Anti-Lock Brake System Light
(If equipped)
[LG03500( ALL)05/94]
This warning light will go on each time you
start your vehicle. If it remains on for longer
than five seconds, you should shut off your
engine and restart. If the anti-lock brake light
stays on, this indicates that the anti-lock feature
is disabled and should receive immediate
attention by a qualified service technician.
Normal braking is not affected unless the brake
warning light is also lit.
[LG03680( ALL)05/95]
one inch art:0011194-B*
[LG03700( ALL)05/95]
RWARNING
If the anti-lock brake system warning
light remains on or comes on while
driving, have the braking system checked
by a qualified service technician as soon
as possible.
*
[LG03800( ALL)10/95]
NOTE: If a fault occurs in the anti-lock
system, and the brake warning light is
not lit, the anti-lock system is disabled
but normal brake function remains
operational.
% [LG03900(M )05/95]
Low Oil Level Light (4.6L engines only)
[LG04000(M )06/93]
This light indicates that the level of the oil in
your engine is low and you have to add more
oil. The light may glow for a moment when the
engine is started. If the light stays on while the
engine is running, check the engine oil.
File:05rclgm.ex
Update:Wed Mar 27 09:29:39 1996
Page 66 of 332
66 [LG04025(M )06/93]1. Park your car on level ground, and turn off
the engine and allow a few minutes for the
engine oil to drain back into the oil pan.
[LG04075(M )06/93]
2. Use the dipstick to check the oil. If the level
is low, add oil, but do not overfill. See
Engine Oil Recommendationsin the Index.
[LG04100(M )12/91]
If you are parked on a steep incline, the LOW
OIL LEVEL warning may come on when you
start your car, even though the oil is at the
correct level.
[LG04125(M )11/90]
NOTE: The LOW OIL LEVEL warning will
stay on until you turn the ignition
OFF. After your car is on level ground,
wait five minutes to allow the oil to
drain back before turning the ignition
ON again.
[LG04200(M )06/93]
one inch art:0010115-B%*
[LG04300( ALL)07/95]
Safety Belt Warning Light and Chime
*
[LG04305( ALL)09/95]
This warning light and chime remind you to
fasten your safety belt. The following conditions
will take place:
*
[LG04315(M )03/95]
q
If the safety belt is not buckled when the key
is turned to the ON position, the light comes
on for 1 to 2 minutes and the chime sounds
for 4 to 8 seconds.
*
[LG04320(MBC )03/95]
q
If the safety belt is buckled while the light is
on and the chime is sounding, both the light
and chime will turn off.
File:05rclgm.ex
Update:Wed Mar 27 09:29:39 1996
Page 77 of 332
77 [LG16280(M )05/95]
one third page art:0010577-C
Battery voltage gauge
%*
[LG16300( ALL)05/94]
Engine Oil Pressure Gauge
[LG16500( ALL)05/94]
This gauge indicates the engine oil pressure, not
the oil level. However, if your engine's oil level
is low, it could affect the oil pressure. With the
engine running, the pointer should move into
the NORMAL band. If the pointer drops below
the NORMAL band while the engine is running,
you have lost oil pressure and continued
operation will cause severe engine damage.
[LG16525(M )09/95]
one third page art:0011145-B
Engine oil pressure gauge
File:05rclgm.ex
Update:Wed Mar 27 09:29:39 1996
Page 78 of 332
78
*
[LG16600( ALL)03/95]
If you lose engine oil pressure:
*
[LG16700( ALL)03/95]
1. Pull off the road as soon as safely possible.
*
[LG16800( ALL)04/95]
2. Shut off the engine immediately or severe
engine damage could result.
*
[LG16900( ALL)05/94]
3. Check the engine's oil level, following the
instructions on checking and adding engine
oil, see theEngine Oilin the Index. If you do
not follow these instructions, you or others
could be injured. To assure an accurate
reading, your car should be on level ground.
[LG17000( ALL)05/94]
4. If the level is low, add oil as necessary
before you start the engine again. Do not
overfill. Do not operate the engine if the
pointer is below the NORMAL band,
regardless of the oil level. Contact your
nearest dealer for further service actions.
[LG17200( ALL)05/94]
For more information about adding oil, see
Engine Oil Recommendationsin the Index.
