Page 249 of 475
ENGINE OIL DIPSTICK
A.–MIN
B. – MAX
ENGINE OIL CHECK
Note:Check the level before starting the engine.
Note:Make sure that the level is between the MIN and MAX marks.
1. Make sure that your vehicle is on level ground.
2. Turn the engine off and wait 10 minutes for the oil to drain into the
oil pan.
3. Remove the dipstick and wipe it with a clean, lint-free cloth. Replace
the dipstick and remove it again to check the oil level.
If the level is at the MIN mark, add oil immediately.
Adding Engine Oil
Note:Do not remove the filler cap when the engine is running.
Note:Do not add engine oil further than the MAX mark. Oil levels above
the MAX mark may cause engine damage.
Only use oils certified for gasoline engines by the
American Petroleum Institute (API). An oil with this
trademark symbol conforms to the current engine and
emission system protection standards and fuel
economy requirements of the International Lubricants
Specification Advisory Council (ILSAC), comprised of
U.S. and Japanese automobile manufacturers.
1. Remove the filler cap.
2. Add engine oil that meets Ford specifications. SeeCapacities and
Specificationsfor more information.
3. Replace the filler cap. Turn it until you feel a strong resistance.
AB
Maintenance249
2013 Focus(foc)
Owners Guide gf, 1st Printing
USA(fus)
Page 303 of 475
ENGINE SPECIFICATIONS
Engine 2.0L GDI engine
Cubic inches 121
Required fuel Minimum 87 octane or E85
Firing order 1–3–4–2
Ignition system Coil On Plug
Compression ratio 12.0:1
Spark plug gap .035 +/ - .001 in.
(0.9 +/- .05 mm)
Engine Drivebelt Routing
2.0L GDI
Capacities and Specifications303
2013 Focus(foc)
Owners Guide gf, 1st Printing
USA(fus)
Page 305 of 475
Item CapacityFord Part Name or
EquivalentFord Part Number / Ford
Specification
Engine oil
4,5
2.0L engine
4.5 quarts (4.3L)•MotorcraftSAE
5W-20 Premium
Synthetic Blend Motor
Oil (US)
•MotorcraftSAE
5W-20 Full Synthetic
Motor Oil (US)
•MotorcraftSAE
5W-20 Super Premium
Motor Oil (Canada)
•MotorcraftSAE
5W-20 Synthetic Motor
Oil (Canada)•XO-5W20-QSP (US)
•XO-5W20-QFS (US)
•CXO-5W20-LSP12
(Canada)
•CXO-5W20-LFS12
(Canada) /
WSS-M2C945-A and API
Certification Mark
Engine coolant
6
2.0L engine
5.3 quarts (5.0L)MotorcraftOrange
Antifreeze/Coolant
PredilutedVC-3DIL-B (US)
CVC-3DIL-B (Canada) /
WSS-M97B44-D2
Capacities and Specifications305
2013 Focus(foc)
Owners Guide gf, 1st Printing
USA(fus)
Page 306 of 475
Item CapacityFord Part Name or
EquivalentFord Part Number / Ford
Specification
Windshield washer
fluidFill as requiredMotorcraftPremium
Windshield Washer
Concentrate (US)
Premium Quality
Windshield Washer
Fluid (Canada)ZC-32-A (US)
CXC-37-(A, B, D, and F)
(Canada) /
WSB-M8B16-A2/- -
Fuel tank12.4 gallons
(46.9L)——
1Use only MotorcraftDOT 4 LV High Performance Brake Fluid or equivalent meeting
WSS-M6C65-A2 and ISO 4925 Class 6. Use of any fluid other than the recommended fluid may
cause brake system damage.2Approximate dry fill capacity. Actual amount may vary during fluid changes.3Automatic transmissions that require MotorcraftDual Clutch Transmission Fluid should only
use MotorcraftDual Clutch Transmission Fluid. Refer toscheduled maintenanceto determine
the correct service interval. Use of any fluid other than the recommended fluid may cause
transmission damage.4Use of synthetic or synthetic blend motor oil is not mandatory. Engine oil need only meet the
requirements of Ford specification WSS-M2C945-A, SAE 5W-20 and display the API Certification
Mark.5Your engine has been designed to be used with Ford engine oil, which gives a fuel economy
benefit while maintaining the durability of your engine. Using oils other than the one specified
can result in longer engine cranking periods, reduced engine performance, reduced fuel economy
and increased emission levels.6Add the coolant type originally equipped in your vehicle.
