FORD F250 1997 Owners Manual

272
*
[MC11050(F )01/96]
Adding washer fluid
*
[MC11100(F )01/96]
RWARNING
Do not put windshield washer fluid in the
container for the engine coolant.
[MC11150(F )04/96]
quarter page art:0020360-C
Adding windshield washer fluid
%*
[MC11300(F )02/96]
Use specially formulated windshield washer
fluid rather than plain water, because specially
formulated washer fluids contain additives that
dissolve road grime. For safety reasons, washer
fluids containing an appropriate antifreeze such
as methanol should be used in freezing weather
(temperatures below32ÊF [0ÊC]).State or local
regulations on Volatile Organic Compounds
(VOCs) may restrict use of the most common
antifreeze, methanol. Washer fluids containing
non-methanol antifreeze agents should be used
only if they provide cold weather protection
without damaging the vehicle's paint finish,
wiper blades, and windshield washer system.
*
[MC11350(F )01/96]
If you choose to use a windshield washing
solution that must be mixed, follow the
manufacturer's mixing instructions. Improperly
mixed solutions may freeze unexpectedly.
File:11ltmcf.ex
Update:Tue May 28 08:52:04 1996
ProCarManuals.com

273 [MC11400(F )01/96]
NOTE: The addition of shields to the front of
the vehicle, as used to deflect bugs,
may also adversely affect the washer
system from delivering fluid to the
windshield. Devices such as bug
shields are not recommended to be
added to your new Ford product.
%
*
[MC11450(F )02/96]
Wiper Blades
*
[MC11500(F )01/96]
Check the windshield wiper blades at least twice
a year. Also check them whenever they seem
less effective than usual. Such substances as tree
sap and some hot wax treatments used by
commercial car washes reduce the effectiveness
of wiper blades.
*
[MC11550(F )01/96]
If the blades do not wipe properly, clean both
the windshield and the wiper blades. Use
undiluted windshield washer solution or a mild
detergent. Rinse thoroughly with clear water. Do
not use fuel, kerosene, paint thinner, or other
solvents to clean your wiper blades. These will
damage your blades.
*
[MC11600(F )01/96]
To make reaching the wiper blades easy, simply
turn the ignition switch to ACC and turn your
wipers on. Wait for them to reach a vertical
position and turn the ignition to OFF. Do not
move the wipers manually. Moving the wipers
manually may damage them.
*
[MC11650(F )02/96]
Wiper blade replacement
[MC11675(F )04/96]
If the wiper blades still do not work properly
after you clean them, you may need to replace
the wiper blade assembly or the blade element.
When replacing the wiper blade assembly, blade
refill, or wiper arm always use a Motorcraft part
or equivalent.
File:11ltmcf.ex
Update:Tue May 28 08:52:04 1996
ProCarManuals.com

274
%*
[MC11700(FM)01/96]
Engine Coolant
[MC11750(FM)01/96]
Checking the engine coolant
*
[MC11800(FM)05/96]
Your vehicle's engine coolant protects the engine
from overheating in the summer and from
freezing in the winter. Check the level of the
engine coolant at least once a month, but
preferably each time you stop for fuel. Simply
look at the engine coolant recovery reservoir
located in the engine compartment. To locate
this reservoir, see the diagram of your vehicle's
engine underEngine typesin this chapter.
*
[MC11850(FM)05/96]
If the engine coolant has not been checked for a
long period of time the engine coolant reservoir
may eventually empty. If the engine coolant
reservoir empties, check the engine coolant level
in the radiator. Read the following warnings
before removing the radiator cap. If it is
necessary to fill the radiator, refer to theEngine
Coolant Refill Procedurein this chapter for
instructions.
*
[MC11950(FM)01/96]
Adding engine coolant
[MC12000(F )04/96]
quarter page art:0020354-A
Adding engine coolant
File:11ltmcf.ex
Update:Tue May 28 08:52:04 1996
ProCarManuals.com

275 % [MC12150(F )04/96]
quarter page art:0020360-C
Adding engine coolant
*
[MC12300(FM)01/96]
RWARNING
Do not put engine coolant in the container
for the windshield washer fluid.
*
[MC12350(FM)01/96]
If sprayed to clean the glass, engine coolant or
antifreeze could make it difficult to see through
the windshield.
*
[MC12400(FM)05/96]
RWARNING
Never remove the coolant recovery cap
while the engine is running or hot.
[MC12450(FM)04/96]
RWARNING
Follow these steps to minimize risk of
personal injury.
*
[MC12500(FM)05/96]
1. Before you remove the radiator cap, turn the
engine off and let it cool. Even when the
engine is cool, be careful when you remove
the radiator cap.
*
[MC12550(FM)05/96]
2. When the engine is cool, wrap a thick cloth
around the cap and turn it slowly
counterclockwise to the first stop.
*
[MC12600(FM)05/96]
3. Step back while the pressure releases.
*
[MC12650(FM)01/96]
4. When you are sure that all the pressure has
been released, use the cloth to press, turn,
and remove cap.
File:11ltmcf.ex
Update:Tue May 28 08:52:04 1996
ProCarManuals.com