File:05rclgm.ex
Update:Wed Mar 27 09:29:39 1996
Page 243 of 332
249
*
[SV13670( ALL)01/95]
Neveruse:
*
[SV13680( ALL)01/95]
q
ªNon-Detergentº oils
*
[SV13690( ALL)04/95]
q
Oils labeled API SA, SB, SC, SD, SE, SF or SG
%*
[SV13700( ALL)01/95]
q
Additional engine oil additives, oil treatments
or engine treatments
%*
[SV13702( ALL)03/95]
Engine oils with anSAE 5W-30viscosity are
PREFERREDfor your vehicle. They provide the
best engine performance, fuel economy and
engine protection for all climates down to-15ÊF
(-25ÊC).
%*
[SV13703( ALL)03/95]
Synthetic engine oils which are CERTIFIED and
of the preferred viscosity may be used in your
engine. The engine oil and oil filter must still be
changed according to the maintenance schedule.
%*
[SV13775( ALL)01/95]
Checking and Adding Engine Oil
*
[SV13800( ALL)03/95]
Since the proper amount of engine oil is
important for safe engine operation, check the oil
using the dipstick each time you put fuel in
your vehicle. Remember the engine must be off,
the oil must be warm and the vehicle must be
parked on level ground.
%*
[SV13900( ALL)04/95]
Checking the engine oil level:
*
[SV14000( ALL)02/95]
1. Turn the engine off after it has warmed up
and allow a few minutes for the engine oil
to drain back into the oil pan.
*
[SV14050(M )03/95]
2. Set the parking brake, making sure that the
gearshift is securely latched in P (Park)
(automatic transmission) or 1 (First) (manual
transmission).
*
[SV14100( ALL)02/95]
3. Open the hood. Protect yourself from engine
heat.
*
[SV14200( ALL)03/95]
4. Locate the engine oil dipstick (highlighted in
yellow) and carefully pull it out of the
engine.
File:15rcsvm.ex
Update:Thu Mar 28 14:48:54 1996
Page 244 of 332
250
*
[SV14300( ALL)01/95]
5. Wipe the dipstick clean and put it back into
position, making sure it is fully seated.
[SV14355(M )10/95]
one inch art:0011386-A
Engine oil dipstick Ð 4.6 liter engines
[SV14450(MBC )03/95]
one inch art:0000970-A
Engine oil dipstick Ð 3.8 liter engines
*
[SV14500( ALL)10/95]
6. Carefully, pull the dipstick out again. If the
oil level is below the ªADD 1 QTº line (3.8L)
or at the ªMINº mark (4.6L), add engine oil
as necessary. If the oil level is beyond the
letter ªFº in Full (3.8L) or ªMAXº (4.6L)
mark, engine damage or high oil
consumption may occur and some oil must
be removed from the engine.
*
[SV14600( ALL)01/95]
7. Put the dipstick back in and make sure it is
fully seated.
File:15rcsvm.ex
Update:Thu Mar 28 14:48:54 1996
Page 245 of 332
251
*
[SV14800( ALL)01/95]
It may be necessary to add some oil between oil
changes. Make sure you use a CERTIFIED
engine oil of the preferred viscosity. Your
vehicle's warranty coverage may not apply if
engine damage is caused by the use of improper
engine oil.
*
[SV15000( ALL)03/95]
Add engine oil through the oil filler cap
highlighted in yellow. To add oil, remove the
filler cap and use a funnel to pour oil into the
opening. Be careful not to overfill the engine.
Recheck the oil level after you finish adding oil.
%*
[SV16300( ALL)06/95]
Changing the Engine Oil and the Oil Filter
*
[SV16400( ALL)04/95]
Change the engine oil and oil filterper the
following, whichever occurs first.
*
[SV16500( ALL)04/95]
one third page art:0060618-C
*
[SV16800( ALL)06/95]
Refer to theMaintenance Schedule and Record
booklet for additional information.
%*
[SV16900( ALL)09/95]
NOTE: Always dispose of used automotive
fluids in a responsible manner. Follow
your community's standards for
disposing of these types of fluids. Call
your local recycling center to find out
about recycling automotive fluids.
File:15rcsvm.ex
Update:Thu Mar 28 14:48:54 1996
Page 246 of 332
252
*
[SV17275( ALL)07/95]
RWARNING
Continuous contact with USED motor oil
has caused cancer in laboratory mice.
*
[SV17285( ALL)07/95]
Protect your skin by washing with soap and
water.