306Capacities and Specifications
2013 Focus(foc)
Owners Guide gf, 1st Printing
USA(fus)
Page 307 of 475
MOTORCRAFT PART NUMBERS
Component 2.0L GDI engine / 2.0L GTDI
EcoBoost engine
Air filter element FA-1908
1
Oil filter FL-910- S2
Battery BXT-96R-500/BXT-96R-590
Spark plugs3
Cabin air filter FP70
Windshield wiper blade WW-2802 (driver side) / WW-2803
(passenger side)
1Failure to use the correct air filter element may result in severe engine
damage. The customer warranty may be void for any damage to the
engine if the correct air filter element is not used.
2Only use the specified replacement oil filter. The use of a non-specified
oil filter can result in engine damage.
3For spark plug replacement, see your authorized dealer. Refer to your
scheduled maintenance information for the appropriate intervals for
changing the spark plugs.
Note:Replace the spark plugs with ones that meet Ford material and
design specifications for your vehicle, such as Motorcraftor equivalent
replacement parts. The customer warranty may be void for any damage
to the engine if such spark plugs are not used.
Capacities and Specifications307
2013 Focus(foc)
Owners Guide gf, 1st Printing
USA(fus)
Page 469 of 475
Brakes ........................................187
anti-lock ...................................187
anti-lock brake system (ABS)
warning light ...........................187
brake warning light ................187
fluid, checking and adding ....254
fluid, refill capacities ..............304
fluid, specifications .................304
lubricant specifications ..........304
parking ....................................188
shift interlock ..........................182
C
Capacities for refilling fluids ....304
CD ......................125, 127, 130, 132
CD player ..........................123, 400
CD voice commands .................401
Cell phone use ............................16
Changing a tire .........................297
Changing the air filter ..............259
Child safety restraints ................27
Child safety seats
attaching with tether straps ....29
automatic locking mode
(retractor) .................................36
LATCH .......................................27
Child safety seats -
booster seats ...............................22
Cleaning the touchscreen ........379
Cleaning your vehicle ...............268
engine compartment ..............270
instrument panel ....................272
interior .....................................272
plastic parts ............................269
washing ....................................268
waxing .....................................270
wheels ......................................274wiper blades ............................271
Climate control (see Air
conditioning or Heating) ..........141
Climate voice commands .........437
Clock ..................125, 127, 130, 426
Clutch
operation while driving ..........184
recommended shift speeds ....184
Console ......................................162
overhead ..................................162
Coolant ......................................250
checking and adding ..............250
refill capacities ........................304
specifications ..........................304
Customer Assistance ................223
Ford Extended Service
Plan ..................................312, 314
Getting assistance outside
the U.S. and Canada ..............232
Getting roadside assistance ...223
Getting the service you
need .........................................228
Ordering additional owner’s
literature .................................234
Utilizing the
Mediation/Arbitration
Program ...................................232
D
Defrost ...............................141, 143
rear window ............................148
Dipstick
automatic transmission
fluid ..........................................254
engine oil .................................249
Display settings .........................426
Doors
central unlocking ......................72
Index469
2013 Focus(foc)
Owners Guide gf, 1st Printing
USA(fus)
Page 470 of 475
Driving under special
conditions ..................................183
through water .........................220
Dual automatic temperature
control (DATC) .........................143
E
Eco Mode ..................................206
Electronic message center .......108
Electronic stability control ......191
Emergencies, roadside
jump-starting ..........................225
running out of fuel .................172
Emission control system ..........176
End user license agreement ....450
Engine ........................................303
cleaning ...................................270
coolant .....................................250
idle speed control ...................255
lubrication specifications .......304
refill capacities ........................304
service points ..........................248
Engine block heater .................167
Engine fan .................................248
Engine oil
checking and adding ..............249
dipstick ....................................249
filter, specifications ................307
refill capacities ........................304
specifications ..........................304
Event data recording ..................12
Exhaust fumes ..........................167
F
Fan, Engine Cooling .................248
Fleet MyKey programming ........66Flexible Fuel Vehicle (FFV) ....169
Floor mats .................................221
Fluid capacities .........................304
Fog lamps ....................................92
Forward and reverse sensing
system ........................................193
Fuel
cap ...........................................174
capacity ...................................304
choosing the right fuel ...........171
filler funnel .............................172
filling your vehicle with fuel ..174
filter, specifications ........254, 307
fuel pump shut-off ..................224
octane rating ...........................171
quality ......................................171
running out of fuel .................172
safety information relating
to automotive fuels ................169
Fuel and distance
computer ...........................110–111
outside temperature
indicator ..........................110–111
to empty indicator ..........110–111
trip distance ....................110–111
trip/reset button .............110–111
Fuel - flex fuel vehicle
(FFV) .................................169, 171
Fuses ..........................236–237, 243
G
Gas cap (see Fuel cap) ............174
Gauges .......................................102
odometer .........................110–111
trip odometer ..................110–111
H
Hazard flashers .........................224
470Index
2013 Focus(foc)
Owners Guide gf, 1st Printing
USA(fus)