276
*
[MC12700(FM)05/96]
5. Stand away from the radiator opening. Hot
steam may blow out or hot engine coolant
may even splash out.
%*
[MC12750(FM)01/96]
Freezing Protection
[MC12800(FM)04/96]
The factory-installed solution of Ford Premium
Cooling System Fluid and water will protect
your vehicle toS35ÊF (S37ÊC).Check the freeze
protection rating of the engine coolant at least
once a year, just before winter.
*
[MC12850(FM)04/96]
Add engine coolant only to the coolant
reservoir.If the coolant level is low, add to the
reservoir a 50/50 mixture of water and the type
of engine coolant that Ford specifies. You may
add water by itself only in an emergency, but
you should replace it with a 50/50 mixture as
soon as possible. Check the engine coolant again
the next few times you drive your vehicle.
*
[MC12900(FM)01/96]
Ford Premium Cooling System Fluid is an
optimized formula that will protect all metals
and rubber elastomers used in Ford engines for
four years or 50,000 miles (80,000 km). It is not
necessary and not recommended to use
supplemental coolant additives in your gasoline
powered vehicle. These additives may harm
your engine cooling system. Follow the
recommended service interval for changing your
engine coolant.
*
[MC12950(FM)01/96]
NOTE: When you change or add engine
coolant, it is important to maintain
your engine coolant concentration
between 40%(-11ÊF [-24ÊC]) and 60%
(-62ÊF [-52ÊC]),depending on your local
climate conditions. Below 40% you will
lose freeze protection and above 60%
your engine may overheat on a warm
day.
File:11ltmcf.ex
Update:Tue May 28 08:52:04 1996
ProCarManuals.com

277 % [MC13000(FM)04/96]
NOTE: Do not use an engine coolant that does
not meet all 14 requirements of Ford
Specification ESE-M97B44-A. The use
of an improper coolant may void your
warranty for the engine cooling system.
Use only a premium nationally
recognized brand name engine coolant.
*
[MC13050(FM)04/96]
Ford Motor Company expressly authorizes the
Ford Rotunda engine coolant recycling process
and chemicals. If you choose to use recycled
coolant, use only Ford Rotunda recycled engine
coolant or an equivalent recycled engine coolant
that is certified by the supplier to meet Ford
specification ESE-M97B44-A.
%*
[MC13100(FM)04/96]
NOTE: Always dispose of used automotive
fluids in a responsible manner. Follow
your community's standards for
disposing of these types of fluids. Call
your local recycling center to find out
about recycling automotive fluids.
%*
[MC13150(FM)01/96]
Use Ford Premium Cooling System Fluid or an
equivalent engine coolant that meets Ford
Specification ESE-M97B44-A. Do not use alcohol
or methanol antifreeze and do not use engine
coolant mixed with alcohol or methanol
antifreeze. If you do not use the proper coolant,
the aluminum radiator on your vehicle will
corrode.
*
[MC13200(FM)01/96]
Leave the engine coolant in all year. Make sure
that the coolant will not freeze at the
temperature level in which you drive during
winter months. Keep a mixture of engine coolant
in your engine that has a protection rating of at
least-34ÊF (-37ÊC), orwhatever protection rating
is appropriate for the climate in which you live.
File:11ltmcf.ex
Update:Tue May 28 08:52:04 1996
ProCarManuals.com

278
*
[MC13250(FM)04/96]
To find out how much engine coolant mixture
your vehicle's coolant system can hold, seeRefill
capacities for fluidsin the Index.
[MC13300(FM)04/96]
You may add water by itself only in an
emergency, but you should replace it with a
50/50 or appropriate mixture as soon as
possible.
*
[MC13350(FM)04/96]
Have your dealer check the engine cooling
system for leaks if you have to add a quart
(liter) of engine coolant more than once a month.
[MC13400(FM)01/96]
Checking hoses
*
[MC13450(FM)01/96]
Inspect all engine and heater system hoses for
deterioration, leaks and loose clamps before
adding or replacing engine coolant. Make
whatever repairs or replacements that are
necessary using Motorcraft parts or their
equivalents.
[MC13500(FM)01/96]
Engine coolant drain and flush
*
[MC13550(FM)05/96]
To drain your vehicle's engine coolant:
*
[MC13600(FM)01/96]
1. Turn off the engine and let it cool. Fully
depressurize the engine cooling system by
covering the radiator cap with a thick cloth
and turning it slowly counterclockwise to the
first stop. Step back while the pressure
releases.
*
[MC13650(FM)01/96]
2. Remove the cap.
*
[MC13750(FM)01/96]
3. Attach a small hose to the drain tube at the
bottom of the radiator.
File:11ltmcf.ex
Update:Tue May 28 08:52:04 1996
ProCarManuals.com

