ........................................................... 137
Driving ........................................................... 145
Roadside Emergencies ................................ 223
Maintenance and Care ............................... 257
Capacities and Specifications ................... 317
Reporting Safety Defects ........................... 333
Customer Assistance ................................... 335
Accessories .................................................... 347
Quick Index.................................................... 359
Index ............................................................... 367
File:01ltpif.ex
Update:Tue May 28 08:39:31 1996
ProCarManuals.com

1
Introduction
*
[II00300(FM)01/96]
Ford's Commitment to You
*
[II00400(FM)01/96]
At Ford Motor Company, excellence is the
continuous commitment to achieve the best
result possible. It is dedication to learning what
you want, determination to develop the right
concept, and execution of that concept with care,
precision, and attention to detail. In short,
excellence means being the standard by which
others are judged.
*
[II00500(FM)01/96]
Our Guiding Principles
*
[II00600(FM)01/96]
q
Quality comes first.For your satisfaction, the
quality of our products and services must be
our number one priority.
*
[II00700(FM)01/96]
q
You are the focus of everything we do.Our
work must be done with you in mind,
providing better products and services than
our competition.
*
[II00750(FM)01/96]
q
Continuous improvement is essential to our
success.We must strive for excellence in
everything we do: in our products Ð in their
safety and value Ð and in our services, our
human relations, our competitiveness, and
our profitability.
*
[II00800(FM)01/96]
q
Employee involvement is our way of life.
We are a team. We must treat one another
with trust and respect.
*
[II00900(FM)01/96]
q
Dealers and suppliers are our partners.We
must maintain mutually beneficial
relationships with dealers, suppliers, and our
other business associates.
File:02ltiif.ex
Update:Tue May 28 08:39:40 1996
ProCarManuals.com

2
*
[II01000(FM)01/96]
q
Integrity is never compromised.Our conduct
worldwide must be pursued in a manner that
is socially responsible and commands respect
for its integrity and for its positive
contributions to society.
*
[II01100(FM)03/96]
Things to Know About Using
This Guide
*
[II01150(F )03/96]
Congratulations on the purchase of your new
vehicle. This guide has information about the
equipment and the options for your new vehicle.
You may not have bought all of the options
available to you. If you do not know which
information applies to your vehicle, talk to your
dealer.
*
[II01200(F )03/96]
This guide describes equipment and gives
specifications for equipment that was in effect
when this guide was approved for printing. Ford
may discontinue models or change specifications
or design without any notice and without
incurring obligation.
*
[II01300(FM)03/96]
NOTES and WARNINGS
*
[II01350(FM)02/96]
NOTESgive you additional information about
the subject matter you are referencing.
*
[II01400(FM)01/96]
WARNINGSremind you to be especially careful
in those areas where carelessness can cause
damage to your vehicle or personal injury to
yourself, your passengers or other people. Please
read allWARNINGScarefully.
*
[II01450(FM)01/96]
RWARNING
File:02ltiif.ex
Update:Tue May 28 08:39:40 1996
ProCarManuals.com

3
*
[II01600(FM)01/96]
Finding Information in This Guide
[II01700(FM)01/96]
After you have read this guide once, you will
probably return to it when you have a specific
question or need additional information. To help
you find specific information quickly, you can
use the table of contents or the index.
*
[II01800(F )03/96]
TheQuick Indexat the end of the book
provides a page number following each item
which indicates where detailed information can
be found.
*
[II02000(FM)01/96]
This guide has atable of contentsat the
beginning of the book to show chapter titles.
*
[II02100(FM)01/96]
To use theIndex, turn to the back of the book
and search in the alphabetical listing for the
word that best describes the information you
need. If the word you chose is not listed, think
of other related words and look them up. We
have designed the Index so that you can find
information under a technical term.
%*
[II02200(FM)01/96]
Canadian Owners Ð French Version
*
[II02300(FM)01/96]
French Owner Guides can be obtained from your
dealer or by writing to Ford Motor Company of
Canada, Limited, Service Publications, P.O. Box
1580, Station B, Mississauga, Ontario L4Y 4G3.
%
*
[II02400(FM)01/96]
Your Maintenance Schedule
Booklet
*
[II02500(FM)03/96]
TheMaintenance Schedulebooklet lists the
services that are most important for keeping
your vehicle in good condition. A record log is
also provided to help you keep track of all
services performed.
File:02ltiif.ex
Update:Tue May 28 08:39:40 1996
ProCarManuals.com