%
*
[SV17300( ALL)03/95]
Engine Coolant
%*
[SV17400( ALL)09/95]
Checking the Engine Coolant
*
[SV17500( ALL)09/95]
NOTE: Be sure to read and understand
Precautions When Servicing Your
Vehicleat the beginning of this chapter.
*
[SV17550(M )10/95]
RWARNING
The cooling fan is automatic and may
come on at any time. Always disconnect
the negative terminal of the battery before
working near the fan.
%*
[SV17800( ALL)05/94]
Your vehicle's coolant protects your engine from
overheating in the summer and from freezing in
the winter. Check the level of the coolant at least
once a month. Simply look at the engine coolant
reservoir located in the engine compartment. To
locate the reservoir, see the diagram of your
vehicle's engine underEngine Type, in this
chapter.
*
[SV17850( ALL)05/95]
The coolant additives also protect the entire
cooling system from internal passageway
corrosion and these additives lubricate the water
pump. The coolant should be serviced as noted
in theMaintenance Schedule and Recordbooklet.
File:15rcsvm.ex
Update:Thu Mar 28 14:48:54 1996
Page 263 of 332
269
*
[SV29200( ALL)01/95]
q
Put the chains on tightly with the ends held
down securely. Verify that no chain touches
any wiring, brake lines, or fuel lines. Follow
the chain manufacturer's instructions.
*
[SV29300( ALL)01/95]
q
Drive slowly. If you can hear the chains rub
or bang against your vehicle, stop the vehicle
and tighten the chains. If you continue to
hear the chains rub or bang against your
vehicle, remove the chains to prevent damage
to your vehicle.
*
[SV29400( ALL)10/94]
q
Avoid fully loading your vehicle if possible.
*
[SV29500( ALL)05/94]
q
Remove tire chains at the first opportunity
after using them on snow and ice. Do not use
the chains on dry roads.
%*
[SV29600( ALL)04/95]
Cleaning the Wheels
*
[SV29700( ALL)05/95]
Wash the wheels with the same detergent you
use to wash your vehicle's body. Do not use
acid-based wheel cleaners, steel wool, abrasives,
fuel, or strong detergents. These substances will
damage protective coatings. Use tar and road oil
remover to remove grease and tar.
*
[SV29800( ALL)09/95]
NOTE: Before going to a car wash, find out if
the brushes are abrasive.
%
*
[SV30450( ALL)01/95]
Automatic Transmission Fluid
*
[SV30475( ALL)01/95]
Under normal circumstances, you do not need to
check the fluid level of the transmission, since
your vehicle does not use up transmission fluid.
Refer to theMaintenance Schedule and Record
booklet for replacement intervals. However, if
the transmission is not working properly Ð for
instance, the transmission may slip or shift
slowly, or you may notice some sign of fluid
leakage Ð the fluid level should be checked.
File:15rcsvm.ex
Update:Thu Mar 28 14:48:54 1996
Page 266 of 332
272
% [SV30875(M )12/94]
Manual Transmission Fluid
% [SV30925(M )03/95]
The fluid level and quality should not
deteriorate under normal driving conditions.
However, it is suggested that you have the fluid
level checked occasionally. If fluid is required,
seeLubricant Specificationsin the Index.
%
*
[SV30950(M )02/95]
The Clutch
[SV30975(M )12/94]
The clutch on your vehicle is operated by a
cable that adjusts itself with a little help from
you. Complete the following steps every
5,000-6,000 miles (10,000 km) to adjust the
clutch.
[SV31001(M )01/89]
1. Turn your engine off and put your gearshift
in First.
[SV31025(M )10/89]
2. Put your foot under the clutch pedal and
gently pull it up until the pedal stops.
[SV31050(M )01/89]
3. Then push the clutch down slowly. You will
hear a click if your clutch needed adjusting
and adjusted itself.
%
*
[SV31900( ALL)03/95]
Brake Fluid
*
[SV32000( ALL)04/95]
Under normal circumstances, your vehicle
should not use up brake fluid rapidly. However,
expect the level of the brake fluid to slowly fall
as you put more mileage on your vehicle and
the brake lining wears.
[SV32300(M )03/95]
Check the brake fluid at each scheduled engine
oil change or at least once a year. You can do
this by looking at the fluid level in the plastic
reservoir on the master cylinder. Also, see label
on reservoir cap. (To locate the master cylinder,
seeThe Engine Typesin the Index.) The fluid
level should be between the MIN and MAX
marks.
File:15rcsvm.ex
Update:Thu Mar 28 14:48:54 1996