279
*
[MC13800(FM)01/96]
4. Let the engine coolant drain into a suitable
container. Disconnect the lower radiator hose
at the radiator connector and drain any
remaining engine coolant into a container.
*
[MC13850(FM)01/96]
5. Reconnect the lower radiator hose and close
the radiator drain cock.
[MC13900(FM)04/96]
Proper procedures for flushing the cooling
system can be found in theTruck Service Manual.
[MC13950(FM)01/96]
Engine coolant refill procedure
*
[MC14000(FM)01/96]
After you have drained the engine cooling
system:
*
[MC14050(FM)01/96]
1. Fill the radiator with a 50/50 mixture of the
specified engine coolant concentrate and
water. Allow several minutes for trapped air
to escape (bubble out) and for engine coolant
to flow through the radiator.
*
[MC14100(FM)01/96]
2. Replace the radiator cap to its fully installed
position, then back off to the first stop. This
will prevent high pressure from building up
in the cooling system during this part of the
fill procedure.
*
[MC14150(FM)01/96]
3. Start and idle the engine until the thermostat
opens and the radiator upper hose becomes
warm.
*
[MC14200(FM)01/96]
4. Shut off the engine and allow the engine to
cool. Cover the radiator cap with a thick
cloth and cautiously remove it. Step back
while the pressure releases.
*
[MC14250(FM)01/96]
5. Finally, check the radiator and add more
engine coolant if needed, following the
procedures noted above. Reinstall the
radiator cap securely, when finished.
*
[MC14300(FM)01/96]
6. If more engine coolant is necessary, fill the
overflow reservoir to the appropriate level
marked on the bottle.
File:11ltmcf.ex
Update:Tue May 28 08:52:04 1996
ProCarManuals.com

280
%*
[MC18300(FM)01/96]
Power Steering Fluid
*
[MC18350(FM)01/96]
Check the level of the power steering fluid at
least twice a year (i.e., every Spring and Fall).
*
[MC18400(FM)01/96]
To check the level of your power steering fluid:
*
[MC18450(FM)04/96]
1. Start the engine and let it run until the
power steering fluid reaches normal
operating temperature. The power steering
fluid will be at the right temperature when
the engine coolant temperature gauge in the
instrument cluster is near the center of the
NORMAL operating temperature range.
*
[MC18500(FM)01/96]
2. While the engine idles, turn the steering
wheel back and forth several times. Make
sure that the cap assembly is installed at this
time.
*
[MC18550(F )01/96]
3. Turn the engine off.
%*
[MC18650(FM)01/96]
4. Check the fluid level on the dipstick (which
is highlighted in yellow in your vehicle). The
fluid level should be between the arrows in
the FULL HOT range, which is marked on
the side of the dipstick, opposite the side
marked FULL COLD. Do not add fluid if the
level is within the FULL HOT range.
*
[MC18700(FM)01/96]
one third page art:0021016-B
Power steering dipstick
File:11ltmcf.ex
Update:Tue May 28 08:52:04 1996
ProCarManuals.com

281
*
[MC18800(F )01/96]
quarter page art:0020386-B
Power steering reservoir
*
[MC19050(FM)01/96]
5. If the power steering fluid is low, add fluid
in small amounts, continuously checking the
level, until you reach the FULL HOT range.
Do not overfill.
*
[MC19060(FM)03/96]
6. When you are finished, put the dipstick back
in and make sure that it fits snugly.
*
[MC19070(FM)03/96]
If you check the power steering fluid when it is
cold, make sure that the fluid reaches the FULL
COLD range on the dipstick. The reading will
only be accurate if the fluid temperature is
approximately 50 to85ÊF (10 to 30ÊC).
[MC19100(F )05/96]
Use only MERCONHAutomatic Transmission
Fluid.
*
[MC19250(FM)01/96]
If the power steering fluid is low, do not drive
your vehicle for a long period of time before
adding fluid. This can damage the power
steering pump.
*
[MC19400(FM)01/96]
NOTE: Do not turn the steering wheel of your
vehicle with the engine off. It could
force power steering fluid out from the
reservoir cap or in extreme cases, it
could unseat the cap.
File:11ltmcf.ex
Update:Tue May 28 08:52:04 1996
ProCarManuals.com