4
%*
[II02600(FM)01/96]
About the Warranties
[II02700(F )04/96]
Your vehicle is covered by three types of
warranties: Basic Vehicle Warranty, Extended
Warranties on certain parts, and Emissions
Warranties.
%*
[II03100(FM)01/96]
Read yourWarranty Information Bookletcarefully
to find out about your vehicle's warranties and
your basic rights and responsibilities.
*
[II03250(FM)03/96]
If you lose yourWarranty Information Booklet,you
can get a new one free of charge. Contact any
Ford or Lincoln-Mercury dealer, or refer to the
addresses and phone numbers on the first page
of this Owner's Guide.
%*
[II04000(F )03/96]
Ford Extended Service Plan
*
[II04010(F )05/96]
More Protection for Your Vehicle
*
[II04020(F )05/96]
You can get more protection for your new car or
light truck by purchasing a Ford Extended
Service Plan (Ford ESP). Ford ESP is the only
extended service program with the Ford name
on it and the only service contract backed by
Ford Motor Company.
*
[II04030(F )05/96]
Ford ESP is an optional service contract, backed
and administered by Ford. It provides:
*
[II04040(F )05/96]
q
protection against repair costs after your
Bumper to Bumper Warranty expires;
*
[II04050(F )05/96]
and
*
[II04060(F )05/96]
q
other benefits during the warranty period
(such as: reimbursement for rentals; coverage
for certain maintenance and wear items).
File:02ltiif.ex
Update:Tue May 28 08:39:40 1996
ProCarManuals.com

5
*
[II04070(F )05/96]
You may purchase Ford ESP from any
participating Ford Motor Company dealer. There
are several Ford ESP plans available in various
time-and-mileage combinations. Each plan can be
tailored to fit your own driving needs, including
reimbursement benefits for towing and rental.
(In Hawaii, rules vary. See your dealer for
details.)
*
[II04080(F )05/96]
When you buy Ford ESP, you receive
peace-of-mind protection throughout the United
States and Canada, provided by a network of
more than 5,100 participating Ford Motor
Company dealers.
*
[II04090(F )05/96]
NOTE: Repairs performed outside the United
States and Canada are not eligible for
ESP coverage.
*
[II04110(F )05/96]
This information is subject to change. Ask your
dealer for complete details about Ford ESP
coverage.
%
*
[II04300(F )01/96]
Special Notices
%*
[II04450(F )01/96]
NOTICE TO OWNERS OF
FOUR-WHEEL DRIVE VEHICLES
%*
[II04500(F )05/96]
As with other vehicles of this type, failure to
operate this vehicle correctly may result in loss
of control or an accident. Be sure to read the
Additional Special Driving Instructions for
Four-Wheel Drive Vehicle Operatorsin this book
and the special supplement included with
four-wheel drive vehicles entitled4-Wheeling.
File:02ltiif.ex
Update:Tue May 28 08:39:40 1996
ProCarManuals.com

6
% [II04650(F )04/96]
NOTICE TO OWNERS OF
LIGHT TRUCK AMBULANCE
CONVERSIONS
[II04800(F )04/96]
If your light truck is equipped with theFord
Ambulance Preparation Package, it can be
utilized as an ambulance. Ford urges ambulance
manufacturers to follow the recommendations of
theFord Incomplete Vehicle Manual,Ford
Truck Body Builder's Layout Book, and the
QVM Guidelinesas well as pertinent
supplements. For further information, please call
the Light Truck Body Builders Advisory Service
on 1-800-635-5560.
[II04850(F )04/96]
Use of your Ford light truck as an ambulance,
without theFord Ambulance Preparation
Packagevoids the Ford New Vehicle Limited
Warranty and may void the Emissions
Warranties. In addition, ambulance usage
without the preparation package could cause
high underbody temperatures, overpressurized
fuel, and a risk of spraying fuel which could
lead to fires. If your light truck is equipped with
theFord Ambulance Preparation Packageit will
say so on its information decal. The decal is
located on the driver's side door pillar or on the
rear edge of the driver's door. You can
determine whether the ambulance manufacturer
followed Ford's recommendations by directly
contacting that manufacturer.NOTE: Ford
Ambulance Preparation Packageis only
available on certain 7.3L Diesel F-Series vehicles.
File:02ltiif.ex
Update:Tue May 28 08:39:40 1996
ProCarManuals.com

7
% [II04900(F )04/96]
NOTICE TO OWNERS OF
DIESEL-POWERED VEHICLES
[II05000(F )04/96]
Read the7.3L Diesel Engine Owner's Guide
Supplementfor information regarding correct
operation and maintenance of your
diesel-powered light truck.
%
*
[II05100(FM)01/96]
Your Vehicle Identification
Number (VIN)
*
[II05200(FM)04/96]
You should include your Vehicle Identification
Number (VIN) any time you write to Ford
Motor Company about your vehicle.
*
[II05300(F )03/96]
The Vehicle Identification Number is attached to
your vehicle in the following places:
[II05350(F )04/96]
Complete Ford Built Vehicles
*
[II05400(F )03/96]
q
on the metal tag attached to the top of the
instrument panel on the driver's side Ð you
can see the tag by looking through the
windshield from outside your vehicle.
*
[II05450(F )03/96]
one inch art:0010558-A
Vehicle Identification Number (VIN/Serial Number)
%*
[II05500(F )03/96]
q
on the Safety Compliance Certification Label
Ðthis label is attached to the left front door
lock facing or the door latch post pillar. It is
required by the National Highway Traffic
Safety Administration and is made of special
material. If someone tampers with it, it will
be destroyed and/or a destruction pattern
will appear.
File:02ltiif.ex
Update:Tue May 28 08:39:40 1996
ProCarManuals.com
